CHRYSLER 300 SRT 2006 1.G Owners Manual

Front Power Distribution Center Fuses
Cavity Fuse Circuits
1 20 Amp Yellow Left High Beam Headlight
2 20 Amp Yellow Right High Beam Head-
light
3— —
4 20 Amp Yellow Horn
5 25 Amp Clear Headlamp Washer
6 15 Amp Dk. Blue Front Control Module
(FCM)
7 20 Amp Yellow Fog Lamp
8 15 Amp Dk. Blue Park Lamp
9 15 Amp Dk. Blue Non ABS Brakes
10 5 Amp Orange Starter
11 20 Amp Yellow Auto Shutdown/
Powertrain Control Mod-
ule (PCM)
12 — —
13 — —
Cavity Fuse Circuits
14 25 Amp Clear Powertrain Control Mod-
ule
15 20 Amp Yellow Injectors, Ignition Coils
16 15 Amp Dk. Blue Powertrain Control Mod-
ule
17 30 Amp Pink Antilock Brake System
(ABS) Valves
18 30 Amp Pink Windshield Wiper/Washer
19 50 Amp Red Radiator Fan
20 20 Amp Lt. Blue Starter
21 50 Amp Red ABS Pump Motor
22 40 Amp Green Radiator Fan High/Low
23 50 Amp Red High Intensity Lighting
24 60 Amp Yellow Radiator Fan
25 30 Amp Pink Lighting Left High Beam/
Right Low Beam
26 — —
27 30 Amp Pink Lighting Left Low Beam/
Right High Beam
MAINTAINING YOUR VEHICLE 271
7

Rear Power Distribution Center
There is also a power distribution center located in the
trunk under an access panel. This center contains fuses
and relays.CAUTION!
•When installing the Power Distribution Center
cover, it is important to ensure the cover is prop-
erly positioned and fully latched. Failure to do so
may allow water to get into the Power Distribu-
tion Center, and possibly result in a electrical
system failure.
•When replacing a blown fuse, it is important to
use only a fuse having the correct amperage
rating. The use of a fuse with a rating other than
indicated may result in a dangerous electrical
system overload. If a properly rated fuse contin-
ues to blow, it indicates a problem in the circuit
that must be corrected.
Rear Power Distribution Center
272 MAINTAINING YOUR VEHICLE

Rear Power Distribution Center Fuses
Cavity Fuse Circuits
1 60 Amp Clear Ignition Off Draw
2 40 Amp Green Battery
3— —
4 40 Amp Green Battery
5 30 Amp Pink Heated Seat/Steering Col-
umn
6 20 Amp Yellow Fuel Pump
7— —
8 15 Amp Dk. Blue Ignition Start/Run - Start
9 20 Amp Yellow Console Power Outlet
10 10 Amp Red Rear Fog Lamp — If
Equipped
11 25 Amp C/BRKR Memory Module/Door
Locks
12 25 Amp C/BRKR Passenger Power Seat
13 30 Amp C/BRKR Door Module Run/Acc/
Delay
14 10 Amp Red Sentry Key/Remote Key-
less Entry/Cluster
Cavity Fuse Circuits
15 — —
16 — —
17 — —
18 20 Amp Yellow Selectable Power Outlet
19 10 Amp Red Stop Lamp
20 — —
21 — —
22 — —
23 — —
24 — —
25 — —
26 — —
27 10 Amp Red Airbag/Occupant Classifi-
cation Module
28 10 Amp Red Curtain Airbag - if
equipped
29 5 Amp Orange Sentry Key/Remote Key-
less Entry/Powertrain
Control Module Ignition
Feed
MAINTAINING YOUR VEHICLE 273
7

Cavity Fuse Circuits
30 10 Amp Red Steering Column Module/
Power Mirrors
31 — —
32 — —
33 — —
34 — —
35 5 Amp Orange Power Antenna/Garage
Door Opener/Ignition De-
lay
36 20 Amp Yellow Radio/Navigation
37 15 Amp Dk. Blue Transmission
38 5 Amp Orange Analog Clock/Garage
Door OpenerCavity Fuse Circuits
39 10 Amp Red Heated Mirror
40 5 Amp Orange Power Mirror
41 10 Amp Red Climate Control Module/
Headlamp Leveling — if
equipped/Rear Park As-
sist
42 30 Amp Pink Automatic Temperature
Control (ATC) Blower Mo-
tor
43 30 Amp Pink Rear Defroster
44 20 Amp Lt. Blue Audio Amplifier
274 MAINTAINING YOUR VEHICLE

