battery CHRYSLER CROSSFIRE 2005 1.G Owners Manual

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
CONTENTS

A Word About Your Keys................. 9
▫Keys............................... 9
▫Obtaining Replacement Keys..............10
▫Ignition Key Removal...................10
▫Key-In-Ignition Reminder................10

Glove Compartment Lock.................11

Door Locks...........................11
▫Central Locking Switch..................12
▫Automatic Central Locking...............13
▫General Notes On The Central Locking
System..............................13
▫Emergency Unlocking Feature.............14▫Start Lockout.........................14

Remote Keyless Entry....................14
▫To Unlock The Doors...................14
▫To Lock The Doors.....................15
▫Panic Alarm..........................15
▫To Use The Panic Alarm.................16
▫General Information....................16
▫Transmitter Battery Service...............16

Security Alarm System...................17
▫Tow-Away Alarm......................18

Decklid Internal Emergency
Release - Roadster
......................19
2

A WORD ABOUT YOUR KEYS
You can insert the double-sided keys into the locks with
either side up.
The dealer that sold you your new vehicle has the key
code numbers for your vehicle locks. These numbers can
be used to order duplicate keys only from an authorized
dealer. Ask your dealer for these numbers and keep them
in a safe place.
CAUTION!
An unlocked car is an invitation to thieves. Always
remove the key from the ignition and lock all the
doors when leaving the vehicle unattended.
NOTE:To avoid discharging the battery, the key must
be removed from the ignition when the vehicle is parked.
Keys
Included with your vehicle are two remote controls with
folding keys. The remote control operates all locks on the
vehicle, including the locking fuel filler door.
To release the key from the folded position, press the
button. The key unfolds from the fob.
The transmitter for the remote control is located in the
key fob.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 9
2

NOTE:The fuel filler door and center console (roadster
only) cannot be locked or unlocked with the central
locking switch.
Automatic Central Locking
The central locking switch also operates the automatic
central locking feature. With the automatic central lock-
ing feature activated, the doors and rear liftgate/decklid
are locked at vehicle speeds of approximately 9 mph (15
km/h) or more; however, the fuel filler door remains
unlocked.
To activate this feature, turn the key to the ON/RUN
position and hold the upper portion of the switch for a
minimum of five seconds. To deactivate, turn the key to
the ON/RUN position and hold the lower portion of the
switch for a minimum of five seconds.
NOTE:If the doors are unlocked with the central
locking switch after activating the automatic central
locking feature and neither door is opened, the doors
remain unlocked even at vehicle speeds of approximately
9 mph (15 km/h) or more.
NOTE:If you attempt to lock the doors with the key in
the ignition and the driver’s door open, the doors will not
lock.
General Notes On the Central Locking System
If the key in the ignition switch is in the ON/RUN
position, the vehicle cannot be locked or unlocked with
the remote control.
If the vehicle cannot be locked or unlocked at any time
with the remote control, it may be necessary to change
the batteries in the remote.
NOTE:To help prevent the vehicle battery from dis-
charging during short periods of inactivity, perform the
following:
1. Make sure that the rear liftgate/decklid, hood and
doors are completely closed.
2. Make sure that remote transmitter is operating and
that the battery is good.
3. Make sure that the hood, rear liftgate/decklid and
door switches are in adjustment.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13
2

To Use the Panic Alarm:
Press and hold the Panic button to activate the alarm.
Press and hold the Panic button or unlock the door with
the key to deactivate the alarm. The alarm will also shut
off after three minutes or when vehicle speed reaches 15
mph (24 km/h).
General Information
This transmitter complies with FCC rules part 15. Opera-
tion is subject to the following conditions:
1. This device may not cause harmful interference.2. This device must accept any interference that may be
received, including interference that may cause undes-
ired operation.
Transmitter Battery Service
The recommended replacement Lithium battery is Pana-
sonicCR 2025 or equivalent.
To change the batteries:
•Press release button (2) on the key fob. The key folds
out.
•Press the battery cover (1) in the direction of the arrow.
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

•Remove the old batteries.
•Insert the new batteries in the direction of the arrow
with the positive symbol facing upwards.
•Replace the battery cover and press on it until you feel
it engage.
NOTE:Only replace the batteries in pairs.
The system may have to be resynchronized if the trans-
mitter is without voltage for several minutes. To synchro-
nize, aim the transmitter eye at the vehicle and briefly
press either the Lock or the Unlock button twice. Withinapproximately 30 seconds, insert the key in the ignition
and turn it to the ON/RUN position. The remote control
should once again be operational.
SECURITY ALARM SYSTEM
The system monitors the doors, rear liftgate/decklid,
hood, and ignition for unauthorized operation. The se-
curity alarm system is automatically armed or disarmed
with the remote control or any of your vehicle’s keys by
locking or unlocking the vehicle.
The antitheft alarm is armed within approximately 10
seconds after locking the vehicle. A blinking light in the
tow away alarm switch indicates that the alarm is armed.
Once the alarm system has been armed, the exterior
vehicle lights will flash and an alarm will sound when a
door, the rear liftgate/decklid, the hood, or the glove
compartment is opened, or if someone attempts to raise
the vehicle for towing. The alarm will flash the exterior
lamps for approximately three minutes and sound an
audible alarm for 30 seconds. The alarm will stay on even
if the activating element is immediately closed.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17
2

