2007 Passenger Cars17
OTHER THINGS YOU SHOULD KNOW
RECLAIMED REFRIGERANT
To help control suspected ozone-depleting agents, regulations
require the capture, purification and reuse of automotive refrigerant
gases. As a result, any repairs to the sealed portion of your air
conditioning system, if so equipped, may involve the installation of
purified reclaimed refrigerant.
CASSETTE TA P E S AND CDS
There are some things you should know about cassette
tapes and non-commercial CDs. Labels applied to tape
cassettes and home-recorded CDs may curl, buckle or peel off.
This can result in ejection failure, and repairs required to remove
a “stuck” CD or cassette are not covered by warranty. In addition,
some home-recorded CDs of the CD-R and CD-RW formats may
not be compatible with automotive CD players and may skip or
produce error messages. If you encounter this, check your CD
player by using a commercial CD which is known to be playable. If
a CD is not compatible with the player, replacing or servicing the
player will not solve the problem.

2007 Passenger Cars
Retailer Copy
Remove and attach to Repair Order
26-92-02-01 3N.

Maintenance Service
Schedule “B”
Odometer Reading
Date
20,000 km Maintenance Service Schedule “B”
20,000 km
 Change engine oil and engine oil filter (or every 3 months, whichever occurs first).
 Inspect the engine air cleaner filter, replace if necessary (Pacifica and Minivan only).
 Replace the air conditioning filter (Pacifica and Minivan only).
 Check spare tire for proper pressure and correct stowage.
 Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
 Inspect the front and rear brake linings and rotors (PT Cruiser only).
 Inspect the brake hoses.
 Inspect the CV joints and front and rear suspension components.
 Check the coolant level, hoses and clamps.
 Inspect the exhaust system.
 Check the manual transmission fluid level (if equipped) (Sebring only).
 Check the manual transaxle fluid level and fill plug condition (PT Cruiser only).
 Check the automatic transaxle fluid level (PT Cruiser only).
 Check the automatic transmission fluid level.

2007 Passenger Cars
DAIMLERCHRYSLER
R
ETAILER STAMP
Signature of authorized DaimlerChrysler Canada Retailer
Odometer Reading
Date
Repair Order No.
 Change engine oil and engine oil filter (or every 3 months,
whichever occurs first).
 Inspect the engine air cleaner filter, replace
if necessary (Pacifica and Minivan only).
 Replace the air conditioning filter (Pacifica and Minivan
only).
 Check spare tire for proper pressure and correct stowage.
 Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
 Inspect the front and rear brake linings and rotors
(PT Cruiser only).
 Inspect the brake hoses.

Inspect the CV joints and front and rear suspension
components.
 Check the coolant level, hoses and clamps.
 Inspect the exhaust system.
 Check the manual transmission fluid level (if equipped)
(Sebring only).
 Check the manual transaxle fluid level and fill plug
condition (PT Cruiser only).
 Check the automatic transaxle fluid level (PT Cruiser
only).
 Check the automatic transmission fluid level.
Maintenance Service Schedule “B”
20,000 km

2007 Passenger Cars
Retailer Copy
Remove and attach to Repair Order
26-92-02-01 3N.

Maintenance Service
Schedule “B”
Odometer Reading
Date
40,000 km Maintenance Service Schedule “B”
40,000 km
 Change engine oil and engine oil filter (or every 3 months, whichever occurs first).
 Inspect the engine air cleaner filter, replace if necessary (Pacifica and Minivan only).
 Replace the air conditioning filter (Pacifica and Minivan only).
 Check spare tire for proper pressure and correct stowage.
 Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
 Inspect the front and rear brake linings and rotors (PT Cruiser only).
 Inspect the brake hoses.
 Inspect the CV joints and front and rear suspension components.
 Check the coolant level, hoses and clamps.
 Inspect the exhaust system.
 Check the manual transmission fluid level (if equipped) (Sebring only).
 Check the manual transaxle fluid level and fill plug condition (PT Cruiser only).
 Check the automatic transaxle fluid level (PT Cruiser only).
 Check the automatic transmission fluid level.

