Page 11 of 280
GLOVE COMPARTMENT LOCK
The glove compartment can be locked by turning the key
straight up to the vertical or right position, and then
removing the key.
To unlock the glove compartment, turn the key to the
horizontal or left position, and then remove the key.
DOOR LOCKS
The vehicle doors can be locked when the doors are
closed by either manually pressing the button down at
the top of the door panel, pressing and releasing the
bottom portion of the central locking switch located in
the console, or by pressing and releasing the Lock
transmit button on the key fob. Also, by turning the key
clockwise in the driver’s door, both doors, liftgate/
decklid, fuel filler door, and center console (roadster
only) will lock.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11
2
Page 12 of 280
The doors can be unlocked by pulling on the inside door
handle, pressing and releasing the top portion of the
central locking switch located in the console, or by
pressing and releasing the Unlock transmit button on the
key fob. Both doors can also be unlocked by turning the
key counterclockwise in the driver’s door.
NOTE:If the key in the ignition switch is in the
ON/RUN position, the vehicle cannot be locked or
unlocked with the remote control.
When you lock the vehicle, both door lock buttons
should move down. If either one stays up, the respective
door is not properly closed. You should then unlock the
vehicle, open and reclose the door, and lock the vehicle
again.
Each individual door can be locked with the respective
door lock button - the driver’s door can only be locked
when it is closed. If the vehicle has previously been
locked from the outside, only the door being opened
from the inside will unlock, and the alarm will come on.
The other door, the rear liftgate/decklid, fuel filler door,
and center console (roadster only) will remain locked.
NOTE:In case of a malfunction in the central locking
system, the doors can be locked and unlocked individu-
ally. To lock, turn the key in the driver’s door lock
clockwise, or push down the lock buttons. To unlock,
turn the key in the driver’s door lock counterclockwise,
or pull the inside door handles.
WARNING!
For personal security and safety in the event of an
accident, lock the vehicle doors as you drive and
when you park and leave the vehicle.
Central Locking Switch
The central locking switch is located in the console. The
doors and rear liftgate/decklid can only be locked with
the central locking switch if both doors are closed.
If the vehicle was previously locked with the remote
control or key, the doors and rear liftgate/decklid cannot
be unlocked with the central locking switch. If the vehicle
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 13 of 280
was previously locked with the central locking switch,
the complete vehicle is unlocked when a door is opened
from the inside.
NOTE:The fuel filler door and center console (roadster
only) cannot be locked or unlocked with the central
locking switch.
Automatic Central Locking
The central locking switch also operates the automatic
central locking feature. With the automatic central lock-
ing feature activated, the doors and rear liftgate/decklid
are locked at vehicle speeds of approximately 9 mph (15
km/h) or more; however, the fuel filler door remains
unlocked.
To activate this feature, turn the key to the ON/RUN
position and hold the upper portion of the switch for a
minimum of five seconds. To deactivate, turn the key to
the ON/RUN position and hold the lower portion of the
switch for a minimum of five seconds.
NOTE:If the doors are unlocked with the central
locking switch after activating the automatic centrallocking feature and neither door is opened, the doors
remain unlocked even at vehicle speeds of approximately
9 mph (15 km/h) or more.
NOTE:If you attempt to lock the doors with the key in
the ignition and the driver’s door open, the doors will not
lock.
General Notes On the Central Locking System
If the key in the ignition switch is in the ON/RUN
position, the vehicle cannot be locked or unlocked with
the remote control.
If the vehicle cannot be locked or unlocked at any time
with the remote control, it may be necessary to change
the batteries in the remote.
NOTE:To help prevent the vehicle battery from dis-
charging during short periods of inactivity, perform the
following:
1. Make sure that the rear liftgate/decklid, hood and
doors are completely closed.
2. Make sure that remote transmitter is operating and
that the battery is good.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13
2
Page 14 of 280
3. Make sure that the hood, rear liftgate/decklid and
door switches are in adjustment.
Perform the quick system check which follows: Use
the remote transmitter to set the alarm. If the parking
lamps flash three times, the system is operating prop-
erly. If not, there is a problem with a switch or the
system. See your authorized dealer for service.
Emergency Unlocking Feature
In the case of an accident, the doors unlock automatically
a short time after a strong deceleration is detected, such
as in a collision (this is intended to aid rescue and exit).
However, the key must still be in the ignition.
Start Lockout
Removing the key from the ignition switch activates the
start lockout. The engine cannot be started. Turning the
key to the ON/RUN position deactivates the start lock-
out. If the engine cannot be started, and the messages
START and ERROR are shown in the odometer display
field, the system is not operational. Contact an autho-
rized dealer.
REMOTE KEYLESS ENTRY
This feature allows you to lock or unlock the vehicle from
remote locations using a hand-held transmitter located in
the key fob. You don’t have to point the transmitter at the
vehicle to activate the system. The vehicle doors, rear
liftgate/decklid, fuel filler door, and center console (road-
ster only) can be locked and unlocked using the remote
control.
To Unlock the Doors:
Press and release the unlock button on the key fob.
NOTE:If within 40 seconds of unlocking with the key
fob, neither door is opened, the key is not inserted in the
ignition switch, or the central locking switch is not
activated, the vehicle will automatically lock.
Press the Unlock transmit button on the key fob once to
unlock driver’s door, rear liftgate/decklid, fuel filler
door, and center console (roadster only). Press the Unlock
transmit button twice to unlock both doors, rear liftgate/
decklid, fuel filler door, and center console (roadster
only).
