spark plugs replace CHRYSLER PACIFICA 2007 1.G Owners Manual

MAINTAINING YOUR VEHICLE
CONTENTS

4.0L Engines..........................364

3.8L Engines..........................365

Onboard Diagnostic System — OBD II........366
▫Loose Fuel Filler Cap Message............366

Emissions Inspection And Maintenance
Programs............................367

Replacement Parts......................368

Dealer Service.........................369

Maintenance Procedures..................369▫Engine Oil..........................369
▫Engine Oil Filter......................374
▫Drive Belts — Check Condition And Tension . . 374
▫Spark Plugs.........................374
▫Engine Air Cleaner Filter................374
▫Catalytic Converter....................375
▫Maintenance-Free Battery................376
▫Air Conditioner Maintenance.............378
▫Power Steering — Fluid Check............379
7

Engine Oil Filter
The engine oil filter should be replaced at every engine
oil change.
Engine Oil Filter Selection
This manufacture’s engines have a full-flow type oil filter.
Use a filter of this type for replacement. The quality of
replacement filters varies considerably. Only high quality
filters should be used to assure most efficient service.
Mopar Engine Oil Filters are a high quality oil filter and
are recommended.
Drive Belts — Check Condition and Tension
At the mileage indicated in the maintenance schedule, all
belts should be checked for condition and proper tension.
Improper belt tension can cause belt slippage and failure.
Belts should be inspected for evidence of cuts, cracks, or
glazing, and replaced if there is indication of damage
which could result in belt failure. Low generator belt
tension can cause battery failure.Also check belt routing to make sure there is no interfer-
ence between the belts and other engine components.
Spark Plugs
Spark plugs must fire properly to assure engine perfor-
mance and emission control. New plugs should be in-
stalled at the specified mileage. The entire set should be
replaced if there is any malfunction due to a faulty spark
plug. Malfunctioning spark plugs can damage the cata-
lytic converter. For proper type of replacement spark
plugs, refer to the “Vehicle Emission Control Informa-
tion” label in the engine compartment.
Engine Air Cleaner Filter
Under normal driving conditions, replace the air filter at
the intervals shown on Schedule “A”. If, however, you
drive the vehicle frequently under dusty or severe con-
ditions, the filter element should be inspected periodi-
cally and replaced if necessary at the intervals shown on
Schedule “B”.
374 MAINTAINING YOUR VEHICLE

Miles 75, 000 78, 000 81, 000 84, 000 87, 000 90, 000
(Kilometers) (120 000) (125 000) (130 000) (134 000) (139 000) (144 000)
Change engine oil and engine oil filter.XXXXXX
Rotate TiresXXX
Inspect the brake linings.XX
Inspect the engine air cleaner filter, replace if necessary. *XXXX
Replace theengine air cleaner filter X X
Replace thespark plugs. X
Inspect the tie rod ends and boot seals. (Front & Rear)X
Check thePCV valve
and replace if necessary. Not re-
quired if previously changed.*X
Inspect the serpentine drive belt, replace if necessary. ‡XX
Change the All Wheel Drive power transfer unit fluid.
(See the note at the end of this chart.)XX
Change the All Wheel Drive (AWD) rear carrier fluid.
(See note at the end of this chart)X
Replace the air conditioning filter.X
424 SCHEDULE “B”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 138, 000 141, 000 144, 000 147, 000 150, 000
(Kilometers) (221 000) (226 000) (230 000) (235 000) (240 000)
Change engine oil and engine oil filter.XXXXX
Rotate TiresXXX
Inspect the brake linings.X
Inspect the engine air cleaner filter, replace if neces-
sary. *XXXX
Replace theengine air cleaner filter.X
Replace thespark plugs.X
Inspect the serpentine drive belt, replace if neces-
sary. ‡X
Inspect the tie rod ends and boot seals. (Front &
Rear)X
Inspect thePCV valveand replace as necessary.*X
Change the All Wheel Drive (AWD) power transfer
unit fluid. (See note at the end of this chart)X
428 SCHEDULE “B”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 78, 000 84, 000 90, 000 96, 000 100, 000
(Kilometers) (125 000) (134 000) (144 000) (154 000) (160 000)
[Months] [78] [84] [90] [96]
Change engine oil and engine oil filter.XXXX
Rotate TiresXXXX
Inspect the brake linings.X
Inspect the engine air cleaner filter, replace if neces-
sary. *XX XX
Replace theengine air cleaner filter. X
Inspect the tie rod ends and boot seals. (Front &
Rear)X
Check and replace thePCV valve, if necessary.*X
Inspect the serpentine drive belt, replace if neces-
sary. ‡X
Replace thespark plugs.X
Flush and replace the engine coolant at 60 months
or 100,000 miles, whichever comes first.X
Replace the air conditioning filter.XX
432 SCHEDULE “A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
