wiper fluid CHRYSLER 300 SRT 2005 1.G Owners Manual

▫Memory Feature.......................89
▫Programming The Remote Keyless Transmitter
For The Memory Feature.................91
▫Driver’s Seat Glide To Exit Feature..........91
▫Head Restraints.......................92
▫Folding Rear Seat......................93

Adjustable Pedals.......................94

To Open And Close The Hood.............95

Lights...............................97
▫Overhead Console Map/Reading Lights......97
▫Interior Lights........................97
▫Headlight Switch......................98
▫Multi-Function Lever....................99
▫Headlights, Parking Lights, Instrument Panel
Lights..............................99
▫Automatic Headlights..................100▫Headlamps On With Wipers.............100
▫Daytime Running Lights (Canada Only).....100
▫Lights-On Reminder...................100
▫Headlight Time Delay..................100
▫Fog Lights..........................101
▫Turn Signals.........................101
▫Highbeam/Lowbeam Select Switch.........101
▫Flash To Pass........................101
Windshield Wipers And Washers..........102
▫Windshield Washers...................102
▫Rain Sensing Wipers...................103
▫Mist Feature.........................103
▫Headlamps On With Wipers.............104
▫Windshield Wiper Operation.............104
▫Intermittent Wiper System...............104
▫Adding Washer Fluid..................104
60 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Headlamps On With Wipers
The headlights will turn on approximately 10 seconds
after the wipers are turned on if the headlight switch is
placed in the AUTO position. The headlights will also
turn off when the wipers are turned off if they were
turned on by this feature. This feature can be turned on or
off using the Electronic Vehicle Information Center
(EVIC). Refer to ”Headlamps On With Wipers” in the
Electronic Vehicle Information Center section of this
manual for details.
Windshield Wiper Operation
Rotate the end of the lever to the second detent for Low
speed wiper operation, or to the third detent for High
speed operation.
Intermittent Wiper System
Use the intermittent wiper when weather conditions
make a single wiping cycle, with a variable pause be-
tween cycles, desirable. Rotate the end of the lever to the
first detent position, then turn the end of the lever to
select the desired delay interval. There are 6 possibledelay wiper positions. The delay can be regulated from a
maximum of approximately 23 seconds between cycles,
to a cycle every second.
Adding Washer Fluid
The windshield washer fluid reservoir is located in the
front of the engine compartment on the passenger side
and should be checked for fluid level at regular intervals.
Fill the reservoir with windshield washer solvent (not
radiator antifreeze) and operate the system for a few
seconds to flush out the residual water.
Windshield Washer Fluid Reservoir
104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

The washer fluid reservoir will hold a full gallon of fluid
when “Low Washer Fluid” appears in the Electronic
Vehicle Information Center.
Headlight Washers
This feature operates in combination with the windshield
washers. To use the headlight washers, turn the head-
lights ON and press in on the windshield washer control
knob while the engine is running.This will operate the windshield washers and direct a
timed high pressure spray onto the headlight lens.
NOTE:The headlamp washers will operate on the first
spray of the windshield washers, then every fourth spray
of the windshield washers after that.
Windshield Wiper/Washer Control
Headlamp Washer
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105
3

MAINTAINING YOUR VEHICLE
CONTENTS

6.1L Engine..........................237

Onboard Diagnostic System — OBD II......238

Emissions Inspection And Maintenance
Programs
............................239

Replacement Parts.....................240

Dealer Service........................240

Maintenance Procedures.................241
▫Engine Oil..........................241
▫Engine Oil Filter......................243
▫Drive Belts — Check Condition And
Tensioner...........................244
▫Spark Plugs.........................244▫Engine Air Cleaner Filter................244
▫Fuel Filter..........................245
▫Catalytic Converter....................245
▫Maintenance-Free Battery................247
▫Air Conditioner Maintenance.............248
▫A/C Air Filter — If Equipped............249
▫Power Steering — Fluid Check............249
▫Front & Rear Suspension Ball Joints........250
▫Steering Linkage......................250
▫Body Lubrication.....................250
▫Windshield Wiper Blades................250
7

Refrigerant Recovery and Recycling
R-134a Air Conditioning Refrigerant is a hydrofluorocar-
bon (HFC) that is endorsed by the Environmental Pro-
tection Agency and is an ozone-saving product. How-
ever, the manufacturer recommends that air conditioning
service be performed by dealers or other service facilities
using recovery and recycling equipment.
NOTE:Use only manufacturer approved A/C System
Sealers, Stop Leak Products, Seal Conditioners, Compres-
sor Oil, or Refrigerants.
A/C Air Filter — If Equipped
The filter is located in the fresh air inlet under the hood,
behind a removable panel in the cowl on the passenger
side of the vehicle, next to the windshield wipers. When
installing a new filter, ensure its proper orientation. To
replace the filter remove the access door in the cowl
screen by pressing the retaining clips. Slide the lid on the
filter adapter forward and down and remove used filter.
Install new filter with arrows pointing in the direction of
airflow, which is toward the rear of the vehicle (text and
arrows on the filter indicate this).Refer to the “Maintenance Schedules” section of this
manual for the recommended air conditioning filter
replacement intervals.
Power Steering — Fluid Check
Checking the power steering fluid level at a defined
service interval is not required. The fluid should only be
checked if a leak is suspected, abnormal noises are
apparent, and/or the system is not functioning as antici-
pated. Coordinate inspection efforts through a certified
DaimlerChrysler Dealership.
WARNING!
Fluid level should be checked on a level surface and
with the engine off to prevent injury from moving
parts and to insure accurate fluid level reading. Do
not overfill. Use only manufacturer’s recommended
power steering fluid.
MAINTAINING YOUR VEHICLE 249
7

