CHEVROLET VENTURE 2002 1.G Owners Manual

3-9
Rear Temperature Control
Press the TEMP button in the overhead entertainment
console to adjust the temperature of the air to the rear
seat. Press the left arrow button to make air cooler.
Press the right arrow button to make the air warmer.
Rear Air Vents
To maximize airflow through the rear floor outlet, place
the left bucket seat in the second row in the forward
position. See ªAdjusting Rear Seatsº in the Index.
The vent behind the left rear seat is the cold air return
vent. Be sure to keep it free of obstructions.
Keep the area around the base of the center instrument
panel console, between and under the front seats, free of
objects that could obstruct airflow to the rear.

3-10 Ventilation System
Your vehicle's flow-through ventilation system supplies
outside air into the vehicle when it is moving. Outside
air will also enter the vehicle when the fan is running.
Your vehicle has air outlets that allow you to adjust the
direction and amount of airflow inside the vehicle. Push
the outlet up or down to change the direction of the
airflow. Increase or reduce the amount of airflow by
opening and closing the louvers. Opening and closing
the louvers will also direct airflow from side to side.
The air
-flow through the vents can be shut off
completely by turning the thumbwheel next to each
outlet all the way down. You can also stop outside air
from entering the vehicle by turning the fan to off and
pressing the recirculation button.

3-11
Ventilation Tips

Keep the hood and front air inlet free of ice, snow or
any other obstruction (such as leaves). This will
allow the heater and defroster to work much better,
reducing the chance of fogging the inside of
your windows.

When you enter a vehicle in cold weather, turn the
fan knob to 5, the highest setting, for a few moments
before driving off. This helps clear the intake ducts
of snow and moisture, and reduces the chance of
fogging the inside of your windows.

Keep the area around the base of the center
instrument panel console and the air path under the
front seats clear of objects. This helps air to circulate
throughout your vehicle.

In cold weather, operating the system in the
outside air mode will improve the time it takes to
warm the vehicle.Audio Systems
Your audio system has been designed to operate easily
and give years of listening pleasure. You will get the
most enjoyment out of it if you acquaint yourself with it
first. Find out what your audio system can do and how
to operate all of its controls to be sure you're getting the
most out of the advanced engineering that went into it.
Your vehicle may have a feature called Retained
Accessory Power (RAP). With RAP, you can play your
audio system even after the ignition is turned off. See
ªRetained Accessory Powerº in the Index.
Setting the Clock for Systems without
Radio Data System
Press and hold the HR or MIN arrow for two seconds.
Then press the HR arrow until the correct hour appears.
Press and hold the MIN arrow until the correct minute
appears. The clock may be set with the ignition on
or off.

3-12 Setting the Clock for Systems with Radio
Data System (RDS)
Your radio may have a button marked with an H or HR
to represent hours and an M or MN to represent minutes.
Press and hold the hour button until the correct hour
appears. AM will appear on the display for morning
hours. Press and hold the minute button until the correct
minute appears. The clock may be set with the ignition
on or off.
To set the clock to the time of an FM station
broadcasting Radio Data System (RDS) information,
press and hold the hour and minute buttons at the same
time until TIME UPDATED appears on the display. If
the time is not available from the station, NO UPDATE
will appear on the display instead.
AM-FM Stereo
Playing the Radio
PWR (Power): Press this knob to turn the system on
and off.
VOL (Volume): Turn the knob clockwise to increase
volume. Turn it counterclockwise to decrease volume.
RCL (Recall): Pressing this knob will display the
station being played or it will display the clock. Clock
display is available with the ignition turned off.