DECKLID INTERNAL EMERGENCY RELEASE -
ROADSTER
WARNING!
Do not allow children to have access to the trunk by
climbing into the trunk from outside. Always close
the decklid when your vehicle is unattended. Once
in the trunk, young children may not be able to
escape. If trapped in the trunk, children can die from
suffocation or heat stroke.
WARNING!
If the battery voltage drops below the minimum
threshold during the convertible top operation, the
Trunk Internal Emergency Release will not function.
WARNING!
The Trunk Internal Emergency Release will not
function during the convertible top operation.
NOTE:As a security measure, a Decklid Internal Emer-
gency Release lever is built into the decklid latching
mechanism. In the event of an individual being locked
inside the trunk, the decklid can be easily opened by
pulling on the glow-in-the-dark handle attached to the
decklid latching mechanism. See picture.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19
2

To Open And Close The Hood.............70

Interior Lights.........................71
▫Front Map/Reading Lights...............72
▫Battery Saver Feature...................72
▫Instrument Panel Lighting................72
▫Night Security Illumination...............72

Exterior Lights.........................73
▫Headlights And Parking Lights............73
▫Daytime Running Lights (Where Applicable) . . .73
▫Fog Lights...........................74
▫Standing Lights.......................74

Multifunction Control Lever...............75
▫Turn Signals..........................75
▫Headlight Dimmer Switch................76
▫Passing Light.........................76
▫Windshield Wipers And Washer............77▫Mist Function.........................78

Telescoping Steering Column..............79

Tire Pressure Monitor System..............80

Rear Spoiler...........................82

Brake Assist System (BAS)................85

Electronic Stability Program (ESP)...........86
▫Synchronizing ESP.....................88

Electronic Speed Control..................88
▫To Vary The Speed Setting................90
▫To Deactivate.........................90
▫To Resume Speed......................91
▫Using Speed Control On Hills.............91

Garage Door Opener....................92
▫Programming The Universal Transceiver......92
▫Gate Operator/Canadian Programming......95
▫Using The Universal Transceiver...........95
50 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Convertible Top Lamp and Audible Signal Chart
Below is a table containing all of the visual and audible
signals that can be seen or heard during the tops opera-
tion or if a fault is present.
Visual and Audible Signals Operation Mode or Fault
Single audible signal is heard Roof reaches fully open posi-
tion
Roof reaches fully closed po-
sition
Convertible top switch lamp
flashes slowly and a slow
audible beep is heardDecklid open
Cargo compartment divider
not secured in vertical posi-
tion
Top latched at winshield
header
Top unlatched but not re-
leased from windshield
header
Vehicle speed greater than 9
mph (15 km/h) while trying
to operate the top
Battery voltage less than 10.6
Volts
60 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Front Map/Reading Lights
These lights are located between the sun visors. A single
centrally located switch operates both lights.
Battery Saver Feature
To prevent battery drain if a door is left open or ajar, the
interior lights will turn off automatically after 15 minutes.
After the door is closed, the interior lights will return to
their normal function.
Instrument Panel Lighting
With the parking lights or headlights on, rotate the
dimmer control to the left of the speedometer to increase
or decrease brightness of the instrument panel.
Night Security Illumination
For added security when exiting the vehicle after driving
with the exterior lights on, the lights will switch on again
for approximately 30 seconds after closing the last door.
The lights-on timing can be changed at your authorized
dealer.
72 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Fog Lights
To operate the fog lights, pull the headlight
switch out one stop, with the parking lights
and/or low beam headlights on. A light to the
lower left of the headlight switch will illumi-
nate when the fog lights are on.
To turn off the fog lights, push the headlight switch in
fully. Selecting high beam headlights will also turn off the
fog lights.
Standing Lights
When the vehicle is parked on the street, the standing
lights (left or right side parking lights) can be turned on,
making your vehicle more visible to passing vehicles.To operate the standing lights, turn the headlight switch
counterclockwise one stop (right lamps) or two stops (left
lamps) from the OFF position. To turn off the standing
lights, return the headlight switch to the OFF position.
The standing lights cannot be operated when the ignition
switch is in the ON/RUN position.
CAUTION!
Standing lamps are intended for short term use
when parking. If these lights are left on for a long
period of time, your car’s battery may drain, causing
a possible starting problem. Assure that the head-
lamp switch is in the OFF position when leaving the
vehicle.
74 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