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 15 of 280
To Lock The Doors:
Press the Lock button on the key fob once. All turn signal
lights blink three times to indicate that the vehicle is
locked. If the turn signal lights do not blink, a door or
rear liftgate/decklid is not closed properly.
The entire vehicle, including the fuel filler door, may be
locked or unlocked by using the key in the driver’s door.
The doors and liftgate/decklid can be locked or unlocked
by pressing the central locking switch located in the
center console.If the vehicle cannot be locked or unlocked by pressing
the transmit button, then it may be necessary to change
the batteries in the remote control.
Panic Alarm
The panic alarm unlocks the driver’s door, turns on the
interior lights, flashes the foglights and sounds the horn
for about three minutes or until the alarm is turned off.
The vehicle can be driven while in the Panic mode.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15
2
Page 16 of 280
To Use the Panic Alarm:
Press and hold the Panic button to activate the alarm.
Press and hold the Panic button or unlock the door with
the key to deactivate the alarm. The alarm will also shut
off after three minutes or when vehicle speed reaches 15
mph (24 km/h).
General Information
This transmitter complies with FCC rules part 15. Opera-
tion is subject to the following conditions:
1. This device may not cause harmful interference.2. This device must accept any interference that may be
received, including interference that may cause undes-
ired operation.
Transmitter Battery Service
The recommended replacement Lithium battery is Pana-
sonicCR 2025 or equivalent.
To change the batteries:
•Press release button (2) on the key fob. The key folds
out.
•Press the battery cover (1) in the direction of the arrow.
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 17 of 280
•Remove the old batteries.
•Insert the new batteries in the direction of the arrow
with the positive symbol facing upwards.
•Replace the battery cover and press on it until you feel
it engage.
NOTE:Only replace the batteries in pairs.
The system may have to be resynchronized if the trans-
mitter is without voltage for several minutes. To synchro-
nize, aim the transmitter eye at the vehicle and briefly
press either the Lock or the Unlock button twice. Withinapproximately 30 seconds, insert the key in the ignition
and turn it to the ON/RUN position. The remote control
should once again be operational.
SECURITY ALARM SYSTEM
The system monitors the doors, rear liftgate/decklid,
hood, and ignition for unauthorized operation. The se-
curity alarm system is automatically armed or disarmed
with the remote control or any of your vehicle’s keys by
locking or unlocking the vehicle.
The antitheft alarm is armed within approximately 10
seconds after locking the vehicle. A blinking light in the
tow away alarm switch indicates that the alarm is armed.
Once the alarm system has been armed, the exterior
vehicle lights will flash and an alarm will sound when a
door, the rear liftgate/decklid, the hood, or the glove
compartment is opened, or if someone attempts to raise
the vehicle for towing. The alarm will flash the exterior
lamps for approximately three minutes and sound an
audible alarm for 30 seconds. The alarm will stay on even
if the activating element is immediately closed.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17
2
Page 18 of 280
Tow-Away Alarm
The tow-away alarm switch is located on the console. To
deactivate for towing or jacking up the vehicle, press and
release the upper portion of the switch. Press and release
the upper portion to activate it again.
After the alarm system has been armed, the exterior
vehicle lights will flash and an alarm will sound when
someone attempts to raise the vehicle. The alarm will
flash the exterior lamps for approximately three minutes
and sound an audible alarm for 30 seconds. The alarm
will stay on even if the vehicle is immediately lowered.
To cancel the alarm, insert the key into the ignition switch
or press a transmit button on the key fob.
To prevent triggering the tow-away alarm feature when
parking on a surface subject to movement (such as a
ferry), switch off the tow-away alarm. To do so, turn the
key in the ignition switch to the OFF/LOCK or ACC
position, or remove the key from the ignition switch.
Press the tow-away alarm switch and the indicator light
will illuminate briefly. Exit the vehicle, and lock the
vehicle with the key or the remote control.The tow-away alarm remains switched off until the
vehicle is locked again with the key or the remote control,
at which time it is automatically reactivated.
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 19 of 280
DECKLID INTERNAL EMERGENCY RELEASE -
ROADSTER
As a security measure, a Decklid Internal Emergency
Release lever is built into the decklid latching mecha-
nism. In the event of an individual being locked inside
the trunk, the decklid can be easily opened by pulling on
the glow-in-the-dark handle attached to the decklid
latching mechanism. See picture.
WARNING!
Do not allow children to have access to the trunk by
climbing into the trunk from outside. Always close
the decklid when your vehicle is unattended. Once
in the trunk, young children may not be able to
escape. If trapped in the trunk, children can die from
suffocation or heat stroke.
WARNING!
If the battery voltage drops below the minimum
threshold during the convertible top operation, the
Trunk Internal Emergency Release will not function.
WARNING!
The Trunk Internal Emergency Release will not
function during the convertible top operation. How-
ever, if access to the trunk is required during the
convertible top operation follow the procedure be-
low.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19
2
Page 20 of 280
Opening the Decklid During Top Operation
The decklid can be opened during the top operation by
following this procedure.
CAUTION!
It is possible for the decklid to contact the tonneau
cover if opened during the top operation.
CAUTION!
The tops hydraulic pressure will also be released
during this procedure which will allow the top and
tonneau cover to slowly collapse.
1. Turn the ignition“ON”.
2. Push down and hold the convertible top switch.
3. Turn the ignition“OFF’and continue to push down on
the convertible top switch for 5 seconds.
4. After five seconds the decklid will be released and can
be opened.
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
