NOTE:The fog lights will only operate with the head-
lights on low beam. Selecting high beam headlights will
turn off the fog lights.
Turn Signals
Move the Multi-Function Control Lever up or down and
the arrows on each side of the instrument cluster flash to
show proper operation of the front and rear turn signal
lights. You can signal a lane change by moving the lever
partially up or down without moving beyond the detent.
If either light remains on and does not flash, or there is a
very fast flash rate, check for a defective outside light
bulb. If an indicator fails to light when the lever is
moved, it would suggest that the fuse or indicator bulb is
defective.
Highbeam/Lowbeam Select Switch
Pull the Multi-Function Control Lever towards you to
switch the headlights to HIGH beam. Pull the control
lever a second time to switch the headlights to LOW
beam.
Passing Light
You can signal another vehicle with your headlights by
lightly pulling the Multi-Function Control Lever toward
you. This will cause the headlights to turn on at high
beam and remain on until the lever is released.
WINDSHIELD WIPERS AND WASHERS
The wipers and washers are operated by a switch
on the control lever. The lever is located on the
right side of the steering column. Move the con-
trol lever up to select the desired wiper speed.
98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

▫Air Conditioner Maintenance.............279
▫Power Steering — Fluid Check............280
▫Front Suspension Ball Joints..............280
▫Body Lubrication.....................281
▫Windshield Wiper Blades................281
▫Windshield Washer Reservoir.............282
▫Exhaust System......................283
▫Cooling System.......................284
▫Hoses And Vacuum/Vapor Harnesses.......289
▫Fuel System Connections................289
▫Brake System........................290
▫Automatic Transaxle...................293
▫Manual Transaxle.....................296▫Appearance Care And Protection From
Corrosion...........................297

Fuses...............................303
▫Underhood Fuses (Power Distribution
Center)............................303
▫Interior Fuses........................304

Vehicle Storage........................306

Replacement Bulbs......................306

Bulb Replacement......................308
▫Headlight Bulb Replacement.............308
▫Front Park/Turn Signal/Side Marker Lights . . 309
▫Front Fog Lights — If Equipped...........309
▫Tail/Stop, And Rear Turn Signal Lights......309
▫Back Up Light Bulb....................310
262 MAINTAINING YOUR VEHICLE

Overhead Reading Light (Overhead Console). . . T1037
Overhead Reading Light (Rearview Mirror).....T192
Rear Cargo............................T906
Seat Belt Indicator....................... LED
Security Alarm Indicator................... LED
Malfunction Indicator Light................ LED
Temperature Indicator.................... LED
Trac (Active) Indicator................... VFD*
TRAC OFF Indicator..................... LED
Trip Indicator......................... VFD*
Turn Signal Indicator...................... 103
Visor Vanity.........................6501966
Voltage Indicator........................ LED
NOTE:* Vacuum Fluorescent Display
All the inside bulbs are brass or glass wedge base.
Aluminum base bulbs are not approved and should not
be used for replacement.LIGHTS BULBS — Outside Bulb No.
Low Beam Headlight...................9006XS
High Beam Headlight...................9005XS
Front Park/Turn Signal/Side Marker
Light............................4157NAKX
Front Fog Light.........................9006
Center High Mounted Stop Light
(CHMSL).........................921–W16W
Rear Tail/Stop/Turn Signal Light......3157–P27/7W
Backup Light.....................3157-P27/7W
License Light........................... 168
MAINTAINING YOUR VEHICLE 307
7

BULB REPLACEMENT
Headlight Bulb Replacement
CAUTION!
Do not touch the new headlight bulb with your
fingers. Oil contamination will severely shorten
bulb life.
1. Remove the headlight access cover splash shield,
located in the front wheel well opening.
2. Disconnect the electrical connector.3. Rotate the socket to the left one quarter turn and
replace the bulb.
308 MAINTAINING YOUR VEHICLE

Front Park/Turn Signal/Side Marker Lights
1. Remove the headlight access cover splash shield,
located in the front wheel well opening.
2. Rotate the socket to the left one quarter turn to replace
and replace the bulb.
Front Fog Lights — If Equipped
1. Remove the fasteners attaching the lower splash
shield to gain access to the fog light.
2. Twist and remove the bulb from the fog light housing.
3. Disconnect the electrical connector and replace bulb.
Tail/Stop, and Rear Turn Signal Lights
1. Remove the screw attaching the tail light housing and
remove the housing from the vehicle.
MAINTAINING YOUR VEHICLE 309
7

Headlights
Bulb Replacement...................... 308
Cleaning............................ 301
High Beam.........................98,139
High Beam/Low Beam Select Switch......... 98
Passing.............................. 98
Switch............................... 96
Heated Seats............................ 86
Homelink Transmitter.................... 105
Hood Release........................... 93
Hoses................................ 289
Ignition............................... 12
Key ................................. 12
Wiring System........................ 274
Immobilizer..........................14,27
Indicator, Traction Control...............140,142
Infant Restraint.......................... 53
Inside Rearview Mirror.................... 67Instrument Cluster....................134,137
Instrument Panel and Controls.............. 133
Instrument Panel Cover................... 302
Instrument Panel Lens Cleaning............. 302
Integrated Power Module.................. 303
Interior Appearance Care.................. 300
Interior Fuses.......................... 304
Interior Lights........................... 95
Intermittent Wipers...................... 100
Introduction............................. 4
Jack Location........................... 249
Jack Operation.......................248,251
Jacking Instructions...................... 251
Jump Starting.......................... 254
Key, Programming........................ 16
Key Release Button....................... 13
Key, Replacement........................ 16
356 INDEX

Key, Sentry............................. 14
Key-In Reminder......................... 14
Keyless Entry System...................... 22
Keys................................. 12
Knee Bolster..........................47,49
Lane Change and Turn Signals.............. 138
Lap/Shoulder Belts....................... 34
Latches
Hood............................... 93
Lead Free Gasoline...................... 235
Liftgate................................ 28
Light Bulbs.........................306,308
Lights...............................62,94
Airbag........................47,52,62,142
Anti-Lock........................... 139
Back-Up............................. 310
Brake Warning........................ 140
Center Mounted Stop................... 310Courtesy/Reading...................... 94
Daytime Running....................... 97
Dimmer Switch, Headlight................ 96
Engine Temperature Warning.............. 138
Fog ...........................97,143,309
Front Replacement..................... 308
Headlight Switch....................... 96
Headlights............................ 96
High Beam Indicator.................... 139
Instrument Cluster...................... 96
Interior.............................. 95
Liftgate Ajar.......................... 137
Lights On Reminder..................... 97
Low Fuel............................ 143
Malfunction Indicator................... 142
Oil Pressure.......................... 137
Rear Servicing........................ 309
Seat Belt Reminder..................... 139
Security Alarm......................... 26
