Page 38 of 592
NOTE:The teal color represents the data while under
Electric power and the blue color represents the data while
under Hybrid power.
Charging Schedule
The third screen within the “Hybrid Electric” App is the
Charging Schedule screen. From this screen you can set
when you want you vehicle to charge. To do so, press the
check box next to the setting “Enable Schedule” until a
check mark appears in the box, from there you can set the
schedule. The Charging Schedule can also be set using the
Uconnect App on your smartphone.
Driving History Screen
Charging Schedule Screen
36 GETTING TO KNOW YOUR VEHICLE
Page 109 of 592
IconDescription
Driver and Passenger Temperature Up and Down Buttons
Provides the driver and passenger with independent temperature control. Push the red button
on the faceplate or touchscreen or press and slide the temperature bar towards the red arrow
button on the touchscreen for warmer temperature settings. Push the blue button on the face-
plate or touchscreen or press and slide the temperature bar towards the blue arrow button on
the touchscreen for cooler temperature settings
SYNC Button
Press the SYNC button on the touchscreen to toggle the Sync feature on/off. The SYNC indica-
tor is illuminated when this feature is enabled. SYNC is used to synchronize the passenger tem-
perature setting with the driver temperature setting. The SYNC feature also synchronizes the
rear passengers’ temperature to the driver temperature setting. Changing the passenger tem-
perature setting while in SYNC will automatically exit this feature.
Faceplate Knob
Touchscreen Buttons
Blower Control
Blower Control is used to regulate the amount of air forced through the climate system. There
are seven blower speeds available. The speeds can be selected using either the blower control
knob on the faceplate or the buttons on the touchscreen.
• Faceplate: The blower speed increases as you turn the blower control knob clockwise from
the lowest blower setting. The blower speed decreases as you turn the blower control knob
counterclockwise.
• Touchscreen: Use the small blower icon to reduce the blower setting and the large blower
icon to increase the blower setting. Blower can also be selected by pressing the blower bar
area between the icons. 3
GETTING TO KNOW YOUR VEHICLE 107
Page 155 of 592
GETTING TO KNOW YOUR INSTRUMENT PANEL
CONTENTS
INSTRUMENT CLUSTER ..................154
▫ Instrument Cluster Descriptions ............155
INSTRUMENT CLUSTER DISPLAY ...........156
▫ Instrument Cluster Display Location and
Controls ............................ .156
▫ Oil Life Reset ........................ .158
▫ KeySense Cluster Messages — If Equipped .....159
▫ Instrument Cluster Display Menu Items .......160
▫ Battery Saver On/Battery Saver Mode Message —
Electrical Load Reduction Actions — If
Equipped ........................... .165
WARNING/INDICATOR LIGHTS AND
MESSAGES ........................... .167
▫ Red Telltale Lights .....................168
▫ Yellow Telltale Lights ....................177
▫ Green Telltale Lights .....................185
▫ Blue Telltale Lights ..................... .189
▫ White Telltale Lights .....................189
ONBOARD DIAGNOSTIC SYSTEM — OBD II . . .190
▫ Onboard Diagnostic System (OBD II)
Cybersecurity ........................ .1914
Page 191 of 592
Blue Telltale Lights
High Beam Indicator Light
Blue TelltaleLight What It Means
High Beam Indicator Light
This indicator shows that the high beam headlights are on. Push the multifunction control lever
away from you to switch the headlights to high beam. Pull the lever toward you to switch the
headlights back to low beam. Pull the lever toward you for a temporary high beam on,
flash to
pass scenario.
White Telltale Lights
Adaptive Cruise Control (ACC) Ready Light — If Equipped
White Telltale
Light What It Means
Adaptive Cruise Control (ACC) Ready Light — If Equipped
This light will turn on when the vehicle equipped with Adaptive Cruise Control (ACC) has been
turned on and in the READY state. Refer to “Adaptive Cruise Control (ACC) — If Equipped” in
“Starting And Operating” for further information.
