Black plate (23,1)Chevrolet Volt Owner Manual - 2011
Instruments and Controls 5-23
Light On Steady:An emission
control system malfunction has
been detected on the vehicle.
Diagnosis and service might be
required.
The following may correct an
emission system malfunction:
.Check that the fuel cap is fully
installed. The diagnostic system
can determine if the fuel cap
has been left off or improperly
installed. A loose or missing fuel
cap allows fuel to evaporate into
the atmosphere. A few driving
trips with the cap properly
installed should turn the light off.
.Check that the electrical system
is not wet. The system could
be wet if the vehicle was
driven through a deep puddle of
water. The condition is usually
corrected when the electrical
system dries out. A few driving
trips should turn the light off.
.Check that good quality fuel
is used. Poor fuel quality
causes the engine not to run
as efficiently as designed and
may cause stalling after start-up
or misfiring. These conditions
might go away once the engine
is warmed up.
If one or more of these
conditions occurs, change the
fuel brand used. It will require at
least one full tank of the proper
fuel to turn the light off.
If none of the above have made
the light turn off, your dealer can
check the vehicle. The dealer
has the proper test equipment
and diagnostic tools to fix any
mechanical or electrical problems
that might have developed.Emissions Inspection and
Maintenance Programs
Some state and local governments
have or might begin programs
to inspect the emission control
equipment on the vehicle. Failure to
pass this inspection could prevent
getting a vehicle registration.
Here are some things to know to
help the vehicle pass an inspection:
.The vehicle will not pass this
inspection if the malfunction
indicator lamp is on while the
vehicle is in ON/RUN, or if the
vehicle is placed in Service
Only Mode and the malfunction
indicator lamp does not come
on. See your dealer for
assistance in verifying proper
operation of the malfunction
indicator lamp.

Black plate (28,1)Chevrolet Volt Owner Manual - 2011
5-28 Instruments and Controls
When the Light Flashes First and
Then is On Steady
This indicates that there may be
a problem with the Tire Pressure
Monitor System. The light flashes
for about one minute and stays on
steady until the vehicle is in OFF.
This sequence repeats each time
the vehicle is in ON/RUN. SeeTire
Pressure Monitor System on
page 10‑55 for more information.
Engine Oil Pressure Light
{WARNING
Do not keep driving if the oil
pressure is low. The engine can
become so hot that it catches
fire. Someone could be burned.
Check the oil as soon as possible
and have the vehicle serviced. Notice:
Lack of proper engine
oil maintenance can damage the
engine. The repairs would not be
covered by the vehicle warranty.
Always follow the maintenance
schedule for changing engine oil.
The oil pressure light should come
on briefly as the vehicle is started.
If it does not come on have the
vehicle serviced by your dealer.
If the light comes on and stays on, it
means that oil is not flowing through
the engine properly. The vehicle
could be low on oil and might
have some other system problem.
See your dealer.
Low Fuel Warning Light
The low fuel warning light comes on
briefly when the vehicle is started.
This light also comes on when the
fuel level is low. When fuel is added,
the light should go off. If it does not,
have the vehicle serviced.

Black plate (16,1)Chevrolet Volt Owner Manual - 2011
10-16 Vehicle Care
When the system has calculated
that oil life has been diminished,
it indicates that an oil change is
necessary. A CHANGE ENGINE
OIL SOON message comes on.
Change the oil as soon as possible
within the next 1 000 km (600 mi).
It is possible that, if driving under
the best conditions, the oil life
system might indicate that an oil
change is not necessary for up
to two years. The engine oil and
filter must be changed at least
once every two years and, at this
time, the system must be reset.
Your dealer has trained service
people who will perform this work
and reset the system. It is also
important to check the oil regularly
over the course of an oil drain
interval and keep it at the proper
level.
If the system is ever reset
accidentally, the oil must be
changed at 5 000 km (3,000 mi)
since the last oil change.
