automatic transmission fluid CHRYSLER ASPEN HYBRID 2008 2.G Warranty Booklet

❏Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ Inspect the brake linings, replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.
❏ Inspect the front suspension, tie rod ends and boot seals, replace if necessary.
❏ Replace the engine air cleaner filter.
❏ Inspect the transfer case fluid.
❏ Replace the top row of spark plugs on 4.7L engines. **
❏ Replace the spark plugs on 3.7L and 5.7L engines.
❏ Change the transfer case fluid if using your vehicle for any of the following:
police, taxi, fleet, off-road or frequent trailer towing.
❏ Change the manual transmission fluid if using your vehicle for any of the fol-
lowing: trailer towing, snowplowing, heavy loading, taxi, police, delivery ser-
vice (commercial service), off-road, desert operation or more then 50% of your
driving is at sustained high speeds during hot weather, above 32C°.
❏ Drain and refill automatic transmission fluid, change filter (3.7L engines).
❏ Drain and refill automatic transmission fluid and change main sump filter and
spin-on cooler return filter (4.7L/5.7L engines only).
❏ Replace accessory drive belt(s).
** Vehicles built with the 4.7L engine are equipped with sixteen spark plugs, one
set is located on the top of the engine under the coils and the second set is lo-
cated on the side of the engine. The spark plugs located under the coils are a stan-
dard plug and must be change every 50,000 kilometres. The spark plugs located
on the side of the engine are a premium plug and must be changed every
170,000 kilometres.
Perform Maintenance Every
200,000 km or 120 Months
Odometer Reading
Date
Repair Order No.
DAIMLERCHRYSLER
RETAILERSTAMP
Signature of authorized DaimlerChrysler Canada Retailer
................................................................................................

Perform Maintenance Every
200,000 km or 120 Months
❏ Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ Inspect the brake linings, replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.
❏ Inspect the front suspension, tie rod ends and boot seals, replace if necessary.
❏ Replace the engine air cleaner filter.
❏ Inspect the transfer case fluid.
❏ Replace the top row of spark plugs on 4.7L engines. **
❏ Replace the spark plugs on 3.7L and 5.7L engines.
❏ Change the transfer case fluid if using your vehicle for any of the following: police, taxi, fleet, off-road
or frequent trailer towing.
❏ Change the manual transmission fluid if using your vehicle for any of the following: trailer towing,
snowplowing, heavy loading, taxi, police, delivery service (commercial service), off-road, desert
operation or more then 50% of your driving is at sustained high speeds during hot weather, above 32C°.
❏ Drain and refill automatic transmission fluid, change filter (3.7L engines).
❏ Drain and refill automatic transmission fluid and change main sump filter and spin-on cooler return filter
(4.7L/5.7L engines only).
❏ Replace accessory drive belt(s).
** Vehicles built with the 4.7L engine are equipped with sixteen spark plugs, one set is located on the top of the
engine under the coils and the second set is located on the side of the engine. The spark plugs located under the
coils are a standard plug and must be change every 50,000 kilometres. The spark plugs located on the side of the
engine are a premium plug and must be changed every 170,000 kilometres.
Perform Maintenance
Every
120 Months or
200,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

❏Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ Inspect the brake linings, replace if necessary.
❏ Replace the engine air cleaner filter.
❏ Inspect the transfer case fluid.
❏ Replace the top row of spark plugs on 4.7L engines. **
❏ Replace the spark plugs on 3.7L and 5.7L engines.
❏ Change the automatic transmission fluid and main sump filter, if using your
vehicle for any of the following: police, taxi, fleet, snow plowing, or frequent
trailer towing (3.7L, 4.7L, and 5.7L engines only).
❏ Change the transfer case fluid if using your vehicle for any of the following:
police, taxi, fleet, off-road or frequent trailer towing.
❏ Change the manual transmission fluid if using your vehicle for any of the fol-
lowing: trailer towing, snowplowing, heavy loading, taxi, police, delivery ser-
vice (commercial service), off-road, desert operation or more then 50% of your
driving is at sustained high speeds during hot weather, above 32C°.
** Vehicles built with the 4.7L engine are equipped with sixteen spark plugs, one
set is located on the top of the engine under the coils and the second set is lo-
cated on the side of the engine. The spark plugs located under the coils are a stan-
dard plug and must be change every 50,000 kilometres. The spark plugs located
on the side of the engine are a premium plug and must be changed every
170,000 kilometres.
Perform Maintenance Every
100,000 km or 60 Months
Odometer Reading
Date
Repair Order No.
DAIMLERCHRYSLER
RETAILERSTAMP
Signature of authorized DaimlerChrysler Canada Retailer
................................................................................................

Perform Maintenance Every
100,000 km or 60 Months
❏ Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ Inspect the brake linings, replace if necessary.
❏ Replace the engine air cleaner filter.
❏ Inspect the transfer case fluid.
❏ Replace the top row of spark plugs on 4.7L engines. **
❏ Replace the spark plugs on 3.7L and 5.7L engines.
❏ Change the automatic transmission fluid and main sump filter, if using your vehicle for any of
the following: police, taxi, fleet, snow plowing, or frequent trailer towing (3.7L, 4.7L, and 5.7L
engines only).
❏ Change the transfer case fluid if using your vehicle for any of the following: police, taxi, fleet,
off-road or frequent trailer towing.
❏ Change the manual transmission fluid if using your vehicle for any of the following: trailer
towing, snowplowing, heavy loading, taxi, police, delivery service (commercial service),
off-road, desert operation or more then 50% of your driving is at sustained high speeds during
hot weather, above 32C°.
** Vehicles built with the 4.7L engine are equipped with sixteen spark plugs, one set is located on the top of the
engine under the coils and the second set is located on the side of the engine. The spark plugs located under the
coils are a standard plug and must be change every 50,000 kilometres. The spark plugs located on the side of the
engine are a premium plug and must be changed every 170,000 kilometres.
Perform Maintenance
Every
60 Months or
100,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................
