CHRYSLER 300 2006 1.G Owners Manual

Cavity Fuse Circuits
18 20 Amp
YellowSelectable Power Outlet
19 10 Amp
RedStop Lights
20——
21——
22——
23——
24——
25——
26——
27 10 Amp
RedAirbag/Occupant Classifica-
tion Module
28 10 Amp
RedCurtain Airbag - if equipped
29 5 Amp
OrangeAntilock Brakes Module/
Cluster/Front Control Module
(FCM)/Powertrain Control
Module (PCM)/Sentry Key
Remote Keyless Entry/Stop
LightsCavity Fuse Circuits
30 10 Amp
RedDoor Modules/Power Mirrors
- if equipped/Steering Control
Module
31——
32——
33——
34——
35 5 Amp
OrangeAmplifier - if equipped/
Antenna/Ignition Delay/
Overhead Console - if
equipped/Passenger Door
Lock & Express Power Win-
dow Switch - if equipped/
Power Mirrors - if equipped/
Rain Sensor - if equipped/
Rear Defrost
36 20 Amp
YellowHands Free Phone - if
equipped/Media System
Monitor DVD - if equipped/
Radio/Satellite Receiver - if
equipped
MAINTAINING YOUR VEHICLE 331
7

Cavity Fuse Circuits
37 15 Amp
BlueTransmission - NAG1
38 5 Amp
OrangeAnalog Clock/Cargo Light/
Overhead Console - if
equipped
39 10 Amp
RedHeated Mirrors - if equipped
40 5 Amp
OrangeHeated Seats - if equipped/
Inside Rearview Mirror/
Manual Temperature Control
(early build) - if equipped
41 10 Amp
RedAC Heater Control (except
early build MTC)/Park Assist
- if equipped/Tire Pressure
Monitoring - if equipped
42 30 Amp
PinkFront Blower Motor
43 30 Amp
PinkAmplifier - if equipped/
Antenna/Rear Defrost
44 20 Amp
BlueAmplifier - if equipped/Front
Control Module (FCM)/
Sunroof - if equippedVEHICLE STORAGE
If you are leaving your vehicle dormant for more than 21
days you may want to take steps to protect your battery.
You may:
•Disconnect the negative cable from the battery.
•Anytime you store your vehicle, or keep it out of
service (i.e. vacation) for two weeks or more, run the
air conditioning system at idle for about five minutes
in the fresh air and high blower setting. This will
insure adequate system lubrication to minimize the
possibility of compressor damage when the system is
started again.
332 MAINTAINING YOUR VEHICLE

REPLACEMENT LIGHT BULBS
LIGHT BULBS—Interior Bulb Number
Rear Courtesy/Reading Lights.............. W5W
Rear Compartment (Trunk) Light............. 579
Overhead Console Reading Lights............. 578
Visor Vanity Lights.....................A6220
Glove Box Light......................... 194
Door Courtesy.......................... 562
Shift Indicator Light.................JKLE14140
NOTE:For lighted switches, see your dealer for re-
placement instructions.
All of the interior bulbs are glass wedge base or glass
cartridge types. Aluminum base bulbs are not approved
and should not be used for replacement.LIGHT BULBS—Exterior
(300, 300 Touring Models) Bulb Number
Low Beam Headlight.....................9006
High Beam Headlight.....................9005
Front Park/Turn Light..................3757AK
Front Inner Park Light..................194NA
Front Outer Park Light..................194NA
Front Fog Light—
If Equipped..........9145/H10 (Serviced at Dealer)
Front Sidemarker......... W5W(Serviced at Dealer)
Tail/Stop/Turn Light.....................3057
Rear Sidemarker......................... 168
Backup Light...........................3057
Center High Mount Stop Light (CHMSL)....... LED
License................................ 168
MAINTAINING YOUR VEHICLE 333
7

LIGHT BULBS—
Exterior (300C Models) Bulb Number
Low Beam Headlight (Standard Halogen).....9006XS
Low Beam Headlight–High Intensity Discharge
(HID).................. D1S(Serviced at Dealer)
High Beam Headlight.....................9005
Front Park/Turn Light..................3157AK
Front Fog Light........9145/H10 (Serviced at Dealer)
Front Sidemarker......... W5W(Serviced at Dealer)
Tail/Stop Light.........................3057
Tail Light.............................3057
Turn Signal Light........................3057
Backup Light...........................3057
Center High Mount Stop Light (CHMSL)....... LED
License.............................. W5WBULB REPLACEMENT
Low Beam Headlight, High Beam Headlight,
Park/Turn Light, Inner Park Light, and Outer Park
Light–300 Models
•
Open the hood.
•Twist the appropriate bulb socket assembly counter-
clockwise and pull out. Pull the bulb out of the socket
assembly.
NOTE:Removal of the air cleaner filter housing may be
necessary prior to replacing bulbs on the headlight
assembly on the driver side of the vehicle.
•Replace the bulb and push into socket assembly.
Reinstall the socket assembly, and turn clockwise.
334 MAINTAINING YOUR VEHICLE

MAINTAINING YOUR VEHICLE 335
7

CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with an oily surface, clean the
bulb with rubbing alcohol.
Low Beam Headlight, High Beam Headlight, and
Park/Turn Light–300C
High Intensity Discharge Headlights (HID)—If
Equipped
The headlights are a type of high voltage discharge tube.
High voltage can remain in the circuit even with the
headlight switch off and the key removed.Because of
this, you should not attempt to service a headlight bulb
yourself. If a headlight bulb fails, take your vehicle to
an authorized dealer for service.
WARNING!
A transient high tension occurs at the bulb sockets of
High Intensity Discharge (HID) headlights when the
headlight switch is turned ON. It may cause serious
electrical shock or electrocution if not serviced prop-
erly. See your authorized dealer for service.
336 MAINTAINING YOUR VEHICLE

NOTE:On vehicles equipped with High Intensity Dis-
charge Headlights (HID), when the headlights are turned
on there is a blue hue to the lights. This diminishes and
becomes more white after approximately 10 seconds, as
the system charges.
•Open the hood.
•Twist the appropriate bulb socket assembly counter-
clockwise and pull out. Pull the bulb out of the socket
assembly.
NOTE:Removal of the air cleaner filter housing may be
necessary prior to replacing bulbs on the headlight
assembly on the driver side of the vehicle.
•Replace the bulb and push into socket assembly.
Reinstall the socket assembly, and turn clockwise.
MAINTAINING YOUR VEHICLE 337
7

CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with an oily surface, clean the
bulb with rubbing alcohol.
Backup Light, Side Marker Light, and Tail/Stop
Turn Light—300 Models
1. Open the Trunk.
2. Remove two fasteners from the back of the tail light
assembly.
338 MAINTAINING YOUR VEHICLE

3. Pull back the trunk liner.
4. Remove the remaining fastener from the back of the
tail light assembly.
5. Push the electrical connector locking tab to the side.
6. Disconnect the electrical connector.7. Pull tail light assembly clear from vehicle to access
bulbs. Turn bulb sockets counter-clockwise to remove.
MAINTAINING YOUR VEHICLE 339
7

8. Pull the appropriate bulb to remove it from the socket.
9. Replace the bulb, reinstall the socket, and reattach the
tail light assembly.
10. Close the trunk.
