fuse CHRYSLER PT CRUISER 2007 1.G Owners Manual

NOTE:When entering program mode using that fob, all
other programmed fobs will be erased and you will have
to reprogram them for your vehicle.
Use the Following procedure to program additional key
fobs if the vehicle is not equipped with Sentry Key:
1. Enter your vehicle and close all doors.
2. Fasten your seat belt (Fastening the seatbelt will cancel
any chiming that may confuse you during this program-
ming procedure).
3. Place the key into the ignition.
4. Turn the ignition to the ON position (Do not start the
engine).
5. Press and hold the UNLOCK button on the key fob.
6. After holding the UNLOCK button for four seconds,
also press the PANIC button within 6 seconds.7. When a single chime is heard release both buttons. The
chime is an indication that you have successfully entered
program mode. All fobs that are to be programmed must
be done so within 60 seconds of when the chime was
heard.
8. Using the fob to be programmed, press and release
both the LOCK and UNLOCK buttons, simultaneously.
9. A single chime will be heard.
10. Within four seconds of hearing the chime, press and
release the UNLOCK button on the fob.
11. A single chime will be heard.
12. Repeat steps 8 through 10 to program up to six
additional fobs.
13. Turn the ignition to the OFF position.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27
2

NOTE:The fog lights will only operate with the head-
lights on low beam. Selecting high beam headlights will
turn off the fog lights.
Turn Signals
Move the Multi-Function Control Lever up or down and
the arrows on each side of the instrument cluster flash to
show proper operation of the front and rear turn signal
lights. You can signal a lane change by moving the lever
partially up or down without moving beyond the detent.
If either light remains on and does not flash, or there is a
very fast flash rate, check for a defective outside light
bulb. If an indicator fails to light when the lever is
moved, it would suggest that the fuse or indicator bulb is
defective.
Turn Signal Control
184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
In an accident, there is a greater risk of being thrown
from a vehicle with an open sunroof. You could also
be seriously injured or killed. Always fasten your
seat belt properly and make sure all passengers are
properly secured too.
Do not allow small children to operate the sunroof.
Never allow fingers or other body parts, or any
object to project through the sunroof opening. Injury
may result.
Wind Buffeting
Wind buffeting can be described as the perception of
pressure on the ears or a helicopter type sound in the
ears. Your vehicle may exhibit wind buffeting with the
windows down, or the sunroof (if equipped) in certain
open or partially open positions. This is a normal occur-
rence and can be minimized. If the buffeting occurs withthe rear windows open, open the front and rear windows
together to minimize the buffeting. If the buffeting occurs
with the sunroof open, adjust the sunroof opening to
minimize the buffeting or open any window.
Sunroof Maintenance
Use only a non-abrasive cleaner and a soft cloth to clean
the glass panel.
ELECTRICAL POWER OUTLETS
The outlets include tethered caps, labeled with a key
symbol or battery symbol, indicating power source. All
outlets are protected by a single 20 Amp fuse.
The standard outlet in the front of the center floor console
is a conventional cigar lighter outlet.
202 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

The second is in the right rear cargo area. This outlet is powered directly by the battery (as an
option, fuse #11 in the Integrated Power Module (IPM),
may be repositioned to allow power to come from the
ignition switch only when in the9ON9or9ACCESSORY9
positions).
NOTE:Neither of the power outlets will accept a cigar
lighter unit. They are intended only for accessory usage.
Rear Power Outlet
204 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Cloth Top Additional Cleaning Procedure
For additional cleaning assistance in removing stubborn
stains, apply Mopar Convertible Cloth Top Cleaner (part
number 05012245AA) to the complete stain, extending 2
inches (50 mm) beyond the stain. With a soft bristle
brush, scrub in all directions over the stain. Avoid heavy
scrubbing. Rinse the area with warm water. If the stain is
still apparent, repeat the cleaning procedure. When the
stain is no longer showing, rinse the complete top with
warm water. Let the top dry before lowering it. 7
Cloth Top Protection
For appearance purposes, you may wish to protect your
TwillfastŸ (cloth) top periodically. Use Mopar Convert-
ible Cloth Top Treatment or a fabric protectant such as
Scotchguard_ is suggested. The top should be clean and
dry before application of the protectant.
CAUTION!
Avoid getting Scotchguard_ on the surrounding
weather strips, moldings, paint, or glass. Damage to
these items might occur.
Weather Strip Care
Lubricate all top and door glass weather strips periodi-
cally with Mopar Weather Strip Lubricant (part number
4773427), to keep them soft and pliable.
INTEGRATED POWER MODULE (IPM)
An Integrated Power Module is located in the engine
compartment near the air cleaner assembly. This center
contains cartridge fuses and mini fuses. A description of
each fuse and component may be stamped on the inside
of the cover.
400 MAINTAINING YOUR VEHICLE

