airbag off CHRYSLER PACIFICA 2005 1.G Owners Manual

▫To Turn Off“Flash Lights On Lock/Unlock”...23
▫General Information....................23
▫Transmitter Battery Service...............24

Vehicle Theft Alarm......................25

Liftgate...............................27
▫Power Liftgate—If Equipped.............28

Windows.............................30
▫Power Windows.......................30

Occupant Restraints......................32
▫Lap/Shoulder Belts.....................33
▫Lap/Shoulder Belt Untwisting Procedure.....39
▫Seat Belt Pretensioners...................41▫Enhanced Driver Seat Belt Reminder System
(BeltAlert)...........................41
▫Seat Belts And Pregnant Women............42
▫Seat Belt Extender......................43
▫Driver And Front Passenger Supplemental
Restraint System - Airbag................44
▫Child Restraint........................59

Engine Break-In Recommendations...........67

Safety Tips............................68
▫Exhaust Gas..........................68
▫Safety Checks You Should Make Inside The
Vehicle..............................68
▫Periodic Safety Checks You Should Make
Outside The Vehicle....................69
10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

•Interconnecting Wiring
•Knee Impact Bolster
•Driver Inflatable Knee Blocker
•Front Passenger Seat Occupant Classification System
(OCS)
Occupant Classification Module
Passenger Airbag Disabled (PAD) Indicator Light
Interconnecting Wiring
Bladder Assembly
Belt Tension Sensor
How The Airbag System Works
•
TheOccupant Restraint Controller (ORC)determines
if a frontal collision is severe enough to require the
airbags to inflate. Based on the level of collisionseverity, the front control module determines the
proper rate of inflation. The front airbag inflators are
designed to provide different rates of airbag inflation.
•The ORC may modify the rate of inflation based on the
occupant size provided by the Occupant Classification
Module.
•The ORC will not detect side, roll over, or rear impacts.
•The ORC monitors the readiness of the electronic parts
of the system whenever the ignition switch is in the
START or RUN positions. These include all of the
items listed above except the steering wheel and
column, instrument panel and passenger knee bol-
sters. If the key is in the OFF position, in the ACC
position, or not in the ignition, the airbags are not on
and will not inflate.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49
2

Also, the ORC turns on the AIRBAG warning
light and PAD indicator light in the center of
the instrument panel for 6 to 8 seconds for a
self-check when the ignition is first turned on.
After the self-check, the AIRBAG warning light will turn
off. The PAD indicator light will function normally (Refer
to“Passenger Airbag Disable (PAD) Indicator Light”in
this section). If the ORC detects a malfunction in any part
of the system, it turns on the AIRBAG warning light
either momentarily or continuously. A single chime will
sound if the light comes on again after initial start up.WARNING!
Ignoring the AIRBAG warning light in your instru-
ment panel could mean you won’t have the airbags
to protect you in a collision. If the light does not
come on, stays on after you start the vehicle, or if it
comes on as you drive, have the airbag system
checked right away.
•TheDriver and Passenger Airbag/Inflator Unitsare
located in the center of the steering wheel and the right
side of the instrument panel. When the ORC and
impact sensors detects a collision requiring the air-
bags, it signals the inflator units. A large quantity of
nontoxic gas is generated to inflate the front airbags.
Different airbag inflation rates may be possible based
on collision severity and occupant size. The steering
wheel hub trim cover and the upper right side of the
instrument panel separate and fold out of the way as
50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

The ORC will not allow front airbag deployment in the
event of a collision for occupants classified into the
empty or child size categories. The PAD indicator light
will illuminate indicating that the Passenger Airbag is
OFF when the OCS has determined that the occupant size
category is a child. Also, when the seat is empty or an
object that weighs less than a predetermined threshold is
placed on the seat, the light will remain OFF. (The PAD
indicator light is an amber light located on the center of
the instrument panel above the climate controls.)
Passenger Airbag Disabled Light
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53
2

