The recirculation control is now programmed so that the
recirculation mode willnotreset to the outside air mode
when the engine is restarted. The recirculation program-
ming can be changed back by repeating this procedure.
Rear Fan Operation
To operate the rear fan, press theREARbutton. The first
time this button is pressed theREAR AUTOdisplay
will illuminate indicating that the rear fan speed is
automatically controlled. To manually control the rear
fan speed, press theREARbutton again and only
REARwill illuminate in the display. This allows the rear
seat occupants to control the rear fan speed using the
switch located in the center console between the second
row seats. By pressing theREARbutton a third time,
the rear fan will shut off.
When the ATC display readsREAR AUTOor when the
rear fan is off, the switch located in the center console
between the second row seats is not functional. When theATC display readsREAR, only the rear seat occupants
can control the rear fan speed from the rear switch. When
in the“REAR”mode, the rear occupants can set the rear
switch to any fan speed includingOFF,orAUTO.
While in theAUTOposition, the rear fan speed will be
automatically controlled.
Summer Operation
The engine cooling system in air conditioned vehicles
must be protected with a high-quality antifreeze coolant
to provide proper corrosion protection and to protect
against engine overheating. A 50% solution of ethylene
glycol antifreeze coolant in water is recommended. Refer
to section 7, Maintenance Procedures, of this manual for
proper coolant selection.
UNDERSTANDING YOUR INSTRUMENT PANEL 241
4

Winter Operation
To insure the best possible heater and defroster perfor-
mance, make sure the engine cooling system is function-
ing properly and the proper amount, type, and concen-
tration of coolant is used. Refer to section 7, Maintenance
Procedures, of this manual for proper coolant selection.
Use of the air Recirculation mode during winter months
is not recommended because it may cause window
fogging.
Vacation Storage
Anytime you store your vehicle, or keep it out of service
(i.e. vacation) for two weeks or more, run the air condi-
tioning system at idle for about five minutes in the fresh
air and high blower setting. This will insure adequate
system lubrication to minimize the possibility of com-
pressor damage when the system is started again.
Window Fogging
Vehicle windows tend to fog on the inside in mild rainy
or humid weather. To clear the windows, use the A/C
button to reduce the humidity inside the vehicle.
Fogging on the inside of the windshield can be quickly
removed by pressing the defrost button and increasing
the blower speed.
Do not use the Recirculation mode without the A/C
button for long periods as fogging may occur.
Outside Air Intake
Before driving, always make sure the air intake located
directly in front of the windshield is free of obstructions
such as leaves, ice, or snow, which could reduce airflow
and/or plug the water drain tube inside the plenum.
242 UNDERSTANDING YOUR INSTRUMENT PANEL

A/C Air Filter
The climate control system filters out dust, pollen and
some odors from the air. Strong odors can not be totally
filtered out. Refer to section 7“Air Conditioning”for
filter replacement instructions.
Outside Temperature Display
The outside temperature can be shown in the ATC
display by pressing theOUTSIDE TEMPbutton. After
pressing this button, the front seat passenger’s tempera-
ture setting display will be replaced with the current
outside temperature. Press theOUTSIDE TEMPbutton
again or press the passenger’sTEMPbutton to return
the display to the passenger’s temperature setting.
Electric Rear Window Defroster
Press this button to turn on the rear window
defroster and the heated side mirrors. A light inthe button will illuminate to indicate the rear window
defroster is ON. The defroster automatically turns off
after about 10 minutes of operation.
CAUTION!
To avoid damaging the electrical conductors of the
rear window defroster, do not use scrapers, sharp
instruments, or abrasive window cleaners on the
interior surface of the window.
Labels can be peeled off after soaking with warm
water.
UNDERSTANDING YOUR INSTRUMENT PANEL 243
4

STARTING AND OPERATING
CONTENTS

Starting Procedures.....................248
▫Normal Starting......................248

Engine Block Heater—If Equipped.........250

Automatic Transmission..................251
▫Brake/Transmission Interlock System.......251
▫Automatic Transmission Ignition Interlock
System.............................252
▫Four Speed Automatic Transmission........252

AutoStick............................254▫AutoStick Operation...................254
▫AutoStick General Information............254

All Wheel Drive—If Equipped............255

Parking Brake.........................256

Brake System..........................258
▫Anti-Lock Brake System................258

Power Steering........................261

Traction Control—If Equipped............262

Tire Safety Information...................263
5

▫Tire Markings........................263
▫Tire Identification Number (TIN)..........267
▫Tire Loading And Tire Pressure...........268

