Page 47 of 280
SAFETY TIPS
Exhaust Gas
WARNING!
Exhaust gases can injure or kill. They contain carbon
monoxide (CO) which is colorless and odorless.
Breathing it can make you unconscious and can
eventually poison you. To avoid breathing (CO)
follow the safety tips below.
•Do not run the engine in a closed garage or in confined
areas any longer than needed to move your vehicle in
or out of the area.
•If it is necessary to sit in a parked vehicle with the
engine running, adjust your heating or cooling con-
trols to force outside air into the vehicle. Set the blower
at high speed.
•To avoid drawing exhaust gases into the vehicle, close
the rear liftgate/decklid while driving. However, if for
some reason it must remain open, close all windows.Adjust the heating or cooling system to force outside
air into the vehicle. Set the blower at high speed.
Safety Checks You Should Make Inside the
Vehicle
Seat Belts
Inspect the belt system periodically, checking for cuts,
frays and loose parts. Damaged parts must be replaced
immediately. Do not disassemble or modify the system.
Seat belt assemblies must be replaced after an accident if
they have been damaged (bent retractor, torn webbing,
etc.). If there is any question regarding belt or retractor
condition, see your authorized dealer.
Airbag Light
The light should come on and remain on for
four seconds as a bulb check when the ignition
switch is first turned ON. If the bulb is not lit
during starting, have it replaced. If the light
stays on or comes on while driving, have the system
checked by an authorized dealer.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47
2
Page 76 of 280
To operate the turn signals continuously, move the con-
trol lever up or down past the point of resistance. The
operation is automatically canceled when the steering
wheel is turned to a large enough degree.
If one of the turn signal lights fail, the turn signal
indicator system flashes and sounds at a faster than
normal rate. If an indicator fails to light when the control
lever is moved, it may mean that the fuse or indicator
bulb is defective.Headlight Dimmer Switch
Push the multifunction control lever toward the instru-
ment panel to turn the headlights to high beam. Pull the
lever toward you to switch to low beam.
76 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 107 of 280
The sensor for the outside temperature indicator is
located in the front fascia area. Due to its location, the
sensor can be affected by road or engine heat during
idling or slow driving. This means that the accuracy of
the displayed temperature can only be verified by com-
parison to a thermometer placed next to the sensor, not
by comparison to external displays (e.g., bank signs, etc.).
Adaptation to ambient temperature takes place in steps
and depends on the prevailing driving conditions (stop-
and- go or moderate, constant driving) and amount of
temperature change.
WARNING!
The outside temperature indicator is not designed to
serve as an ice-warning device and is unsuitable for
that purpose. Indicated temperatures just above the
freezing point do not guarantee that the road surface
is free of ice.
24. Airbag Light
The operational readiness of the airbag sys-
tem is verified by the airbag indicator light
in the instrument cluster when turning the
key in the ignition switch to the ACC or
ON/RUN position. If no fault is detected, the light
will go out after approximately 4 seconds. After the
lamp goes out, the system continues to monitor the
components and circuitry of the airbag system and
will indicate a malfunction by coming on again.
The light will come on and remain on for 4 seconds as a
bulb check when the ignition switch is first turned ON. If
the bulb is not lit during starting, have it replaced. If the
light stays on, or comes on while driving, have the
system checked by an authorized dealer.
UNDERSTANDING YOUR INSTRUMENT PANEL 107
4
Page 108 of 280
WARNING!
In the event a malfunction of the airbag is indicated,
the airbag may not be operational. For your safety,
we strongly recommend that you visit an authorized
dealer immediately to have the system checked;
otherwise the airbag may not be activated when
needed in an accident, which could result in serious
or fatal injury, or it might deploy unexpectedly and
unnecessarily which could also result in injury.
25. Telescoping Wheel Indicator Light
With the key in the ignition and turned to the
ON/RUN position, the indicator light in the
instrument cluster comes on. It should go
out when the engine is running. If the indi-
cator light does not go out after starting the engine, the
telescoping steering column is not locked properly.
