WARNING!
²Do not put anything on or around the front airbag
covers or attempt to manually open them. You may
damage the airbags and you could be injured
because the airbags are not there to protect you.
These protective covers are designed to open only
when the airbags are inflated.
²Do not place objects between you and the side
airbags; the performance could be adversely af-
fected and/or objects could be pushed into you,
causing serious injury.
²Do not attach cup holders or any other objects on
or around the door. The inflating side airbag could
drive objects into occupants, causing serious
injury.
NOTE:The passenger front airbag may not deploy
even when the driver front airbag has deployed if the
Occupant Classification System (refer to ªOccupant Clas-
sification Systemº in this section) has determined the seatis empty or is occupied by someone that is classified in
the ªchildº category. This could be a child, a teenager, or
even a small adult. The side airbags on the crash side of
the vehicle is triggered in moderate to severe side colli-
sions. However even in collisions where the airbags
work, you need the seat belts to keep you in the right
position for the airbags to protect you properly.
The seat belts are designed to protect you in many types
of collisions. The front airbags deploy only in moderate
to severe front collisions. In certain types of collisions,
both the front and side airbags may be triggered.
Here are some simple steps you can take to minimize
the risk of harm from a deploying airbag.
1. Infants in rear-facing child safety seats shouldNEVER
ride in the front seat of a vehicle with a passenger frontal
airbag unless the airbag is shut OFF. See ªPassenger
Airbag On/Off Switchº and ªTo Shut Off the Passenger
Airbag.º The rear-facing seat places them too close to the
passenger air bag in the event of a crash. An airbag
deployment can cause severe injury or death to infants in
this position.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31
2

Children that are not big enough to properly wear the
vehicle seat belt (see section on ªChild Restraintº) should
be secured in child safety seats or booster seats that are
appropriate for the child's age, height, and weight.
Older children who do not use child safety seats or
booster seats should ride properly buckled. Never allow
children to place the shoulder belt behind them or under
the arm.
If a child from 1 to 12 years old must ride in the vehicle,
move the seat as far back as possible, shut off the
passenger airbag, and use the proper child restraint. See
the section on ªChild Restraint.ºYou should read the instructions provided with your
child restraint or belt-positioning booster seat to make
sure that you are using it properly.
2. All occupants should wear their lap and shoulder belts
properly.
3. The driver and passenger seats should be moved back
as far as practical to allow the front airbags room to
inflate.
4. Do not lean against the door, as the side airbags will
inflate forcefully into the space between you and the
door. (See the section on ªSide Airbags.º)
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING!
After installing a child safety seat or booster seat on
the passenger seat, do not adjust the back rest for-
ward. This could cause a higher load being perceived
by the OCS system which in turn could lead to the
passenger airbag being turned on. Failure to follow
this warning could result in serious or fatal injury. It
is always recommended to turn off the passenger
front air bags using the passenger front airbags
on/off switch located at the right end of the instru-
ment panel when the passenger is:
²an infant (less than 1 year old),
²a child, age 1 to 12,
²an adult with a medical condition which makes
passenger airbags inflation (deployment) a greater
risk for the passenger than the risk of hitting the
dashboard (instrument panel) or windshield in a
crash.
The on/off switch is accessible by opening the pas-
senger door.
WARNING!
²Relying on the airbags alone could lead to more
severe injuries in a collision. The airbags work
with your seat belt to restrain you properly. In
some collisions the airbags won't deploy at all.
Always wear your seat belts even though you have
airbags.
²Being too close to the steering wheel or instrument
panel during airbag deployment could cause seri-
ous injury.
²Airbags need room to inflate. Sit back, comfort-
ably extending your arms to reach the steering
wheel or instrument panel.
²The side airbags also need room to inflate. Do not
lean against the door. Sit upright in the center of
the seat.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33
2

