2-21
Arming and Disarming the Content
Theft-Deterrent System
To arm and disarm the Content Theft-Deterrent system,
the system must be turned on by using Modes 1, 2 or 4
listed previously in this section under ªContent
Theft
-Deterrent System.º
With the Arming and Disarming feature, you can
program the vehicle to do the following:

Arm the system when you lock the doors using either
power door lock switch while any door or the liftgate
is open and the key is removed from the ignition.

Arm the system when you lock the doors with your
key or remote keyless entry transmitter and the key
is removed from the ignition.

Disarm the system when you unlock the doors with
your key or remote keyless entry transmitter.
To customize this feature to your preference, see
ªProgrammable Modesº following.Programmable Modes
Your vehicle can be programmed to one of the
following modes.
Mode 1: Power Door Lock Switch Arming Off

The system will arm when you lock the doors with
your key or remote keyless entry transmitter. The
key must be removed from the ignition when you
lock the doors or the Content Theft
-Deterrent system
will not arm.

The system will disarm when you unlock the doors
with your key or remote keyless entry transmitter.
Mode 2: Remote Keyless Entry Transmitter
Arm/Disarm Only

The system will arm when you lock the doors with
your remote keyless entry transmitter. The key must
be removed from the ignition when you lock the
doors or the Content Theft
-Deterrent system will
not arm.

The system will disarm when you unlock the doors
with your remote keyless entry transmitter.

yellowblue
2-22
NOTE: While this mode provides increased security, it
can be a problem if your remote keyless entry
transmitter is damaged, lost or if it fails to operate for
any reason while the Content Theft
-Deterrent system is
armed. The Content Theft
-Deterrent system must be
disarmed for the engine to run while in Mode 2; your
key can no longer disarm the system.
If your vehicle is equipped with the optional dealer
installed OnStar

system, OnStar will not be able to
remotely unlock your vehicle if it has been programmed
to Mode 2.
Mode 3: Standard Arming and Disarming

The system will arm when you lock the doors using
either power door lock switch while any door or the
liftgate is open and the key is removed from
the ignition.

The system will arm when you lock the doors with
your key or remote keyless entry transmitter and the
key is removed from the ignition.

The system will disarm when you unlock the doors
with your key or remote keyless entry transmitter.
Vehicles are delivered programmed in Mode 1.To change the mode:
1. Follow the instructions for ªEntering Programming
Modeº listed previously.
2. Insert your second key fully into any door key
cylinder and turn it to the unlock position.
This step is necessary to prevent accidental
programming of this feature to Mode 2. Do not
program this feature to Mode 2 without first reading
the special note contained in the description for that
mode. The door key cylinder must remain in the
unlock position during Steps 2 through 4.
3. Press the horn symbol on the remote keyless
entry transmitter.
4. Count the number of chimes you hear. The number
of chimes tells you which mode your vehicle is in.
You can change the mode by pressing the horn
symbol on the remote keyless entry
transmitter again.

yellowblue
2-23
5. Repeat Step 3 until you hear the number of chimes
that matches the mode you want.
6. Remove your key from the door key cylinder.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
next in this section or program the next feature available
on your vehicle.
Exiting Programming Mode
To exit programming mode, just turn the key from
ACCESSORY to OFF and put the BCM PRGRM fuse
back into the instrument panel fuse block.
NOTE: After programming a feature, you can exit the
programming mode at anytime. Also, if your vehicle is
equipped with the Content
-Theft Deterrent system,
remember to arm the system before exiting.
Sliding Door
To open the sliding door from outside the vehicle, pull
the handle out and then pull the door toward the rear. If
you slide the door all the way back, the door will rest in
a detent position. The door must overcome this detent
when closing.
To move the door forward, you must first pull the door
past the open detent position.
If your vehicle has a sliding door on the driver's side,
the door is designed to open only a little if the fuel door
is open. If this ever happens, don't try to force the
sliding door. Just close the driver's side sliding door.
Then when the fuel filler door is closed, the driver's side
sliding door can be opened normally.

yellowblue
2-24Sliding Door Lock
CAUTION:
If your vehicle is facing downward on a steep
grade (15 percent or more), the door may not
stay open and could slam shut, possibly injuring
someone. To make sure the door does not slam
shut, be sure to hold it open until everyone is
clear of the door, and only then allow it to
slowly close.

yellowblue
2-25
Lock the sliding door from inside the vehicle by moving
the manual locking lever down. Unlock it by moving the
lever up.
With power door locks, the sliding door lock has a delay
feature. See ªPower Door Locksº and ªMultifunction
Alarm Locks and Lighting Choicesº in the Index.
Power Sliding Door (Option)
With this option, you can open and close the sliding
door with the switches inside your vehicle. If you have
the optional remote keyless entry system, you can also
operate the power sliding door with your remote
transmitter. See ªKeyless Entry Systemº in the Index.
CAUTION:
Leaving young children or pets unattended in
your vehicle can be dangerous. They could
operate the power sliding door. A child or others
could be injured. Do not leave children or pets
unattended in your vehicle.
To help avoid accidental operation of the sliding door,
turn the power sliding door off by pushing the bottom of
the power sliding door on/off switch.