For almost all sizes of properly seated adults, the airbag
will be enabled in the event of a collision. For small
teenagers and some small adults, depending on size, the
airbag may or may not be enabled in the event of a
collision. Both drivers and passengers should always use
the PAD indicator light as an indication if the front
passenger is properly positioned or not. If the PAD
indicator light comes on when an adult is in the passen-
ger seat, have the passenger re-position themselves in the
seat until the light goes out.
Remember, if the PAD indicator light is illuminated the
passenger front airbag will not inflate. For properly
installed child restraint systems and children properly
seated on the front passenger seat, the airbag will be
disabled. If at all possible, place children 12 years and
younger in a back seat.
•TheOccupant Classification Module (OCM)is lo-
cated beneath the front passenger seat. The OCMclassifies the occupant into one of three size categories
based on the input from the Bladder Assembly and
Belt Tension Sensor. The size categories include empty,
child, and adult. The OCM sends the Occupant Clas-
sification to the ORC to identify if a front passenger
airbag is allowed. If a fault is present, the AIRBAG
warning light is illuminated.
•ThePassenger Airbag Disabled (PAD) Indicator
Lightindicates to the driver and passenger when the
airbag is turned OFF in the presence of a properly
seated occupant. When the PAD indicator light is
illuminated, the airbag is OFF. Also, when the Occu-
pant Classification System (OCS) detects either an
empty seat of a weight less than the predetermined
occupant threshold, the ORC will not illuminate the
PAD indicator light even though the airbag is turned
off. When the OCS detects an adult the PAD indicator
light will be off, and the airbag will be enabled.
54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

However, if you haven’t healed significantly within a
few days, or if you have any blistering, see your doctor
immediately.
•As the airbags deflate you may see some smoke-like
particles. The particles are a normal by-product of the
process that generates the nontoxic gas used for airbag
inflation. These airborne particles may irritate the skin,
eyes, nose, or throat. If you have skin or eye irritation,
rinse the area with cool water. For nose or throat
irritation, move to fresh air. If the irritation continues,
see your doctor. If these particles settle on your
clothing, follow the garment manufacturer’s instruc-
tions for cleaning.
•It is not advisable to drive your vehicle after the
airbags have deployed. If you are involved in another
collision, the airbags will not be in place to protect you.
WARNING!
Deployed airbags, seat belt pretensioners and driver
inflatable knee blocker cannot protect you in an-
other collision. Have the airbags, seat belt preten-
sioners, driver inflatable knee blocker and the front
passenger seat belt retractor assembly, replaced by
an authorized dealer as soon as possible. Also, have
the Occupant Classification System serviced as well.
Enhanced Accident Response
If the airbags and seat belt pertensioners deploy after an
impact and the electrical system remains functional,
vehicles equipped with power door locks will unlock
automatically. In addition, approximately 10 seconds
after the vehicle has stopped moving, the interior lights
will illuminate until the ignition switch is turned off.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57
2

22. Airbag Light
This light turns on and remains on for 6 to 8
seconds as a bulb check when the ignition
switch is first turned ON. If the light is not on
during starting, stays on, or turns on while
driving, have the system inspected by an authorized
dealer as soon as possible.
23. Electronic Vehicle Information Center Display—If
Equipped
When the appropriate conditions exist, this display
shows the Electronic Vehicle Information Center (EVIC)
messages.
24. Engine Temperature Warning Light
This light warns of an overheated engine condi-
tion. If this light is accompanied by a continuous
chime, the engine temperature is critically hot, and
the vehicle should be turned off immediately. The vehicle
should be serviced as soon as possible.25. Liftgate Ajar—If Equipped
This light turns on if the liftgate is not com-
pletely closed.
26. Door Ajar Light—If Equipped
This light turns on if a door is not completely
closed.
27. Washer Fluid Light—If Equipped
This light turns on when the washer fluid level
falls below approximately 1/4 filled. The light will
remain on until fluid is added.
UNDERSTANDING YOUR INSTRUMENT PANEL 173
4
