CHRYSLER 200 2015 2.G Owners Manual

▫ParkSense® Warning Display .............222
▫ ParkSense® Display ....................222
▫ Enabling And Disabling ParkSense® ........228
▫ Service The ParkSense® Rear Park Assist
System ............................ .229
▫ Cleaning The ParkSense® System ..........229
▫ ParkSense® System Usage Precautions .......230
 PARKSENSE® FRONT AND REAR PARK
ASSIST — IF EQUIPPED .................232
▫ ParkSense® Sensors ....................234
▫ ParkSense® Warning Display .............234
▫ ParkSense® Display ....................235
▫ Enabling And Disabling ParkSense® ........245
▫ Service The ParkSense® Park Assist System . . .246 ▫
Cleaning The ParkSense® System ..........247
▫ ParkSense® System Usage Precautions .......247
 PARKSENSE® ACTIVE PARK ASSIST SYSTEM —
IF EQUIPPED ........................ .250
▫ Enabling And Disabling The ParkSense® Active
Park Assist System .....................251
▫ Parallel Parking Space Assistance
Operation/Display .....................253
▫ Perpendicular Parking Space Assistance
Operation/Display .....................262
 PARKVIEW® REAR BACK UP CAMERA — IF
EQUIPPED .......................... .274
 OVERHEAD CONSOLE ..................277
▫ Front Map/Reading Lights ..............278
▫ Sunglass Bin Door ....................279
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119

GARAGE DOOR OPENER — IF EQUIPPED . . .281
▫
Before You Begin Programming HomeLink® . . .282
▫ Programming A Rolling Code .............283
▫ Programming A Non-Rolling Code .........285
▫ Canadian/Gate Operator Programming ......286
▫ Using HomeLink® ....................288
▫ Security ........................... .288
▫ Troubleshooting Tips ...................288
▫ General Information ....................289
 POWER SUNROOF — IF EQUIPPED ........290
▫ Opening Sunroof — Express ..............291
▫ Opening Sunroof — Manual Mode .........291
▫ Closing Sunroof — Express ...............292 ▫
Closing Sunroof — Manual Mode ..........292
▫ Pinch Protect Feature ...................292
▫ Venting Sunroof — Express ..............292
▫ Sunshade Operation ....................293
▫ Wind Buffeting ...................... .293
▫ Sunroof Maintenance ...................293
▫ Ignition Off Operation ..................293
 POWER SUNROOF WITH POWER SHADE —
IF EQUIPPED ........................ .294
▫ Opening Sunroof — Express ..............295
▫ Opening Sunroof — Manual Mode .........296
▫ Closing Sunroof — Express ...............296
▫ Closing Sunroof — Manual Mode ..........296
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

▫Venting Sunroof — Express ..............296
▫ Opening Power Shade — Express ..........297
▫ Opening Power Shade — Manual Mode .....297
▫ Closing Power Shade — Express ...........297
▫ Closing Power Shade — Manual Mode ......297
▫ Pinch Protect Feature ...................298
▫ Wind Buffeting ...................... .298
▫ Sunroof Maintenance ...................298
▫ Ignition Off Operation ..................298
 ELECTRICAL POWER OUTLETS —
IF EQUIPPED ........................ .299
 POWER INVERTER — IF EQUIPPED ........302
 CUPHOLDERS ....................... .303
▫ Front Seat Cupholders ..................303 ▫
Rear Seat Cupholders ..................304
 STORAGE ........................... .305
▫ Glove Compartment ...................305
▫ Console Features .....................306
▫ Door Storage ........................ .309
▫ Rear Seat Armrest Storage — If Equipped . . . .310
 CARGO AREA FEATURES ................310
▫ Cargo Area — 60/40 Split-Folding Rear Seat —
If Equipped ......................... .310
▫ Grocery Bag Hooks ....................313
▫ Ski Pass-Through ..................... .313
 REAR WINDOW FEATURES ..............314
▫ Rear Window Defroster .................314
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121

MIRRORS
Inside Day/Night Mirror — If Equipped
A single ball joint mirror is provided in the vehicle. It is
a twist on mirror that has a fixed position at the wind-
shield. The mirror installs on the windshield button with
a counterclockwise rotation and requires no tools for
mounting. The mirror head can be adjusted up, down,
left, and right for various drivers. The mirror should be
adjusted to center on the view through the rear window.
Headlight glare from vehicles behind you can be reduced
by moving the small control under the mirror to the night
position (toward the rear of the vehicle). The mirror
should be adjusted while the small control under the
mirror is set in the day position (toward the windshield).
Adjusting Rearview Mirror
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Automatic Dimming Mirror — If Equipped
A single ball joint mirror is provided in the vehicle. It is
a twist on mirror that has a fixed position at the wind-
shield. The mirror installs on the windshield button with
a counterclockwise rotation and requires no tools for
mounting. The mirror head can be adjusted up, down,
left, and right for various drivers. The mirror should be
adjusted to center on the view through the rear window.
This mirror automatically adjusts for headlight glare
from vehicles behind you.
NOTE:The Automatic Dimming Mirror feature is dis-
abled when the vehicle is in reverse gear to improve rear
view viewing.
The Automatic Dimming Mirror feature can be turned
On or Off through the touchscreen.
• Press the Mirror Dimmer button once to turn the
feature On. •
Press the Mirror Dimmer button a second time to turn
the feature Off.
If equipped, the rearview mirror contains an ASSIST and
a 9-1-1 button.
Automatic Dimming Mirror
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123

