MAINTAINING YOUR VEHICLE
CONTENTS

2.4L Turbo Engine Compartment............362

2.4L Engine Compartment................363

Onboard Diagnostic System — OBD II........364
▫Loose Fuel Filler Cap Message............364

Emissions Inspection And Maintenance
Programs............................365

Replacement Parts......................366

Dealer Service.........................367

Maintenance Procedures..................367▫Engine Oil..........................368
▫Drive Belts — Check Condition And Tension . . 372
▫Spark Plugs.........................372
▫Ignition Wiring System.................372
▫Catalytic Converter....................372
▫Engine Timing Belt....................374
▫Crankcase Emission Control System........374
▫Fuel Filter..........................374
▫Air Cleaner Element (Filter)..............374
7

•Do not shut off the engine or interrupt the ignition
when the transaxle is in gear and the vehicle is in
motion.
•Do not try to start the engine by pushing or towing the
vehicle.
•Do not idle the engine with any spark plug wires
disconnected for prolonged period.
Engine Timing Belt
Replace the engine timing belt at the intervals described
in the appropriate maintenance schedule.
Crankcase Emission Control System
Proper operation of this system depends on freedom
from sticking or plugging due to deposits. As vehicle
mileage builds up, the PCV valve and passages may
accumulate deposits. If a valve is not working properly,
replace it with a new valve. DO NOT ATTEMPT TO
CLEAN THE OLD PCV VALVE!Check ventilation hose for indication of damage or
plugging deposits. Replace if necessary.
Fuel Filter
A plugged fuel filter can cause hard starting or limit the
speed at which a vehicle can be driven. Should an
excessive amount of dirt accumulate in the fuel tank,
frequent filter replacement may be necessary. The fuel
filters are located inside the fuel tank. See your dealer for
service.
Air Cleaner Element (Filter)
Under normal driving conditions, replace the filter at the
intervals shown on Schedule “A”. If, however, you drive
the vehicle frequently under dusty or severe conditions,
the filter element should be inspected periodically and
replaced if necessary at the intervals shown on Schedule
“B”.
NOTE:For vehicles with a Turbo engine, a small
amount of oil accumulation in the air cleaner box is
374 MAINTAINING YOUR VEHICLE

FLUIDS AND CAPACITIES
U.S. Metric
Fuel (Approximate)15 Gallons 56.7 Liters
Engine Oil-With Filter
2.4 Liter Engines (Use API Certified SAE 5W-30 Engine Oil. 5.0 qts 4.7 Liters
Cooling System *
2.4 Liter Engines (MoparAntifreeze/Coolant 5 Year/100,000
Miles Formula), or equivalent.6.5 qts 6.2 Liters
* Includes heater and coolant recovery bottle filled to MAX level.
MAINTAINING YOUR VEHICLE 411
7

FLUIDS, LUBRICANTS AND GENUINE PARTS
Engine
Component Fluids, Lubricants and Genuine Parts
Engine Coolant MoparAntifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or-
ganic Additive Technology) or equivalent.
Engine Oil Use API Certified SAE 5W-30 Engine Oil. Refer to your engine oil filler cap
for correct SAE grade meeting DaimlerChrysler Material Standard MS-6395.
Engine Oil Filter Non Turbo—Mopar 4105409AB or equiv. Turbo—Mopar 4781452BB or equiv.
Spark Plugs Refer to the Vehicle Emission Control Information label in the engine com-
partment.
Fuel Selection 91 Octane for High Output 2.4L Turbo and 87 Octane for 2.4L Standard
Turbo and 2.4L Standard Non Turbo Engines.
412 MAINTAINING YOUR VEHICLE

At Each Stop for Fuel
•Check the engine oil level about 5 minutes after a fully
warmed engine is shut off. Checking the oil level while
the vehicle is on level ground will improve the accu-
racy of the oil level reading. Add oil only when the
level is at or below the ADD or MIN mark.
•Check the windshield washer solvent and add if
required.
Once a Month
•Check tire pressure and look for unusual wear or
damage.
•Inspect the battery and clean and tighten the terminals
as required.
•Check the fluid levels of coolant reservoir, brake
master cylinder and transaxle and add as needed.
•Check all lights and all other electrical items for correct
operation.
•Check rubber seals on each side of the radiator for
proper fit.
At Each Oil Change
•Change the engine oil filter.
•Inspect the exhaust system.
•Inspect the brake hoses.
•Inspect the CV joints and front suspension compo-
nents.
•Check the automatic transaxle fluid level.
•Check the manual transaxle fluid level and fill plug
condition.
•Check the coolant level, hoses, and clamps.
418 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

