Page 205 of 277
performance may be impaired by supplemental addi-
tives.
Disposing of Used Engine Oil
Care should be taken in disposing of used engine oil from
your vehicle. Used oil, indiscriminately discarded, can
present a problem to the environment. Contact your
dealer, service station, or governmental agency for advice
on how and where used oil can be safely discarded in
your area.
Engine Oil Filter
The engine oil filter should be replaced at every engine
oil change.
Engine Oil Filter Selection
All of the manufacturer’s engines have a full-flow type
disposable oil filter. Use a filter of this type for replace-
ment. The quality of replacement filters varies consider-
ably. Only high quality filters should be used to assure
most efficient service. Mopar Engine Oil Filters are high
quality oil filters and are recommended.
Drive Belts — Check Condition and Tension
At the mileage shown in the maintenance schedules,
check all drive belts for condition and proper tension.
Improper belt tension can cause belt slippage and failure.
Inspect the drive belts for evidence of cuts, cracks, or
glazing and replace them if there is any sign of damage
which could result in belt failure. If adjustment is re-
quired, adjust the belts according to the specifications
and procedures shown in the Service Manual.
Special tools are required to properly measure tension
and to restore belt tension to factory specifications. Also,
check belt routing to make sure there is no interference
between the belts and other engine components.
Spark Plugs
Spark plugs must fire properly to assure engine perfor-
mance and emission control. New plugs should be in-
stalled at the mileage specified in the appropriate main-
tenance chart. The entire set should be replaced if there is
any malfunction due to a faulty spark plug. Check the
specifications section for the proper type of spark plug
for use in your vehicle.
MAINTAINING YOUR VEHICLE 205
7
Page 249 of 277
Miles 93,000 96,000 99,000 100,000 102,000 105,000
(Kilometers) (149 000) (154 000) (158 000) (160 000) (163 000) (168 000)
Change engine oil and engine oil filter. X X X X X
Inspect theair cleaner filterand replace if re-
quired.*XXX X
Replace theair cleaner filter.X
Inspect the front and rear brake linings and
rotors.X
Flush and replace the engine coolant. X
Replace theengine timing belt(Federal Emis-
sions).X
Replace theengine timing belt(California
Emissions).X
Replace thespark plugs.X
Adjust the drive belt tension.X
Change the differential fluid. X
* This maintenance is recommended by the manufacture
to the owner but is not required to maintain the emis-
sions warranty.
‡ This maintenance is not required if previously replaced.Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
SCHEDULE “B” 249
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 252 of 277
Miles 78,000 84,000 90,000 96,000 102,000
(Kilometers) (125 000) (134 000) (144 000) (154 000) (163 000)
[Months] [78] [84] [90] [96] [102]
Change engine oil and engine oil filter. X X X X X
Inspect theair cleaner filterand replace if re-
quired.*XX XX
Replace theair cleaner filter.*X
Adjust the drive belt tension. X
Inspect the front and rear brake linings and rotors. X
Replace thespark plugs.X
Check and replace, if necessary, thePCV valve.*‡ X
Replace theengine timing belt(Federal Emissions
equipped vehicles only).X
Replace theengine timing belt(California Emis-
sions equipped vehicles only).X
Flush and replace the engine coolant at 60 months
or 100,000 miles.X
* This maintenance is recommended by the manufacture
to the owner but is not required to maintain the emis-
sions warranty.
‡ This maintenance is not required if previously replaced.Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
252 SCHEDULE “A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 275 of 277
Seat Belt Maintenance................... 227
Seat Belts.........................27,28,48
Adjustable Upper Shoulder Anchorage...... 32
Child Restraint........................ 45
Extender............................ 32
Inspection........................... 48
Reminder........................... 114
Seats................................. 57
Cleaning............................ 225
Glide-To-Exit......................... 58
Heated.............................. 59
Lumbar Support....................... 59
Power.............................. 57
Rear Folding......................... 62
Reclining............................ 58
Sentry Key............................. 9
Sentry Key Programming.................. 11
Sentry Key Replacement.................. 10
Service Assistance...................... 256
Service Contract........................ 258
Service Engine Soon Light................ 198
Service Manuals........................ 261
Setting the Clock....................... 118Shoulder Belts.......................... 32
Side Airbag............................ 38
Side View Mirror Adjustment............... 56
Side Window Demisters.................. 150
Signals, Turn........................... 68
Slippery Surfaces, Driving On............. 191
Snow Chains.......................... 170
Snow Tires............................ 170
Spare Tire............................ 169
Spark Plugs........................... 205
Speed Control.......................... 71
Speedometer.......................... 114
Starting.............................. 155
Steering
Linkage............................ 210
Power...........................163,210
Tilt Column.......................... 70
Steering Wheel Mounted Sound System
Controls............................ 142
Stuck, Freeing......................... 192
Sulfur in Gasoline...................... 177
Sun Roof............................86,87
Supplemental Restraint System - Airbag....... 33
INDEX 275
10
