CHRYSLER CROSSFIRE 2005 1.G Owners Manual

SPECIFICATIONS
Engine Specifications
Engine Size 195.2 CID (3.2 Liters)
Mode of Operation 4–stroke engine, gasoline
injection
No. of Cylinders 6
Horsepower (SAE J 1349) 215 hp (160 kW) @ 5700
rpm
Bore 3.54 in. (89.90 mm)
Stroke 3.30 in. (84.00 mm)
Torque (SAE J 1349) 229 ft. lbs. (310 N·m) @
3000 rpm
Firing Order 1–4–3–6–2–5
Compression Ratio 10:1
Spark Plugs Bosch F 8 DPER/ NGK
PFR 5–11
Spark Plug Gap 0.039 in. (1.0 mm)
Tightening Torque 15-22 ft. lbs. (20-30 N·m)
Maximum Engine Speed 6000 rpm
Accessory Drive Belt 94.1 in. (2390 mm)Performance Specifications (approximate)
Maximum Speed 150 mph (242 km/h)
Acceleration 0–60 mph 6.5 seconds
1/4 mile time 14.9 seconds at 96 mph
(154 km/h)
Gear Ratios - 6-Speed Manual Transmission
First 4.459
Second 2.614
Third 1.723
Fourth 1.245
Fifth 1.000
Sixth 0.838
Reverse 4.062
Gear Ratios - 5-Speed Automatic Transmission
First 3.95
Second 2.423
Third 1.486
Fourth 1.00
Fifth 0.833
Reverse 3.147/1.93
MAINTAINING YOUR VEHICLE 241
7

Body Specifications
Overall Length 159.8 in. (4058 mm)
Maximum Width 69.5 in. (1766 mm)
Maximum Width With
Mirrors76.9 in. (1954 mm)
Overall Height
Coupe: 51.5 in. (1307 mm)
Roadster: 51.8 in. (1315 mm)
Front Track 58.8 in. (1493 mm)
Rear Track 59.1 in. (1502 mm)
Wheelbase 94.5 in. (2400 mm)
Front Overhang 32.4 in. (822 mm)
Rear Overhang 32.9 in. (836 mm)
Front Ground Clearance 5.0 in. (127 mm)
Rear Ground Clearance 5.8 in. (147 mm)
Turning Radius 32.2 ft. (9.8 m)
Weight
Coupe: 3061 lbs. (1388 kg)
Roadster: 3140 lbs. (1424 kg)
Maximum Vehicle Load 415 lbs. (188 kg)
Luggage Capacity
Coupe: 7.7 cu. ft. (215 l)
Roadster: 6.5 cu. ft. (190 l) - Top Up
3.6 cu. ft. (104 l) - Top
Down
242 MAINTAINING YOUR VEHICLE

FLUID CAPACITIES
U.S. Metric
Fuel (Approximate)15.8 Gallons 60.0 Liters
Fuel Tank Reserve2.1 Gallons 8.0 Liters
Engine Oil (with filter)
3.2 L Engine 8.5 Qts. 8.0 Liters
Cooling System *
3.2 L Engine 11.8 Qts. 11.2 Liters
Manual Transmission1.9 Qts. 1.8 Liters
Automatic Transmission8.5 Qts. 8.0 Liters
Rear Axle1.4 Qts. 1.3 Liters
Power Steering Reservoir1.1 Qts. 1.0 Liters
Brake Reservoir.5 Qts. .5 Liters
Windshield Washer Reservoir
(MAX fill when empty)7.4 Qts. 7.0 Liters
* Includes heater and coolant recovery bottle filled to MAX level.
MAINTAINING YOUR VEHICLE 243
7

RECOMMENDED FLUIDS, LUBRICANTS AND GENUINE PARTS
Engine
Component Fluids, Lubricants and Genuine Parts
Engine Coolant Use coolant approved to MB 325.0, such as Valvoline GO5, or an equivalent
extended life coolant.
Engine Oil Only use synthetic engine oils, approved to MB 229.3 or MB 229.5, such as
Mobil 1 SAE 0W-40. The FSS may not alert for an oil change at the proper
interval if an unapproved engine oil is used; engine damage and reduced
engine life may result.
Engine Oil Filter Mopar5102905AA or equivalent
Spark Plugs Bosch F 8 DPER/NGK PFR 5-11
Spark Plug Gap 0.039 in (1.0 mm)
Fuel Selection Premium Unleaded 91 Octane
244 MAINTAINING YOUR VEHICLE

Chassis
Component Fluids, Lubricants and Genuine Parts
Automatic Transmission Only use ATF approved to MB 236.10, MB 236.12. Synthetic Dexron III
Transmission Fluid may be substituted.
Brake Master Cylinder Use brake fluid approved to MB 331.0, or a DOT 4 brake fluid with:
minimum dry boiling point (ERBP) 500°F (260°C), minimum wet boiling
point (WERBP) 356°F (180°C), maximum viscosity 1500 mm
2/s,
conforming to FMVSS 116 and ISO 4925.
Clutch Fluid Use brake fluid approved to MB 331.0, or a DOT 4 brake fluid with:
minimum dry boiling point (ERBP) 500°F (260°C), minimum wet boiling
point (WERBP) 356°F (180°C), maximum viscosity 1500 mm
2/s,
conforming to FMVSS 116 and ISO 4925.
Manual Transmission Fluid No fluid service required. Only use fluid approved to MB 236.2. SAE
5W-20 engine oil, meeting API SL or GF-3, may be substituted.
Power Steering Reservoir No fluid service required. Filled at the factory with Pentosin CHF 11S.
Steering noise and reduced component life may result if an unapproved
fluid is used.
Rear Axle Fluid Only use synthetic SAE 75W-85 axle lubricant that meets MB 231.1.
Reduced axle durability may result if an unapproved product is used.
Tire Pressure Refer to label on driver’s door frame.
MAINTAINING YOUR VEHICLE 245
7