Remember to reset the oil life
system whenever the oil is changed.How to Reset the Engine Oil
Life System
Reset the system whenever the
engine oil is changed so that the
system can calculate the next
engine oil change. To reset the
system:
1. Use the SELECT knob to selectOIL LIFE on the DIC menu.
2. Press SELECT to start the OIL LIFE reset procedure.
3. The DIC menu will display “Are
you sure that you want to reset?”
Use SELECT to choose YES to
reset oil life or NO to exit and
return to the previous menu.
4. If YES is selected, the DIC menu will display RESET OIL LIFE for
a short time and then 100% OIL
LIFE will be displayed when
OIL LIFE is successfully reset.
If the CHANGE ENGINE OIL SOON
message comes back on when the
vehicle is started, the engine oil life
system has not reset. Repeat the
procedure.
Engine Air Cleaner/Filter
See Engine Compartment Overview
on page 10‑10 for the location of the
engine air cleaner/filter.
When to Inspect the Engine Air
Filter
Inspect the air filter at the scheduled
maintenance intervals and replace
it at the first oil change after each
80 000 km (50,000 mi) interval.
See Scheduled Maintenance on
page 11‑2 for more information.
If driving in dusty/dirty conditions,
inspect the air filter at each engine
oil change.
How to Inspect the Engine Air
Filter
To inspect the air filter, remove it
from the engine air cleaner/filter
assembly and lightly shake to
release loose dust and dirt. If the
air filter remains covered with dirt,
a new air filter is required.

Black plate (1,1)Chevrolet Volt Owner Manual - 2011
INDEX i-1
A
Accessories andModifications . . . . . . . . . . . . . . . . . 10-4
Accessory Power . . . . . . . . . . . . . . 9-22
Add-On Electrical Equipment . . . . . . . . . . . . . . . . . . . 9-63
Air Cleaner/Filter, Engine . . . . . 10-16
Air Conditioning . . . . . . . . . . . . . . . . 8-1
Air Vents . . . . . . . . . . . . . . . . . . . . . . . 8-9
Airbag Adding Equipment to the
Vehicle . . . . . . . . . . . . . . . . . . . . . . 3-38
Airbag System Check . . . . . . . . . . . . . . . . . . . . . . . . 3-40
How Does an AirbagRestrain? . . . . . . . . . . . . . . . . . . . 3-30
Passenger Sensing System . . . . . . . . . . . . . . . . . . . . . . 3-33
What Makes an Airbag Inflate? . . . . . . . . . . . . . . . . . . . . . . 3-30
What Will You See after an Airbag Inflates? . . . . . . . . . . . . . 3-31
When Should an Airbag Inflate? . . . . . . . . . . . . . . . . . . . . . . 3-28
Where Are the Airbags? . . . . . . 3-27 Airbags
Passenger Status Indicator . . . 5-20
Readiness Light . . . . . . . . . . . . . . 5-19
Servicing Airbag-Equipped
Vehicles . . . . . . . . . . . . . . . . . . . . . 3-38
System Check . . . . . . . . . . . . . . . . 3-25
Alarm System
Anti-theft . . . . . . . . . . . . . . . . . . . . . . 2-13
Alert Pedestrian Friendly . . . . . . . . . . . . 6-2
AM-FM Radio . . . . . . . . . . . . . . . . . . 7-10
Antenna
Multi-band . . . . . . . . . . . . . . . . . . . . 7-18
Anti-theft Alarm System . . . . . . . . . . . . . . . . 2-13
Alarm System Messages . . . . . 5-51
