engine CHRYSLER ASPEN HYBRID 2007 2.G Warranty Booklet

2007 Chrysler Aspen
8
5/100 POWERTR aiN W aRR aNTY
The following powertrain components are covered for 5 years or
100,000 kilometres, whichever occurs first, measured from the
vehicle’s original warranty start date.
Vehicles placed in police, taxi, limousine, postal or ambulance
service and all SRT vehicles , are excluded from the 5-year or
100,000-kilometre Powertrain Warranty and are covered only under
the 3-year or 60,000-kilometre Basic Warranty.
•
Engine – Cylinder block and all internal parts; cylinder head
assemblies; timing case, timing chain, timing belt, gears and
sprockets; vibration damper; oil pump; water pump and housing;
intake and exhaust manifolds; flywheel with starter ring gear; core
plugs; valve covers; oil pan; turbocharger housing and internal
parts; turbocharger wastegate actuator; supercharger; serpentine
belt tensioner; seals and gaskets for listed components only.
• Transmission – Transmission case and all internal parts;
torque converter; drive/flex plate; transmission range switch;
transmission control module; bell housing; oil pan; seals and
gaskets for listed components only.
Note: Manual transmission clutch parts are not covered at any time.
• Rear-Wheel Drive – Rear axle housing and all internal parts; axle
shafts; axle shaft bearings; driveshaft assemblies; driveshaft centre
bearings; universal joints and yokes; seals and gaskets for listed
components only.
• 4-Wheel Drive (4x4) – Transfer case and all internal parts;
transfer case control module and shift mode motor assembly;
axle housing and all internal parts; axle shafts; axle shaft bearings;
driveshaft assemblies (front and rear); driveshaft centre bearings;
universal joints and yokes; disconnect housing assembly; seals
and gaskets for the listed components.
5/100 POWERTRAIN WARRANTY

2007 Chrysler Aspen
11
EmISSION DEfECT WARRANTY / EmISSION PERfORmANCE W ARRANTY
EM iSS iON dE fECT Wa RRaNTY
T h e 3 / 6 0 B a s i c Wa r r a n t y c o v e r s a l l e m i s s i o n c o n t r o l
components for 3 years or 60,000 kilometres, whichever occurs
first. The Emission Defect Warranty provides longer coverage for
specified components.
light-duty trucks
For light-duty trucks, the Defect Warranty covers the following
major emission control parts, if so equipped, for 8 years or 130,000
kilometres, whichever occurs first:
• catalytic converter
• powertrain control module
heavy-duty trucks
Heavy-duty trucks are trucks over 45 6 kg (10,000 lb) GVW,
designated by an “M” in the fourth position of the Vehicle
Identification Number (VIN), or any truck equipped with a heavy-
duty gasoline or diesel engine, designated by a “5,” “6,” “7” or “W” in
the eighth position of the VIN.
For heavy-duty trucks, the Defect Warranty covers the following
parts, if so equipped, for 5 years or 80,000 kilometres, whichever
occurs first:
• air system controls • onboard diagnostic system
• catalytic converter components

• distributor and components • oxygen sensors

• electronic fuel injection • PCV valve or orifice

system and injectors • powertrain control module

• evaporative-emission canister • secondary ignition wires

and controls • spark plugs

• exhaust manifold • throttle body

• EGR valve and control system • transmission control module

• exhaust pipes (exhaust manifold • vacuum hoses, clamps, fittings

to catalyst) and tubing used for these
• fuel cap and tank assembly, components

pump and fuel lines • vacuum, temperature, altitude,

• ignition coil and module
speed, and time-sensitive sensors,
• intake manifold valves and switches used in these

components and systems

2007 Chrysler Aspen
1
W ha T iS NOT COVERE d
damage frOm misuse Or accident
The warranties in this booklet do not cover repairs required due
to fire, accidents, abuse, negligence, objects striking your vehicle,
carrying corrosive materials (such as chemicals, acids and fertilizers),
misuse (such as driving over curbs, overloading, spinning wheels,
etc.), racing or participating in a racing event, improper discon -
nection of components, modifying the exhaust system, tampering
or making adjustments which do not comply with DaimlerChrysler
specifications.
Disconnecting, tampering with or changing the reading of the
odometer will void your warranties.
damage frOm the envirOnment
The warranties in this booklet do not cover fading or deterioration
caused by exposure to the elements, or repairs required due to
airborne fallout, acid rain, chemicals, tree sap, insects, bird or
insect droppings, salt, sand, gravel, road hazards, hail, win dstorms,
lightning, floods or any other event of nature.
Road salt, car washes, scuffs and scratches, and everyday abrasion
from sand and dirt can affect the appearance of a vehicle’s wheels
(steel, chrome and aluminum) and other undercarriage parts. Some
surface corrosion with use is normal; it is not a defect and is not
covered by any warranty.
nOrmal maintenance and Wear
The warranties in this booklet do not cover normal mai ntenance
services, such as oil and filter changes, general lubrication, tire
rotation, engine tune-ups and replacing spark plugs. Required
maintenance services are described in detail in your Owner’s
Manual and herein. The warranties also do not cover worn
wiper blades, clutch discs, brake rotors, pads, linings or drums,
windshield and rear window, wheel alignment and wheel balancing
(unless they are defective, see page 7).
WHAT IS NOT COVERED

