Page 143 of 368
Certain conditions such as a loose or missing gas cap,
poor fuel quality, etc. may illuminate the light after
engine start. The vehicle should be serviced if the light
stays on through several of your typical driving cycles. In
most situations the vehicle will drive normally and will
not require towing.
If the Malfunction Indicator Light flashes when the
engine is running, serious conditions may exist that
could lead to immediate loss of power or severe catalytic
converter damage. The vehicle should be serviced as
soon as possible if this occurs. (See page 266 for more
information.)
23. Front Fog Light Indicator — If Equipped
This light shows when the front fog lights are ON.
(See page 97 for more information.)24. Low Fuel Light
When the fuel level drops to about 1/8 tank, the
fuel symbol will light and a single chime will
sound. The light will remain on until fuel is added.
If the fuel level drops to approximately 1.0 gallon (3.75
Liter), the fuel symbol will flash several times and the
chime will sound several times.
25. AutoStick Gear Position— If Equipped
This vacuum fluorescent display indicator illuminates
when the gearshift lever is moved to the AutoStick
position and shows the current gear selection.
26. Fuel Door Reminder
This symbol is a reminder that the Fuel Filler Door is
located on the front passenger’s (right) side of the vehicle.
UNDERSTANDING YOUR INSTRUMENT PANEL 143
4
Page 195 of 368
Snow Tires...........................233
Tire Rotation Recommendations............234
Fuel Requirements......................235
▫2.4L Standard Engine And 2.4L Standard Turbo
Engine.............................235
▫2.4L High Output Turbo Engine...........235
▫Reformulated Gasoline.................236
▫Gasoline/Oxygenate Blends..............236
▫MMT In Gasoline.....................237▫Materials Added To Fuel................237
▫Fuel System Cautions..................237
▫Carbon Monoxide Warnings..............238
Adding Fuel..........................239
▫Fuel Filler Cap (Gas Cap)...............239
Vehicle Loading........................241
Trailer Towing.........................241
▫Warranty...........................242
STARTING AND OPERATING 195
5
Page 239 of 368
•Guard against carbon monoxide with proper mainte-
nance. Have the exhaust system inspected every time
the vehicle is raised. Have any abnormal conditions
repaired promptly. Until repaired, drive with all side
windows fully open.
•Keep the liftgate closed when driving your vehicle to
prevent carbon monoxide and other poisonous ex-
haust gases from entering the vehicle.
ADDING FUEL
The fuel tank filler tube has a restricting door about 2
inches (50 mm) inside the opening. If using a portable
container, it should have a flexible nozzle long enough to
force open the restricting door.
Fuel Filler Cap (Gas Cap)
The gas cap is behind the fuel filler door, on the passen-
ger’s side of the vehicle. If the gas cap is lost or damaged,
be sure the replacement cap is for use with this vehicle.
NOTE:When removing the fuel filler cap, lay the cap
tether in the hook, located on the fuel filler cap door
reinforcement.
CAUTION!
Damage to the fuel system or emission control
system could result from using an improper fuel
tank filler tube cap (gas cap). A poorly fitting cap
could let impurities into the fuel system.
STARTING AND OPERATING 239
5
Page 240 of 368
CAUTION!
A poorly fitting gas cap may cause the Malfunction
Indicator Light to turn on.
CAUTION!
To avoid fuel spillage and overfilling, do not “top
off” the fuel tank after filling.
NOTE:When the fuel nozzle “clicks” or shuts off, the
fuel tank is full.
WARNING!
•Never have any smoking materials lit in or near
the vehicle when the gas cap is removed or the
tank filled.
•Never add fuel when the engine is running. This
is in violation of most state and federal fire
regulations and will cause the malfunction indi-
cator light to turn on.
NOTE:Tighten the gas cap about 1/4 turn until you
hear one click. This is an indication that cap is properly
tightened.
If the gas cap is not tighten properly, the Malfunction
Indicator Light will come on. Be sure the gas cap is
tightened every time the vehicle is refueled.
240 STARTING AND OPERATING
Page 272 of 368
Engine Oil Selection
For best performance and maximum protection under all
types of operating conditions, the manufacturer only
recommends engine oils that are API certified and meet
the requirements of DaimlerChrysler Material Standard
MS-6395.
American Petroleum Institute (API) Engine Oil
Identification Symbol
This symbol means that the oil has
been certified by the American
Petroleum Institute (API). The
manufacturer only recommends
API Certified engine oils.
Engine Oil Viscosity (SAE Grade)
SAE 5W-30 engine oil is recommended for all operating
temperatures. This engine oil improves low tempera-
ture starting and vehicle fuel economy. Refer to your
engine oil filler cap for the recommended engine oil
viscosity for your vehicle.
For information on engine oil filler cap location, see the
Engine Compartment illustration in this section.
Lubricants which do not have both, the engine oil certi-
fication mark and the correct SAE viscosity grade num-
ber should not be used.
Synthetic Engine Oils
There are a number of engine oils being promoted as
either synthetic or semi-synthetic. If you chose to use
such a product, useonlythose oils that are American
Petroleum Institute (API) Certified and have the recom-
mended SAE viscosity grade. Follow the maintenance
schedule that describes your driving type.