Antilock Brake System (ABS) . . . . . . . . . . . . . . . . 9-33
Warning Light . . . . . . . . . . . . . . . . . 5-26
Appearance Care Exterior . . . . . . . . . . . . . . . . . . . . . 10-89
Interior . . . . . . . . . . . . . . . . . . . . . . 10-93
Assistance Program, Roadside . . . . . . . . . . . . . . . . . . . . . 13-6 Audio Players
CD/DVD . . . . . . . . . . . . . . . . . . . . . . 7-18
MP3 . . . . . . . . . . . . . . . . . . . . . . . . . . 7-23
Audio System Hard Drive Device (HDD) . . . . . 7-26
Radio Reception . . . . . . . . . . . . . . 7-17
Theft-Deterrent Feature . . . . . . . . 7-3
Automatic Climate Control System . . . . . . . . 8-1
Door Locks . . . . . . . . . . . . . . . . . . . 2-11
Auxiliary Devices . . . . . . . . . . . . . . 7-38
B
Battery . . . . . . . . . . . . . . . . . . . . . . . 10-28
Gauge . . . . . . . . . . . . . . . . . . . . . . . . 5-16
High Voltage . . . . . . . . . . . . . . . . . . 5-16
Jump Starting . . . . . . . . . . . . . . . 10-79
Power Protection . . . . . . . . . . . . . . 6-6
Battery and Charging Messages. . . . . . . . . . . . . . . . . . . . 5-45
Blade Replacement, Wiper . . . 10-31
Bluetooth . . . . . . . . . . . . . . . . . . . . . . 7-85
Brake Parking, Electric . . . . . . . . . . . . . . 9-35

Black plate (2,1)Chevrolet Volt Owner Manual - 2011
i-2 INDEX
Brake System Warning Light . . . 5-24
Brakes . . . . . . . . . . . . . . . . . . . . . . . . 10-25Antilock . . . . . . . . . . . . . . . . . . . . . . . 9-33
Fluid . . . . . . . . . . . . . . . . . . . . . . . . 10-26
Regenerative Braking . . . . . . . . . 9-37
System Messages . . . . . . . . . . . . 5-46
Braking . . . . . . . . . . . . . . . . . . . . . . . . . 9-5
Break-In, New Vehicle . . . . . . . . . 9-18
Bulb Replacement . . . . . . . . . . . . 10-37
Back-up Lamps . . . . . . . . . . . . . 10-35
Halogen Bulbs . . . . . . . . . . . . . . 10-34
Headlamp Aiming . . . . . . . . . . . 10-32
Headlamps . . . . . . . . . . . . . . . . . 10-34
License Plate Lamps . . . . . . . 10-36
Buying New Tires . . . . . . . . . . . . . 10-63
C
Calibration . . . . . . . . . . . . . . . . . . . . . 5-16
California Fuel Requirements . . . . . . . . . . . 9-58
Perchlorate MaterialsRequirements . . . . . . . . . . . . . . . 10-3
Warning . . . . . . . . . . . . . . . . . . . . . . 10-3 Camera, Rear Vision . . . . . . . . . . 9-46
Canadian Vehicle Owners . . . . . . . . iii
Capacities and
Specifications . . . . . . . . . . . . . . . . 12-2
Carbon Monoxide Engine Exhaust . . . . . . . . . . . . . . . 9-30
Hatch . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
Winter Driving . . . . . . . . . . . . . . . . 9-11
Cargo Cover . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Cautions, Danger, and
Warnings . . . . . . . . . . . . . . . . . . . . . . . . iv
CD/DVD Player . . . . . . . . . . . . . . . . 7-18
Chains, Tire . . . . . . . . . . . . . . . . . . 10-69
Charge Cord . . . . . . . . . . . . . . . . . . . 9-54
Charging . . . . . . . . . . . . . . . . . . . . . . 5-33 Delay Override . . . . . . . . . . . . . . . 9-52
Electrical Requirements . . . . . . 9-56