Body
Component Fluids, Lubricants and Genuine Parts
Hinges:
Door MoparSpray White Lube
Liftgate / Decklid MoparMulti-Purpose Lube NLGI Grade 2 EP, GC-LB
Hood Springs and Links MoparSpray White Lube
Latches:
Liftgate/Decklid MoparSpray White Lube
Hood/Safety Catch MoparMulti-Purpose Lube NLGI Grade 2 EP, GC-LB
Door MoparSpray White Lube
Seat Regulator and Track MoparMulti-Purpose Lube NLGI Grade 2 EP, GC-LB
Window System Components MoparSpray White Lube
Lock Cylinders MoparLock Cylinder Lube
Spoiler MoparSpray White Lube
246 MAINTAINING YOUR VEHICLE

MAINTENANCE SCHEDULES
CONTENTS

Introduction..........................248

Warranty............................248

Emission Control System Maintenance......249

Maintenance Schedules..................249
▫Scope Of Work For “A” Schedule Maintenance
Service.............................250
▫Scope Of Work For “B” Schedule Maintenance
Service.............................251

FSS System...........................252

Regular Check-Ups.....................254
▫Additional Periodic Maintenance..........255

Special Maintenance Requirements.........256
▫Coolant............................256
▫Dust Filter For Heating/Ventilation
Replacement.........................256

Engine Oil Change And Filter Replacement...2568
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

INTRODUCTION
This is intended as a guide to the service requirements of
your vehicle.
It contains all necessary instructions concerning service
intervals and operations which have to be carried out.
Scope and frequency of maintenance work primarily
depend on the vehicle’s operating conditions. In the
interest of maintaining the vehicle’s operating safety, the
specified work should be performed regularly and in
good time.
Our vehicles are subject to ongoing development. Tech-
nical progress may also affect the scope of service work
performed.
“Daily vehicle checks” before starting a journey are the
responsibility of the driver.
WARRANTY
The DaimlerChrysler Corporation Dealer network is at
your disposal for maintenance work. Each of these work-
shops has the equipment and tools, the specially trained,
skilled and experienced personnel and receives regular
technical instruction from DaimlerChrysler Corporation
to ensure that your vehicle is inspected and maintained
thoroughly and in accordance with the latest procedures.
Please follow the instructions given in this Owner’s
Manual and ensure that they are observed, even if you
hand the vehicle over to a third party for use or care. By
not observing these instructions you may void your
warranty rights.
If the specified oil and maintenance services are not
carried out regularly or at the time intervals specified, a
decision as to the validity of a warranty claim can only be
made after DaimlerChrysler Corporation has investi-
gated your claim.
248 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

The use of Special lubricant additives is not recom-
mended. The use of such additives may affect your
warranty rights. With regard to legal stipulations con-
cerning emissions control, please note that engines have
to be serviced and adjusted in accordance with special
instructions and using special measuring equipment.
Modifications to or interference with the emissions con-
trol systems are not permissible.
All DaimlerChrysler Corporation dealers are familiar
with the relevant and applicable regulations.
EMISSION CONTROL SYSTEM MAINTENANCE
The “Scheduled” maintenance services, listed inbold
typemust be done at the times or mileages specified to
assure the continued proper functioning of the emission
control system. These, and all other maintenance services
included in this manual, should be done to provide best
vehicle performance and reliability. More frequent main-
tenance may be needed for your Crossfire in severe
operating conditions such as dusty areas and very short
trip driving.Inspection and service also should be done any time a
malfunction is suspected.
NOTE:Maintenance, replacement, or repair of the
emission control devices and systems on your vehicle
may be performed by any automotive repair establish-
ment or individual using any automotive part which has
been certified pursuant to U.S. EPA or, in the State of
California, California Air Resources Board regulations.
MAINTENANCE SCHEDULES
There are two maintenance schedules that show the
requiredservice for your vehicle.
Schedule “A” typically rotates with Schedule “B.” Follow
Schedule “A” after the first service interval, Schedule “B”
after the second service interval, and so on. In some cases
where the service interval has been extended due to very
light duty driving, a Schedule “B” service may be indi-
cated following a previous Schedule “B” service. There
are additional service tasks required under Schedule “B.”
MAINTENANCE SCHEDULES 249
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Your Flexible Service System (FSS) — see Understanding
Your Instrument Panel section — should give you an
exact indication of when your vehicle should be sched-
uled for service and which schedule to follow.
Additional Periodic Maintenanceitems should also be
performed beyond the items listed in the following charts
to assure the optimum performance of your Crossfire.
SCOPE OF WORK FOR “A” SCHEDULE
MAINTENANCE SERVICE
Oil Change
•Change oil and replace filter
Maintenance
•Lubricate hood hinges, latch, and secondary latch
•Reset FSS Display
Function Check
•Horn, hazard warning flashers, turn signals, and indi-
cator lamps
•Headlamps and exterior lighting
•Windshield wipers and washer system
Inspection
•Check front and rear brake pads for lining thickness
•Check tires for damage and general condition
•Check tire inflation pressures and correct if necessary
Fluid Levels
Check fluid levels for the following systems and correct if
necessary. Should there be a loss of fluid that cannot be
explained by regular use, trace and eliminate the cause.
•Engine cooling system (check corrosion inhibitor/
antifreeze)
•Hydraulic brake system
•Power steering system
•Windshield washer system
250 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
