CHRYSLER 300 2004 1.G Warranty Booklet
Manufacturer: CHRYSLER, Model Year: 2004, Model line: 300, Model: CHRYSLER 300 2004 1.GPages: 131, PDF Size: 1.11 MB
Page 91 of 131
Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate as required all steering and suspension components.
l Replace the engine air cleaner filter if required (all models).
l Replace the spark plugs (2.4L).
l Inspect the PCV valve and replace as necessary.
l Inspect the serpentine drive belt, replace if necessary (Pacifica only).
l Replace the engine timing belt (2.4L, Sebring and Sebring Convertible only).
l Adjust the drive belt tension (Concorde, Intrepid and 300M only).
l Change the all-wheel-drive power transfer unit fluid.*
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the front and rear brake linings and components (Concorde, Intrepid, 300M and Pacifica only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
* All-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if the vehicle is operated more than 50% at sustained high speeds during hotweather, above 32 ¡C (90 ¡F) or if used for trailer tow or commercial service.Maint enance Service Sc hedule ÒBÓ
144,0 00 km
04 Early LaunchMaintenance Book 1/15/03 10:09 AM Page 90
Page 92 of 131
Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
149,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-31-01 3N.
Maint enance Service Sc hedule ÒBÓ
149,0 00 km
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate as required all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (all models).
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
04 Early LaunchMaintenance Book 1/15/03 10:09 AM Page 91
Page 93 of 131
Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate as required all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (all models).
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.Maint enance Service Sc hedule ÒBÓ
149,0 00 km
04 Early LaunchMaintenance Book 1/15/03 10:09 AM Page 92
Page 94 of 131
Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
154,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-32-01 3N.
Maint enance Service Sc hedule ÒBÓ
154,0 00 km
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate as required all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (all models).
l Replace the air conditioning filter (Pacifica only).
l Replace the differential fluid (Concorde, Intrepid and 300M only).
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the front and rear brake linings and components (Sebring and Sebring Convertible only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
04 Early LaunchMaintenance Book 1/15/03 10:09 AM Page 93
Page 95 of 131
Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate as required all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (all models).
l Replace the air conditioning filter (Pacifica only).
l Replace the differential fluid (Concorde, Intrepid and 300M only).
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the front and rear brake linings and components (Sebring and Sebring Convertible only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.Maint enance Service Sc hedule ÒBÓ
154,0 00 km
04 Early LaunchMaintenance Book 1/15/03 10:09 AM Page 94
Page 96 of 131
Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
158,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-33-01 3N.
Maint enance Service Sc hedule ÒBÓ
158,0 00 km
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate as required all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (all models).
l Replace the spark plugs (2.7L Sebring and Sebring Convertible only).
l Replace the spark plugs (Concorde, Intrepid and 300M only).
l Flush and replace engine coolant at 60 months or 160,000 kilometres.
l Replace the accessory drive belts (2.4L Sebring and Sebring Convertible only).
l Adjust the drive belt tension (Concorde, Intrepid and 300M only).
l Replace the engine timing belt (Concorde, Intrepid and 300M only).
INSPECT THE FOLLOWING: l Inspect the front and rear brake linings and components (Concorde, Intrepid, 300M and Pacifica only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
04 Early LaunchMaintenance Book 1/15/03 10:09 AM Page 95
Page 97 of 131
Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate as required all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (all models).
l Replace the spark plugs (2.7L Sebring and Sebring Convertibleonly).
l Replace the spark plugs (Concorde, Intrepid and 300M only).
l Flush and replace engine coolant at 60 months or 160,000 kilometres.
l Replace the accessory drive belts (2.4L Sebring and Sebring Convertible only).
l Adjust the drive belt tension (Concorde, Intrepid and 300M only).
l Replace the engine timing belt (Concorde, Intrepid and 300M onl y).
INSPECT THE FOLLOWING: l Inspect the front and rear brake linings and components (Concorde, Intrepid, 300M and Pacifica only).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.Maint enance Service Sc hedule ÒBÓ
158,0 00 km
04 Early LaunchMaintenance Book 1/15/03 10:09 AM Page 96
Page 98 of 131
Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
163,0 00 km
Maint
enance Service Sc hedule ÒBÓ
163,0 00 km
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate as required all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (all models).
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
Dealer copy.
Remove and attach to Repair Order 26-92-34-01 3N.
04 Early LaunchMaintenance Book 1/15/03 10:09 AM Page 97
Page 99 of 131
Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate as required all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (all models).
l Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.Maint enance Service Sc hedule ÒBÓ
163,0 00 km
04 Early LaunchMaintenance Book 1/15/03 10:09 AM Page 98
Page 100 of 131
Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
168,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-35-01 3N.
Maint enance Service Sc hedule ÒBÓ
168,0 00 km
lChange engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate as required all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (Sebring, Sebring Convertible only).
l Replace the engine air cleaner filter if required (Pacifica, Concorde, Intrepid and 300M only).
l Check and retension accessory drive belts (2.7L Sebring, Sebring Convertible only).
l Adjust the drive belt tension (Concorde, Intrepid and 300M only).
l Inspect the serpentine drive belt, replace if necessary (Pacifica only).
l Change the all-wheel-drive power transfer unit fluid.*
l Change the all-wheel-drive overrunning clutch and rear carrier fluid.*
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
* All-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if the vehicle is operated more than 50% at sustained
high speeds during hot weather, above 32 ¡C (90 ¡F) or if used for trailer tow or commercial service.
04 Early LaunchMaintenance Book 1/15/03 10:09 AM Page 99
