Procedure For Checking Fluid Level
The fluid level in the automatic transmission should be
checked whenever the vehicle is serviced. Operation with
an improper fluid level will greatly reduce the life of the
transmission and of the fluid.
To properly check the automatic transmission fluid level,
the following procedure must be used:
1. The vehicle must be on level ground.
2. The engine should be running at curb idle speed for a
minimum of 60 seconds.3. Fully apply parking brake.
4. Place the gear selector momentarily in each gear
position ending with the lever in P (PARK). Wipe the area
around the dipstick clean to eliminate the possibility of
dirt entering the transmission.
5. Remove the dipstick and determine if the fluid is hot
or warm. Hot fluid is approximately 180°F (82°C), which
is the normal operating temperature after the vehicle has
been driven at least 15 miles (24 km). The fluid cannot be
comfortably held between the finger tips. Cold is when
the fluid is below 80°F (27°C).
6. Wipe the dipstick clean and reinsert until seated.
Remove dipstick and note reading.
a. If the fluid is hot, the reading should be in the
crosshatched area marked “HOT” (between the upper
two holes in the dipstick).
MAINTAINING YOUR VEHICLE 393
7

•Taxi, police, or delivery service (commercial ser-
vice).
•Off-road or desert operation.
NOTE:IfANYof these apply to you then change your
engine oil every 3,000 miles (5 000 km) or 3 months,
whichever comes first and follow schedule “B” of the
Maintenance Schedulessection of this manual.
NOTE:Most vehicles are operated under the conditions
listed for ScheduleB.
Second is Schedule“A”. It is for vehicles that are not
operated under any of the conditions listed under Sched-
uleB.
Use the schedule that best describes your driving condi-
tions. Where time and mileage are listed, follow the
interval that occurs first.NOTE:Under no circumstances should oil change in-
tervals exceed 6000 miles (10 000 km) or 6 months
whichever comes first.
CAUTION!
Failure to perform the required maintenance items
may result in damage to the vehicle.
At Each Stop for Fuel
•Check the engine oil level about 5 minutes after a fully
warmed engine is shut off. Checking the oil level while
the vehicle is on level ground will improve the accu-
racy of the oil level reading. Add oil only when the
level is at or below the ADD or MIN mark.
•Check the windshield washer solvent and add if
required.
MAINTENANCE SCHEDULES 417
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Once a Month
•Check tire pressure and look for unusual wear or
damage.
•Inspect the battery and clean and tighten the terminals
as required.
•Check the fluid levels of coolant bottle, brake master
cylinder and transmission, add as needed.
•Check all lights and all other electrical items for correct
operation.At Each Oil Change
•Change the engine oil filter.
•Inspect the exhaust system.
•Inspect the brake hoses.
•Inspect the CV joints and front suspension compo-
nents.
•Check the automatic transmission fluid level.
•Check the coolant level, hoses, and clamps.
418 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 75, 000 78, 000 81, 000 84, 000 87, 000 90, 000
(Kilometers) (120 000) (125 000) (130 000) (134 000) (139 000) (144 000)
Change engine oil and engine oil filter.XXXXXX
Rotate TiresXXX
Inspect the brake linings.XX
Inspect the engine air cleaner filter, replace if necessary. *XXXX
Replace theengine air cleaner filter X X
Replace thespark plugs. X
Inspect the tie rod ends and boot seals. (Front & Rear)X
Check thePCV valve
and replace if necessary. Not re-
quired if previously changed.*X
Inspect the serpentine drive belt, replace if necessary. ‡XX
Change the All Wheel Drive power transfer unit fluid.
(See the note at the end of this chart.)XX
Change the All Wheel Drive (AWD) rear carrier fluid.