SCHEDULE “B”—ALL ENGINES
Follow schedule “B”—All Engines if you usually operate
your vehicle under one or more of the following condi-
tions.
Change the automatic transmission fluid and filter every
60,000 miles (100 000 km) if the vehicle is usually
operated under one or more of the conditions marked
with an.
Change the manual transaxle fluid every 48,000 miles (80
000 km) if the vehicle is usually operated under one or
more of the conditions marked with an †.
•Day and night temperatures are below 32° F (0° C).
•Stop and go driving.
•Extensive engine idling.
•Driving in dusty conditions.
•Short trips of less than 10 miles (16.2 km).
•More than 50% of your driving is at sustained high
speeds during hot weather, above 90° F (32° C ).
•Trailer towing.†
•Taxi, police, or delivery service (commercial ser-
vice).†
•Off-road or desert operation.
•If equipped for and operating with E-85 (ethanol)
fuel.
NOTE:IfANYof these apply to you then change your
engine oil every 3,000 miles (5 000 km) or 3 months,
whichever comes first, and follow schedule “B—All
Engines” of theMaintenance Schedulessection of this
manual.
NOTE:IFANYof these apply to you then flush and
replace the engine coolant every 102,000 miles (170 000
SCHEDULE “B”—ALL ENGINES 419
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

ABS (Anti-Lock Brake System).............. 297
Adding Engine Coolant (Antifreeze).......... 384
Adding Fuel........................... 326
Adding Washer Fluid..................187,275
Additives, Fuel......................... 324
Air Cleaner, Engine (Engine Air Cleaner Filter) . . . 374
Air Conditioner Maintenance............... 377
Air Conditioning Controls................. 266
Air Conditioning, Operating Tips............ 271
Air Conditioning Refrigerant.............377,378
Air Conditioning System................266,377
Air Pressure, Tires....................... 312
Airbag.............................. 55,89
Airbag Deployment.................... 68,101
Airbag Light.................... 70,103,115,227
Airbag Maintenance.................... 69,103
Airbag, Side.......................... 65,99
Alarm, Panic............................ 33
Alarm System (Security Alarm)............ 36,226Alignment and Balance................... 319
Alterations/Modifications, Vehicle............. 7
Antenna, Satellite Radio................... 265
Antifreeze (Engine Coolant)...........383,411,412
Capacities........................... 411
Disposal............................ 385
Anti-Lock Brake System (ABS).............. 297
Anti-Lock Warning Light.................. 227
Anti-Theft Security Alarm (Theft Alarm)........ 36
Appearance Care........................ 395
Auto Down Power Windows................ 43
Automatic Door Locks................... 20,21
Automatic Transaxle.............. 13,280,284,391
Fluid and Filter Changes................. 393
Fluid Level Check...................... 392
Interlock System..................... 18,285
Reset Mode.......................... 285
Selection Of Lubricant................... 391
Shifting ............................. 286
448 INDEX

Emergency Deck Lid Release Latch (Convertible) . . 41
Emergency, In Case of
Jacking............................. 346
Jump Starting......................... 351
Towing ............................. 355
Emergency Seat Back Release (Sedan).......... 40
Emission Control System Maintenance......365,416
Engine............................362,363
Break-In Recommendations............... 113
Checking Oil Level..................... 368
Cooling ............................. 382
Exhaust Gas Caution.................... 325
Fuel Requirements..................... 322
Jump Starting......................... 351
Oil ...........................368,411,412
Oil Change Interval.................... 369
Oil Filler Cap...................362,363,370
OilFilter ............................ 412
Oil Selection.......................... 370Oil Synthetic......................... 371
Overheating.......................... 344
Temperature Gauge..................... 222
TimingBelt .......................... 374
Event Data Recorder................... 70,103
Exhaust Gas Caution.............. 39,114,325,381
Exhaust System......................... 381
Filler Location Fuel...................... 222
Filters
Air Cleaner.......................... 374
Engine Fuel.......................... 374
Engine Oil........................371,412
Flashers.............................. 344
Hazard Warning....................... 344
Flat Tire Stowage........................ 351
Flooded Engine Starting................... 281
Fluid, Brake........................... 413
Fluid Capacities......................... 411
452 INDEX

Fluid Leaks............................ 115
Fluid Level Checks
Automatic Transaxle.................... 392
Fluids ................................ 412
Fluids, Lubricants and Genuine Parts.......... 412
Fog Light Service........................ 409
Fog Lights..........................183,227
Folding Front Passenger Seat............... 162
Folding Rear Seat.....................166,168
Folding Rear Seat (Convertible).............. 168
Folding Rear Seat (Sedan).................. 166
Freeing A Stuck Vehicle................... 354
Fuel..............................322,412
Adding............................. 326
Additives............................ 324
Capacity............................ 411
CleanAir ............................ 323
Filler Cap (Gas Cap).................222,326
Filler Door (Gas Cap)................... 222Filter ............................... 374
Gasoline............................ 322
Gauge.............................. 222
Hoses.............................. 387
Light ............................... 227
Octane Rating........................ 322
Requirements......................... 322
System Hoses......................... 387
Tank Capacity........................ 411
Fuel System Caution..................... 329
Fueling ............................... 326
Fuses................................ 403
Garage Door Opener (HomeLink) ........... 192
Gas Cap (Fuel Filler Cap)............326,328,364
Gasoline, Clean Air...................... 323
Gasoline (Fuel)......................322,411
Gasoline, Reformulated................... 323
INDEX 453
