WARNING!
A frayed or torn belt could rip apart in a collision and
leave you with no protection. Inspect the belt system
periodically, checking for cuts, frays, or loose parts.
Damaged parts must be replaced immediately. Do
not disassemble or modify the system. Seat belt
assemblies must be replaced after a collision if they
have been damaged (bent retractor, torn webbing,
etc.).
Rear Center Lap/Shoulder Belt Retractor Lock-Out
This feature is designed to lock the retractor whenever
the rear seat back is not fully latched. This prevents
someone from wearing the rear center lap/shoulder belt
when the rear seat back is not fully latched.NOTE:
²If the rear center lap/shoulder belt can not be pulled
out, check that the rear seat back is fully latched.
²If the rear seat back is properly latched and the rear
center lap/shoulder belt still can not be pulled out, the
Automatic-Locking Retractor (ALR) system may be
activated. To reset this feature you must let all of the
belt webbing return into the retractor. You will not be
able to pull out more webbing until all of the webbing
has been returned back into the retractor.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51
2

WARNING!
The rear center lap/shoulder belt is equipped with a
lockout feature to ensure that the rear seat back is in
the fully upright and locked position when occupied.
If the rear seat back is not fully upright and locked
and the rear center lap/shoulder belt can be pulled
out of the retractor, the vehicle should immediately
be taken to your dealer for service. Failure to follow
this warning could result in serious or fatal injury.
LAP/SHOULDER SEAT BELT UNTWISTING
PROCEDURE
Use the following procedure to untwist a twisted lap/
shoulder belt.
1. Position the latch plate as close as possible to the
anchor point.2. At about six to twelve inches (15 to 30 cm) above the
latch plate, grasp and twist the belt webbing 180É to
create a fold that begins immediately above the latch
plate.
3. Slide the latch plate upward over the folded webbing.
The folded webbing must enter the slot at the top of the
latch plate.
4. Continue to slide the latch plate up until it clears the
folded webbing.
ADJUSTABLE UPPER SHOULDER SEAT BELT
ANCHORAGE
In the front seat, the shoulder belt can be adjusted
upward or downward to position the belt away from
your neck. Push up or down on the anchorage button to
release the anchorage, and move it up or down to the
position that serves you best.
52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

As a guide, if you are shorter than average, you will
prefer a lower position, and if you are taller than average,
you'll prefer a higher position. When you release the
anchorage, try to move it up or down to make sure that
it is locked in position.
SEAT BELT PRETENSIONERS
The seat belts for both front seating positions are
equipped with pretensioning devices that are designed to
remove slack from the seat belt in the event of a collision.
These devices improve the performance of the seat belt
by assuring that the belt is tight about the occupant early
in a collision. Pretensioners work for all size occupants,
including those in child restraints.
NOTE:These devices are not a substitute for proper seat
belt placement by the occupant. The seat belt still must be
worn snugly and positioned properly.
The pretensioners are triggered by the front airbag con-
trol module (see Airbag Section). Like the front airbags,
the pretensioners are single use items. After a collision
that is severe enough to deploy the airbags and preten-
sioners, both must be replaced.
Adjusting Upper Shoulder Belt
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53
2

ENHANCED SEAT BELT REMINDER SYSTEM
(BELTALERTT)
If the driver's or front passenger's seat belt has not been
buckled within 60 seconds of starting the vehicle and if
the vehicle speed is greater than 5 mph (8 km/h), the
Enhanced Warning System (BeltAlertt) will alert the
driver or front passenger to buckle their seat belt. The
driver should also instruct all other occupants to buckle
their seat belts. If the driver unbuckles the seat belt while
the vehicle is in motion an immediate chime will be heard
and, the Enhanced Warning System (BeltAlertt) will
continue to chime and flash the Seat Belt Warning Light
for 96 seconds or until the driver's seat belt is buckled.
The Enhanced Warning System (BeltAlertt) will be reac-
tivated if the driver's or front passenger's seat belt is
unbuckled for more than 10 seconds and the vehicle
speed is greater than 5 mph (8 km/h).NOTE:
²The Enhanced Warning System (BeltAlertt) can be
enabled or disabled by your authorized dealer.
²DaimlerChrysler does not recommend deactivating
the Enhanced Warning System (BeltAlertt).
If the Enhanced Warning System (BeltAlertt) is deacti-
vated, the Seat Belt Warning Light will continue to
illuminate while the driver seat belt remains unfastened.
SEAT BELTS AND PREGNANT WOMEN
We recommend that pregnant women use the seat belts
throughout their pregnancy. Keeping the mother safe is
the best way to keep the baby safe.
Pregnant women should wear the lap part of the belt
across the thighs and as snug across the hips as possible.
Keep the belt low so that it does not come across the
abdomen. That way the strong bones of the hips will take
the force if there is a collision.
54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

DRIVER AND FRONT PASSENGER
SUPPLEMENTAL RESTRAINT SYSTEM (SRS)
AIRBAG
This vehicle has airbags for both the driver and front
passenger as a supplement to the seat belt restraint
systems. The driver's front airbag is mounted in the
center of the steering wheel. The passenger's front airbag
is mounted in the instrument panel, above the glove
compartment. The words SRS AIRBAG are embossed on
the airbag covers.
Head/Thorax airbags (if equipped) are located inside the
driver and front passenger seats, and their covers are also
labeled SRS AIRBAG.
Front Panel SRS Features
1 Ð Driver Airbag 3 Ð Passenger Knee Blocker
2 Ð Passenger Airbag 4 Ð Driver Knee BlockerTHINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55
2