272 MAINTAINING YOUR VEHICLE
Page 311 of 368
FLUIDS AND CAPACITIES
U.S. Metric
Fuel (Approximate)15 Gallons 56.7 Liters
Engine Oil-With Filter
2.4 Liter Engines (Use API Certified SAE 5W-30 Engine Oil.
Refer to your engine oil filler cap for correct SAE grade meet-
ing DaimlerChrysler Material Standard MS-6395.)5.0 qts 4.7 Liters
Cooling System *
2.4 Liter Engines (MoparAntifreeze/Coolant 5 Year/100,000
Miles Formula)6.5 qts 6.2 Liters
* Includes heater and coolant recovery bottle filled to MAX level.
MAINTAINING YOUR VEHICLE 311
7
Page 312 of 368
RECOMMENDED FLUIDS, LUBRICANTS AND GENUINE PARTS
Engine
Component Fluids, Lubricants and Genuine Parts
Engine Coolant MoparAntifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or-
ganic Additive Technology) or equivalent.
Engine Oil Use API Certified SAE 5W-30 Engine Oil. Refer to your engine oil filler cap
for correct SAE grade meeting DaimlerChrysler Material Standard MS-6395.
Engine Oil Filter Non Turbo—Mopar 4105409 or equiv. Turbo—Mopar 4781452AA or equiv.
Spark Plugs Refer to the Vehicle Emission Control Information label in the engine com-
partment.
Fuel Selection 91 Octane for High Output 2.4L Turbo and 87 Octane for 2.4L Standard
Turbo and 2.4L Standard Non Turbo Engines.
312 MAINTAINING YOUR VEHICLE
Page 350 of 368
ABS (Anti-Lock Brake) System.............. 212
Adding Engine Coolant (Antifreeze).......... 286
Adding Fuel........................... 239
Adding Washer Fluid..................... 192
Additives, Fuel......................... 237
Air Cleaner, Engine (Engine Air Cleaner Filter) . . . 276
Air Conditioner Maintenance............... 279
Air Conditioning Controls................. 183
Air Conditioning, Operating Tips............ 188
Air Conditioning Refrigerant.............279,280
Air Conditioning System................183,279
Air Pressure, Tires....................... 225
Airbag................................ 43
Airbag Deployment....................... 50
Airbag Light.....................47,52,62,142
Airbag Maintenance....................... 51
Airbag, Side............................ 49
Alarm, Panic............................ 23
Alarm System........................26,137Alignment and Balance................... 232
Alterations/Modifications, Vehicle............. 7
Antenna, Satellite Radio................... 181
Antifreeze (Engine Coolant)...........285,311,312
Capacities........................... 311
Disposal............................ 287
Anti-Lock Brake System (ABS).............. 212
Anti-Lock Warning Light.................. 139
Anti-Theft Security Alarm.................. 26
Appearance Care........................ 297
Auto Down Power Windows................ 32
Automatic Door Locks..................... 20
Automatic Transaxle..............12,196,199,293
Fluid and Filter Changes................. 295
Fluid Level Check...................... 294
Interlock System.....................18,200
Reset Mode.......................... 201
Selection Of Lubricant................... 293
Shifting............................. 201
350 INDEX
Page 351 of 368
Special Additives...................... 296
Autostick...........................143,204
Back-Up Lights......................... 310
Ball Joints............................. 280
Battery............................... 277
Keyless Transmitter Replacement............ 25
Belts, Drive............................ 273
Belts, Engine........................... 276
Body Mechanism Lubrication............... 281
B-Pillar Location........................ 220
Brake Fluid............................ 313
Brake, Parking.......................... 209
Brake System........................ 211,290
Anti-Lock........................... 212
Hoses.............................. 290
Master Cylinder....................... 291
Parking............................. 209
Warning Light........................ 140Brakes............................. 211,290
Brake/Transmission Interlock............... 200
Break-In Recommendations, New Vehicle........ 60
Bulb Replacement.....................306,308
Bulbs, Light............................ 306
Calibration, Compass..................... 114
Capacities, Antifreeze (Engine Coolant)........ 311
Capacities, Fluid........................ 311
Caps, Filler
Fuel................................ 239
Oil (Engine)....................264,265,272
Carbon Monoxide Warning................. 238
Cargo Compartment
Luggage Carrier....................... 126
Carrier, Luggage........................ 126
Cassette Tape and Player Maintenance......... 181
Cassette Tape Player................146,149,152
Catalytic Converter...................... 274
INDEX 351
10
Page 354 of 368
Emission Control System Maintenance......267,316
Engine............................264,265
Break-In Recommendations................ 60
Checking Oil Level..................... 269
Cooling............................. 284
Exhaust Gas Caution.................... 238
Fuel Requirements..................... 235
Jump Starting......................... 254
Oil ...........................269,311,312
Oil Change Interval.................... 270
Oil Filler Cap...................264,265,272
Oil Filter............................ 312
Oil Selection.......................... 272
Oil Synthetic......................... 272
Overheating.......................... 246
Temperature Gauge..................... 138
Timing Belt.......................... 276
Exhaust Gas Caution..............29,61,238,283
Exhaust System......................... 283Filler Location Fuel...................... 143
Filters
Air Cleaner.......................... 276
Engine Fuel.......................... 276
Engine Oil........................273,312
Flashers.............................. 246
Hazard Warning....................... 246
Flat Tire Stowage........................ 253
Flooded Engine Starting................... 197
Fluid, Brake........................... 313
Fluid Capacities......................... 311
Fluid Leaks............................. 62
Fluid Level Checks
Automatic Transaxle.................... 294
Fluids................................ 312
Fog Light Service........................ 309
Fog Lights...........................97,143
Folding Rear Seat........................ 87
Freeing A Stuck Vehicle................... 257
354 INDEX