2007 Passenger Cars
DAIMLERCHRYSLER
R
ETAILER STAMP
Signature of authorized DaimlerChrysler Canada Retailer
Odometer Reading
Date
Repair Order No.
 Change engine oil and engine oil filter (or every 3 months,
whichever occurs first).
 Inspect the engine air cleaner filter, replace if necessary
(Pacifica and Minivan only).
 Replace the air conditioning filter (Pacifica and Minivan
only).
 Check spare tire for proper pressure and correct stowage.
 Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
 Inspect the front and rear brake linings and rotors
(PT Cruiser only).
 Inspect the brake hoses.
 Inspect the CV joints and front and rear suspension
components.
 Check the coolant level, hoses and clamps.
 Inspect the exhaust system.
 Check the manual transmission fluid level (if equipped)
(Sebring only).
 Check the manual transaxle fluid level and fill plug
condition (PT Cruiser only).
 Check the automatic transaxle fluid level (PT Cruiser only).
 Check the automatic transmission fluid level.Maintenance Service Schedule “B”
40,000 km

2007 Passenger Cars
Maintenance Service
Schedule “B”
Odometer Reading
Date
Retailer Copy
Remove and attach to Repair Order
26-92-02-01 3N.

60,000 km Maintenance Service Schedule “B”
60,000 km
 Change engine oil and engine oil filter (or every 3 months, whichever occurs first).
 Inspect the engine air cleaner filter, replace if necessary (Pacifica and Minivan only).
 Replace the air conditioning filter (Pacifica and Minivan only).
 Check spare tire for proper pressure and correct stowage.
 Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
 Inspect the front and rear brake linings and rotors (All models).
 Inspect the brake hoses.
 Inspect the CV joints and front and rear suspension components.
 Check the coolant level, hoses and clamps.
 Inspect the exhaust system.
 Check the manual transmission fluid level (if equipped) (Sebring only).
 Check the manual transaxle fluid level and fill plug condition (PT Cruiser only).
 Check the automatic transaxle fluid level (PT Cruiser only).
 Check the automatic transmission fluid level.

2007 Passenger Cars
DAIMLERCHRYSLER
R
ETAILER STAMP
Signature of authorized DaimlerChrysler Canada Retailer
Odometer Reading
Date
Repair Order No.
 Change engine oil and engine oil filter (or every 3 months,
whichever occurs first).
 Inspect the engine air cleaner filter, replace if necessary
(Pacifica and Minivan only).
 Replace the air conditioning filter (Pacifica and Minivan
only).
 Check spare tire for proper pressure and correct stowage.
 Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
 Inspect the front and rear brake linings and rotors
(All models).
 Inspect the brake hoses.
 Inspect the CV joints and front and rear suspension
components.
 Check the coolant level, hoses and clamps.
 Inspect the exhaust system.
 Check the manual transmission fluid level (if equipped)
(Sebring only).
 Check the manual transaxle fluid level and fill plug
condition (PT Cruiser only).
 Check the automatic transaxle fluid level (PT Cruiser only).
 Check the automatic transmission fluid level.Maintenance Service Schedule “B”
60,000 km

2007 Passenger Cars
Retailer Copy
Remove and attach to Repair Order
26-92-02-01 3N.

Maintenance Service
Schedule “B”
Odometer Reading
Date
80,000 km Maintenance Service Schedule “B”
80,000 km
 Change engine oil and engine oil filter (or every 3 months, whichever occurs first).
 Inspect the engine air cleaner filter, replace if necessary (Pacifica and Minivan only).
 Change the brake fluid (if vehicle is used for trailer towing) (PT Cruiser only).
 Replace the air conditioning filter (Pacifica and Minivan only).
 Change the manual transaxle fluid (PT Cruiser only).
†
 Check spare tire for proper pressure and correct stowage.
 Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
 Inspect the front and rear brake linings and rotors (PT Cruiser only).
 Inspect the brake hoses.
 Inspect the CV joints and front and rear suspension components.
 Check the coolant level, hoses and clamps.
 Inspect the exhaust system.
 Check the manual transmission fluid level (if equipped) (Sebring only).
 Check the manual transaxle fluid level and fill plug condition (PT Cruiser only).
 Check the automatic transaxle fluid level (PT Cruiser only).
 Check the automatic transmission fluid level.
†This maintenance is required only for police, taxi, limousine type operation, or trailer towing.

