THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
CONTENTS
mA Word About Your Keys..................11
NIgnition Key Removal...................11
NKey-In-Ignition Reminder................12
mSentry Key............................12
NReplacement Keys......................14
NSentry Key Programming.................14
NGeneral Information....................15
mIlluminated Entry System..................15
mDoor Locks............................16NManual Door Locks.....................16
NPower Door Locks.....................17
NChild Protection Door Lock...............18
mRemote Keyless Entry.....................19
NTo Unlock The Doors And Liftgate..........20
NTo Lock The Doors And Liftgate............21
NUsing The Panic Alarm..................21
NGeneral Information....................23
NTransmitter Battery Service...............23
2

mVehicle Theft Alarm......................24
mLiftgate...............................26
NPower Liftgate Ð If Equipped.............27
mWindows.............................30
NPower Windows.......................30
mOccupant Restraints......................31
NLap/Shoulder Belts.....................32
NLap/Shoulder Belt Untwisting Procedure.....38
NSeat Belt Pretensioners...................40
NEnhanced Driver Seat Belt Reminder System
(BeltAlertŸ)..........................40
NSeat Belts And Pregnant Women............41NSeat Belt Extender......................42
NDriver And Front Passenger Supplemental
Restraint System - Airbag................43
NSide Airbags Supplemental Restraint System
(SRS) Ð If Equipped....................50
NChild Restraint........................53
mEngine Break-In Recommendations...........61
mSafety Tips............................62
NExhaust Gas..........................62
NSafety Checks You Should Make Inside The
Vehicle..............................62
NPeriodic Safety Checks You Should Make
Outside The Vehicle....................63
10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

The Sentry Key Immobilizer System does not need to be
armed or activated. Operation of the system is automatic
regardless of whether or not the vehicle is locked or
unlocked. During normal operation, the Theft Alarm/
Immobilizer Light will come on for three (3) seconds
immediately after the ignition switch is turned on for a
bulb check. Afterwards, if the bulb remains on, this
indicates a problem with the electronics.
If the bulb begins to flash after the bulb check, this
indicates that an invalid key has been used to start the
vehicle. Both of these conditions will result in the engine
being shut off after two (2) seconds of running.
Keep in mind that a key which has not been programmed
is also considered an invalid key even if it is cut to fit the
ignition lock cylinder for that vehicle.
If the Theft Alarm/Immobilizer Light comes on during
normal vehicle operation (vehicle has been running forlonger than 10 seconds), a fault has been detected in the
electronics and the vehicle should be serviced as soon as
possible.
NOTE:
²The Sentry Key Immobilizer System is not compatible
with remote starting systems. Use of these systems
may result in vehicle starting problems and loss of
security protection.
²Exxon/Mobil Speed Pass,Ÿ additional Sentry Keys, or
any other transponder equipped components on the
same keychain willnotcause a key-related (transpon-
der) fault unless the additional part isphysically held
against the ignition keybeing used when starting the
vehicle. Cell phones, pagers, or other RF electronics
will not cause interference with this system.
All of the keys provided with your new vehicle have
been programmed to the vehicle electronics.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13
2

Replacement Keys
NOTE:Only keys that have been programmed to the
vehicle electronics can be used to start the vehicle. Once
a Sentry Key has been programmed to a vehicle, it can
not be programmed to any other vehicle.
At the time of purchase, the original owner is provided
with a four digit PIN number. This number is required
for dealer replacement of keys. Duplication of keys may
be performed at an authorized dealer or by using the
Customer Key Programming procedure. This procedure
consists of programming a blank key to the vehicle
electronics. A blank key is one which has never been
programmed.
NOTE: When having the Sentry Key Immobilizer
System serviced, bring all vehicle keys with you to the
dealer.
Sentry Key Programming
You can program new keys to the system if you have two
valid sentry keys by performing the following procedure:
1. Cut the additional Sentry Key Transponder blank(s) to
match the ignition switch lock cylinder key code.
2. Insert the first valid key into the ignition switch and
turn the ignition switch ON for at least 3 seconds but no
longer than 15 seconds. Turn the ignition switch OFF and
remove the first key.
3. Insert the second valid key and turn the ignition
switch ON within 15 seconds. After ten seconds a chime
will sound and the Theft Alarm Light will begin to flash.
Turn the ignition switch OFF and remove the second key.
4. Insert a blank Sentry Key into the ignition switch and
turn the ignition switch ON within 60 seconds. After 10
seconds a single chime will sound. The Theft Alarm Light
will stop flashing, turn on for 3 seconds; then turn off.
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

To activate the system, open the rear door and move the
child lock control, located near the door's rear latch, to
the ON position.When the child lock system is engaged the door can be
opened only by using the outside door handle even
though the inside door lock is in the unlocked position.
REMOTE KEYLESS ENTRY
This system allows you to lock or unlock the doors and
liftgate, and activate the panic alarm from distances up to
about 23 feet (7 meters) using a hand held radio trans-
mitter. The transmitter need not be pointed at the vehicle
to activate the system.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19
2

