fog light CHRYSLER ASPEN 2007 2.G Owners Manual

▫Headlight Delay......................133
▫Automatic Headlights — If Equipped.......133
▫Headlights, Parking Lights, Panel Lights.....134
▫Illuminated Entry.....................134
▫Daytime Running Lights (Canada Only).....134
▫Lights-On Reminder...................135
▫Fog Lights — If Equipped...............135
▫Multifunction Control Lever..............135
Windshield Wipers And Washers............138
▫Windshield Wipers....................138
▫Windshield Washers...................139
Tilt Steering Column....................140
Driver Adjustable Pedals — If Equipped......141▫Adjustment.........................141
Electronic Speed Control — If Equipped......142
▫To Activate..........................143
▫To Set At A Desired Speed...............143
▫To Deactivate........................143
▫To Resume Speed.....................144
▫To Vary The Speed Setting...............144
▫To Accelerate For Passing...............145
Rear Park Assist System — If Equipped.......146
Overhead Console......................150
▫Courtesy/Reading Lights................151
Overhead Console With Electronic Vehicle
Information Center (EVIC) — If Equipped.....151
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 77
3

If the ignition is off and any door is left ajar for eight
minutes or the dimmer control is rotated upwards for 15
minutes, the interior lights will automatically turn off.
If the headlights remain on while the ignition is cycled
off, the exterior lights will automatically turn off after 8
minutes. If the headlights are turned on and left on for 8
minutes while the ignition is off, the exterior lights will
automatically turn off.
NOTE:Battery Saver mode is cancelled if the ignition is
ON.
NOTE:While the engine is running, the system will
deactivate the Fog Lights and Heated seats if a low
battery system voltage is detected.Headlight Delay
To aid in your exit, your vehicle is equipped with a
headlight delay that will leave the headlights on for 90
seconds. This delay is initiated when the ignition is
cycled off while the headlight switch is on, and then the
headlight switch is cycled off. The headlights will remain
on for 90 seconds. Headlight delay can be cancelled by
either turning the headlight switch ON then OFF or by
turning the ignition ON.
NOTE:This feature can be disabled by your authorized
dealer.
Automatic Headlights — If Equipped
Automatic Headlights can be activated by rotating the
rotary headlight switch to the symbol “A.” The head-
lights will turn on when the engine is running and the
ambient light sensor indicates that the headlights should
be activated. The headlights will turn off if the headlight
switch is rotated to the off position or 90 seconds after the
ignition is turned to OFF.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133
3

Lights-on Reminder
If the headlights, parking lights, or courtesy lights are left
On, after the ignition is turned Off, a continuous fast
chime will sound when the driver’s door is opened.
Fog Lights — If Equipped
The fog lights are turned ON by placing the headlight
rotary control in the parking light, headlight, or Auto
position and pressing the fog light button. The fog lights
will operate only when the parking lights are ON or
when the vehicle headlights are ON low beam. An
indicator light located in the instrument cluster will
illuminate when the fog lights are on. The fog lights will
turn off when the switch is pressed in, when the head-
light switch is rotated to the OFF position, or the high
beam is selected.
Multifunction Control Lever
The multifunction control lever is located on the left side
of the steering column.
Turn Signals
Move the lever up or down to signal a right-hand or
left-hand turn.
The arrow on either side of the instrument cluster flashes
to indicate the direction of the turn, and proper operation
Fog Light Switch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135
3

left/right turn signal is left on with the engine RPM
vehicle speed greater than 15 mph (24 km/h) for more
than one mile.
4. Low Fuel Warning Light
This indicator lights when the fuel gauge reads 1/8
of a tank or less.
5. High Beam Indicator
Indicates that headlights are on high beam.
6. Seat Belt Reminder Light
This light comes on for several seconds after the
ignition is turned ON as a reminder to “buckle
up.” This light will remain on as long as the seat
belt remains unbuckled. If this light flashes, it indicates a
fault in the airbag system. Have the system checked by
an authorized dealer.7. Fog Light Indicator
This light shows when the fog lights are ON.
8. Coolant Temperature Light
This light warns of an overheated engine condi-
tion. For a bulb check, this light will come on
momentarily when the ignition is turned On. If the
light turns on while driving, stop the vehicle, shift into N
(Neutral) and increase the engine speed for 2 to 3
minutes. If the temperature reading does not return to
normal, seek authorized service immediately.
188 INSTRUMENT PANEL AND CONTROLS

