WHAT TO DO IN EMERGENCIES
CONTENTS
mHazard Warning Flasher..................342
mIf Your Engine Overheats.................342
mJacking And Tire Changing................344
NJack Location........................345
NSpare Tire Stowage....................345
NPreparations For Jacking................346
NJacking Instructions....................347
mJump-Starting Procedures Due To A Low
Battery..............................350mDriving On Slippery Surfaces..............352
NAcceleration.........................352
NTraction............................352
mFreeing A Stuck Vehicle..................353
mTowing A Disabled Vehicle................354
NWith Ignition Key.....................354
NWithout The Ignition Key...............355
mConvertible Top Manual Override...........356
6
Page 344 of 467
WARNING!
A hot engine cooling system is dangerous. You or
others could be badly burned by steam or boiling
coolant. You may want to call a service center if your
vehicle overheats. If you decide to look under the
hood yourself, refer to Section 7, Maintenance, of
this manual. Follow the warnings under the Cooling
System Pressure Cap paragraph.
JACKING AND TIRE CHANGING
WARNING!
²Being under a jacked-up vehicle is dangerous.
The vehicle could slip off the jack and fall on you.
You could be crushed. Never put any part of your
body under a vehicle that is on a jack. Never start
or run the engine while the vehicle is on a jack. If
you need to get under a raised vehicle, take it to a
service center where it can be raised on a lift.
²The jack is designed to use as a tool for changing
tires only. The jack should not be used to lift the
vehicle for service purposes. The vehicle should
be jacked on a firm level surface only. Avoid ice or
slippery areas.
344 WHAT TO DO IN EMERGENCIES
Page 346 of 467
Spare Tire Removal
Lift up the cover and fit the jack-handle over the drive
nut. Rotate the nut to the left until you can remove the
swivel hook from the stowage basket. Swing the basket
down to remove the compact spare tire.
CAUTION!
The hook is designed for use with the jack handle
only. Use of an air wrench or other power tools is not
recommended and can damage the winch.
Preparations For Jacking
Park the vehicle on a firm level surface, avoid ice or
slippery areas,set the parking brakeand place the gear
selector in PARK (automatic transaxle) or REVERSE
(manual transaxle). Turn OFF the ignition.
Lowering Spare Tire
346 WHAT TO DO IN EMERGENCIES
Page 347 of 467
WARNING!
Do not attempt to change a tire on the side of the
vehicle close to moving traffic. Pull far enough off
the road to avoid the danger of being hit when
operating the jack or changing the wheel.
²Turn on the Hazard Warning Flasher.
²Block both the front and rear
of the wheel diagonally oppo-
site the jacking position. For
example, if changing the right
front tire, block the left rear
wheel.
²Passengers should not remain in the vehicle while the
vehicle is being jacked.
Jacking Instructions
1. Remove the scissors jack and lug wrench from the
stowage bag.
NOTE:If equipped with a center cap that covers the
wheel nuts, pry off the cap using the small end of the lug
wrench. To reinstall the cap, make sure it is properly
lined up before pushing it on to the wheel.
2. Loosen, but do not remove, the wheel nuts by turning
them to the left one turn while the wheel is still on the
ground.
CAUTION!
Do not attempt to raise the vehicle by jacking on the
crossmember below the radiator, on the front sus-
pension crossmember, or on the rear axle assembly.
WHAT TO DO IN EMERGENCIES 347
6
Page 348 of 467
3. There are two front jacking locations on each side of
the body and rear jacking locations located on the trailing
arm bracket under the triangular cut out symbol. Turn
the jack screw to the right until the jack head is properly
engaged with the lift area closest to the wheel to be
changed.Do not raise the vehicle until you are sure the jack is
securely engaged.
4. Raise the vehicle by turning the jack screw to the right,
using the swivel wrench. Raise the vehicle only until the
tire just clears the surface and enough clearance is
obtained to install the spare tire. Minimum tire lift
provides maximum stability.
WARNING!
Raising the vehicle higher than necessary can make
the vehicle less stable. It could slip off the jack and
hurt someone near it. Raise the vehicle only enough
to remove the tire.
5. Remove the wheel nuts and pull the wheel and wheel
covers where applicable off the hub. Install the spare
wheel and wheel nuts with the cone shaped end of the
Jacking Locations
348 WHAT TO DO IN EMERGENCIES