VEHICLE STORAGE
If you are leaving your vehicle dormant for more than 21
days you may want to take steps to protect your battery.
You may:
•Disconnect the negative cable from the battery.
•Anytime you store your vehicle, or keep it out of
service (i.e. vacation) for two weeks or more, run the
air conditioning system at idle for about five minutes
in the fresh air and high blower setting. This will
insure adequate system lubrication to minimize the
possibility of compressor damage when the system is
started again.
REPLACEMENT LIGHT BULBS
LIGHT BULBS — Interior Bulb Number
Rear Courtesy/Reading Lights.............. W5W
Rear Compartment (Trunk) Light............. 579
Overhead Console Reading Lights............. 578
Visor Vanity Lights.....................A6220
Glove Box Light......................... 194
Door Courtesy.......................... 562
Shift Indicator Light................. JKLE14140
NOTE:For lighted switches, see your dealer for re-
placement instructions.
All of the interior bulbs are glass wedge base or glass
cartridge types. Aluminum base bulbs are not approved
and should not be used for replacement.
MAINTAINING YOUR VEHICLE 275
7

LIGHT BULBS — Exterior Bulb Number
Low Beam Headlamp – High
Intensity Discharge (HID).... D1S(Serviced at Dealer)
High Beam Headlamp....................9005
Front Park/Turn Lamp.................3157AK
Front Fog Lamp.......9145/H10 (Serviced at Dealer)
Front Sidemarker......... W5W(Serviced at Dealer)
Tail/Stop Lamp.........................3057
Tail Lamp.............................3057
Turn Signal Lamp.......................3057
Backup Lamp..........................3057
Center High Mount Stop Lamp (CHMSL)....... LED
License.............................. W5WBULB REPLACEMENT
Low Beam Headlamp, High Beam Headlamp, and
Park/Turn Lamp
High Intensity Discharge Headlights (HID)
The headlights are a type of high voltage discharge tube.
High voltage can remain in the circuit even with the
headlight switch off and the key removed.Because of
this, you should not attempt to service a headlight bulb
yourself. If a headlight bulb fails, take your vehicle to
an authorized dealer for service.
WARNING!
A transient high tension occurs at the bulb sockets of
High Intensity Discharge (HID) headlights when the
headlight switch is turned ON. It may cause serious
electrical shock or electrocution if not serviced prop-
erly. See your authorized dealer for service.
276 MAINTAINING YOUR VEHICLE

NOTE:When HID headlights are turned on there is a
blue hue to the lights. This diminishes and becomes more
white after approximately 10 seconds, as the system
charges.
•Open the hood.
•Twist the appropriate bulb socket assembly counter-
clockwise and pull out. Pull the bulb out of the socket
assembly.
NOTE:Removal of the air cleaner filter housing may be
necessary prior to replacing bulbs on driver’s side head-
lamp assembly.
•Replace the bulb and push into socket assembly.
Reinstall the socket assembly, and turn clockwise.
MAINTAINING YOUR VEHICLE 277
7

CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with an oily surface, clean the
bulb with rubbing alcohol.
Tail/Stop, Tail, Turn Signal Lamp, and Backup
Lamp
1. Open the Trunk.
2. Remove two fasteners from the back of the tail lamp
assembly.3. Pull back the trunk liner.
4. Remove the remaining fastener from the back of the
tail lamp assembly.
5. Push the electrical connector locking tab to the side.
278 MAINTAINING YOUR VEHICLE

6. Disconnect the electrical connector.
7. Pull tail lamp assembly clear from vehicle to access
bulbs. Turn bulb sockets counter-clockwise to remove.
MAINTAINING YOUR VEHICLE 279
7

8. Pull the appropriate bulb to remove it from the socket.
9. Replace the bulb, reinstall the socket, and reattach the
tail light assembly.
10. Close the trunk.
280 MAINTAINING YOUR VEHICLE