▫Center High-Mounted Stoplight...........412
▫Fog Lights..........................413
Fluids And Capacities...................414Fluids, Lubricants And Genuine Parts........415
▫Engine.............................415
▫Chassis............................416
MAINTAINING YOUR VEHICLE 361
7

REPLACEMENT LIGHT BULBS
LIGHT BULBS — Interior Bulb No.
Dome Light........................WL212–2
Liftgate Lamp........................... 567
Overhead Console Lights............. PLW214–2A
Reading Light.......................WL212–2
Visor Vanity Lights............... NotServiceable
LIGHT BULBS — Outside Bulb No.
Headlight............................. H13
Front Park/Turn......................3457AK
Back-Up..............................3057
Center High Mounted Stoplight.............. 921
Front Side Marker........................ 168
Fog Lamp...........................9006LL
License Plate Light....................... 168
Rear Tail, Stop, Turn Signal and Side Marker....3057
BULB REPLACEMENT
Headlights/Parking/Turn Signal
1. Remove the two bolts attaching the headlight to the
upper fender reinforcement (hood must be opened to
access bolts).
MAINTAINING YOUR VEHICLE 407
7

Fog Lights
To replace the left foglamp bulb:
1. Remove the three wheel liner screws2. Remove the remove the far left air dam screw at the
bottom of the fascia.
3. Peel back the liner and access the foglamp
4. Rotate the socket and connector 1/4 turn counter-
clockwise and pull straight reward to disengage from the
lamp.
5. Remove the bulb from the socket and replace.
The right foglamp can be accessed from below the
vehicle. Follow the previous steps 4 and 5 of the left
foglamp to replace the bulb.
NOTE:These are Halogen bulbs. Take care not to touch
the bulb with your fingers. Body oils from your fingers
could cause excessive heat build-up, which reduces bulb
life.
1 – (3) Wheel liner screws
2 – (1) Air dam screwMAINTAINING YOUR VEHICLE 4137

Flashers
Hazard Warning....................... 346
Turn Signal.....................135,187,409
Flat Tire Stowage.....................348,354
Flexible Fuel Vehicles
Cruising Range........................ 320
Engine Oil........................... 320
Fuel Requirements..................318,319
Maintenance.......................... 321
Replacement Parts..................... 320
Starting............................. 320
Flooded Engine Starting................... 256
Floor Console.......................172,175
Fluid, Brake.........................387,416
Fluid Capacities......................... 414
Fluid Level Checks
Automatic Transmission................. 389
Brake............................... 387
Engine Oil........................... 368Power Steering........................ 377
Transfer Case......................... 391
Fluids, Lubricants and Genuine Parts.......... 415
Fog Lights..........................135,413
Folding Rear Seat..................... 117,120
Four Wheel Drive....................... 263
Operation........................... 263
Four-Way Hazard Flasher.................. 346
Freeing A Stuck Vehicle................... 288
Front Axle (Differential)................... 392
Fuel................................. 311
Filler Cap (Gas Cap).................... 316
Filter............................... 373
Gauge.............................. 187
Octane Rating...................... 311,415
Requirements...................... 311,414
Tank Capacity........................ 414
Fuel, Flexible.............See Flexible Fuel Vehicles
Fuel System Caution..................... 318
INDEX 455
10

Lane Change and Turn Signals.........135,187,409
Lap/Shoulder Belts.....................39,45
LATCH (Lower Anchors and Tether for CHildren) . 65
Life of Tires............................ 304
Liftgate................................ 34
Lights..............................74,131
Airbag............................59,196
Anti-Lock Warning..................... 190
Automatic Headlights................... 133
Back-Up............................. 409
Brake Warning........................ 193
Bulb Replacement...................... 407
Center Mounted Stop................... 412
Courtesy/Reading..................... 151
Cruise.............................. 196
Daytime Running...................... 134
Dome.............................. 151
Electronic Stability Program (ESP) Indicator . 193,283
Fog ..........................135,188,413Hazard Warning Flasher................. 346
Headlights........................... 134
High Beam........................... 137
High Beam/Low Beam Select............. 137
Instrument Cluster..................134,187
Interior..........................132,151
License............................. 411
Lights On Reminder.................... 135
Low Fuel.........................187,188
Malfunction Indicator (Check Engine)........ 194
Park............................... 134
Passing............................. 137
Reading............................. 151
Seat Belt Reminder..................... 188
Service.............................. 407
Tire Pressure Monitoring (TPMS)........... 195
Traction Control....................... 283
Turn Signal........................135,409
Warning (Instrument Cluster Description)..... 187
458 INDEX