4
GETTING TO KNOW YOUR INSTRUMENT PANEL 189
Page 402 of 592
CavityCartridge Fuse Blade FuseDescription
F06 –15 Amp Blue Low Temp Active Pump
F07 –25 Amp Clear Ignition Coil/Fuel Injector
F08 –25 Amp Clear Amplifier / ANC
F09 ––Not Used
F10 –15 Amp Blue High Temp Aux Pump &
HV Electric Coolant Htr Enable
F11 –15 Amp Blue ELCM / FTIV
F12 –5 Amp Tan Battery Sensor (IBS)
F13 ––Not Used
F14A –10 Amp Red Media Hub 1, 2, 3
F14B – Pwr Lumbar Switch
F15 40 Amp Green –Power Locks
F16 –20 Amp Yellow ECM
F17 ––Not Used
F18 40 Amp Green –CBC Feed #4 (Exterior
Lights #1)
F19 ––Not Used
F20 –10 Amp RedLow Temp Passive Pump
F21 20 Amp Blue –PIM - Park PAWL Motor
400 IN CASE OF EMERGENCY
Page 403 of 592
CavityCartridge Fuse Blade FuseDescription
F22 ––Not Used
F23 ––Not used
F24 –20 Amp Yellow RR Wiper
F25A –10 Amp Red Handsfree (Lt & Rt Rear
Door Release Module)
F25B – Active Grill Shutter
F26 40 Amp Green –Front HVAC Blower Motor
F27 25 Amp Clear –RR Slide Door Module
F28A –10 Amp Red Diagnostic Port
F28B – USB + AUX (UCI) Port (IP)
/ Video USB Port
F29 ––Not Used
F30A –10 Amp Red ECM / PIM
F30B – Not Used
F31 –10 Amp Red 3, 4 way Valves
F32 20 Amp Blue –ECM
F33 30 Amp Pink –Power Liftgate Module
F34 25 Amp Clear –Rear Door Control
Module - Lt
F35 25 Amp Clear –Sunroof Control Module
7
IN CASE OF EMERGENCY 401
Page 404 of 592
CavityCartridge Fuse Blade FuseDescription
F36 ––Not Used
F37 40 Amp Green –CBC Feed #4 (Exterior
Lighting / PCM #2)
F38 ––Not Used
F39 25 Amp Clear –Rear HVAC Blower Motor
F40 20 Amp Blue –Trans Oil Pump
F41 ––Not Used
F42 ––Not Used
F43 –20 Amp Yellow Fuel Pump Motor
F44 30 Amp Pink –CBC Feed #1 (Interior
Lights)
F45 30 Amp Pink –Power Inverter
F46 30 Amp Pink –Driver Door Module
F47 30 Amp Pink –Passenger Door Module
F48 40 Amp Green –EBCM Motor
F49 25 Amp Clear –Rear Sliding Door
Module - Lt
F50 25 Amp Clear –Rear Door Control
Module - Rt
F51 30 Amp Pink –Front Wiper
402 IN CASE OF EMERGENCY
Page 405 of 592
CavityCartridge Fuse Blade FuseDescription
F52 ––Not Used
F53 ––Not Used
F54 40 Amp Green –ESP-ECU And Valves
F55A –15 Amp Blue RF Hub/KIN/ESL - BUX
Only
F55B – DVD / VRM
F56A –10 Amp Red OCM / ESL
F56B – ESC - Electric Stability
Control / ESP / EBCM
F57 –20 Amp Yellow PIM - Main Power Supply
F58 ––Not Used
F59 ––Not Used
F60 –20 Amp Yellow Rear Cargo APO
F61 ––Not Used
F62 –20 Amp Yellow PIM - Redundant Main
Power Supply
F63 ––Not Used
F64 ––Not Used
F65 ––Not Used
7
IN CASE OF EMERGENCY 403
Page 406 of 592
CavityCartridge Fuse Blade FuseDescription
F66 –15 Amp Blue
Instrument Panel Cluster
(IPC)
F67 –10 Amp RedHALF / PTS / Drivers Assist
System Module (DASM)
F68 ––Not Used
F69A –15 Amp Blue BPCM
F69B – BPCM (Redundant)
F70 –5 Amp Tan EAC
F71 –20 Amp Yellow Horn
F72 ––Not Used
F73 30 Amp Pink –Rear Defroster (EBL)
F74 ––Not Used
F75 –5 Amp Tan
Overhead Console / Rear ICS
F76 –20 Amp Yellow Uconnect/DCSD/
Telematics
F77A –10 Amp Red Rear Entertainment / Me-
dia Hub
F77B – Sunroof / Rain Snsr /
ECM / Pass WDO Sw En- able / EC Mirror / PIM
404 IN CASE OF EMERGENCY
Page 407 of 592
CavityCartridge Fuse Blade FuseDescription
F78A –15 Amp Blue TCM / E-Shifter
F78B – Instrument Cluster
F79A –10 Amp Red ICS / Frt & Rr HVAC /
EPB Sw / SCCM
F79B – Not Used
F80 –5 Amp Tan OBCM
F81 –5 Amp Tan APM
F82 ––Not Used
F83 30 Amp Pink –Trans Oil Pump 1 - Protect
For
F84 ––Not Used
F85 –20 Amp Yellow Cigar Lighter
F86 ––Not Used
F87 ––Not Used
F88 –20 Amp Yellow Front Heated Seats
F89 –20 Amp Yellow Rear Heated Seats
F90 –5 Amp Tan EBCM - ECU
F91 –15 Amp Blue Front Ventilated Seats/
Heated Steering Wheel
F92A ––Not Used
7
IN CASE OF EMERGENCY 405
