WARNING!
Fast spinning tires can be dangerous. Forces gener-
ated by excessive wheel speeds may cause tire dam-
age or failure. A tire could explode and injure some-
one. Do not spin your vehicle's wheels faster than 30
mph (48 km/h) when you are stuck. And don't let
anyone near a spinning wheel, no matter what the
speed.
CAUTION!
Racing the engine or spinning the wheels too fast
may lead to transaxle overheating and failure. It can
also damage the tires. Do not spin the wheels above
30 mph (48 km/h).
TOWING A DISABLED VEHICLE
With Ignition Key
Four Speed Automatic Transaxle
Your vehicle may be towed under the following condi-
tions: The steering column must be unlocked and the
gear selector must be in NEUTRAL, the distance to be
towed must not exceed 100 miles (160 km), and the
towing speed must not exceed 44 mph (72 km/h). If the
transaxle is not operative, or if the vehicle is to be towed
more than 100 miles (160 km), the vehicle must be towed
with the front wheels off the ground to avoid damage to
the transaxle.
Manual Transaxle
Your vehicle may be towed in a forward direction, with
all 4 wheels on the ground, and the gearshift lever is in
NEUTRAL. If the transaxle is not operative, the vehicle
must be towed with the front wheels off the ground.
WHAT TO DO IN EMERGENCIES 371
6

All Transaxles
CAUTION!
If the vehicle being towed requires steering, the
ignition switch must be in the ACC position, not in
the LOCK positions.
Do not attempt to use sling type equipment when
towing. When securing vehicle to flat bed truck, do
not attach to front or rear suspension components.
Damage to your vehicle may result from improper
towing.
If it is necessary to use the accessories while being towed
(wipers, defrosters, etc.), the key must be in the ON
position, not the ACC position. Make certain the trans-
axle remains in NEUTRAL.
Without The Ignition Key
Special care must be taken when the vehicle is towed
with the ignition in the LOCK position. A dolly should be
used under the front wheels if the rear wheels are raised.
Proper towing equipment is necessary to prevent dam-
age to the vehicle.
Towing This Vehicle Behind Another Vehicle (Flat
Towing With All Four Wheels On The Ground)
If your vehicle is equipped with a manual transaxle, it
may be towed in a forward direction, at any legal
highway speed, for any distance, if the transaxle is in
NEUTRAL.
If the ignition key is not available, vehicles with auto-
matic transaxles can not be flat towed at any time.
372 WHAT TO DO IN EMERGENCIES

CONVERTIBLE TOP MANUAL OVERRIDE
If your vehicle is experiencing electrical failure (low
battery, etc.) and it is necessary to raise the convertible
top, perform the following steps:
1. Locate the convertible top motor bypass screw, which
is found in the trunk under the convertible top storage
area.
2. Turn the screw counterclockwise until the screw stops.
This will relieve the hydraulic pressure and allow the
convertible top to be raised manually.
Bleeder Screw
WHAT TO DO IN EMERGENCIES 373
6

3. Using the latch handle raise the top until the two pins
seat themselves in the windshield header.
4. Rotate the latch handle clockwise to open the latches.
5. Pull down and rotate the handle counterclockwise to
engage the latches.6. Raise the handle into the stowed position.
7. Close the convertible top motor bypass screw by
turning the screw clockwise until it stops. Tighten the
screw securely.
NOTE:Failure to tighten the bypass screw securely can
cause convertible top operating concerns.
Engaging Convertible Top
374 WHAT TO DO IN EMERGENCIES

MAINTAINING YOUR VEHICLE
CONTENTS
m2.4L Turbo Engine Compartment............378
m2.4L Engine Compartment................379
mOnboard Diagnostic System Ð OBD II........380
NLoose Fuel Filler Cap Message............381
mEmissions Inspection And Maintenance
Programs............................381
mReplacement Parts......................383
mAuthorized Dealer Service................383
mMaintenance Procedures..................384NEngine Oil..........................384
NDrive Belts Ð Check Condition And Tension . . 388
NSpark Plugs.........................388
NIgnition Wiring System.................388
NCatalytic Converter....................389
NEngine Timing Belt....................390
NCrankcase Emission Control System........390
NFuel Filter..........................391
NAir Cleaner Element (Air Filter)...........391
7

NMaintenance-Free Battery................392
NAir Conditioner Maintenance.............393
NPower Steering ± Fluid Check............394
NFront Suspension Ball Joints..............395
NSteering Linkage......................395
NBody Lubrication.....................395
NWindshield Wiper Blades................396
NWindshield Washer Reservoir.............396
NExhaust System......................397
NCooling System.......................398
NHoses And Vacuum/Vapor Harnesses.......403
NFuel System Connections................404
NBrake System........................404NAutomatic Transaxle...................408
NManual Transaxle.....................410
NAppearance Care And Protection From
Corrosion...........................411
mConvertible Top Care....................416
NWashing............................416
NGeneral Cleaning.....................417
NCloth Top Additional Cleaning Procedure....418
NCloth Top Protection...................418
NWeather Strip Care....................418
mIntegrated Power Module (IPM)............419
mVehicle Storage........................423
mReplacement Bulbs......................424
376 MAINTAINING YOUR VEHICLE

mBulb Replacement......................425
NHeadlights..........................425
NFront Park/Turn Signal/Side Marker Lights . . 426
NFront Fog Lights Ð If Equipped...........426
NTail/Stop, And Rear Turn Signal Lights......427
NBack Up Lights.......................427NCenter High Mounted Stop Light..........428
mFluids And Capacities...................429
mFluids, Lubricants And Genuine Parts........430
NEngine.............................430
NChassis............................431
MAINTAINING YOUR VEHICLE 377
7

2.4L TURBO ENGINE COMPARTMENT
378 MAINTAINING YOUR VEHICLE

2.4L ENGINE COMPARTMENT
MAINTAINING YOUR VEHICLE 379
7

ONBOARD DIAGNOSTIC SYSTEM Ð OBD II
Your vehicle is equipped with a sophisticated onboard
diagnostic system called OBD II. This system monitors
the performance of the emissions, engine, and automatic
transmission control systems. When these systems are
operating properly, your vehicle will provide excellent
performance and fuel economy, as well as engine emis-
sions well within current government regulations.
If any of these systems require service, the OBD II system
will turn on the ªMalfunction Indicator Light.º It will
also store diagnostic codes and other information to
assist your service technician in making repairs. Al-
though your vehicle will usually be drivable and not
need towing, see your dealer for service as soon as
possible.CAUTION!
²Prolonged driving with the ªMalfunction Indica-
tor Lightº on could cause further damage to the
emission control system. It could also affect fuel
economy and driveability. The vehicle must be
serviced before any emissions tests can be per-
formed.
²If the ªMalfunction Indicator Lightº is flashing
while the engine is running, severe catalytic con-
verter damage and power loss will soon occur.
Immediate service is required.
