CavityCartridge Fuse Blade FuseDescription
F10 ––Not Used
F11 ––Not Used
F12 –5 Amp Tan Battery Sensor (IBS)
F13 ––Not Used
F14 –10 Amp Red ECM
F15 40 Amp Green –Power Locks
F16 –20 Amp Yellow ECM
F17 30 Amp Pink –Starter
F18 40 Amp Green –CBC Feed #4 (Exterior
Lights #1)
F19 25 Amp Clear –2nd Row Folding Seats
Solenoid LT
F20 –10 Amp Red A/C Compressor Clutch
F21 25 Amp Clear –2nd Row Folding Seat
Solenoid RT
7
IN CASE OF EMERGENCY 549

CavityCartridge Fuse Blade FuseDescription
F22 ––Not Used
F23 ––Not used
F24 –20 Amp Yellow RR Wiper
F25B –10 Amp Red LT RR Door/RT RR Re-
lease Module/Active GrillShutter/Power Mirror
F26 40 Amp Green –Front HVAC Blower Mo-
tor
F27 25 Amp Clear –RR Slide Door Module
F28 –10 Amp Red Diagnostic Port/ USB
Port/ AUX Port/ Video USB Port
F29 ––Not Used
F30 –15 Amp Blue Media Hub 1, 2/ Power
Lumbar
F31 ––Not Used
550 IN CASE OF EMERGENCY

CavityCartridge Fuse Blade FuseDescription
F32 20 Amp Blue –ECM
F33 30 Amp Pink –Power Liftgate Module
F34 25 Amp Clear –RR Door Node
F35 25 Amp Clear –Sunroof Control Module
F36 ––Not Used
F37 40 Amp Green –CBC Feed #4 (Exterior
Lighting #2)
F38 60 Amp Yellow –Vacuum Cleaner
F39 25 Amp Clear –HVAC Blower Motor
F40 ––Not Used
F41 ––Not Used
F42 30 Amp Pink –Folding Seat Module
F43 –20 Amp Yellow Fuel Pump Motor
F44 30 Amp Pink –CBC Feed #1 (Interior
Lights)
7
IN CASE OF EMERGENCY 551

CavityCartridge Fuse Blade FuseDescription
F45 30 Amp Pink –Power Inverter
F46 30 Amp Pink –Driver Door Module
F47 30 Amp Pink –Passenger Door Module
F48 ––Not Used
F49 25 Amp Clear –RR Sliding Door Module
F50 25 Amp Clear –RR Door Module
F51 30 Amp Pink –Front Wiper
F52 30 Amp Pink –Brake Vacuum Pump
F53 ––Not Used
F54 40 Amp Green –ESP-ECU And Valves
F55 –15 Amp Blue Keyless Ignition System/
DVD/Voice RecognitionModule
552 IN CASE OF EMERGENCY

CavityCartridge Fuse Blade FuseDescription
F56 –10 Amp Red Front and Rear HVAC
Control Module/ESP/ ESC
F57 ––Not Used
F58 ––Not Used
F59 30 Amp Pink –7 Way Connector Recep-
tacle — If Equipped
F60 –20 Amp Yellow Rear Cargo APO
F61 –20 Amp Yellow Trailer Tow Right Stop/
Turn — If Equipped
F62 ––Not Used
F63 –20 Amp Yellow Trailer Tow Left Stop/
Turn — If Equipped
F64 –15 Amp Blue RT HID Headlamp
F65 ––Not Used
7
IN CASE OF EMERGENCY 553

CavityCartridge Fuse Blade FuseDescription
F66 –15 Amp Blue Instrument Panel Cluster
(IPC)
F67 –10 Amp Red In Vehicle Temperature
Sensor/Humidity Sensor/Drivers Assist System
Module (DASM)/Park Assist (PAM) – If Equipped
F68 ––Not Used
F69 ––Not Used
F70 ––Not Used
F71 –20 Amp Yellow Horn
F72 –10 Amp Red Heated Mirrors – If
Equipped
F73 30 Amp Pink –Rear Defroster (EBL)
F74 20 Amp Blue –Trailer Tow Backup
554 IN CASE OF EMERGENCY

CavityCartridge Fuse Blade FuseDescription
F75 –5 Amp TanOverhead Console / RR
ISC
F76 –20 Amp Yellow Uconnect/DCSD/
Telematics
F77 –10 Amp Red RR Entertainment Screen
1 And 2/ Media Screen 1And 2/ 3rd Row Row
USB Charge Only/ 2nd
Row YSB Charge Only/ Sunroof/Rainsensor/ CRVMM/
F78 –15 Amp Blue Instrument Cluster/E-
Shifter
F79 –10 Amp Red ICS/Front And Rear
HVAC/ SCCM/ EPB
F80 ––Not Used
7
IN CASE OF EMERGENCY 555

CavityCartridge Fuse Blade FuseDescription
F81 ––Not Used
F82 ––Not Used
F83 20 Amp Blue –TT Park Lights — If
Equipped
F84 40 Amp Green –ESP Motor Pump
F85 –20 Amp Yellow Cigar Lighter
F86 ––Not Used
F87 ––Not Used
F88 –20 Amp Yellow Front Heated Seats
F89 –20 Amp Yellow Rear Heated Seats
F90 ––Not Used
F91 –20 Amp Yellow Front Ventilated Seats/
Heated Steering Wheel
F92 ––Not Used
F93 ––Not Used
556 IN CASE OF EMERGENCY

CavityCartridge Fuse Blade FuseDescription
F94 ––Not Used
F95 –10 Amp Red USB Charge Only Port
F96 –10 Amp Red Occupant Restraint Con-
troller (ORC) (Airbag)
F97 –10 Amp Red Occupant Restraint Con-
troller (ORC) (Airbag)
F98 –15 Amp Blue Left HID Headlamp
F99 30 Amp Pink –Electrical Brake Module/
Trailer Tow — IfEquipped
F100 –10 Amp Red AHLM/Rear Camera/
LBSS/RBSS/CVPM/
Humidity Sensor/In Ve-
hicle Temperature Sensor
7
IN CASE OF EMERGENCY 557

Interior Fuses
The interior fuse panel is located in the passenger compartment on the left side dash panel under the instrument
panel.
CavityBlade Fuse Description
F13 15 Amp Blue Low Beam Left
F32 10 Amp Red Interior Lighting
F36 10 Amp Red Intrusion Module / Siren
F37 7.5 Amp Brown Aux. Switch Bank Module (ASBM)
F38 20 Amp Yellow All Doors Lock/Unlock
F43 20 Amp Yellow Washer Pump Front
F48 20 Amp Yellow Horns
F49 7.5 Amp Brown Lumbar Support
F51 10 Amp Red Driver Window Switch / Power Mirrors – If
Equipped
F53 7.5 Amp Brown UCI Port (USB & AUX)
F89 5 Amp Tan Trunk Lamp