WARNING!
Do not drive the vehicle until you have properly
locked the steering column.
26. Check Engine Light
This light is part of an onboard diagnostic
system that monitors the emissions and en-
gine control systems. If a problem is detected in one of
these systems, the Check Engine light will come on.
The light comes on and stays on briefly as a bulb check
when the ignition is first turned on.
Certain conditions, such as a loose or missing gas cap, or
poor fuel quality may illuminate the light after the engine
is started. Be sure the gas cap is tightened every time you
refuel.
108 UNDERSTANDING YOUR INSTRUMENT PANEL
Page 190 of 280
▫Appearance Care And Protection From
Corrosion...........................215
Convertible Top Care...................219
▫Washing............................220
▫General Cleaning.....................220
▫Weather Strip Care....................221
Fuses...............................221
▫Underhood Accessory Fuse Block Fuses.....221
▫Relay Control Module Fuses.............225
▫Interior Fuses........................226
Replacement Bulbs.....................228
▫Interior Light Bulbs....................228
▫Exterior Light Bulbs...................228
Exterior Light Bulb Service...............228
▫Headlights..........................228▫Front Turn Signal And Parking/Standing
Lights.............................229
▫Front And Rear Sidemarker Lights.........229
▫Tail, Stop, Back Up And Turn Signal Lights . . . 230
▫License Plate Light....................230
▫Headlight Aiming.....................231
Vehicle Storage........................231
Specifications.........................233
Fluid Capacities.......................235
Recommended Fluids, Lubricants And Genuine
Parts
...............................236
▫Engine.............................236
▫Chassis............................237
▫Body..............................238
190 MAINTAINING YOUR VEHICLE
Page 193 of 280
EMISSIONS INSPECTION AND MAINTENANCE
PROGRAMS
In some localities, it may be a legal requirement to pass
an inspection of your vehicle’s emissions control system.
Failure to pass could prevent vehicle registration.
For states which have an I/M (Inspection and
Maintenance) requirement, this check verifies
the following: the CHECK ENGINE Light is functioning
and is not on when the engine is running, and that the
OBD (Onboard Diagnostic) system is ready for testing.
Normally, the OBD system will be ready. The OBD
system maynotbe ready if your vehicle was recently
serviced, if you recently had a dead battery, or a battery
replacement. If the OBD system should be determined
not ready for the I/M test, your vehicle may fail the test.
Your vehicle has a simple ignition key actuated test
which you can use prior to going to the test station. To
check if your vehicle’s OBD system is ready, you must do
the following:1. Insert your ignition key into the ignition switch.
2. Turn the ignition to the ON/RUN position, but do not
crank or start the engine.
3. If you crank or start the engine, you will have to start
this test over.
4. As soon as you turn your key to the ON/RUN
position, you will see your CHECK ENGINE light come
on as part of a normal bulb check.
5. Approximately 15 seconds later, one of two things will
happen:
a. The CHECK ENGINE light will flash for about 10
seconds and then return to being fully illuminated
until you turn off the ignition key or start the
engine. This means that your vehicle’s OBD system
isnot readyand you shouldnotproceed to the I/M
station.
MAINTAINING YOUR VEHICLE 193
7
Page 228 of 280
REPLACEMENT BULBS
Interior Light Bulbs
For lighted switches and interior lights, see your autho-
rized dealer for servicing requirements.
Exterior Light Bulbs
Bulb Bulb No.
Headlight - High and Low Beam......12V55W H7U
Front Turn Signal.......................Y21W
Front Parking/Standing Light.............. W5W
Front Side Marker Light.................. W5W
Rear Marker Light...................... W5W
Center High-Mounted Stop Light (CHMSL)..... LED
Front Fog Lights.....................HB455W
Rear Turn Signal Light...................Y21W
Rear Tail and Stop Light.................21/5W
Backup Light........................... 21W
License................................ 168
EXTERIOR LIGHT BULB SERVICE
Headlights
WARNING!