NOTE:Airbag covers may not be obvious in the interior
trim; but they will open to allow airbag deployment.
WARNING!
²Do not drill, cut or tamper with the knee impact
blocker panels in any way.
²Do not mount any accessories to the knee blocker
panel such as alarm lights, stereos, citizens band
radios etc.
56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING!
²Do not put anything on or around the airbag
covers or attempt to manually open them. You may
damage the airbags and you could be injured
because the airbags are not there to protect you.
These protective covers for the airbag cushions are
designed to open only when the airbags are inflat-
ing.
²If your vehicle is equipped with Head/Thorax
airbags, do not use accessory seat covers or place
objects between you and the airbags; the perfor-
mance could be adversely affected and/or objects
could be pushed into you, causing serious injury.
Airbags inflate in moderate to high speed impacts. Along
with seat belts and pretensioners, front airbags work with
the instrument panel knee impact blockers to provideimproved protection for the driver and front passenger.
Head/Thorax side airbags also work with seat belts to
improve occupant protection.
The seat belts are designed to protect you in many types
of collisions. The front airbags deploy in moderate to
severe frontal collisions. If your vehicle is equipped, the
Head/Thorax airbag on the crash side of the vehicle is
triggered in moderate to severe side collisions. In certain
types of collisions, both the front seat Head/Thorax
airbags may be triggered. But even in collisions where
the airbags work, you need to wear the seat belts to keep
you in the right position for the airbags to protect you
properly.
NOTE:The passenger front airbag may not deploy even
when the driver front airbag has if the Occupant Classi-
fication System (refer to9Occupant Classification System9
in this section) has determined the passenger seat is
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57
2

empty or is occupied by someone that is classified in the
ªchild9category. This could be a child, a teenager, or even
a small adult.
Here are some simple steps you can take to minimize the
risk of harm from a deploying airbag.
1.Children 12 years old and under should always ride
buckled up in a rear seat.
Infants in rear facing child restraints shouldNEVERride
in the front seat of a vehicle with a passenger front airbag.
An airbag deployment can cause severe injury or death to
infants in that position.
Children that are not big enough to properly wear the
vehicle seat belt (see Section on Child Restraints) should
be secured in the rear seat in child restraints or belt-
positioning booster seats. Older children who do not use
child restraints or belt-positioning booster seats shouldride properly buckled up in the rear seat. Never allow
children to slide the shoulder belt behind them or under
their arm.
You should read the instructions provided with your
child restraint to make sure that you are using it properly.
2. All occupants should wear their lap and shoulder belts
properly.
3. The driver and front passenger seats should be moved
back as far as practical to allow the front airbags room to
inflate.
4. If your vehicle has supplemental side and or thorax
airbags, do not lean against the door, airbags will inflate
forcefully into the space between you and the door.
5. If the airbag system in this vehicle needs to be
modified to accommodate a disabled person, contact the
Customer Center. Phone numbers are provided under9If
You Need Assistance9in Section 9 of this manual.
58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING!
²Relying on the airbags alone could lead to more
severe injuries in a collision. The airbags work
with your seat belt to restrain you properly. In
some collisions the airbags won't deploy at all.
Always wear your seat belts even though you have
airbags.
²Being too close to the steering wheel or instrument
panel during front airbag deployment could cause
serious injury. Airbags need room to inflate. Sit
back, comfortably extending your arms to reach
the steering wheel or instrument panel.
²Seat airbags also need room to inflate. Do not lean
against the door. Sit upright in the center of the
seat.The front airbag system consists of the following:
²Occupant Restraint Controller
²Side Remote Acceleration Sensors (If equipped)
²Airbag Warning Light
²Driver and Front Passenger Airbag
²Front Seat Mounted Head/Thorax Airbags (if
equipped)
²Steering Wheel and Column
²Instrument Panel
²Driver and Front Passenger Knee Impact Blockers
²Front Acceleration Sensors
²Driver and Front Passenger Seat Belt Pretensioners
²Passenger Airbag Disable (PAD) Indicator Light
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59
2

The Head/Thorax airbag system (if equipped) consists
of the following:
²AIRBAG Readiness Light (shared with the front airbag
system)
²Front SeatÐ side mounted Head/Thorax Airbags Ð if
equipped
²Airbag Control Module (shared with the front airbag
system)
²Side impact sensors
How The Airbag System Works
²
TheOccupant Restraint Controller (ORC)determines
if a frontal collision is severe enough to require the
airbags to inflate. The front airbag inflators are de-
signed to provide different rates of airbag inflation
from direction provided by the ORC. The ORC mayalso modify the rate of inflation based on the occupant
size provided by the Occupant Classification Module.
The ORC will not detect roll over.
The ORC also monitors the readiness of the electronic
parts of the system whenever the ignition switch is in
the START or RUN positions. These include all of the
items listed above except the steering wheel and
column, and knee blocker panels. If the key is in the
OFF position, in the ACC position, or not in the
ignition, the airbags are not on and will not inflate.
During a moderate-to-severe rear impact the ORC may
deploy the seat belt pretensioners alone.
Also, the ORC turns on the AIRBAG warning
light and PAD indicator light in the instrument
panel for six to eight seconds for a self-check
when the ignition is first turned on. After the
self-check, the AIRBAG warning light will turn off. The
PAD indicator light will function normally (Refer to
60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