Cavity Cartridge
FuseMini
FuseDescription
1 40 Amp
GreenPower Top Feed Ð
Convertible Only
2 20 Amp
YellowAWD ECU Feed
Cavity Cartridge
FuseMini
FuseDescription
3 10 Amp
RedCHMSL Brake Switch
Feed
4 10 Amp
RedIgnition Switch Feed
5 20 Amp
YellowTrailer Tow
6 10 Amp
RedIOD Sw/Pwr Mir/
Ocm Steering Cntrl
Sdar/Hfm
7 30 Amp
GreenIOD Sense1
8 30 Amp
GreenIOD Sense2
9 40 Amp
GreenPower Seats
10 20 Amp
YellowCCN, Power Locks
Integrated Power Module Location
MAINTAINING YOUR VEHICLE 401
7

Cavity Cartridge
FuseMini
FuseDescription
11 15 Amp
Lt BluePower Outlet
12 20 Amp
YellowIgn Run/Acc Inverter
13 20 Amp
YellowPwr run/Acc Outlet
RR
14 10 Amp
RedIOD CCN/ Interior
Lighting
15 50 Amp
RedRAD Fan Relay Bat-
tery Feed
16 15 Amp
Lt. BlueIGN Run/Acc Cigar
Ltr/Sunroof
17 10 Amp
RedIOD Feed CVT Mod/
Mod_Wcm
18 40 Amp
GreenASD Relay Contact
PWR FeedCavity Cartridge
FuseMini
FuseDescription
19 20 Amp
YelowPWR Amp 1 & Amp
2 Feed
20 15 Amp
Lt. BlueIOD Feed Radio
21 10 Amp
RedIOD Feed Intrus
Mod/Siren
22 10 Amp
RedIGN RUN Hvac/
Compass Sensor
23 15 Amp
Lt. BlueENG ASD Relay Feed
3
24 25 Amp
NaturalPWR Sunroof Feed
25 10 Amp
RedHeated Mirror
26 15 Amp
Lt. BlueENG ASD Relay Feed
2
402 MAINTAINING YOUR VEHICLE

Cavity Cartridge
FuseMini
FuseDescription
27 10 Amp
RedIGN RUN Only ORC
Feed
28 10 Amp
RedIGN RUN ORC/OCM
Feed
29 EMPTY
30 20 Amp
YellowHeated Seats
31 10 Amp
RedHeadlamp Washer
Relay Control
32 30 Amp
PinkENG ASD Control
Feed 1
33 10 Amp
RedABS MOD/J1962
Conn/PCM
34 30 Amp
PinkABS Valve FeedCavity Cartridge
FuseMini
FuseDescription
35 40 Amp
GreenABS Pump Feed
36 30 Amp
PinkHeadlamp Washer
Control
37 25 Amp
NaturalSpare
MAINTAINING YOUR VEHICLE 403
7

CAUTION!
²When installing the Integrated Power Module
cover, it is important to ensure the cover is prop-
erly positioned and fully latched. Failure to do so
may allow water to get into the Integrated Power
Module, and possibly result in a electrical system
failure.
²When replacing a blown fuse, it is important to
use only a fuse having the correct amperage
rating. The use of a fuse with a rating other than
indicated may result in a dangerous electrical
system overload. If a properly rated fuse contin-
ues to blow, it indicates a problem in the circuit
that must be corrected.
VEHICLE STORAGE
If you will not be using your vehicle for more than 21
days you may want to take steps to preserve your battery.
You may:
²Disengage the mini fuse in the Power Distribution
Center labeled IOD (Ignition Off-Draw).
²Or, disconnect the negative cable from the battery.
404 MAINTAINING YOUR VEHICLE

Flat Tire Stowage........................ 349
Flooded Engine Starting................... 282
Fluid, Brake........................... 412
Fluid Capacities......................... 410
Fluid Leaks............................ 114
Fluid Level Checks
Automatic Transaxle.................... 391
Fluids................................ 411
Fluids, Lubricants and Genuine Parts.......... 411
Fog Light Service........................ 407
Fog Lights..........................183,229
Folding Front Passenger Seat............... 163
Folding Rear Seat.....................167,169
Folding Rear Seat (Convertible).............. 169
Folding Rear Seat (Sedan).................. 167
Freeing A Stuck Vehicle................... 353
Fuel..............................321,411
Adding............................. 325
Additives............................ 324Capacity............................ 410
Clean Air............................ 322
Filler Cap (Gas Cap).................224,325
Filler Door (Gas Cap)................... 224
Filter............................... 374
Gasoline............................ 321
Gauge.............................. 224
Hoses.............................. 387
Light............................... 229
Octane Rating........................ 321
Requirements......................... 321
System Hoses......................... 387
Tank Capacity........................ 410
Fueling............................... 325
Fuses................................ 400
Garage Door Opener (HomeLinkt) ........... 193
Gas Cap (Fuel Filler Cap)............325,328,364
Gasoline, Clean Air...................... 322