Plug-In . . . . . . . . . . . . . . . . . . . . . . . 9-49
Charging Status Screens . . . . . . 9-52
Charging System Light . . . . . . . . 5-21
Check Engine Light . . . . . . . . . . . . . . . . . . 5-21 Child Restraints
Infants and Young
Children . . . . . . . . . . . . . . . . . . . . . 3-43
Lower Anchors and Tethers for Children . . . . . . . . . 3-49
Older Children . . . . . . . . . . . . . . . . 3-41
Securing . . . . . . . . . . . . . . . . 3-57, 3-60
Systems . . . . . . . . . . . . . . . . . . . . . . 3-45
Cleaning Exterior Care . . . . . . . . . . . . . . . 10-89
Interior Care . . . . . . . . . . . . . . . . 10-93
Climate Control Systems Automatic . . . . . . . . . . . . . . . . . . . . . . 8-1
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . 5-42
Cluster, Instrument . . . . . . . . . . . . . 5-9
Collision Damage Repair . . . . . 13-10
Compass . . . . . . . . . . . . . . . . . . . . . . 5-16
Compressor Kit, Tire Sealant . . . . . . . . . . . . . . . . . . . . . . 10-71
Configure Menu . . . . . . . . . . . . . . . 7-66
Control of a Vehicle . . . . . . . . . . . . . 9-5
Convex Mirrors . . . . . . . . . . . . . . . . 2-15

Black plate (4,1)Chevrolet Volt Owner Manual - 2011
i-4 INDEX
E
Electric Drive Unit . . . . . . . . . . . . . 9-32
Electric Drive UnitMessages . . . . . . . . . . . . . . . . . . . . 5-47
Electric Drive Unit Shift Lock Control Function
Check . . . . . . . . . . . . . . . . . . . . . . . 10-30
Electric Mode . . . . . . . . . . . . . . . . . . 9-25
Electric Parking Brake . . . . . . . . . 9-35
Electric Parking Brake Light . . . 5-25
Electrical Equipment, Add-On . . . . . . . . . . . . . . . . . . . . . . 9-63
Electrical Requirements for Battery Charging . . . . . . . . . . . . . 9-56
Electrical System Engine Compartment
Fuse Block . . . . . . . . . . . . . . . . 10-38
Instrument Panel Fuse Block . . . . . . . . . 10-42, 10-43
Overload . . . . . . . . . . . . . . . . . . . 10-37
Rear Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . 10-45
Electronic Stability Control . . . . . 9-39
Energy Efficiency Driving . . . . . . . . . . . . . . . . . . . 1-25, 9-2
Energy Information . . . . . . . . . . . . 5-41 Engine
Air Cleaner/Filter . . . . . . . . . . . 10-16
Check and Service Engine
Soon Light . . . . . . . . . . . . . . . . . . 5-21
Compartment Overview . . . . . 10-10
Coolant . . . . . . . . . . . . . . . . . . . . . 10-21
Coolant Temperature Warning Light . . . . . . . . . . . . . . . 5-27
Cooling System . . . . . . 10-18, 10-20
Cooling System Messages . . . 5-47
Drive Belt Routing . . . . . . . . . . . . 12-3
Exhaust . . . . . . . . . . . . . . . . . . . . . . 9-30
Overheating . . . . . . . . . . . . . . . . 10-23
Pressure Light . . . . . . . . . . . . . . . . 5-28
Running While Parked . . . . . . . . 9-31
Engine Oil
Life System . . . . . . . . . . . . . . . . . 10-15
Messages . . . . . . . . . . . . . . . . . . . . 5-48
Engine Unavailable Out of Fuel . . . . . . . . . . . . . . . . . . . 9-28
Entry Lighting . . . . . . . . . . . . . . . . . . . 6-5
Event Data Recorders . . . . . . . . 13-26