Halogen lamps contain pressurized gas. A bulb can
explode if you:
•Touch or move it when hot
•Drop the bulb
•Scratch the bulb
Wear eye and hand protection.
NOTE:To prevent a possible electrical short circuit,
switch off light prior to replacing a bulb.
1. Push the tab down at the top end of the cover and
remove.
2. Disconnect the electrical connector.
228 MAINTAINING YOUR VEHICLE
Page 229 of 280
3. Release the spring clamps holding the bulb in place,
and pull out the bulb. Replace the bulb and reverse the
removal procedure exactly.
CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with an oily surface, clean the
bulb with rubbing alcohol.
Front Turn Signal and Parking/Standing Lights
•
Twist the bulb socket counterclockwise and pull out.
Push the bulb into the socket, turn counterclockwise
and remove.
•Replace the bulb, push in and twist clockwise. Rein-
stall the socket, and turn clockwise.
Front and Rear Sidemarker Lights
1. Push the front sidemarker assembly in and slide it
forward. Push the rear sidemarker assembly in and slide
rearward. The assembly will release from the fascia.
2. Twist the bulb socket counterclockwise and pull out.
Push the bulb into the socket, turn counterclockwise and
remove.
3. Replace the light, push in and twist clockwise.
MAINTAINING YOUR VEHICLE 229
7
Page 230 of 280
4. Realign the two tabs and push the light in until it
engages into the lock.
Tail, Stop, Back Up and Turn Signal Lights
1. Open the rear liftgate / decklid and remove the access
door in the trim panel.
2. Twist the bulb socket counterclockwise and pull out.
3. Replace the light and return to open socket, turn
clockwise until it stops.
4. Replace the access door in the trim panel.
License Plate Light
1. Remove the two lens assembly mounting screws.
2. Pull the bulb out of the socket.
3. Replace the bulb and reattach the lens assembly.
4. Align and resecure the two lens assembly mounting
screws.
NOTE:Be sure not to over-torque the mounting screws
or permanent damage to the lens may occur.
230 MAINTAINING YOUR VEHICLE
Page 266 of 280
ABS (Anti-Lock Brake) System............. 102
Adding Engine Coolant (Antifreeze)......... 209
Adding Fuel.......................... 160
Aiming Headlights...................... 231
Air Cleaner, Engine (Engine Air Cleaner Filter) . 199
Air Conditioning....................120,202
Air Conditioning Filter................... 248
Air Conditioning Refrigerant.............. 203
Air Conditioning System................. 202
Air Pressure, Tires...................148,149
Airbag................................ 29
Airbag Deployment...................... 33
Airbag Light........................32,107
Airbag Maintenance...................... 39
Airbag On/Off Switch..................36,41
Alignment and Balance.................. 157
Antenna.............................. 119
Antifreeze (Engine Coolant)............... 235
Anti-Lock Warning Light................. 102
Appearance Care....................... 215
Ashtrays and Lighter..................... 63
Automatic Door Locks.................... 13
Automatic Transmission...............131,214Fluid and Filter Changes................ 214
Fluid Level Check..................... 214
Fluid Type.......................... 214
Autostick............................. 134
Ball Joints............................ 204
Battery............................103,201
Saving Feature (Protection)............... 73
Belts, Drive........................... 199
Belts, Seat............................. 22
Body Mechanism Lubrication.............. 204
Brake Assist System...................... 82
Brake, Parking......................... 138
Brake System.......................139,211
Anti-Lock........................... 139
Hoses.............................. 212
Master Cylinder...................... 213
Break-In Recommendations, New Vehicle . . . 46,147
Bulbs, Light........................... 228
Capacities, Fluid....................... 233
Capacity, Cargo Weight.................. 162
Carbon Monoxide Warning................ 47
266 INDEX
