wiper fluid CHEVROLET VENTURE 2003 1.G Owners Manual

Windshield Washer
L
(Windshield Washer):Press and hold the
windshield washer paddle with this symbol on it to wash
your windshield. The washers and wipers will operate.
When you release the paddle, the washers will stop, and
the wipers will continue to operate for two cycles,
unless your wipers had already been on. In that case,
the wipers will resume the wiper speed you had selected
earlier.
{CAUTION:
In freezing weather, do not use your washer
until the windshield is warmed. Otherwise the
washer ¯uid can form ice on the windshield,
blocking your vision.
Rear Window Washer/Wiper
Your vehicle may have a
rear window wiper. If it
does, the rear window
wiper switch is located in
the instrument panel
switchbank.
Press the wiper symbol on the bottom of the switch to
turn on the intermittent wiper. To turn off the wiper,
gently press the top of the switch.
To wash and wipe the rear window, press the washer
symbol on the top of the switch. Washer ¯uid will
run down the glass as long as the switch is held in.
When the top of the switch is released, the wiper will
continue to cycle three more times. There is only
one washer ¯uid reservoir for the front and rear
windshield wipers. See
Windshield Washer Fluid on
page 5-38.
3-10

The exit ramp can be curved, sometimes quite sharply.
The exit speed is usually posted.
Reduce your speed according to your speedometer, not
to your sense of motion. After driving for any distance
at higher speeds, you may tend to think you are
going slower than you actually are.
Before Leaving on a Long Trip
Make sure you're ready. Try to be well rested. If you
must start when you're not fresh Ð such as after a day's
work Ð don't plan to make too many miles that ®rst
part of the journey. Wear comfortable clothing and shoes
you can easily drive in.
Is your vehicle ready for a long trip? If you keep it
serviced and maintained, it's ready to go. If it needs
service, have it done before starting out. Of course,
you'll ®nd experienced and able service experts in GM
dealerships all across North America. They'll be
ready and willing to help if you need it.Here are some things you can check before a trip:
·Windshield Washer Fluid:Is the reservoir full? Are
all windows clean inside and outside?
·Wiper Blades:Are they in good shape?
·Fuel, Engine Oil, Other Fluids:Have you checked
all levels?
·Lamps:Are they all working? Are the lenses clean?
·Tires:They are vitally important to a safe,
trouble-free trip. Is the tread good enough for
long-distance driving? Are the tires all in¯ated to the
recommended pressure?
·Weather Forecasts:What's the weather outlook
along your route? Should you delay your trip a
short time to avoid a major storm system?
·Maps:Do you have up-to-date maps?
4-22

Service............................................................5-3
Doing Your Own Service Work.........................5-3
Adding Equipment to the Outside of
Your Vehicle..............................................5-4
Fuel................................................................5-4
Gasoline Octane............................................5-4
Gasoline Speci®cations....................................5-5
California Fuel...............................................5-5
Additives.......................................................5-6
Fuels in Foreign Countries...............................5-6
Filling Your Tank............................................5-7
Filling a Portable Fuel Container.......................5-9
Checking Things Under the Hood....................5-10
Hood Release..............................................5-10
Engine Compartment Overview.......................5-12
Engine Oil...................................................5-13
Engine Air Cleaner/Filter................................5-18
Automatic Transaxle Fluid..............................5-20
Engine Coolant.............................................5-23
Radiator Pressure Cap..................................5-26
Engine Overheating.......................................5-26
Cooling System............................................5-29
Power Steering Fluid.....................................5-37
Windshield Washer Fluid................................5-38
Brakes........................................................5-40Battery........................................................5-43
Jump Starting...............................................5-44
All-Wheel Drive..............................................5-50
Bulb Replacement..........................................5-52
Halogen Bulbs..............................................5-52
Headlamps..................................................5-52
Front Turn Signal, Sidemarker and
Parking Lamps..........................................5-54
Taillamps, Turn Signal, Stoplamps and
Back-up Lamps.........................................5-56
Replacement Bulbs.......................................5-57
Windshield Wiper Blade Replacement..............5-58
Tires..............................................................5-60
In¯ation - Tire Pressure.................................5-61
Tire Inspection and Rotation...........................5-62
When It Is Time for New Tires.......................5-63
Buying New Tires.........................................5-64
Uniform Tire Quality Grading..........................5-65
Wheel Alignment and Tire Balance..................5-66
Wheel Replacement......................................5-66
Tire Chains..................................................5-67
Accessory In¯ator.........................................5-68
If a Tire Goes Flat........................................5-70
Changing a Flat Tire.....................................5-71
Compact Spare Tire......................................5-86
Section 5 Service and Appearance Care
5-1

