2005 Passenger Car • Minivan • PacificaDealer Copy
Remove and attach to Repair Order 26-92-02-01 3N.
Maint enance Service
Sc hedule “B”
Odometer Reading
Date
48,0 00 km
Maint
enance Service Sc hedule “B”
48,0 00 km
Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension componen\
ts.
Inspect the engine air cleaner filter and replace if necessary (Sebring\
, PT Cruiser,
SRT-4 and SX 2.0 only).
Replace the engine air cleaner filter if required (all models).
Replace the spark plugs (PT Cruiser, SRT-4, Sebring and SX 2.0 only).
Check and replace, if necessary, the PCV valve.
Inspect and replace, if required, the make-up air filter located inside \
the air cleaner
(PT Cruiser, SRT-4 and SX 2.0 only).
Adjust the generator belt tension (PT Cruiser, SX 2.0 and SRT-4 only).\
Inspect and adjust the power-steering pump belt tension (2.4L Sebring o\
nly).
Change the all-wheel-drive power transfer unit fluid.*
Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
Inspect the tie rod ends and boot seals (Pacifica, Minivan, PT Cruiser,\
SRT-4
and SX 2.0 only).
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug condition (SX 2.0,\
SRT-4
and PT Cruiser only, if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
*The all-wheel-drive power transfer unit fluid and overrunning clutch/re\
ar carrier fluid
must be changed at more frequent intervals than shown in schedule B if t\
he vehicle
is used for trailer tow, taxi, or other type of commercial service.

DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
2005 Passenger Car • Minivan • Pacifica
Odometer Reading
Date
Repair Order No.
Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension
components.
Inspect the engine air cleaner filter and replace if necessary
(Sebring, PT Cruiser, SRT-4 and SX 2.0 only).
Replace the engine air cleaner filter if required (all models).
Replace the spark plugs (PT Cruiser, SRT-4, Sebring
and SX 2.0 only).
Check and replace, if necessary, the PCV valve.
Inspect and replace, if required, the make-up air filter located
inside the air cleaner (PT Cruiser, SRT-4 and SX 2.0 only).
Adjust the generator belt tension (PT Cruiser, SX 2.0 and
SRT-4 only).
Inspect and adjust the power-steering pump belt tension
(2.4L Sebring only).
Change the all-wheel-drive power transfer unit fluid.*
Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
Inspect the tie rod ends and boot seals (Pacifica, Minivan,
PT Cruiser, SRT-4 and SX 2.0 only).
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug condition
(SX 2.0, SRT-4 and PT Cruiser only, if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
*The all-wheel-drive power transfer unit fluid and overrunning clutch/re\
ar
carrier fluid must be changed at more frequent intervals than shown in
schedule B if the vehicle is used for trailer tow, taxi, or other type o\
f
commercial service.
Maint enance Service Sc hedule “B”
48,0 00 km

2005 Passenger Car • Minivan • PacificaDealer Copy
Remove and attach to Repair Order 26-92-02-01 3N.
Maint enance Service
Sc hedule “B”
Odometer Reading
Date
96,0 00 km
Maint enance Service Sc hedule “B”
96,0 00 km
Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension componen\
ts.
Replace the engine air cleaner filter if required (all models).
Replace the ignition cables (PT Cruiser, SRT-4, Sebring and SX 2.0 only).Replace the spark plugs (PT Cruiser, SRT-4, Sebring and SX 2.0 only).
Check and replace, if necessary, the PCV valve.
Inspect and replace, if required, the make-up air filter located inside \
the air cleaner (PT Cruiser, SRT-4
and SX 2.0 only).
Inspect the serpentine drive belt, replace if necessary (Pacifica and M\
inivan only).
Adjust the generator belt tension (PT Cruiser, SX 2.0 and SRT-4 only).\
Inspect and adjust the power-steering pump belt tension (2.4L Sebring o\
nly).
Replace the drive belts (SX 2.0 only).
Replace the accessory drive belts (2.4L Sebring only).
Replace the accessory drive belts (2.7L Sebring only).
Change the automatic transaxle fluid and filter.**
Change the all-wheel-drive power transfer unit fluid.*
Replace the air conditioning filter (Pacifica and Minivan if equipped)\
.
Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
Inspect the tie rod ends and boot seals (Pacifica, Minivan, PT Cruiser,\
SRT-4 and SX 2.0 only).
Inspect the front and rear brakes and components (Sebring, PT Cruiser a\
nd SRT-4 only).
Inspect the brake hoses.
Check the manual transaxle fluid level and fill-plug condition (SX 2.0,\
SRT-4 and PT Cruiser only, if equipped).
Check the coolant level, hoses, and clamps.
Inspect the exhaust system.
*The all-wheel-drive power transfer unit fluid and overrunning clutch/re\
ar carrier fluid must be changed at more frequent
intervals than shown in schedule B if the vehicle is used for trailer to\
w, taxi, or other type of commercial service.
**Change the automatic transaxle fluid and filter every 96,000 km if the\
vehicle is used for trailer tow, taxi, police
or other type of commercial service.

DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
2005 Passenger Car • Minivan • Pacifica
Odometer Reading
Date
Repair Order No.
Maint enance Service Sc hedule “B”
96,0 00 kmChange engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension componen\
ts.
Replace the engine air cleaner filter if required (all models).
Replace the ignition cables (PT Cruiser, SRT-4, Sebring and SX 2.0 only\
).Replace the spark plugs (PT Cruiser, SRT-4, Sebring and SX 2.0 only).
Check and replace, if necessary, the PCV valve.
Inspect and replace, if required, the make-up air filter located inside \
the
air cleaner (PT Cruiser, SRT-4 and SX 2.0 only).
Inspect the serpentine drive belt, replace if necessary (Pacifica and
Minivan only).
Adjust the generator belt tension (PT Cruiser, SX 2.0 and SRT-4 only).\
Inspect and adjust the power-steering pump belt tension (2.4L Sebring o\
nly).
Replace the drive belts (SX 2.0 only).
Replace the accessory drive belts (2.4L Sebring only).
Replace the accessory drive belts (2.7L Sebring only).
Change the automatic transaxle fluid and filter.**
Change the all-wheel-drive power transfer unit fluid.*
Replace the air conditioning filter (Pacifica and Minivan if equipped)\
.
Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
Inspect the tie rod ends and boot seals (Pacifica, Minivan, PT Cruiser,\
SRT-4 and SX 2.0 only).
Inspect the front and rear brakes and components (Sebring,
PT Cruiser and SRT-4 only).
Inspect the brake hoses.
Check the manual transaxle fluid level and fill-plug condition (SX 2.0,\
SRT-4 and PT Cruiser only, if equipped).
Check the coolant level, hoses, and clamps.
Inspect the exhaust system.
*The all-wheel-drive power transfer unit fluid and overrunning clutch/re\
ar
carrier fluid must be changed at more frequent intervals than shown in s\
chedule
B if the vehicle is used for trailer tow, taxi, or other type of commerc\
ial service.
**Change the automatic transaxle fluid and filter every 96,000 km if the\
vehicle
is used for trailer tow, taxi, police or other type of commercial servic\
e.

2005 Passenger Car • Minivan • PacificaDealer Copy
Remove and attach to Repair Order 26-92-02-01 3N.
Maint enance Service
Sc hedule “B”
Odometer Reading
Date
120,0 00 km
Maint
enance Service Sc hedule “B”
120,0 00 km
Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension componen\
ts.
Inspect the engine air cleaner filter and replace if necessary (Sebring\
, PT Cruiser,
SRT-4 and SX 2.0 only).
Replace the engine air cleaner filter if required (Pacifica and Minivan\
only).
Replace the ignition cables (Minivan only).
Replace the spark plugs (Pacifica and Minivan only).
Inspect and replace, if required, the make-up air filter located inside \
the air cleaner
(PT Cruiser, SRT-4 and SX 2.0 only).
Inspect the serpentine drive belt, replace if necessary (Pacifica and M\
inivan only).
Change the all-wheel-drive power transfer unit fluid.*
INSPECT THE FOLLOWING:
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug condition (SX 2.0,\
SRT-4
and PT Cruiser only, if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
*The all-wheel-drive power transfer unit fluid and overrunning clutch/re\
ar carrier
fluid must be changed at more frequent intervals than shown in schedule \
B if the
vehicle is used for trailer tow, taxi, or other type of commercial servi\
ce.

DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
2005 Passenger Car • Minivan • Pacifica
Odometer Reading
Date
Repair Order No.

Change engine oil and engine oil filter
(or every 3 months).
Inspect and lubricate, as required, all steering and
suspension components.
Inspect the engine air cleaner filter and replace if necessary
(Sebring, PT Cruiser, SRT-4 and SX 2.0 only).
Replace the engine air cleaner filter if required
(Pacifica and Minivan only).
Replace the ignition cables (Minivan only).
Replace the spark plugs (Pacifica and Minivan only).
Inspect and replace, if required, the make-up air filter
located inside the air cleaner (PT Cruiser, SRT-4 and
SX 2.0 only).
Inspect the serpentine drive belt, replace if necessary
(Pacifica and Minivan only).
Change the all-wheel-drive power transfer unit fluid.*
INSPECT THE FOLLOWING:
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug
condition (SX 2.0, SRT-4 and PT Cruiser only, if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
*The all-wheel-drive power transfer unit fluid and overrunning
clutch/rear carrier fluid must be changed at more frequent intervals
than shown in schedule B if the vehicle is used for trailer tow, taxi,
or other type of commercial service.
Maint enance Service Sc hedule “B”
120,0 00 km