Airbag System Components
The airbag system consists of the following:
²Occupant Restraint Controller
²Airbag Warning Light
²Driver and passenger frontal airbag/inflator units
²Driver and passenger side airbag/inflator units
²Driver and Passenger Inflatable Knee Blocker
²Driver and Front Passenger Seat Belt Pretensioners
²Side impact sensors
²Front Passenger Seat Occupant Classification System
(OCS)
How the Front Airbag System Works
²
The Occupant Restraint Controller (ORC) determines
if a frontal collision is severe enough to require the
airbags to inflate. Based on the level of collision
severity, the front control module determines the
proper rate of inflation. The front airbag inflators are
designed to provide different rates of airbag inflationfrom direction provided by the ORC. The ORC may
modify the rate of inflation based on the occupant size
provided by the Occupant Classification Module. The
ORC will not detect roll overs. The ORC monitors the
readiness of the electronic parts of the system when-
ever the ignition switch is in the START or RUN
positions. If the key is in the OFF position, in the ACC
position, or not in the ignition, the airbags are not on
and will not inflate.
Also, the ORC turns on the AIRBAG warning light
(located in the instrument cluster) and Passenger
Airbag Disable (PAD) indicator light (located in the
center console) for 4 seconds for a self-check when the
ignition is first turned on. After the self-check, the
AIRBAG warning light will turn off. The PAD indica-
tor light will function normally (Refer to ªPassenger
Airbag Disable (PAD) Indicator Lightº in this section).
If the ORC detects a malfunction in any part of the
system, it turns on the AIRBAG warning light either
momentarily or continuously.
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

How the Occupant Classification System (OCS)
System Works
The Occupant Classification System (OCS) will classify
an occupant in the front passenger seat into a size
category based on sensor readings from within the seat
cushion. Occupants should try to remain in a normally
seated position. If the occupant's weight is transferred to
another object in the vehicle (i.e. feet on the dashboard),
the OCS may not be able to properly approximate
occupant size. Furthermore, the occupant size may ap-
pear to increase or decrease due to objects hanging on the
seat, other passengers pushing on the seat, or objects
lodged underneath the seat. If there is a rapid change in
temperature or humidity, the OCS may not be able to
properly approximate occupant size. If your seat includ-
ing your trim cover and cushion needs to be serviced in
any way, take the vehicle to your authorized dealer. Only
manufacturer approved seat accessories may be used. If
there is a fault present in the system, the AIRBAG
warning light will light indicating that you should take
the vehicle to an authorized dealer. In the presence of an
occupant in the passenger seat, if both the PAD indicatorlight (located in the center console) and AIRBAG warn-
ing light (located in the instrument cluster) are illumi-
nated the airbag will be disabled. The ORC will not allow
front airbag deployment in the event of a collision for
occupants classified into the empty or child size catego-
ries. The PAD indicator light will illuminate indicating
that the Passenger Airbag is OFF when the OCS has
determined that the occupant size category is a child.
Also, when the seat is empty or an object that weighs less
than a predetermined threshold is placed on the seat, the
light will remain OFF. (The PAD indicator light is an
amber light located in the center console.) For almost all
sizes of properly seated adults, the passenger frontal
airbag will be enabled in the event of a collision. For
small teenagers and some small adults, depending on
size, the airbag may or may not be enabled in the event
of a collision. Both drivers and passengers should always
use the PAD indicator light as an indication if the front
passenger is properly positioned or not. If the PAD
indicator light comes on when an adult is in the passen-
ger seat, have the passenger re-position themselves in the
seat until the light goes out. Remember, if the PAD
indicator light is illuminated the passenger front airbag
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

will not inflate. For most children properly seated on the
front seat and most properly installed child restraint
systems, the airbag will be disabled and the PAD indica-
tor light will be on. However, under certain conditions
even with the child restraint system has been installed
properly, the PAD indicator light may not be on even
though the air bag is disabled. This can occur if the child
restraint is lighter than the threshold weight necessary to
turn the PAD indicator light on. If this happens to you,
you can check to ensure the airbag is disabled by
performing the following simple procedure. Place the
ignition key in the RUN position and apply downward
pressure to the child restraint on the surface that the child
will be sitting on. Slowly count to 10 and watch the PAD
indicator light. The PAD indicator light should turn on.
When you release the pressure, the PAD indicator light
may stay on or may turn off but the airbag is disabled. If
at all possible, place children 12 years and younger in a
back seat.The following requirements must be strictly adhered to:
²Do not modify the front passenger seat assembly or
components in any way.
²Do not modify the front seat center console or center
position seat in any way.
²Do not use prior or future model year seat covers not
designated for the specific model being repaired.
²Always use the correct seat cover specified for the
vehicle.
²Do not replace the seat cover with an aftermarket seat
cover.
²Do not add a secondary seat cover other than those
approved by DaimlerChrysler/Mopar.
²At no time should any supplemental restraint system
(SRS) component or SRS related component or fas-
tener be modified or replaced with any part except
those which are approved by DaimlerChrysler/
Mopar.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41
2