Ti re s—General Information................272
▫Tire Pressure.........................272
▫Tire Inflation Pressures.................273
▫Radial-Ply Tires......................276
▫Compact Spare Tire—If Equipped.........276
▫Limited Use Spare—If Equipped.........277
▫Tire Spinning........................278
▫Tread Wear Indicators..................278
▫Replacement Tires.....................279
▫Alignment And Balance.................280
All Wheel Drive (AWD)—If Equipped.......281

Tire Pressure Monitor System—If Equipped . . . 281
▫1,2,3, Or 4 Tire(s) Low Pressure...........282
▫1,2,3, Or 4 Tire(s) High Pressure...........282
▫Service Tire Pressure System/See Owner’s
Manual............................282
▫General Information...................284

Tire Chains...........................284

Snow Tires...........................285

Tire Rotation Recommendations............286

Fuel Requirements......................287
▫Reformulated Gasoline.................287
▫Gasoline/Oxygenate Blends..............288
246 STARTING AND OPERATING

▫MMT In Gasoline.....................288
▫Materials Added To Fuel................289
▫Fuel System Cautions..................289
▫Carbon Monoxide Warnings..............290

Adding Fuel..........................290
▫Fuel Filler Cap (Gas Cap)...............290

Vehicle Loading........................292
▫Vehicle Certification Label...............292
▫Gross Vehicle Weight Rating (GVWR).......292▫Gross Axle Weight Rating (GAWR).........292
▫Overloading.........................293
▫Loading............................293

Trailer Towing.........................294
▫Towing Requirements..................295

Recreational Towing (Behind Motorhome, Etc.) . . 298
▫Towing This Vehicle Behind Another Vehicle
(Flat Towing With All Four Wheels On The
Ground)............................298
STARTING AND OPERATING 247
5

STARTING PROCEDURES
CAUTION!
Long periods of engine idling, especially at high
engine speeds, can cause excessive exhaust tempera-
tures which can damage your vehicle. Do not leave
your vehicle unattended with the engine running.
WARNING!
Do not leave animals or children inside parked
vehicles in hot weather; interior heat build up may
cause serious injury or death.
The gear selector must be in the NEUTRAL or PARK
position before you can start the engine. Apply the brakes
before shifting into any driving gear.
Normal Starting
Normal Startingof either a cold or a warm engine is
obtained without pumping or depressing the accelerator
pedal. Turn the key to the“START”position and release
when the engine starts. If the engine has not started
within 3 seconds, slightly depress the accelerator pedal
while continuing to crank. If the engine fails to start
within 15 seconds, turn the key to the“OFF”position,
wait 10 to 15 seconds, then repeat the normal starting
procedure.
Extremely Cold Weather(below
29°Cor
20°F) To
insure reliable starting at these temperatures, use of an
externally powered electric engine block heater (available
from your dealer) is recommended.
248 STARTING AND OPERATING

WARNING!
•Do not attempt to push or tow your vehicle to get
it started. Vehicles equipped with an automatic
transmission cannot be started this way. Un-
burned fuel could enter the catalytic converter and
once the engine has started, ignite and damage the
converter and vehicle. If the vehicle has a dis-
charged battery, booster cables may be used to
obtain a start from a booster battery or the battery
in another vehicle. This type of start can be
dangerous if done improperly. See section 6 of
this manual for the proper jump starting proce-
dures and follow them carefully.
•Never pour fuel or other flammable liquid into
the throttle body air inlet opening in an attempt to
start the vehicle. This could result in flash fire
causing serious personal injury.
If Engine Fails to Start
If the engine fails to start after you have followed the
“NORMAL STARTING”procedure, it may be flooded.
Push the accelerator pedal all the way to the floor and
hold it there while cranking the engine. This should clear
any excess fuel in case the engine is flooded.
CAUTION!
To prevent damage to the starter, do not crank the
engine for more than 15 seconds at a time. Wait 10 to
15 seconds before trying again.
If the engine has been flooded, it may start to run, but not
have enough power to continue running when the key is
released. If this occurs, continue cranking up to 15
seconds with the accelerator pedal pushed all the way to
STARTING AND OPERATING 249
5

the floor. Release the accelerator pedal and the key once
the engine is running smoothly. Do not overspeed en-
gine.
If the engine shows no sign of starting after two 15
second periods of cranking with the accelerator pedal
held to the floor, the“NORMAL STARTING”procedure
should be repeated.
After Starting
The idle speed will automatically decrease as the engine
warms up.
ENGINE BLOCK HEATER—IF EQUIPPED
The engine block heater warms engine coolant and
permits quicker starts in cold weather. Connect the cord
to a standard 110-115 volt AC electrical outlet with a
grounded, three-wire extension cord.The engine block heater cord is routed under the hood on
the driver side of the vehicle. It has a removable cap that
is located on the driver side of the Integrated Power
Module.
WARNING!
Remember to disconnect the cord before driving.
Damage to the 110-115 volt electrical cord could
cause electrocution.