NOTE:The ASSIST and 9–1–1 features operate through
the Uconnect® Access service. These buttons will only
operate as long as your Uconnect® Access service is
active. Refer to your “Uconnect® System supplement
manual” for further information.
ASSIST Call
The ASSIST Button is used to automatically connect you
to any one of the following support centers:
• Roadside Assistance – If you get a flat tire, or need a
tow, just press the Assist button and you’ll be con-
nected to someone who can help. Roadside Assistance
will know what vehicle you’re driving and its location.
Additional fees may apply for roadside Assistance.
• Uconnect® Access Customer Care – In-vehicle support
for Uconnect® Access and Uconnect® Access Via
Mobile features. •
Vehicle Customer Care – Total support for all other
vehicle issues.
9-1-1 Call
1. Press the 9-1-1 Call button on the Rearview Mirror.
NOTE: In case the 9-1-1 Call button is pushed in error,
there will be a 10 second delay before the 9-1-1 Call
system initiates a call to a 9-1-1 operator. To cancel the
9-1-1 Call connection, press the 9-1-1 Call button on the
Rearview Mirror or press the cancellation button on the
Phone Screen. Termination of the 9-1-1 Call will turn the
green LED light on the Rearview Mirror off.
2. The LED light located between the Assist and 9-1-1 buttons on the Rearview Mirror will turn green once a
connection to a 9-1-1 operator has been made.
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

3. Once a connection between the vehicle and a 9-1-1operator is made, the 9-1-1 Call system may transmit
the following important vehicle information to a 9-1-1
operator:
• Indication that the occupant placed a 9-1-1 Call.
• The vehicle brand.
• The last known GPS coordinates of the vehicle.
4. You should be able to speak with the 9-1-1 operator through the vehicle audio system to determine if
additional help is needed. NOTE:Once a connection is made between the vehicle’s
9-1-1 Call system and the 9-1-1 operator, the 9-1-1 operator
may be able to open a voice connection with the vehicle to
determine if additional help is needed. Once the 9-1-1
operator opens a voice connection with the vehicle’s 9-1-1
Call system, the operator should be able to speak with you
or other vehicle occupants and hear sounds occurring in
the vehicle. The vehicle’s 9-1-1 Call system will attempt to
remain connected with the 9-1-1 operator until the 9-1-1
operator terminates the connection.
5. The 9-1-1 operator may attempt to contact appropriate emergency responders and provide them with impor-
tant vehicle information and GPS coordinates.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125

WARNING!
•If anyone in the vehicle could be in danger (e.g.,
fire or smoke is visible, dangerous road conditions
or location), do not wait for voice contact from a
9-1-1 operator. All occupants should exit the vehicle
immediately and move to a safe location.
(Continued)
WARNING! (Continued)
•The 9-1-1 Call system is embedded into the vehi-
cle’s electrical system. Do not add aftermarket
electrical equipment to the vehicle’s electrical sys-
tem. This may prevent your vehicle from sending a
signal to initiate an emergency call. To avoid inter-
ference that can cause the 9-1-1 Call system to fail,
never add aftermarket equipment (e.g., two-way
mobile radio, CB radio, data recorder, etc.) to your
vehicle’s electrical system or modify the antennas
on your vehicle. IF YOUR VEHICLE LOSES BAT-
TERY POWER FOR ANY REASON (INCLUDING
DURING OR AFTER AN ACCIDENT), THE
UCONNECT FEATURES, APPS AND SERVICES,
AMONG OTHERS, WILL NOT OPERATE.
(Continued)
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!(Continued)
•Modifications to any part of the 9-1-1 Call system
could cause the air bag system to fail when you
need it. You could be injured if the air bag system
is not there to help protect you.
9-1-1 Call System Limitations
Vehicles sold in Canada and Mexico DO NOThave 9-1-1
Call system capabilities.
9-1-1 or other emergency line operators in Canada and
Mexico may not answer or respond to 9-1-1 system calls.
If the 9-1-1 Call system detects a malfunction, any of the
following may occur at the time the malfunction is
detected, and at the beginning of each ignition cycle: •
The Rearview Mirror light located between the Assist
and 9-1-1 buttons will continuously be illuminated
red.
• The Phone Screen will display the following message
“Vehicle phone requires service. Please contact your
dealer.”
• An In-Vehicle Audio message will state “Vehicle phone
requires service. Please contact your dealer.”
WARNING!
• Ignoring the Rearview Mirror light could mean you
will not have 9-1-1 Call services. If the Rearview
Mirror light is illuminated, have an authorized
dealer service the 9-1-1 Call system immediately.
(Continued)
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127

WARNING!(Continued)
•The Occupant Restraint Control module turns on
the Air Bag Warning Light on the instrument panel
if a malfunction in any part of the system is
detected. If the Air Bag Warning Light is illumi-
nated, the air bag system may not be working
properly and the 9-1-1 system may not be able to
send a signal to a 9-1-1 operator. If the Air Bag
Warning Light is illuminated, have an authorized
dealer service the ORC system immediately.
Even if the 9-1-1 Call system is fully functional, factors
beyond Chrysler Group LLC’s control may prevent or
stop the 9-1-1 Call system operation. These include, but
are not limited to, the following factors:
• The ignition key has been removed from the ignition
and the delayed accessories mode is active.
• The ignition key is in OFF position. •
The vehicle’s electrical systems are not intact.
• The 9-1-1 Call system software and/or hardware are
damaged during a crash.
• The vehicle battery loses power or becomes discon-
nected during a vehicle crash.
• Wireless and/or Global Positioning Satellite signals
are unavailable or obstructed.
• Equipment malfunction at the 9-1-1 operator facility.
• Operator error by the 9-1-1 operator.
• Wireless network congestion.
• Weather.
• Buildings, structures, geographic terrain, or tunnels.
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