3-13
Finding a Station
AM FM: Press this button to switch between AM, FM1
and FM2. The display shows your selection.
TUNE: Turn this knob to choose radio stations.
SEEK SEEK : Press the right or left arrow to
seek to the next or previous station and stay there. The
radio will seek to stations with a strong signal only.
To scan stations, press and hold one of the SEEK arrows
for two seconds until you hear a beep. The radio will go
to a station, play for a few seconds and flash the station
frequency, then go on to the next station. Press one of
the SEEK arrows again to stop scanning. The radio will
scan to stations with a strong signal only.
To scan preset stations, press and hold one of the SEEK
arrows for more than four seconds until you hear
two beeps. The radio will go to the first preset station
stored on your pushbuttons, play for a few seconds and
flash the station frequency, then go on to the next preset
station. This feature will only scan the six presets that
are in the selected band. Press one of the SEEK arrows
again to stop scanning presets. The channel number
(P1 through P6) will appear momentarily before the
frequency is displayed. The radio will scan preset
stations with a strong signal only.Setting Preset Stations
The six numbered pushbuttons let you return to
your favorite stations. You can set up to 18 stations
(six AM, six FM1 and six FM2) by performing the
following steps:
1. Turn the radio on.
2. Press AM FM to select AM, FM1 or FM2.
3. Tune in the desired station.
4. Press and hold one of the six numbered pushbuttons
until you hear a beep. Whenever you press that
numbered pushbutton, the station you set will return.
5. Repeat the steps for each pushbutton.
Setting the Tone (Bass/Treble)
AUDIO: To adjust the bass, press and release the
AUDIO button repeatedly until BAS appears on the
display. Then press and hold the up arrow to increase
bass. B and a positive number will appear on the display.
Press and hold the down arrow to decrease bass. B and a
negative number will appear on the display. B and a zero
will appear on the display when the bass level is
adjusted to the middle position. Release the up or down
arrow when you find the bass level you want or when
the maximum or minimum level is reached.

3-14
To adjust the treble, press and release the AUDIO button
until TRE appears on the display. Then press and hold
the up arrow to increase treble. T and a positive number
will appear on the display. Press and hold the down
arrow to decrease treble. T and a negative number will
appear on the display. T and a zero will appear on the
display when the treble level is adjusted to the middle
position. Release the up or down arrow when you find
the treble level you want or when the maximum or
minimum level is reached. If a station is weak or noisy,
you may want to decrease the treble.
To adjust bass or treble to the middle position, select
BAS or TREB. Then press and hold the AUDIO button
for more than two seconds until you hear a beep. B and
a zero or T and a zero will appear on the display. To
adjust both tone controls and both speaker controls to
the middle position, end out of audio mode by pressing
another button, which the radio will perform that
function, or by waiting 5 seconds which the radio will
go to the clock display. Then press and hold the AUDIO
button for more than two seconds until you hear a beep.
CEN will appear on the display.Adjusting the Speakers (Balance/Fade)
AUDIO: To adjust the balance between the right and
left speakers, press and release the AUDIO button until
BAL appears on the display. Then press and hold the
up arrow to move the sound to the right speakers or the
down arrow to move the sound to the left speakers.
R and a number will appear on the display when the
sound is balanced toward the right speakers. L and a
number will appear on the display when the sound is
balanced toward the left speakers. L and a zero will
appear on the display when the sound is balanced
between the speakers. Release the up or down arrow
when you find the speaker balance you want or when
the maximum or minimum level is reached.
To adjust the fade between the front and rear speakers,
press and release the AUDIO button until FAD appears
on the display. Then press and hold the up arrow to
move the sound to the front speakers or the down arrow
to move the sound to the rear speakers. F and a number
will appear on the display when the sound is balanced
toward the front speakers. R and a number will appear
on the display when the sound is balanced toward the
rear speakers. F and a zero will appear on the display
when the sound is balanced between the speakers.
Release the up or down arrow when you find the speaker
balance you want or when the maximum or minimum
level is reached.

3-15
To adjust balance or fade to the middle position, select
BAL or FAD. Then press and hold AUDIO for more
than two seconds until you hear a beep. L and a zero or
F and a zero will appear on the display. To adjust both
tone controls and both speaker controls to the middle
position, end out of audio mode by pressing another
button, which the radio will perform that function, or by
waiting 5 seconds which the radio will go to the clock
display. Then press and hold AUDIO for more than
two seconds until you hear a beep. CEN will appear on
the display.
Radio Messages
CAL (Calibration): Your audio system has been
calibrated for your vehicle from the factory. If CAL
appears on the display it means that your radio has not
been configured properly for your vehicle and must be
returned to the dealership for service.AM-FM Stereo with Compact Disc Player
with Radio Data System (RDS) and
Automatic Tone Control (If Equipped)
Playing the Radio
PWR (Power): Press this knob to turn the system on
and off.
 VOL
(Volume): Turn the knob clockwise
to increase volume. Turn it counterclockwise to
decrease volume.

