navigation system CHRYSLER ASPEN 2007 2.G Owners Manual

▫Operating Instructions - Hands Free Phone —
If Equipped.........................207
▫Operating Instructions - Satellite Radio —
If Equipped.........................207
Sales Code RAQ – AM/FM/CD (6-Disc) Radio
With Optional Satellite Radio, Hands Free Phone,
And Vehicle Entertainment Systems (VES)
Capabilities...........................208
▫Operating Instructions - Radio Mode.......208
▫Operation Instructions - (CD Mode For CD
Audio Play).........................213
▫Load/Eject Button (CD Mode For CD
Audio Play).........................215
▫Notes On Playing MP3 Files.............217
▫Operation Instructions - (CD Mode For MP3
Audio Play).........................219▫Load/Eject Button (CD Mode For MP3 Play) . . 219
Sales Code REC — AM/FM/CD (6–Disc) Radio
With Navigation System..................222
▫Operating Instructions — Satellite Radio
(If Equipped)........................222
▫REC Setting The Clock.................222
▫Audio Clock Display...................225
Video Entertainment System (Sales Code XRV) —
If Equipped...........................226
Satellite Radio — If Equipped..............226
▫System Activation.....................226
▫Electronic Serial Number/Sirius Identification
Number (ESN/SID)....................227
▫Selecting Satellite Mode In REF, RAQ, And RAK
Radios.............................228
182 INSTRUMENT PANEL AND CONTROLS

SALES CODE REC — AM/FM/CD (6–DISC) RADIO
WITH NAVIGATION SYSTEM
Satellite Navigation Radio with CD Player with MP3
Capability (REC) - combines a Global-Positioning
System-based navigation system with an integrated color
screen to provide maps, turn identification, selectionmenus and instructions for selecting a variety of destina-
tions and routes, AM/FM stereo radio and six-disc CD
changer with MP3 capability.
Mapping information for navigation is supplied on a
DVD that is loaded into the unit. One map DVD covers
all of North America. Refer to your “Navigation User’s
Manual” for detailed operating instructions.
Operating Instructions — Satellite Radio (If
Equipped)
Refer to your “Navigation User’s Manual” for detailed
operating instructions.
REC Setting the Clock
GPS Clock
The GPS receiver used in this system is synchronized to
the time data being transmitted by the GPS satellites. The
satellites’ clock is Greenwich Mean Time (GMT). This is
REC Radio
222 INSTRUMENT PANEL AND CONTROLS

Electronic Serial Number/Sirius Identification
Number (ESN/SID)
The Electronic Serial Number/Sirius Identification Num-
ber is needed to activate your Sirius Satellite Radio
system. To access the ESN/SID, refer to the following
steps:
ESN/SID Access With REF Radios
With the ignition switch in the ACCESSORY position and
the radio OFF, press the CD Eject and Time buttons
simultaneously for 3 seconds. The first four digits of the
twelve-digit ESN/SID number will display. Press the
SEEK UP button to display the next four digits. Continue
to press the SEEK UP button until all twelve ESN/SID
digits display. The SEEK DOWN will page down until
the first four digits display. The radio will exit the
ESN/SID mode when any other button is pushed, the
ignition is turned OFF, or 5 minutes has passed since any
button was pushed.
ESN/SID Access With RAQ and RAK Radios
With the ignition switch in the ACCESSORY position and
the radio OFF, press the CD Eject and TIME buttons
simultaneously for 3 seconds. All twelve ESN/SID num-
bers will display. The radio will exit the ESN/SID mode
when any other button is pushed, the ignition is turned
OFF, or 5 minutes has passed since any button was
pushed.
ESN/SID Access With REC Navigation Radios
Please refer to your Navigation User’s Manual.
With the ignition in the ACCESSORY position and the
radio off, press the CD Eject and Set buttons simulta-
neously until the 12 digits of the ESN/SID appear on the
screen.
INSTRUMENT PANEL AND CONTROLS 227
4