How the Occupant Classification Module (OCM)
Works
The Occupant Classification Module (OCM) is located
beneath the passenger seat.. The OCM classifies the
occupant into one of three size categories based on the
input from the Bladder Assembly and a Belt Tension
Sensor. The size categories include empty, child, and
adult. The OCM sends the Occupant Classification to the
ORC to determine if a front passenger airbag is allowed.
If a fault is present, the AIRBAG warning light is illumi-
nated.
How the Passenger Airbag Disabled (PAD)
Indicator Light Works
The Passenger Airbag Disabled (PAD) Indicator Light
indicates to the driver and passenger when the airbag is
turned OFF. In the presence of a properly seated occu-
pant, when the PAD indicator light is illuminated, the
airbag is OFF. Also, when the Occupant Classification
System detects either an empty seat or a weight less than
the predetermined threshold, the ORC will not illuminate
the PAD indicator light even though the airbag is turned
OFF.
How the Belt Tension Sensor (BTS) Works
The Belt Tension Sensor (BTS) is located at the outboard
passenger lap belt anchor. The BTS creates a signal based
on outboard lap belt tension. This signal is sent to the
OCM to ensure that the resultant bladder pressure in-
crease due to applied lap belt tension does not cause a
small occupant to be classified as a larger occupant
How the Bladder Mat and Pressure Sensor Works
The Bladder Mat and Pressure Sensor are located beneath
the seat cushion foam. The pressure sensor sends a signal
to the OCM. The passenger seat assembly contains criti-
cal components that affect the passenger airbag deploy-
ment. Correctly functioning passenger seat components
are critical for the Occupant Classification System (OCS)
to properly classify the passenger and calculate the
proper airbag deployment. Do not make any modifica-
tions to the passenger seat components, assembly, or to
the seat cover.
42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

How the Driver/Passenger Inflatable Knee
Blockers Works
When the ORC and the impact sensors detect a collision
requiring the Driver/Passenger Inflatable Knee Blockers,
it signals the inflator unit. A quantity of nontoxic gas is
generated to inflate the Driver/Passenger Inflatable Knee
Blockers. The Driver/Passenger Inflatable Knee Blockers
inflates rearward towards the driver 's knees to help
protect the knees and position you for the best interaction
with the front airbag. The Driver/Passenger Inflatable
Knee Blockers fully inflates in about 50 milliseconds, this
is only about half of the time it takes you to blink your
eyes. It then quickly deflates while helping to protect the
driver 's knees.
The Knee Impact Blockers help protect the knees and
position the occupant.
Passenger Front Airbag On/Off Switch
The ON/OFF switch is located at the right end of the
instrument panel and is accessible by opening the pas-
senger door.
NOTE:When using certain types of child seats, the
passenger airbag light will remain off even though the
passenger front airbags are disabled.
It is always recommended to turn off the passenger front
air bags using the passenger front airbags on/off switch
located at the right end of the instrument panel when the
passenger is:
²an infant (less than 1 year old),
²a child, age 1 to 12,
²an adult with a medical condition which makes pas-
senger airbag inflation (deployment) a greater risk for
the passenger than the risk of hitting the dashboard
(instrument panel) or windshield in a crash.
The on/off switch is accessible by opening the passenger
door.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43
2

If the airbag is turned off when there is any other
occupant at that position, the supplemental restraint
provided by the airbag will not be available.To turn OFF the passenger front airbag, use the on/off
switch located on the instrument panel.
NOTE:When the passenger airbag is turned off, the
yellow airbag off light will illuminate.
44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

To Shut Off the Passenger Airbag:
²Place the ignition key in the on/off switch, turn the
key clockwise, and remove the key from the switch.
This will shut off the passenger front airbag.
²The air bag will remain off until the switch is turned
back to the ON position.
²The switch does NOT turn off the side airbag.To Turn On the Passenger Airbag:
²Place the ignition key in the on/off switch, turn the
key counterclockwise, and remove the key from the
switch. This will turn on the passenger airbag. The
Passenger Airbag Off light on the console will turn off,
or will not be illuminated when the ignition is turned
to the ON position.
WARNING!
The airbag may malfunction and serious injury could
result if key is left in the airbag shut off switch.
Always remove the key.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45
2
