windshield wipers CHRYSLER ASPEN 2007 2.G Owners Manual

▫Headlight Delay......................133
▫Automatic Headlights — If Equipped.......133
▫Headlights, Parking Lights, Panel Lights.....134
▫Illuminated Entry.....................134
▫Daytime Running Lights (Canada Only).....134
▫Lights-On Reminder...................135
▫Fog Lights — If Equipped...............135
▫Multifunction Control Lever..............135
Windshield Wipers And Washers............138
▫Windshield Wipers....................138
▫Windshield Washers...................139
Tilt Steering Column....................140
Driver Adjustable Pedals — If Equipped......141▫Adjustment.........................141
Electronic Speed Control — If Equipped......142
▫To Activate..........................143
▫To Set At A Desired Speed...............143
▫To Deactivate........................143
▫To Resume Speed.....................144
▫To Vary The Speed Setting...............144
▫To Accelerate For Passing...............145
Rear Park Assist System — If Equipped.......146
Overhead Console......................150
▫Courtesy/Reading Lights................151
Overhead Console With Electronic Vehicle
Information Center (EVIC) — If Equipped.....151
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 77
3

WINDSHIELD WIPERS AND WASHERS
Windshield Wipers
The wipers and washers are operated by a switch in the
multifunction control lever. Turn the end of the handle to
select the desired wiper speed.
Intermittent Wiper System
The intermittent feature of this system was designed for
use when weather conditions make a single wiping cycle,
with a variable pause between cycles, desirable. For
maximum delay between cycles, rotate the control knob
into the upper end of the delay range.
The delay interval decreases as you rotate the knob until
it enters the LO continual speed position. The delay can
be regulated from a maximum of about 15 seconds
between cycles, to a cycle every 2 seconds. The delay
intervals will double in duration when the vehicle speed
is 10 mph (16 km) or less.
WARNING!
Sudden loss of visibility through the windshield could
lead to an accident. You might not see other vehicles or
other obstacles. To avoid sudden icing of the windshield
during freezing weather, warm the windshield with
defroster before and during windshield washer use.Windshield Wiper Switch
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

NOTE:Avoid using the wiper blades to remove frost or
Ice from the windshield.
NOTE:If the front wiper is operating when the ignition
is turned off, the wiper will automatically return to the
Parkposition. When the vehicle is restarted, the wipers
will resume operation.
Windshield Washers
To use the washer, push in on the washer knob on the end
of the multifunction control lever and hold while spray is
desired. If the washer knob is depressed while in the
delay range, the wiper will operate for several seconds
after the washer knob is released. It will then resume the
intermittent interval previously selected. If the washer
knob is pushed, for a period greater than 1 second, while
in the OFF position, the wiper will wipe approximately
three wipes, after the wash knob is released.To prevent freeze-up of your windshield washer system
in cold weather, select a solution or mixture that meets or
exceeds the temperature range of your climate. This
rating information can be found on most washer fluid
containers.
Washer Fluid Switch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139
3

Drive Shaft Constant Velocity Joints
All four wheel drive models are equipped with four
constant velocity joints. Periodic lubrication of these
joints is not required. However, the joint boot should be
inspected for external leakage or damage periodically. If
external leakage or damage is evident, the joint boot and
grease should be replaced immediately. Continued op-
eration could result in failure of the joint due to water
and dirt contamination of the grease. This would require
complete replacement of the joint assembly. Refer to the
Service Manual for the detailed replacement procedure.
Body Lubrication
Locks and all body pivot points, including such items as
seat tracks, doors,liftgate and hood hinges, should be
lubricated periodically to assure quiet, easy operation
and to protect against rust and wear. Prior to the appli-
cation of any lubricant, the parts concerned should be
wiped clean to remove dust and grit; after lubricating
excess oil and grease should be removed. Particularattention should also be given to hood latching compo-
nents to insure proper function. When performing other
underhood services, the hood latch, release mechanism
and safety catch should be cleaned and lubricated.
The external lock cylinders should be lubricated twice a
year, preferably in the fall and spring. Apply a small
amount of a high quality lubricant such as MoparLock
Cylinder Lubricant directly into the lock cylinder.
Windshield Wiper Blades
The rubber edges of the wiper blades and the windshield
should be cleaned periodically with a sponge or soft cloth
and a mild nonabrasive cleaner. This will remove accu-
mulations of salt or road film.
Operation of the wipers on dry glass for long periods
may cause deterioration of the wiper blades. Always use
washer fluid when using the wipers to remove salt or dirt
from a dry windshield.
378 MAINTAINING YOUR VEHICLE

Pressure Cap......................... 383
Radiator Cap......................... 383
Selection of Coolant (Antifreeze)......382,414,415
Temperature Gauge..................... 187
Cruise Control (Speed Control).............. 142
Cup Holder............................ 173
Customer Assistance..................... 442
Data Recorder, Event...................... 60
Daytime Running Lights................... 134
Dealer Service.......................... 367
Defroster, Rear Window................... 250
Defroster, Windshield..........73,235,236,241,242
Delay (Intermittent) Wipers................. 138
Diagnostic System, Onboard................ 364
Dimmer Switch, Headlight................. 188
Dipsticks
Automatic Transmission................. 389
Oil (Engine).......................... 368Power Steering........................ 377
Disarming, Theft System................... 18
Disc Brakes............................ 387
Disposal
Antifreeze (Engine Coolant)............... 384
Door Locks............................. 27
Door Opener, Garage..................... 160
Drive Belts............................ 372
Drive Shaft Universal Joints................ 378
DVD Player (Video Entertainment System)...... 226
E-85 Fuel............................. 318
Electric Remote Mirrors.................... 81
Electrical Power Outlets................... 169
Electronic Brake Control System............. 279
Electronic Speed Control (Cruise Control)...... 142
Electronic Stability Program (ESP).........193,283
Electronic Vehicle Information Center (EVIC).... 152
INDEX 453
10

Washer, Adding Fluid..................362,363
Washers, Windshield..................... 139
Washing Vehicle......................... 393
Weight Load Carrying.................... 321
Wheel Alignment and Balance............... 305
Wheel and Wheel Trim.................... 395
Wheel and Wheel Trim Care................ 395
Wheel Changing........................ 348
Wheel Mounting........................ 349
Wheel Nut Torque....................... 352
Wind Buffeting......................... 168
Window Fogging........................ 246
Windows.............................. 31
Power............................... 31Windshield Defroster..................235,241
Windshield Washers................138,139,379
Fluid.......................138,362,363,379
Windshield Wiper Blades.................. 378
Windshield Wipers....................... 138
Wiper Blade Replacement.................. 378
Wiper, Rear............................ 249
Wipers, Intermittent...................... 138
Wrecker Towing......................... 357
YES EssentialsFabric Cleaning Procedure...... 395
INDEX 467
10