yellowblue
2-26
This switch is located
in the overhead
console switchbank.
Pushing the bottom of the button turns the power sliding
door off. When the power sliding door switch is turned
off, you will not be able to open the door using the
switch located on the overhead console switchbank, the
wall
-mounted switch in front of the passenger's sliding
door or the remote keyless entry transmitter.
NOTICE:
When your vehicle goes through an automatic
car wash, be sure the power sliding door is
turned off. If it isn't, the power sliding door may
open accidentally.
To open or close the sliding door, press and release one
of the following two power door switches.
One switch is located
in the overhead
console switchbank.
The other switch is mounted
on the wall, just in front of
the passenger's side
sliding door.

yellowblue
2-27
The power sliding door on/off switch will also stop the
door immediately, while the door is opening or closing,
when the switch is turned off.
The power sliding door will only open if the transaxle is
in PARK (P). The transaxle does not have to be in
PARK (P) to close the door.
If the power sliding door is open or in the process of
closing when you shift out of PARK (P), a buzzer will
sound. This is a warning that the sliding door is not
completely closed.
If the power sliding door is turned off, the buzzer will
not sound indicating the door is not completely closed.
CAUTION:
If you shift the transaxle out of PARK (P) and
accelerate before the power sliding door latches
closed, the door may reverse to the open position.
A child or others could fall out of the vehicle and
be injured. Always make sure the power sliding
door is closed and latched before you drive away.
If anything obstructs the power sliding door while it is
closing, the door will automatically reverse to the open
position, provided it meets sufficient resistance.
Resistance must be as strong as the force of the closing
door, or stronger. The force of the closing door increases
significantly as the door approaches the latched position.

yellowblue
2-28
CAUTION:
You or others could be injured if caught in the
path of the sliding door. Make sure the door path
is clear before closing the door.
If you want to open the power sliding door when the
switch is turned on, pull the inside or outside handle and
let go. The door will open fully.
To open the power sliding door when the power sliding
door switch is off, pull the inside or outside handle and
slide the door all the way back.

yellowblue
2-29
CAUTION:
If your vehicle is facing downward on a steep
grade (15 percent or more), the door may not
stay open and could slam shut, possibly injuring
someone. To make sure the door does not slam
shut, turn on the power sliding door feature.
Then if the door closes, it will close under the
control of the power door system.
If you want to close the power sliding door when the
switch is turned on, pull the inside or outside handle
or the edge of the door. Move the door about
4 inches (10 cm) toward the closed position and release.
The door will close completely and latch for you.
To close the power sliding door when the switch is
turned off, pull the inside or outside handle and slide the
door all the way forward to the latched position.
Sliding Door Security Lock
Your vehicle is equipped with a sliding door security
lock that helps prevent young children or other
passengers from opening the sliding door by using the
inside door handle.The security lock lever is located on the inside of the
sliding door, on the front edge of the door. To access the
lever, open the sliding door. Use the security lock label on
the edge of the door as a guide. This lock is on both doors
if your vehicle is equipped with dual sliding doors.
To use the security lock,
move the security lock lever
all the way up and close the
door from the outside.
If your vehicle is equipped with a power sliding door,
you can override the security lock by pressing either
power door switch when the power sliding door is
turned off. When the power sliding door is turned on,
the power sliding door cannot be opened from the inside
when the sliding door security lock is in use.

yellowblue
2-30
If you want to open the sliding door when the security
lock is on, unlock the sliding door and open the door
from the outside.
You should let adults and older children know how the
security lock works, and how to cancel the lock. If you
don't, adults or older children who ride in the rear won't
be able to open the sliding door from the inside when
the security lock feature is in use.
Resetting the Power Sliding Door
The power sliding door may operate incorrectly or not at
all because of the following conditions:

A low voltage or dead battery,

Disconnecting the battery or

If the IGN 1, B/U LAMP, RADIO or PWR
SEAT/PSD fuse is removed or blown.
See ªFuse Panelº in the Index for more information
about your fuse panel.
If any of these conditions occur, the power sliding door
will need to be reset. To do this, follow the directions
listed here. It will be easier if you read through them
once before beginning this procedure.1. Check to be sure the power sliding door is unlocked
and securely closed.
2. Turn the ignition key to OFF.
3. Turn on the power sliding door on the switchbank.
4. Remove the RADIO fuse from the underhood fuse
and relay center. Leave it out for 30 seconds.
5. Reinstall the fuse and wait 10 seconds.
6. Disable the power sliding door override feature.
7. Push either of the power door buttons to open the
power sliding door.
8. Open the door.
9. Wait five seconds and close the door by pushing
either power door button.
10. Wait five seconds and repeat Steps 7 through 9.
If the door does not rest in the fully open position after
repeating Step 7, repeat Steps 7 through 9 again. If the
door still does not operate correctly, see your dealer
for service.
NOTE: If your audio system is equipped with
THEFTLOCK and a code has been entered to secure
your radio, the code will need to be unlocked before
resetting the power sliding door. See ªTHEFTLOCKº in
the Index to unlock a secured radio.