Mopar Parts.........................366,445
Multi-Displacement Engine System........... 287
Multi-Function Control Lever............... 135
Navigation Radio........................ 222
Navigation System....................... 222
New Vehicle Break-In Period................ 71
Occupant Classification System (OCS).......... 55
Occupant Restraints....................... 38
Octane Rating, Gasoline (Fuel).............. 311
Oil, Engine.........................368,415
Capacity............................ 414
Change Interval....................... 369
Dipstick............................. 368
Disposal............................ 371
Filter............................371,415
Filter Disposal........................ 371
Identification Logo..................... 370Materials Added to..................... 371
Recommendation...................370,414
Synthetic............................ 371
Viscosity..........................370,414
Onboard Diagnostic System..............364,365
Opener, Garage Door (HomeLink) ........... 160
Outside Rearview Mirrors.................. 81
Overdrive..........................191,261
Overdrive OFF Switch.................... 261
Overhead Console....................150,151
Overheating, Engine...................... 189
Owner’s Manual (Operator Manual).......... 446
Panic Alarm............................ 22
Parking Brake.......................... 273
Parking On Hill......................... 273
Passing Light........................... 137
Pedals, Adjustable....................... 141
Personal Settings........................ 155
460 INDEX

Pets.................................. 71
Pets, Transporting........................ 71
Phone, Cellular.......................... 83
Phone, Hands-Free (UConnect™)............. 83
Placard, Tire and Loading Information......... 293
Positive Crankcase Valve.................. 387
Power
Brakes.............................. 387
Distribution Center (Fuses)..........362,363,401
Door Locks.........................19,28
Lift Gate............................. 35
Mirrors.............................. 81
Outlet (Auxiliary Electrical Outlet).......169,170
Steering..........................277,377
Steering Filler Cap..................362,363
Sunroof............................. 167
Windows............................. 31
Power Steering Fluid..................... 416
Pregnant Women and Seat Belts.............. 50Preparation for Jacking.................... 350
Pretensioners
Seat Belts............................. 48
Programmable Electronic Features......155,162,165
Programming Transmitters
(Remote Keyless Entry)...............23,162,165
Radial Ply Tires......................... 300
Radiator Cap (Coolant Pressure Cap).......381,383
Radio Broadcast Signals................... 198
Radio, Navigation....................... 222
Radio Operation...................200,208,232
Radio, Satellite.......................222,226
Radio (Sound Systems).................200,208
Rear Axle (Differential).................... 392
Rear Cup Holder........................ 175
Rear Liftgate............................ 34
Rear Window Defroster................... 250
Rear Window Features.................... 249
INDEX 461
10

Speedometer........................... 189
Starting............................... 255
Automatic Transmission................. 255
Emergency (Jump Starting)............... 354
Engine Block Heater.................... 257
Engine Fails to Start.................... 256
Remote.............................. 25
Starting Procedures...................... 255
Steering
Column Controls...................... 135
Column Lock.......................... 13
Power...........................277,377
Wheel, Tilt........................... 140
Steering Wheel Mounted Sound System Controls . 230
Storage, Vehicle......................... 406
Stuck, Freeing.......................... 288
Sun Roof.............................. 167
Supplemental Tire Pressure Information........ 306
Synthetic Engine Oil...................... 371System, Navigation...................... 222
System, Remote Starting.................... 25
Tachometer............................ 190
Taillights.............................. 409
Temperature Control, Automatic (ATC)........ 238
Temperature Gauge, Engine Coolant.......... 187
Tether Anchor, Child Restraint............... 65
Theft System Arming...................... 18
Theft System Disarming.................... 18
Tilt Steering Column..................... 140
Tire and Loading Information Placard......293,306
Tire Identification Number (TIN)............. 292
Tire Markings.......................... 288
Tire Safety Information.................... 288
Tires ...............................73,297
Aging (Life of Tires).................... 304
Air Pressure.......................... 297
Alignment........................... 305
464 INDEX