Exit Lighting . . . . . . . . . . . . . . . . . . . . 6-6
Extended Range Mode . . . . . . . . 9-25
Extender, Safety Belt . . . . . . . . . . 3-23
Exterior Lamp Controls . . . . . . . . . 6-1
F
Filter,
Engine Air Cleaner . . . . . . . . . 10-16
Flash-to-Pass . . . . . . . . . . . . . . . . . . . 6-2
Flashers, Hazard Warning . . . . . . 6-4
Flat Tire . . . . . . . . . . . . . . . . . . . . . . 10-69
Floor Console Storage . . . . . . . . . . 4-1
Floor Mats . . . . . . . . . . . . . . . . . . . . 10-96
Fluid Brakes . . . . . . . . . . . . . . . . . . . . . . 10-26
Power Steering . . . . . . . . . . . . . 10-24
Washer . . . . . . . . . . . . . . . . . . . . . 10-24
Folding Mirrors . . . . . . . . . . . . . . . . 2-16
Front Seats Adjustment . . . . . . . . . . . . . . . . . . . . 3-4
Heated . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-57 Additives . . . . . . . . . . . . . . . . . . . . . 9-59
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . 9-62
Filling the Tank . . . . . . . . . . . . . . . 9-60
Fuels in Foreign Countries . . . . 9-58
Gasoline Specifications . . . . . . . 9-58
Gauge . . . . . . . . . . . . . . . . . . . . . . . . 5-16

Black plate (5,1)Chevrolet Volt Owner Manual - 2011
INDEX i-5
Fuel (cont.)Low Fuel Warning Light . . . . . . . 5-28
Requirements, California . . . . . 9-58
System Messages . . . . . . . . . . . . 5-48
Function Check Electric Drive Unit ShiftLock Control . . . . . . . . . . . . . . 10-30
Fuses Engine Compartment
Fuse Block . . . . . . . . . . . . . . . . 10-38
Instrument Panel Fuse Block . . . . . . . . . 10-42, 10-43
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . 10-45
G
Garage Door Opener . . . . . . . . . . 5-60
Programming . . . . . . . . . . . . . . . . . 5-60
Gasoline Specifications . . . . . . . . . . . . . . . . . 9-58
Gauges Battery . . . . . . . . . . . . . . . . . . . . . . . 5-16
Driver Efficiency . . . . . . . . . . . . . . 5-17
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16
Odometer . . . . . . . . . . . . . . . . . . . . . 5-15 Gauges (cont.)
Speedometer . . . . . . . . . . . . . . . . . 5-15
Trip Odometer . . . . . . . . . . . . . . . . 5-15
Warning Lights and
Indicators . . . . . . . . . . . . . . . . . . . . 5-9
General Information Service and Maintenance . . . . . 11-1
Towing . . . . . . . . . . . . . . . . . . . . . . . . 9-62
Vehicle Care . . . . . . . . . . . . . . . . . . 10-3
Global Positioning System (GPS) . . . . . . . . . . . . . . . . 7-74
Glove Box . . . . . . . . . . . . . . . . . . . . . . 4-1
GM Mobility Reimbursement Program . . . . . . . . . . . . . . . . . . . . . . 13-5
H
Halogen Bulbs . . . . . . . . . . . . . . . . 10-34
Hard Drive Device (HDD) . . . . . . 7-26
Hatch . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
Hazard Warning Flashers . . . . . . . 6-4
Head Restraints . . . . . . . . . . . . . . . . 3-2
Headlamps . . . . . . . . . . . . . . . . . . . 10-34
Aiming . . . . . . . . . . . . . . . . . . . . . . 10-32
Bulb Replacement . . . . . . . . . . 10-34
Daytime RunningLamps (DRL) . . . . . . . . . . . . . . . . . 6-3 Headlamps (cont.)