2007 Passenger Cars
DAIMLERCHRYSLER
R
ETAILER STAMP
Signature of authorized DaimlerChrysler Canada Retailer
Odometer Reading
Date
Repair Order No.
 Change engine oil and engine oil filter (or every 3 months,
whichever occurs first).
 Inspect the engine air cleaner filter, replace if necessary
(Pacifica and Minivan only).
 Change the brake fluid (if vehicle is used for trailer towing)
(PT Cruiser only).
 Replace the air conditioning filter (Pacifica and Minivan only).
 Change the manual transaxle fluid (PT Cruiser only).
†
 Check spare tire for proper pressure and correct stowage.
 Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
 Inspect the front and rear brake linings and rotors
(PT Cruiser only).
 Inspect the brake hoses.
 Inspect the CV joints and front and rear suspension
components.
 Check the coolant level, hoses and clamps.
 Inspect the exhaust system.
 Check the manual transmission fluid level (if equipped)
(Sebring only).
 Check the manual transaxle fluid level and fill plug
condition (PT Cruiser only).
 Check the automatic transaxle fluid level (PT Cruiser only).
 Check the automatic transmission fluid level.
†This maintenance is required only for police, taxi, limousine type operation, or
trailer towing.
Maintenance Service Schedule “B”
80,000 km

2007 Passenger Cars
Retailer Copy
Remove and attach to Repair Order
26-92-02-01 3N.

Maintenance Service
Schedule “B”
Odometer Reading
Date
100,000 km
Maintenance Service Schedule “B”
100,000 km
 Change engine oil and engine oil filter (or every 3 months, whichever occurs first).
 Replace the engine air cleaner filter (All models).*
 Replace the air conditioning filter (Pacifica and Minivan only).
 Inspect and adjust the power steering pump belt tension (Caravan 2.4L engine only).
 Replace the spark plugs and ignition cables (PT Cruiser and Caravan 2.4L engines only).
 Replace the spark plugs (2.4L Sebring only).
 Inspect the PCV valve and replace if necessary (Pacifica and Minivan only).*
‡ Replace the make-up air filter (PT Cruiser only).
 Inspect the serpentine drive belt, replace if necessary (Town & Country/Caravan 3.3L and 3.8L engines and
Pacifica only).
‡ Adjust the generator drive belt tension (PT Cruiser only).
 Inspect the generator belt on 2.4L engines, replace if necessary (Caravan only).
 Change the automatic transaxle fluid and filter (All models).
† Flush and replace engine coolant at 60 months or 170,000 kilometres, whichever comes first (All models).
 Check spare tire for proper pressure and correct stowage.
 Rotate tires and check tire pressure.
INSPECT THE FOLLOWING: Inspect the front and rear brake linings and rotors (PT Cruiser only).
 Inspect the brake hoses.
 Inspect the CV joints and front and rear suspension components.
 Check the coolant level, hoses and clamps.
 Inspect the exhaust system.
 Inspect the tie rod ends and boot seals (PT Cruiser, Pacifica and Minivan only).
 Check the manual transmission fluid level (if equipped) (Sebring only).
 Check the manual transaxle fluid level and fill plug condition (PT Cruiser only).
 Check the automatic transaxle fluid level (PT Cruiser only).
 Check the automatic transmission fluid level.
*This maintenance is recommended by the manufacturer, but not required to maintain the emissions warranty.†This maintenance is required only for police, taxi, limousine type operation, or trailer towing.‡This maintenance is not required if previously replaced.
