CHRYSLER PT CRUISER 2008 1.G Owners Manual

INTEGRATED POWER MODULE (IPM)
CavityCartridge
FuseMini Fuse Description
17 10 Amp RedIOD Feed
CVT Mod/
Mod_Wcm
1840 Amp
GreenASD Relay
Contact
PWR Feed
1920 Amp
YelowPWR Amp
1 & Amp 2
Feed
2015 Amp Lt.
BlueIOD Feed
Radio
21 10 Amp RedIOD Feed
Intrus
Mod/SirenINTEGRATED POWER MODULE (IPM)
CavityCartridge
FuseMini Fuse Description
22 10 Amp RedIGN RUN
Hvac/
Compass
Sensor
2315 Amp Lt.
BlueENG ASD
Relay Feed
3
2425 Amp
NaturalPWR Sun-
roof Feed
25 10 Amp RedHeated Mir-
ror
2615 Amp Lt.
BlueENG ASD
Relay Feed
2
MAINTAINING YOUR VEHICLE 421
7

INTEGRATED POWER MODULE (IPM)
CavityCartridge
FuseMini Fuse Description
27 10 Amp RedIGN RUN
Only ORC
Feed
28 10 Amp RedIGN RUN
ORC/OCM
Feed
29 EMPTY
3020 Amp Yel-
lowHeated
Seats
31 10 Amp RedHeadlamp
Washer Re-
lay Control
3230 Amp
PinkENG ASD
Control
Feed 1INTEGRATED POWER MODULE (IPM)
CavityCartridge
FuseMini Fuse Description
33 10 Amp RedABS MOD/
J1962
Conn/PCM
3430 Amp
PinkABS Valve
Feed
3540 Amp
GreenABS Pump
Feed
3630 Amp
PinkHeadlamp
Washer
Control
3725 Amp
NaturalSpare
422 MAINTAINING YOUR VEHICLE

CAUTION!
²When installing the Integrated Power Module
cover, it is important to ensure the cover is prop-
erly positioned and fully latched. Failure to do so
may allow water to get into the Integrated Power
Module, and possibly result in a electrical system
failure.
²When replacing a blown fuse, it is important to
use only a fuse having the correct amperage rating.
The use of a fuse with a rating other than indicated
may result in a dangerous electrical system over-
load. If a properly rated fuse continues to blow, it
indicates a problem in the circuit that must be
corrected.
VEHICLE STORAGE
If you will not be using your vehicle for more than 21
days, you may want to take steps to preserve your
battery. You may:
²Disengage the mini-fuse in the Power Distribution
Center labeled IOD (Ignition Off-Draw).
²Or, disconnect the negative cable from the battery.
MAINTAINING YOUR VEHICLE 423
7

REPLACEMENT BULBS
LIGHT BULBS Ð Inside Bulb No.
Center Console Floor Lamp................. T37
Climate Controls......................6233137
Console Gear Selector...................PC194
Dome Light (sedan)......................T579
Dome Light / Sport Bar Lights (convertible)....T904
Instrument Cluster Illumination.............. 74
Overhead Reading Light (Overhead Console). . . T1037
Overhead Reading Light (Rearview Mirror).....T192
Rear Cargo............................T906
Visor Vanity.........................6501966
All the inside bulbs are brass or glass wedge base.
Aluminum base bulbs are not approved and should not
be used for replacement.LIGHTS BULBS Ð Outside Bulb No.
Low Beam Headlight...................9006XS
High Beam Headlight...................9005XS
Front Park/Turn Signal/Side Marker
Light............................4157NAKX
Front Fog Light.........................9145
Center High Mounted Stop Light
(CHMSL) (Sedan)...................921±W16W
Center High Mounted Stop Light
(CHMSL) (Convertible).................... LED
Rear Tail/Stop..........................3157
Rear Turn Signal.......................3757A
Backup Light.....................3157-P27/7W
License Light........................... 168
424 MAINTAINING YOUR VEHICLE

BULB REPLACEMENT
Headlights
CAUTION!
Do not touch the new headlight bulb with your
fingers. Oil contamination will severely shorten bulb
life.
1. Remove the headlight access cover splash shield,
located in the front wheel well opening.
2. Disconnect the electrical connector.3. Rotate the socket to the left one quarter turn and
replace the bulb.
MAINTAINING YOUR VEHICLE 425
7

Front Park/Turn Signal/Side Marker Lights
1. Remove the headlight access cover splash shield,
located in the front wheel well opening.
2. Rotate the socket to the left one quarter turn to replace
and replace the bulb.
Front Fog Lights Ð If Equipped
1. Remove the fasteners attaching the lower splash
shield to gain access to the fog light.
2. Twist and remove the bulb from the fog light housing.
3. Disconnect the electrical connector and replace bulb.
426 MAINTAINING YOUR VEHICLE

Tail/Stop, and Rear Turn Signal Lights
1. Remove the screw attaching the tail light housing and
remove the housing from the vehicle.
2. Twist the bulb socket 1/4 turn to remove it from the
housing.3. Pull the bulb out of the socket and replace.Back Up Lights
Removing Backup Light Bulbs
MAINTAINING YOUR VEHICLE 427
7

1. To remove the backup lamp, you must take a fiber
stick and slide it along the inboard side of the lamp and
compress a spring clip to allow it to partially9pop9out to
the secondary catch.
2. Fully compress the clip to get the lamp to come out
completely.
3. Remove the socket from the housing.
4. Pull the bulb out of the socket and replace.Center High Mounted Stop Light
1. Open the liftgate and remove the liftgate CHMSL
cover.
2. Remove CHMSL lens from the housing by unlatching
the two side latches.
3. Pull the bulb out of the socket and replace.
428 MAINTAINING YOUR VEHICLE

FLUIDS AND CAPACITIES
FLUIDS AND CAPACITIES
U.S. Metric
Fuel (Approximate)15 Gallons 56.7 Liters
Engine Oil-With Filter
2.4 Liter Engines (Use API Certified
SAE 5W-30 Engine Oil.)5.0 qts 4.7 Liters
Cooling System *
2.4 Liter Engines (Mopart
Antifreeze/Coolant 5 Year/100,000
Miles Formula), or equivalent.6.5 qts 6.2 Liters
* Includes heater and coolant recovery bottle filled to MAX level.
MAINTAINING YOUR VEHICLE 429
7

FLUIDS, LUBRICANTS AND GENUINE PARTS
ENGINE
FLUIDS, LUBRICANTS AND GENUINE PARTS
Component Fluids, Lubricants and Genuine Parts
Engine CoolantMopartAntifreeze/Coolant 5 Year/100,000 Mile For-
mula HOAT (Hybrid Organic Additive Technology) or
equivalent.
Engine Oil (2.4L Standard, 2.4L Standard Turbo)Use API Certified SAE 5W-30 Engine Oil. Refer to your
engine oil filler cap for correct SAE grade meeting
DaimlerChrysler Material Standard MS-6395.
Engine Oil FilterNon TurboÐMopart4105409AB or equiv.
TurboÐMopart4781452BB or equiv.
Spark Plugs2.4L Non Turbo Ð ChampiontRE16MC, 040º Gap 2.4L
Turbo Ð ChampiontRE14MCC5,.050º Gap.
Fuel Selection87 Octane for 2.4L Standard Turbo and 2.4L Standard
Non Turbo Engines.
430 MAINTAINING YOUR VEHICLE