At Least Twice a Year
Restraint System Check
Make sure the safety belt reminder light and all your
belts, buckles, latch plates, retractors and anchorages
are working properly. If your vehicle has a built-in
child restraint, also periodically make sure the harness
straps, latch plates, buckle, clip, child head restraint
and anchorages are working properly. Look for any other
loose or damaged safety belt and built-in child restraint
system parts. If you see anything that might keep a
safety belt or built-in child restraint system from doing
its job, have it repaired. Have any torn or frayed
safety belts or harness straps replaced.
Also look for any opened or broken air bag coverings,
and have them repaired or replaced. (The air bag
system does not need regular maintenance.)
Wiper Blade Check
Inspect wiper blades for wear or cracking. Replace
blade inserts that appear worn or damaged or that
streak or miss areas of the windshield. Also see
Cleaning the Outside of Your Vehicle on page 5-90.
Spare Tire Check
At least twice a year, after the monthly in¯ation check of
the spare tire determines that the spare is in¯ated to
the correct tire in¯ation pressure, make sure that
the spare tire is stored securely. Push, pull, and then try
to rotate or turn the tire. If it moves, use the folding
wrench to tighten the cable. See
Changing a Flat Tire
on page 5-71.
Weatherstrip Lubrication
Silicone grease on weatherstrips will make them last
longer, seal better, and not stick or squeak. Apply
silicone grease with a clean cloth. During very cold,
damp weather more frequent application may be
required. See
Part D: Recommended Fluids and
Lubricants on page 6-17.
Automatic Transaxle Check
Check the transaxle ¯uid level; add if needed. SeeAutomatic Transaxle Fluid on page 5-20. A ¯uid loss
may indicate a problem. Check the system and repair if
needed.
6-11

Electrical System (cont.)
Power Windows and Other Power Options......5-96
Windshield Wiper Fuses...............................5-96
Emissions Inspection and Maintenance
Programs...................................................3-48
Engine Coolant Level Check.............................6-10
Engine Oil Additives........................................5-17
Engine Oil and Chassis Lubrication
Scheduled Maintenance................................. 6-6
Engine Oil Level Check...................................6-10
Engine Speci®cations.....................................5-104
Engine..........................................................5-18
Air Cleaner/Filter.........................................5-18
Battery.......................................................5-43
Change Oil Message...................................3-54
Check and Service Engine Soon Light............3-45
Compartment Overview................................5-12
Coolant Heater............................................2-33
Coolant Temperature Gage...........................3-44
Coolant Temperature Warning Message..........3-51
Coolant......................................................5-23
Cooling System Inspection............................6-16
Exhaust.....................................................2-42
Low Oil Level Message................................3-53
Oil .............................................................5-13
Overheating................................................5-26
Starting......................................................2-32
Entering Programming Mode............................2-62
Entertainment System......................................3-92
Cleaning the Video Screen..........................3-105Entertainment System (cont.)
Cleaning Your DVD Player..........................3-105
DVD Distortion..........................................3-103
Entry Lighting.................................................3-18
Erasing HomeLink
žButtons..............................2-50
Exit Lighting...................................................3-19
Exiting Programming Mode...............................2-70
Express-Down Window....................................2-25
Extender, Safety Belt.......................................1-54
Exterior Lamps...............................................3-15
F
Filter.............................................................5-18
Engine Air Cleaner......................................5-18
Finding a PTY Station.....................3-68, 3-75, 3-85
Finding a Station....................3-62, 3-65, 3-73, 3-82
Finish Care....................................................5-91
Finish Damage...............................................5-93
Fixed Mast Antenna.......................................3-105
Flash-to-Pass................................................... 3-9
Flat Tire, Changing.........................................5-71
Flat Tire........................................................5-70
Flip and Fold Rear Seats.................................. 1-7
Fluid.............................................................5-20
Automatic Transaxle.....................................5-20
Power Steering...........................................5-37
Windshield Washer......................................5-38
FM ..............................................................3-104
6

Wheels (cont.)
When to Add Engine Oil..................................5-15
When to Change Engine Oil
(GM Oil Life System)...................................5-17
When to Check and Change Automatic
Transaxle Fluid...........................................5-20
When to Check Power Steering Fluid................5-37
When to Check..............................................5-61
When to Inspect the Engine Air Cleaner/Filter.....5-18
When You Are Ready to Leave After Parking
on a Hill.....................................................4-43
Where to Put the Restraint...............................1-65
Why Safety Belts Work....................................1-31
Windows.......................................................2-24
Manual......................................................2-24
Power Rear Quarter.....................................2-26Windows (cont.)
Power........................................................2-25
Side Window Latches...................................2-25
Windshield Washer Fluid Level Check................6-10
Windshield Washer.........................................3-10
Fluid..........................................................5-38
Windshield Wiper............................................5-58
Blade Replacement......................................5-58
Fuses........................................................5-96
Windshield Wipers............................................ 3-9
Winter Driving................................................4-26
Wiper Blade Check.........................................6-11
Y
Your Vehicle and the Environment....................... 6-2
18