3-16
AUTO VOL (Automatic Volume): With automatic
volume, your audio system adjusts automatically to
make up for road and wind noise as you drive.
Set the volume at the desired level. Press this button to
select LOW, MEDIUM or HIGH. AVOL will appear on
the display. The volume level should always sound the
same to you as you drive. Each higher volume setting
allows for more volume compensation at faster vehicle
speeds. Then as you drive, automatic volume increases
the volume as necessary to overcome noise at any speed.
NONE will appear on the display if the radio cannot
determine the vehicle speed. If you don't want to use
automatic volume, select OFF.
DISP (Display): Press this knob when the ignition is off
to display the clock.Finding a Station
BAND: Press this button to switch between AM, FM1
and FM2. The display shows your selection.
 TUNE
: Turn this knob to choose radio stations.
 SEEK
: Press the right or left arrow to seek to the
next or previous station and stay there. The radio will
seek to stations with a strong signal only. The sound will
mute while seeking.
 PSCAN
(Preset Scan): Press and hold one of the
arrows for more than two seconds and the radio will
produce one beep. The radio will scan to the first preset
station stored on your pushbuttons, play for a few
seconds and flash the station frequency, then go on to
the next preset station. Press one of the arrows or one of
the pushbuttons again to stop scanning. SCAN will be
displayed whenever the tuner is in the preset scan mode.
The channel number (P1 through P6) will appear with
the frequency. In FM mode, this function will scan
through the current band such as FM1 or FM2. The
radio will scan preset stations with a strong signal only.
The sound will mute while scanning.

3-17
Setting Preset Stations
The six numbered pushbuttons let you return to
your favorite stations. You can set up to 18 stations
(six AM, six FM1 and six FM2) by performing the
following steps:
1. Turn the radio on.
2. Press BAND to select AM, FM1 or FM2.
3. Tune in the desired station.
4. Press AUTO TONE to choose the bass and treble
equalization that best suits the type of station you are
listening to.
5. Press and hold one of the six numbered pushbuttons.
The radio will produce one beep. Whenever you
press that numbered pushbutton, the station you set
will return and the bass and treble equalization that
you selected will also be automatically selected for
that pushbutton.
6. Repeat the steps for each pushbutton.Setting the Tone (Bass/Treble)
AUDIO: Push and release the AUDIO knob until
BASS or TREB appears on the display. Turn the knob
clockwise or counterclockwise to increase or decrease.
The display will show the bass or treble level. If a
station is weak or noisy, you may want to decrease
the treble.
To adjust bass and treble to the middle position, push
and hold the AUDIO knob. The radio will produce one
beep and adjust the display level to the middle position.
To adjust all tone and speaker controls to the middle
position, push and hold the AUDIO knob when no tone
or speaker control is displayed. You will hear one beep
and the radio will display ALL. The bass and treble will
be adjusted to the middle position.
AUTO TONE: This feature allows you to choose
preset bass and treble equalization settings designed
for country/western, jazz, talk, pop, rock and
classical stations.
Each time you press the AUTO TONE button, this
feature will switch to one of these program types.
To return the bass and treble to the manual mode,
push and release the AUDIO knob until the display
goes blank.

3-18
Adjusting the Speakers (Balance/Fade)
AUDIO: To adjust the balance between the right and
left speakers, push and release the AUDIO knob until
BAL appears on the display. Turn the knob clockwise to
move the sound to the right speakers and
counterclockwise to move the sound to the left speakers.
To adjust the fade, push and release the AUDIO knob
until FADE appears on the display. Turn the knob
clockwise to move the sound to the front speakers
and counterclockwise to move the sound to the
rear speakers.
To adjust the balance and fade to the middle position,
push the AUDIO knob, then push it again and hold it
until you hear one beep. The balance and fade will be
adjusted to the middle position and the display will
show the speaker balance.
To adjust all tone and speaker controls to the middle
position, push and hold the AUDIO knob when no tone
or speaker control is displayed. The radio will produce
one beep and display ALL with the level display in the
middle position.Using RDS
Your audio system is equipped with a Radio Data
System (RDS). RDS is a system that receives data along
with the audio of the FM station you are currently tuned
to. You can use RDS to display program information
and to control your radio. With RDS your radio can do
the following:

Seek only to stations with the types of programs you
want to listen to,

seek to stations with traffic announcements,

receive announcements concerning local and
national emergencies, and

receive and display messages from radio stations.
RDS features are only available on FM stations which
broadcast RDS information. The RDS features of your
radio rely on receiving specific RDS information from
these stations. These features will only work when the
RDS information is available. In rare cases, a radio
station may broadcast incorrect information that will
cause the radio features to work improperly. If this
happens, contact the radio station.