2005 Passenger Car • Minivan • PacificaDealer Copy
Remove and attach to Repair Order 26-92-02-01 3N.
Maint enance Service
Sc hedule “B”
Odometer Reading
Date
144,0 00 km
Maint
enance Service Sc hedule “B”
144,0 00 km
Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension componen\
ts.
Replace the engine air cleaner filter, if required (all models).
Replace the spark plugs (PT Cruiser, SRT-4, Sebring and SX 2.0 only).
Check and replace, if necessary, the PCV valve.
Inspect and replace, if required, the make-up air filter located inside \
the air cleaner
(PT Cruiser, SRT-4 and SX 2.0 only).
Inspect the serpentine drive belt, replace if necessary (Pacifica and M\
inivan only).
Adjust the generator belt tension (PT Cruiser, SX 2.0 and SRT-4 only).\
Inspect and adjust the power-steering pump belt tension (2.4L Sebring o\
nly).
Replace the engine timing belt (SRT-4, Sebring and PT Cruiser only).
Change the manual transaxle fluid (SRT-4 only).
Change the all-wheel-drive power transfer unit fluid.*
Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
Inspect the tie rod ends and boot seals (Pacifica, Minivan, PT Cruiser,\
SRT-4 and SX 2.0 only).
Inspect the front and rear brakes and components (Pacifica, Minivan and\
SX 2.0 only).
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug condition (SX 2.0,\
SRT-4
and PT Cruiser only, if equipped).
Check the coolant level, hoses, and clamps.
Inspect the exhaust system.
*The all-wheel-drive power transfer unit fluid and overrunning clutch/re\
ar carrier fluid must be changed at more frequent
intervals than shown in schedule B if the vehicle is used for trailer to\
w, taxi, or other type of commercial service.

DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
2005 Passenger Car • Minivan • Pacifica
Odometer Reading
Date
Repair Order No.

Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension
components.
Replace the engine air cleaner filter if required (all models).
Replace the spark plugs (PT Cruiser, SRT-4, Sebring and SX 2.0 only). Check and replace, if necessary, the PCV valve.
Inspect and replace, if required, the make-up air filter located inside
the air cleaner (PT Cruiser, SRT-4 and SX 2.0 only).
Inspect the serpentine drive belt, replace if necessary (Pacifica
and Minivan only).
Adjust the generator belt tension (PT Cruiser, SX 2.0
and SRT-4 only).
Inspect and adjust the power-steering pump belt tension
(2.4L Sebring only).
Replace the engine timing belt (SRT-4, Sebring and PT Cruiser only).
Change the manual transaxle fluid (SRT-4 only).
Change the all-wheel-drive power transfer unit fluid.*
Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
Inspect the tie rod ends and boot seals (Pacifica, Minivan,
PT Cruiser, SRT-4 and SX 2.0 only).
Inspect the front and rear brakes and components (Pacifica,
Minivan and SX 2.0 only).
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug condition
(SX 2.0, SRT-4 and PT Cruiser only, if equipped).
Check the coolant level, hoses, and clamps.
Inspect the exhaust system.
*The all-wheel-drive power transfer unit fluid and overrunning clutch/re\
ar
carrier fluid must be changed at more frequent intervals than shown in s\
chedule
B if the vehicle is used for trailer tow, taxi, or other type of commerc\
ial service.
Maint enance Service Sc hedule “B”
144,0 00 km

2005 Passenger Car • Minivan • PacificaDealer Copy
Remove and attach to Repair Order 26-92-02-01 3N.
Maint enance Service
Sc hedule “B”
Odometer Reading
Date
158,0 00 km
Maint
enance Service Sc hedule “B”
158,0 00 km
Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension componen\
ts.
Inspect the engine air cleaner filter and replace if necessary (Sebring\
, Pacifica
and Minivan only).
Replace the spark plugs (2.7L Sebring only).
Flush and replace engine coolant at 60 months (regardless of metrage) \
or 160,000 km,
whichever comes first.
INSPECT THE FOLLOWING:
Inspect the front and rear brakes and components (Pacifica, Minivan and\
SX 2.0 only).
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug condition (SX 2.0,\
SRT-4
and PT Cruiser only, if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.

DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
2005 Passenger Car • Minivan • Pacifica
Odometer Reading
Date
Repair Order No.

Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and
suspension components.
Inspect the engine air cleaner filter and replace if necessary
(Sebring, Pacifica and Minivan only).
Replace the spark plugs (2.7L Sebring only).
Flush and replace engine coolant at 60 months (regardless
of metrage) or 160,000 km, whichever comes first.
INSPECT THE FOLLOWING:
Inspect the front and rear brakes and components
(Pacifica, Minivan and SX 2.0 only).
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug
condition (SX 2.0, SRT-4 and PT Cruiser only, if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
Maint enance Service Sc hedule “B”
158,0 00 km