(See note at the end of this chart)X
Replace the air conditioning filter.X
424 SCHEDULE “B”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 42, 000 48, 000 54, 000 60, 000 66, 000 72, 000
(Kilometers) (67 000) (77 000) (86 000) (96 000) (106 000) (115 000)
[Months] [42] [48] [54] [60] [66] [72]
Change engine oil and engine oil filter.X X XXXX
Rotate TiresX X XXXX
Inspect the brake linings.XX
Inspect the engine air cleaner filter, replace if
necessary. *XXX XX
Replace theengine air cleaner filter. X
Inspect the tie rod ends and boot seals. (Front
& Rear)X
Check thePCV valve
and replace, if neces-
sary.*X
Inspect the serpentine drive belt, replace if nec-
essary. ‡XX
Flush and replace the engine coolant at 60
months or 100,000 miles, whichever occurs first.X
Replace the air conditioning filter.XXX
SCHEDULE “A” 431
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 78, 000 84, 000 90, 000 96, 000 100, 000
(Kilometers) (125 000) (134 000) (144 000) (154 000) (160 000)
[Months] [78] [84] [90] [96]
Change engine oil and engine oil filter.XXXX
Rotate TiresXXXX
Inspect the brake linings.X
Inspect the engine air cleaner filter, replace if neces-
sary. *XX XX
Replace theengine air cleaner filter. X
Inspect the tie rod ends and boot seals. (Front &
Rear)X
Check and replace thePCV valve, if necessary.*X
Inspect the serpentine drive belt, replace if neces-
sary. ‡X
Replace thespark plugs.X
Flush and replace the engine coolant at 60 months
or 100,000 miles, whichever comes first.X
Replace the air conditioning filter.XX
432 SCHEDULE “A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 102, 000 108, 000 114, 000 120, 000
(Kilometers) (163 000) (173 000) (182 000) (192 000)
[Months] [102] [108] [114] [120]
Change engine oil and engine oil filter.XXXX
Rotate TiresXXXX
Inspect the brake linings.X
Inspect the engine air cleaner filter, replace if necessary. *XXX
Replace theengine air cleaner filter. X
Replace engine timing belt.X
Inspect the tie rod ends and boot seals. (Front & Rear)X
Check thePCV valveand replace, if necessary.*X
Inspect the serpentine drive belt, replace if necessary. ‡XX
Flush and replace the engine coolant at 120 months, if not
done at 100,000 miles (160 000 km).X
Replace the air conditioning filter.XX
SCHEDULE “A” 433
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 126, 000 132, 000 138, 000 144, 000 150, 000
(Kilometers) (202 000) (211 000) (221 000) (230 000) (240, 000)
[Months] [126] [132] [138] [144] [150]
Change engine oil and engine oil filter.XXXXX
Rotate TiresXXXXX
Inspect the brake linings.XX
Inspect the engine air cleaner filter, replace if neces-
sary. *XXXX
Replace theengine air cleaner filter.X
Inspect the tie rod ends and boot seals. (Front & Rear)X
Check thePCV valve
and replace, if necessary.*X
Inspect the serpentine drive belt, replace if necessary. ‡XX
Replace the air conditioning filter.XX
* This maintenance is recommended by the manufacture
to the owner but is not required to maintain the emis-
sions warranty.‡ This maintenance is not required if previously replaced.
Inspection and service should also be performed anytime a
malfunction is observed or suspected. Retain all receipts.
434 SCHEDULE “A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Selection Of Lubricant................392,413
Shifting............................. 272
Special Additives...................... 394
Automatic Transmission................... 392
Adding Fluid......................... 393
Fluid and Filter Changes................. 394
Fluid Change......................... 394
Fluid Level Check...................... 393
Fluid Type........................... 392
Autostick...........................151,274
Ball Joints............................. 380
Battery............................... 376
Gas Caution.......................... 377
Jump Starting......................... 354
Keyless Transmitter Replacement (RKE)....... 25
Bearings.............................. 396
Belts, Drive............................ 374
Body Mechanism Lubrication............... 381B-Pillar Location........................ 293
Brake, Parking.......................... 276
Brake System........................278,389
Anti-Lock (ABS)....................... 279
Fluid Check.......................390,413
Hoses.............................. 389
Warning Light........................ 182
Brakes.............................278,389
Brake/Transmission Interlock............... 271
Break-In Recommendations, New Vehicle........ 79
Bulb Replacement....................... 406
Bulbs, Light............................ 406
Calibration, Compass..................... 197
Camera, Rear........................... 146
Capacities, Fluid........................ 411
Caps, Filler
Fuel................................ 321
Oil (Engine).......................372,373
INDEX 447
10

Radiator (Coolant Pressure)............... 386
Car Washes............................ 397
Carbon Monoxide Warning................. 321
Cargo Area Cover....................... 167
Cargo Compartment
Luggage Carrier....................... 169
Cargo Tie-Downs........................ 168
Cassette Tape and Player Maintenance......... 239
Catalytic Converter...................... 375
Caution, Exhaust Gas...................79,382
CD (Compact Disc) Changer..........208,218,221
CD (Compact Disc) Player......202,206,212,216,221
CD (Compact Disc) Player Maintenance........ 240
Cellular Phone........................91,240
Chains, Tire............................ 306
Changing A Flat Tire..................... 346
Chart, Tire Sizing........................ 290
Check Engine Light (Malfunction
Indicator Light)......................185,367Child Restraint........................67,69
Child Restraint Tether Anchors.............71,74
Child Safety Locks........................ 31
Child Seat.............................. 76
Clean Air Gasoline....................... 318
Cleaning
Wheels............................. 398
Climate Control......................... 240
Clock.............................199,200
Compact Disc (CD) Maintenance............. 240
Compact Spare Tire...................... 301
Compass.............................. 197
Compass Calibration..................... 197
Compass Variance....................... 198
Computer, Trip/Travel.................... 199
Console.............................. 166
Console, Floor.......................... 166
Console, Overhead....................... 153
Contract, Service........................ 440