2007 Chrysler Aspen17
OTHER THINGS YOU SHOULD kNOW
OTh ER T hi NgS YOU S h OUL d kNOW
OptiOnal service cOntract
DaimlerChrysler Canada has a service contract specially designed
for most new vehicles, to cover repair costs beyond your vehicle’s
warranty. Protection is available for almost every operating part of
your vehicle, and at reasonable cost.
DaimlerChrysler Canada stands fully behind its service
contracts. Be sure that the contract you buy is a genuine
DaimlerChrysler Service Contract. We are not responsible for
other companies’ contracts. See page 26 for details on available
service contracts.
appearance items
Defects or damage to sheet metal, paint, trim and other appearance
items are normally found and corrected during new vehicle
inspection. For your protection, if you find any such defect or
damage, you should tell your selling retailer immediately, because
if the problem worsens due to use and exposure, repairs will not be
covered by any warranty.
prOductiOn changes
DaimlerChrysler Canada and its retailers reserve the right to make
changes in vehicles built and/or sold at any time without i ncu rring
any obligations to make the same or similar changes on vehicles
which were built and/or sold previously.
exchange parts
To reduce the amount of time your vehicle is out of service due
to repairs, DaimlerChrysler may offer exchange service on some
parts. Mopar® or Autopar® brand exchange parts may be new,
remanufactured, reconditioned or repaired, but all meet
DaimlerChrysler standards and are warranted the same as new parts.
Examples of parts that may be serviced by exchange include engines,
transmissions, instrument clusters, radios, tape and CD players,
speedometers and various electronic modules.

2007 Chrysler Aspen
1. pOWertrain plans*
Powertrain plans complement the factory powertrain warranty by
providing enhanced roadside coverage and car rental allowance if
your vehicle is not drivable and must be kept overnight. Certain
plans also provide additional distance coverage.
Major components covered are:
• engine • transmission • front-wheel drive • rear-wheel drive
• 4-wheel drive (4x4) • all-wheel drive vehicles
2. “gOld” plans*
Each plan provides full mechanical repair protection to non-powertrain
(Gold) components. Certain plans also provide full mechanical
protection against powertrain component repairs beyond your vehicle’s
Powertrain Warranty coverage. Contracts are available with or without
a deductible.
Major components covered are:
• steering • air conditioning • engine cooling and fuel • front
suspension • rear suspension • electrical • hydraulic brake
components • anti-lock brakes
*Maximum terms available on new vehicles registered in Canada only.
3. “gOld plus” plans*
The most complete protection available for your new vehicle is a
“Gold Plus” Service Contract which combines the benefits of Gold
component coverage (see “Gold” Plans), plus, the most important
vehicle maintenance functions:
• Engine oil and oil filter changes
• Tire rotation every other service
• “Peace of Mind” motoring with Tire Road Hazard
Protection which provides full, or pro-rata, replacement
of the original four tires, or their repair
•
Rental car allowance for same-day warranty repairs – your
vehicle need not be kept overnight before eligibility for the
rental allowance is met
26
OPTIONAL DAImLERCHRYSLER CANADA SERVICE CONTRACTS