Flash-to-Pass . . . . . . . . . . . . . . . . . . 6-2
High-Beam On Light . . . . . . . . . . 5-29
High/Low Beam Changer . . . . . . 6-2
Lamps On Reminder . . . . . . . . . 5-29
Heated Front Seats . . . . . . . . . . . . . 3-6
Heated Mirrors . . . . . . . . . . . . . . . . . 2-16
Heating and Air Conditioning . . . 8-1
High Voltage Battery Gauge . . . 5-16
High Voltage Devices and Wiring . . . . . . . . . . . . . . . . . . . . . . . 10-37
High-Beam On Light . . . . . . . . . . . 5-29
Highway Hypnosis . . . . . . . . . . . . . 9-10
Hill and Mountain Roads . . . . . . . 9-10
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . 10-9
Hood, Door, Hatch Open Light . . . . . . . . . . . . . . . . . . . . . . . . . 5-30
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
How to Wear Safety Belts
Properly . . . . . . . . . . . . . . . . . . . . . . 3-13

Black plate (8,1)Chevrolet Volt Owner Manual - 2011
i-8 INDEX
N
NavigationDestination . . . . . . . . . . . . . . . . . . . 7-51
Symbols . . . . . . . . . . . . . . . . . . . . . . 7-47
Using the System . . . . . . . . . . . . . 7-39
Vehicle Data Recordingand Privacy . . . . . . . . . . . . . . . 13-27
New Vehicle Break-In . . . . . . . . . . 9-18
O
Object Detection System Messages . . . . . . . . . . . . . . . . . . . . 5-49
Odometer . . . . . . . . . . . . . . . . . . . . . . 5-15
Trip . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-15
Off-Road Recovery . . . . . . . . . . . . . . . . . . . . . . 9-8
Oil Engine . . . . . . . . . . . . . . . . . . . . . . 10-12
Engine Oil Life System . . . . . 10-15
Messages . . . . . . . . . . . . . . . . . . . . 5-48
Pressure Light . . . . . . . . . . . . . . . . 5-28
Older Children, Restraints . . . . . 3-41
Online Owner Center . . . . . . . . . . 13-4
OnStar
®System . . . . . . . . . . . . . . . 1-27
Open Source Information . . . . . 13-24 Ordering
Map DVDs . . . . . . . . . . . . . . . . . . . . 7-76
Service Publications . . . . . . . . 13-12
Out of Fuel/Engine Unavailable . . . . . . . . . . . . . . . . . . 9-28
Outlets Power . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
Overheating, Engine . . . . . . . . . . 10-23
Overview, Infotainment System . . . . . . . . . . . . . . . . . . . . . . . . 7-3
P
ParkShifting into . . . . . . . . . . . . . . . . . . . 9-22
Shifting out of . . . . . . . . . . . . . . . . . 9-23
Parking Assist, Ultrasonic . . . . . . . . . . . . . 9-43
Brake and P (Park)Mechanism Check . . . . . . . . 10-30
Over Things That Burn . . . . . . . 9-24
Passenger Airbag Status Indicator . . . . . . . . . . . . . . . . . . . . . 5-20
Passenger Sensing System . . . 3-33
Pedestrian Friendly Alert . . . . . . . 6-2
Perchlorate Materials
Requirements, California . . . . . 10-3 Personalization
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 5-53
Phone Bluetooth . . . . . . . . . . . . . . . . . . . . . 7-85
Plug-In Charging . . . . . . . . . . . . . . 9-49
Power Button . . . . . . . . . . . . . . . . . . . . . . . . 9-18
Door Locks . . . . . . . . . . . . . . . . . . . 2-11
Flows . . . . . . . . . . . . . . . . . . . . . . . . . 5-31
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . 2-15
Outlets . . . . . . . . . . . . . . . . . . . . . . . . 5-8
Protection, Battery . . . . . . . . . . . . . 6-6
Retained Accessory (RAP) . . . 9-22
Steering Fluid . . . . . . . . . . . . . . . 10-24
Windows . . . . . . . . . . . . . . . . . . . . . 2-17
Pregnancy, Using Safety