If necessary, add fluid to restore to the proper indicated
level. With a clean cloth, wipe any spilled fluid from all
surfaces. Refer to Recommended Fluids, Lubricants, and
Genuine Parts for correct fluid type.
Front & Rear Suspension Ball Joints
The suspension ball joints should be inspected for exter-
nal leakage or damage when other maintenance is per-
formed.
Steering Linkage
The tie rod end ball joints should be inspected for
external leakage or damage when other maintenance is
performed.
Body Lubrication
Locks and all body pivot points, including such items as
seat tracks, doors, trunk and hood hinges, should be
lubricated periodically to assure quiet, easy operation
and to protect against rust and wear. Prior to the appli-
cation of any lubricant, the parts concerned should be
wiped clean to remove dust and grit; after lubricating
excess oil and grease should be removed. Particular
attention should also be given to hood latching compo-
nents to insure proper function. When performing otherunderhood services, the hood latch, release mechanism
and safety catch should be cleaned and lubricated.
The external lock cylinders should be lubricated twice a
year, preferably in the fall and spring. Apply a small
amount of a high quality MoparLock Cylinder Lubri-
cant or equivalent directly into the lock cylinder.
Windshield Wiper Blades
The rubber edges of the wiper blades and the windshield
should be cleaned periodically with a sponge or soft cloth
and a mild nonabrasive cleaner. This will remove accu-
mulations of salt or road film.
Operation of the wipers on dry glass for long periods
may cause deterioration of the wiper blades. Always use
washer fluid when using the wipers to remove salt or dirt
from a dry windshield.
Avoid using the wiper blades to remove frost or ice from
the windshield. Keep the blade rubber out of contact with
petroleum products such as engine oil, gasoline, etc.
250 MAINTAINING YOUR VEHICLE

Pregnant Women and Seat Belts............. 34
Pretensioners
Seat Belts............................ 33
Programmable Electronic Features..... 115,119,147
Programming Transmitters............. 115,119
Radial Ply Tires........................ 208
Radiator Cap (Coolant Pressure Cap)........ 254
Radio Broadcast Signals.................. 168
Radio Operation.....................151,171
Radio Remote Controls.................. 166
Radio, Satellite......................... 163
Radio (Sound Systems)................... 151
Rain Sensitive Wiper System.............. 103
Rear Park Assist System................... 85
Rear Seat, Folding....................... 93
Reclining Front Seats..................... 88
Recommended Fluids, Lubricants and Genuine
Parts............................... 276
Recorder, Event Data..................... 47
Recreational Towing..................... 222
Refrigerant............................ 249
Reminder, Seat Belt...................... 33Remote Keyless Entry.................... 19
Remote Sound System Controls............ 166
Remote Trunk Release.................... 26
Replacement Tires...................... 209
Reporting Safety Defects................. 299
Restraint, Head......................... 92
Restraints, Occupant..................... 28
Rocking Vehicle When Stuck.............. 232
Rotation, Tires......................... 212
Safety Checks Inside Vehicle............... 57
Safety Checks Outside Vehicle.............. 57
Safety Defects, Reporting................. 299
Safety Information, Tire.................. 197
Safety Tips............................. 56
Satellite Radio......................... 163
Satellite Radio Antenna.................. 165
Schedule, Maintenance................... 278
Seat Belt Maintenance................... 263
Seat Belt Reminder...................... 33
Seat Belts.............................. 29
Adjustable Upper Shoulder Anchorage...... 32
And Pregnant Women.................. 34
312 INDEX

Shifting............................ 183
Transmitter Battery Service................ 21
Transmitter, Garage Door Opener........... 115
Transmitter, Remote Keyless Entry........... 19
Transporting Pets........................ 55
Tread Wear Indicators................... 209
Trip Odometer Reset Button............... 138
Trunk Release, Emergency................. 27
Trunk Release Remote Control.............. 26
Turn Signals........................101,134
Uniform Tire Quality Grades.............. 301
Universal Transmitter.................... 115
Unleaded Gasoline...................... 214
Vanity Mirrors.......................... 65
Variance, Compass...................... 144
Vehicle Certification Label................ 219
Vehicle Identification Number............... 6
Vehicle Loading..................202,219,220
Vehicle Modifications/Alterations............ 7
Vehicle Storage......................177,268
Vehicle Theft Alarm...................... 22
Viscosity, Engine Oil..................... 243Warning Flasher, Hazard................. 224
Warnings and Cautions.................... 6
Warranty Information.................... 297
Washer, Adding Fluid..............104,106,251
Washers, Headlight..................... 105
Washers, Windshield.................... 102
Washing Vehicle........................ 261
Wheel Alignment and Balance............. 210
Wheel and Wheel Trim................... 262
Wheel Bearings........................ 260
Wind Buffeting......................26,122
Window Airbag.......................36,44
Window Fogging....................... 177
Windows.............................. 23
Power.............................. 23
Windshield Defroster.................... 175
Windshield Washers..................102,251
Windshield Wiper Blades................. 250
Windshield Wipers...................... 102
Wiper Blade Replacement................. 250
Wipers, Intermittent..................... 104
Wipers, Rain Sensitive................... 103
INDEX 315
10