MAINTENANCE Scheduled maintenance must be completed to provide the best vehicle performance and reliability. The limited warranties in the warranty booklet DO NOT COVER repairs required due to improper maintenance. We strongly suggest you keep track of scheduled maintenance and keep receipts or other documents. Use only recommended Mopar lubricants and genuine Mopar parts. In the event that a condition arises between maintenance intervals, please contact your retailer. AVOID
P RO lONGED PERIODS Of I DlING .
NOTE:
WHERE TIME (MONTHS) AND METRAGE ARE INDICATED, FOLLOW THE INTERVAL THAT OCCURS FIRST.
AT EACH STOP FOR FUEL
•
Check the engine oil level about 5 minutes
after a fully warmed engine is shut off. Checking the oil level while the vehicle is on level ground will improve the accuracy of the oil level reading. Add oil only when the level is at or below the ADD or MIN mark.
•
Check the windshield washer solvent and
add if required.
ONCE A MONTH
•
Check the tire pressure and look for unusual
wear or damage.
•
Inspect the battery and clean and tighten the
terminals as required.
•
Check the fluid levels of coolant reservoir,
brake master cylinder and transmission and add as needed.
•
Check all the lights and all other electrical
items for correct operation.
•
Check and clean wiper blades. Replace if
required.
VISUA l INSPECTIONS –
INSPECT fOR SIGNS O f COMPONENT DETERIORATION
AND PHYSICA l DAMAGE.
There are two maintenance schedules contained in your Owner’s Manual. Schedule “B” best describes operating conditions in Canada and
is the recommended service schedule. for
your convenience, the scheduled maintenance intervals outlined in this booklet follow the Severe Service Schedule as described in your Owner’s Manual. Schedule “B” is for vehicles that are operated under one or more of the following conditions: day or night temperatures
below 0°C (32° f); stop-and-go driving; extensive
engine idling; driving in dusty conditions; short trips of less than 16 km (10 mi.); more than
50% of your driving is at sustained high speeds
during hot weather, above 32°C (90° f); trailer
towing; heavy loading; snowploughing; taxi, police, or delivery service (commercial service); off-road or desert driving; if equipped for and operating with E-85 (ethanol) fuel. Schedule “A” is for vehicles that are not operated under any of the conditions listed under Schedule “B.”The performance of all scheduled service work is required to maintain your vehicle in good operating condition. DaimlerChrysler Canada Inc. reserves the right to deny warranty coverage if the vehicle has not been properly maintained. While we do not insist that such work be performed by factory-authorized retailers, we strongly recommend that an authorized Chrysler, Jeep® or Dodge Retailer perform this work.
INTRODUCTION

2007 Chrysler Aspen
Maintenance Service
Schedule “B”
Odometer Reading
Date
Retailer copy. Remove and attach to Repair Order 26-93-01-01 3N.
5000 km
Maintenance Service Schedule “B”
5000 km
l
Change engine oil and engine oil filter (or every  months, whichever occurs first).
iNSPECT T hE fOLLOW iN g:
l
Inspect the exhaust system.l
Inspect the brake hoses.l
Inspect the CV joints (if equipped) and front suspension components.l
Check the automatic transmission fluid level.l
Check the coolant level, hoses and clamps.

2007 Chrysler Aspen

Odometer Reading
Date
Repair Order No.
DaimlerChrysler
r
etailer stamp
Signature of authorized DaimlerChrysler Canada Retailer
Maintenance Service Schedule “B”
5000 km
l
Change engine oil and engine oil filter
(or every  months, whichever occurs first).
i NSPECT T hE fOLLOW iN g:
l
Inspect the exhaust system.
l
Inspect the brake hoses.
l
Inspect the CV joints (if equipped) and front suspension components.
l
Check the automatic transmission fluid level.
l
Check the coolant level, hoses and clamps.

2007 Chrysler Aspen

Maintenance Service
Schedule “B”
Odometer Reading
Date
Retailer copy. Remove and attach to Repair Order 26-93-02-01 3N.
10,000 km
Maintenance Service Schedule “B”
10,000 km
l
Change engine oil and engine oil filter (or every  months, whichever occurs first).l Rotate tires and check tire pressure.l Check spare tire for proper pressure and correct stowage.
iNSPECT T hE fOLLOW iN g:
l
Inspect the exhaust system.l
Inspect the brake hoses.l
Inspect the CV joints (if equipped) and front suspension components.l
Check the automatic transmission fluid level.l
Check the coolant level, hoses and clamps.

2007 Chrysler Aspen

Odometer Reading
Date
Repair Order No.
DaimlerChrysler
r
etailer stamp
Signature of authorized DaimlerChrysler Canada Retailer
l
Change engine oil and engine oil filter
(or every  months, whichever occurs first).
l Rotate tires and check tire pressure.
l Check spare tire for proper pressure and correct stowage.
i NSPECT T hE fOLLOW iN g:
l
Inspect the exhaust system.
l
Inspect the brake hoses.
l
Inspect the CV joints (if equipped) and front suspension components.
l
Check the automatic transmission fluid level.
l
Check the coolant level, hoses and clamps.
Maintenance Service Schedule “B”
10,000 km