To lock the doors and liftgate:
Press and release the LOCK button on the transmitter to
lock all doors and liftgate. The horn will chirp once to
acknowledge the signal. If desired, the ªSound Horn On
Lockº feature can be turned on and off by referring to the
Customer Programmable Features of the ªElectronic Ve-
hicle Information Center (EVIC)º section or by following
these steps.
1. Press the LOCK button for 4 to 10 seconds.
2. While the LOCK button is pressed (after 4 seconds),
press the PANIC button. Release both buttons.
The ªSound Horn On Lockº feature can be reactivated by
repeating this procedure.
Using The Panic Alarm:
To turn the panic alarm feature ON or OFF, press and
hold the PANIC button on the transmitter for at least one
second and release. When the panic alarm is on, the
headlights and park lights will flash, the horn will pulse
on and off and the interior lights will turn on.
The panic alarm will stay on for 3 minutes unless you
turn it off by pressing the PANIC button a second time or
turn the ignition switch to the ON position.
NOTE:When you turn off the panic alarm by pressing
the PANIC button a second time, you may have to be
closer to the vehicle due to the radio frequency noises of
the system.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21
2

2. Remove and replace the battery. Avoid touching the
new battery with your fingers. Skin oils may cause
battery deterioration. If you touch a battery, clean it with
rubbing alcohol.
3. To reassemble the transmitter case, snap the two
halves together. Make sure there is an even ªgapº be-
tween the two halves. Test transmitter operation.
VEHICLE THEFT ALARM
This system monitors the vehicle doors and ignition
switch for unauthorized entry or operation. When the
alarm is activated, the system provides both audible and
visual signals. The horn will pulse, headlights/park
lights will flash, the Vehicle Theft Alarm/Immobilizer
light, located on the instrument panel below the Elec-
tronic Vehicle Information Center buttons will flash, and
the vehicle will not start. If the alarm is triggered and no
action is taken to disarm it, the system will turn off thehorn after three minutes and after 15 minutes of light
only operation the system will then rearm itself.
To arm the system:Remove the key from the ignition
switch and either:
1. Press a power door lock switch while the driver's or
passenger's door is open.
2. Press the LOCK button on the keyless entry transmit-
ter.
After the last door is closed, or if all doors are closed, the
system will arm itself in about 16 seconds. During that
time, the Vehicle Theft Alarm/Immobilizer light will
flash. If it does not illuminate, the system is not arming.
If you open a door during this arming period, the system
will cancel the arming process. You must repeat one of
the previously described arming sequences to rearm the
system.
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

To disarm the system:Press the UNLOCK button on the
keyless entry transmitter. Also, using a valid sentry key
and moving the ignition switch to the ON/START posi-
tion will disarm the system. If you disarm the system and
access the liftgate area, the system must be rearmed, as
described previously, when closing the liftgate. If some-
thing has triggered the system in your absence, the horn
will sound three times when you disarm the system.
Check the vehicle for tampering.
NOTE:
²The driver's door key cylinder and the liftgate button
on the keyless entry transmitter cannot arm or disarm
the system.
²Once the alarm is set, and the liftgate button on the
keyless entry transmitter is pressed, on a non-power
liftgate vehicle, you have a 30 second one time accessinto the liftgate area. If the liftgate is not opened within
30 seconds the liftgate will automatically re-lock
within 10 seconds.
²The system remains armed during liftgate entry, press-
ing the liftgate button will not disarm the system, if
someone enters the vehicle through the liftgate and
opens any door the alarm will sound.
²When the system is armed, the doors can not be
unlocked from the interior power door lock switches.
The Vehicle Theft Alarm system is designed to protect
your vehicle, however, you can create conditions where
the system will give you a false alarm. If one of the
previously described arming sequences has occurred, the
system will arm regardless of whether you are in the
vehicle or not. If you remain in the vehicle and open a
door, the alarm will sound. If this occurs, disarm the
system.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25
2

The alarm system will be activated when the battery is
connected if the system was previously armed. The
exterior lights will flash, the horn will sound, and the
ignition will not start the vehicle. If this occurs, disarm
the system.
LIFTGATE
The liftgate can be unlocked using the remote keyless
entry or by activating the power door lock switches
located on the front doors.
Once unlocked, the liftgate can be opened or closed. To
open the liftgate, depress the liftgate release switch
located in the exterior handle and pull the liftgate open
with one fluid motion.The liftgate will not manually open if the vehicle is in
gear or the vehicle speed is above 0 mph (0 km/h).
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Adding Fuel........................... 240
Adding Washer Fluid..................109,285
Additives, Fuel......................... 238
Adjustable Pedals........................ 99
Air Conditioner Maintenance............... 281
Air Conditioning Filter.................192,282
Air Conditioning Refrigerant............... 281
Air Conditioning System................183,281
Air Pressure, Tires....................... 223
Airbag................................ 43
Airbag Deployment....................... 50
Airbag Light.....................47,52,63,145
Airbag Maintenance....................... 52
Airbag, Side............................ 50
Alarm System........................... 24
Alignment and Balance................... 229
All Wheel Drive...................205,230,298
Alterations/Modifications, Vehicle............. 7
Antifreeze Disposal...................... 290Antifreeze (Engine Coolant)..............287,288
Anti-Lock Brake System................... 208
Anti-Lock Warning Light.................. 139
Anti-Theft Security Alarm.................. 24
Appearance Care........................ 300
Auto Down Power Windows................ 31
Automatic Dimming Mirror................. 70
Automatic Door Locks...................17,18
Automatic Headlights.................... 105
Automatic Temperature Control............. 183
Automatic Transaxle...................201,295
Adding Fluid......................... 313
Filter............................... 297
Fluid and Filter Changes................. 297
Fluid Level Check...................... 296
Interlock System....................... 202
Reset Mode.......................... 202
Selection Of Lubricant................295,313
Shifting............................. 203
346 INDEX