Belts . . . . . . . . . . . . . . . . . . . . . . . . . 3-23
Privacy Radio FrequencyIdentification (RFID) . . . . . . . 13-27
Problems with Route
Guidance . . . . . . . . . . . . . . . . . . . . 7-76
Program Courtesy Transportation . . . . . . 13-8

Black plate (10,1)Chevrolet Volt Owner Manual - 2011
i-10 INDEX
Safety Defects ReportingCanadian Government . . . . . . 13-25
General Motors . . . . . . . . . . . . . 13-25
U.S. Government . . . . . . . . . . . 13-24
Safety Locks . . . . . . . . . . . . . . . . . . . 2-12
Safety System Check . . . . . . . . . . 3-23
Satellite Radio . . . . . . . . . . . . . . . . . 7-16
Scheduled Maintenance . . . . . . . 11-2
Scheduling Appointments . . . . . . 13-8
Sealant Kit, Tire . . . . . . . . . . . . . . 10-71
Seats Adjustment, Front . . . . . . . . . . . . . . 3-4
Head Restraints . . . . . . . . . . . . . . . 3-2
Heated Front . . . . . . . . . . . . . . . . . . 3-6
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
Reclining Seatbacks . . . . . . . . . . . 3-4
Securing Child Restraints . . . . . . . . . . . . . . 3-57, 3-60
Security Light . . . . . . . . . . . . . . . . . . . . . . . . . . 5-29
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 2-13
Service Accessories andModifications . . . . . . . . . . . . . . . . 10-4
Doing Your Own Work . . . . . . . . 10-8
Engine Soon Light . . . . . . . . . . . . 5-21 Service (cont.)
Maintenance Records . . . . . . . . 11-8
Maintenance, General
Information . . . . . . . . . . . . . . . . . . 11-1
Parts Identification Label . . . . . 12-1
Publications Ordering Information . . . . . . . . . . . . . . . . 13-12
Scheduling Appointments . . . . . 13-8
Vehicle Messages . . . . . . . . . . . . 5-51
Service Electric Parking Brake Light . . . . . . . . . . . . . . . . . . . 5-25
Servicing the Airbag . . . . . . . . . . . 3-38
Shifting Into Park . . . . . . . . . . . . . . . . . . . . . . 9-22
Out of Park . . . . . . . . . . . . . . . . . . . 9-23
Signals, Turn and Lane-Change . . . . . . . . . . . . . . . . . 6-4
Specifications and
Capacities . . . . . . . . . . . . . . . . . . . . 12-2
Speedometer . . . . . . . . . . . . . . . . . . 5-15
Sport Mode Light . . . . . . . . . . . . . . 5-26
Start Check Propulsion
System . . . . . . . . . . . . . . . . . . . . 10-29
Remote . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Starting and Stopping the Vehicle . . . . . . . . . . . . . . . . . . . . . . . 9-20 Starting the Vehicle
Messsages . . . . . . . . . . . . . . . . . . . 5-52
Status Screens Charging . . . . . . . . . . . . . . . . . . . . . 9-52
Steering . . . . . . . . . . . . . . . . . . . . . . . . 9-6 Fluid, Power . . . . . . . . . . . . . . . . 10-24
Wheel Adjustment . . . . . . . . . . . . . 5-6
Wheel Controls . . . . . . . . . . . . . . . . 5-6
Storage Areas Cargo Cover . . . . . . . . . . . . . . . . . . . 4-2
Floor Console . . . . . . . . . . . . . . . . . 4-1
Glove Box . . . . . . . . . . . . . . . . . . . . . 4-1
Instrument Panel . . . . . . . . . . . . . . 4-1
Umbrella . . . . . . . . . . . . . . . . . . . . . . . 4-2
Storing the Tire Sealant and Compressor Kit . . . . . . . . . 10-78
Stuck Vehicle . . . . . . . . . . . . . . . . . . 9-13
Sun Visors . . . . . . . . . . . . . . . . . . . . . 2-19
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Symbols, Navigation . . . . . . . . . . . 7-47
System Infotainment . . . . . . . . . . . . . . . . . . . 7-2
System Needs Service, If . . . . . . 7-76
System Operation . . . . . . . . . . . . . 9-24
