10-30 Vehicle Care
7. Push the spring clip side intoplace.
Replacement Bulbs
Exterior Lamp Bulb
Number
Back-Up Lamps 3157K
High/Low‐Beam
Headlamps HIR2 (9012)
License Plate
Lamps W5W LL
For replacement bulbs not listed
here, contact your dealer.
Electrical System
High Voltage Devices and
Wiring
{Warning
Exposure to high voltage can
cause shock, burns, and even
death. The high voltage
components in the vehicle can
only be serviced by technicians
with special training.
High voltage components are
identified by labels. Do not
remove, open, take apart,
or modify these components.
High voltage cable or wiring has
orange covering. Do not probe,
tamper with, cut, or modify high
voltage cable or wiring.
Electrical System
Overload
The vehicle has fuses and circuit
breakers to protect against an
electrical system overload.
When the current electrical load is
too heavy, the circuit breaker opens
and closes, protecting the circuit
until the current load returns to
normal or the problem is fixed. This
greatly reduces the chance of circuit
overload and fire caused by
electrical problems.
Fuses and circuit breakers protect
the following in the vehicle:
.Headlamp Wiring
.Windshield Wiper Motor
.Power Windows and other
Power Accessories
Replace a bad fuse with a new one
of the identical size and rating.
If there is a problem on the road and
a fuse needs to be replaced, the
same amperage fuse can be

Black plate (12,1)Chevrolet VOLT Owner Manual (GMNA-Localizing-U.S./Canada-7695131) -
2015 - crc - 4/25/14
i-12 INDEX
W
WarningBrake System Light . . . . . . . . . . . 5-19
Lane Departure (LDW) . . . . . . . 9-44
Warning Light Forward CollisionAlert (FCA) . . . . . . . . . . . . . . . . . . 5-22
Warning Lights, Gauges, and Indicators . . . . . . . . . . . . . . . . . . . . . 5-8
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . iv Cautions and Danger . . . . . . . . . . . .iv
Hazard Flashers . . . . . . . . . . . . . . . 6-3
Washer Fluid . . . . . . . . . . . . . . . . . 10-20
Wheels Alignment and TireBalance . . . . . . . . . . . . . . . . . . . 10-57
Different Size . . . . . . . . . . . . . . . 10-55
Replacement . . . . . . . . . . . . . . . 10-58 When It Is Time for New
Tires . . . . . . . . . . . . . . . . . . . . . . . . 10-53
Where to Put the Restraint . . . . 3-36
Windows . . . . . . . . . . . . . . . . . . . . . . 2-18 Power . . . . . . . . . . . . . . . . . . . . . . . . 2-18
Windshield Wiper/Washer . . . . . . . . . . . . . . . . . 5-6
Winter Driving . . . . . . . . . . . . . . . . . . . . . . . . . 9-9
Winter Tires . . . . . . . . . . . . . . . . . . 10-41
Wiper Blade Replacement . . . . 10-26
Wiring, High Voltage Devices . . . . . . . . . . . . . . . . . . . . . 10-30
