UNDERSTANDING THE FEATURES OF YOUR VEHICLE
CONTENTS
mConsole Features.......................53
NConsole Features Ð Without Heated Seats....53
NConsole Features Ð With Heated Seats.......54
mMirrors..............................55
NInside Day/Night MirrorÐ If Equipped......55
NElectric Remote-Control MirrorsÐ If
Equipped............................55
NOutside Mirror Ð Driver's Side............56
NOutside Mirror Ð Passenger's Side..........56
NIlluminated Vanity Mirrors Ð If Equipped....56
mSeats................................57
NManual Front Seat Adjustments............57NPower Seats Ð If Equipped...............58
NHeated Seats Ð If Equipped..............58
NAdjustable Head Restraints...............59
NFolding Rear Seat......................59
mTo Open And Close The Hood.............60
mLights...............................61
NInterior Lights........................61
NFront Map/Reading Lights Ð If Equipped....62
NMulti-Function Control Lever..............63
NHeadlights, Parking Lights, Instrument Panel
Lights..............................64
NDaytime Running Lights (Canada Only)......64
3

WARNING!
The cargo area in the rear of the vehicle (with the
rear seatbacks in the locked-up or folded down
position) should not be used as a play area by
children when the vehicle is in motion. They could
be seriously injured in an accident. Children should
be seated and using the proper restraint system.
TO OPEN AND CLOSE THE HOOD
To open the hood, two latches must be released. First pull
the hood release lever located under the left side of the
instrument panel.
60 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Then lift the secondary latch located under the front edge
of the hood, near the center and raise the hood.
Use the hood prop rod to secure the hood in the open
position. Place the upper end of the prop rod in the hole
marked ªpropº on the underside of the hood.
To prevent possible damage, do not slam the hood to
close it. Use a firm downward push at the center of the
hood to ensure that both latches engage.WARNING!
If the hood is not fully latched it could fly up when
the vehicle is moving and block your forward vision.
You could have a collision. Be sure all hood latches
are fully latched before driving.
LIGHTS
Interior Lights
The map/courtesy lights come on when a door is opened
and the panel lamp dimmer switch (located on the turn
signal control stalk) is in any detent except fully counter-
clockwise (dome lamp ON position) or fully clockwise
(dome lamp OFF position). Rotating the panel dimmer
switch fully counter-clockwise will turn on the lights.
Turn the panel dimmer switch fully clockwise to prevent
the lights from coming on when a door is opened.
NOTE:The interior lights have a ªfade to offº feature.
When the lights are turned off, they gradually ªfadeº off.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 61
3

Cooling System
Inspection
WARNING!
²When working near the radiator cooling fan, dis-
connect the fan motor lead or turn the ignition key
to the OFF position. The fan is controlled by both
the temperature of the engine cooling system and
the pressure in the air conditioning system and
can start at any time the ignition key is in the ON
position.
²You or others can be badly burned by hot coolant
or steam from your radiator. If you see or hear
steam coming from under the hood, don't open
the hood until the radiator has had time to cool.
Never try to open a cooling system pressure cap
when the radiator or cap is hot.
Coolant Checks
Check coolant protection every 12 months (before the
onset of freezing weather, where applicable). If coolant isdirty or rusty in appearance, the system should be
drained, flushed and refilled with fresh coolant.
Check the front of the radiator for any accumulation of
bugs, leaves, etc. Clean the radiator by gently spraying
water from a garden hose at the back of the core.
Check the recovery bottle tank tubing for condition and
tightness of connections at the bottle. Inspect the entire
system for leaks.
Do not remove the cap when the cooling system is hot.(2.7L Engine Shown)
MAINTAINING YOUR VEHICLE 205
7

BULB REPLACEMENT
Headlight Bulb Replacement
1. Open the hood and remove the two headlight mount-
ing screws.2. Remove the push-in fasteners by prying under the
head of the fasteners with a flat bladed tool.
222 MAINTAINING YOUR VEHICLE

7. Reinsert the bulb and socket assembly and turn the
retaining ring clockwise to secure the bulb.
8. Reinstall the headlight assembly.
Park, Turn Signal, Sidemarker Bulb Replacement
1. Open the hood and remove the two headlight assem-
bly mounting screws. Pull the headlight assembly away
from the vehicle.2. Turn the bulb socket counterclockwise and remove the
bulb and socket assembly.
3. Pull the bulb out of the socket, replace the bulb, and
reinstall the bulb and socket to the headlight assembly.
Reinstall the headlight assembly.
224 MAINTAINING YOUR VEHICLE

Fluid Level Checks
Automatic Transaxle................... 212
Capacities........................... 227
Fog Light Service....................... 225
Fog Lights..........................64,225
Freeing A Stuck Vehicle.................. 183
Fuel
Adding............................. 164
Filler Cap........................... 164
Filter.............................. 196
Gauge.............................. 86
Hoses.............................. 211
Light............................... 91
Tank Capacity........................ 227
Fuses................................ 219
Garage Door Opener..................... 71
GasCap .............................. 164
Gasoline, Reformulated.................. 161
Gasoline/Oxygenate Blends............... 162
Gauges
Coolant Temperature................... 88
Fuel................................ 86Gearshift............................. 137
Glass Cleaning......................... 218
Hazard Warning Flasher.................. 172
Head Restraints......................... 59
Headlights............................ 222
Aiming............................. 227
Bulb Replacement..................... 222
Cleaning............................ 217
High Beam........................... 87
Switch.............................. 64
Time Delay........................... 65
Heater............................... 121
Homelink Transmitter.................... 71
Hood Prop............................ 61
Hood Release.......................... 60
Hoses.............................209,211
Ignition
Key ................................ 11
Lock................................ 11
Illuminated Entry....................... 14
Immobilizer............................ 12
266 INDEX

Replacement......................... 156
Rotation............................ 158
Safety...........................144,151
Sizes............................... 145
Snow Tires.......................... 158
Spinning............................ 155
Tread Wear Indicators.................. 156
Towing...........................183,184
Disabled Vehicle...................... 183
Traction Control....................67,86,143
Trailer Towing......................... 165
Minimum Requirements................ 166
Trailer and Tongue Weight.............. 166
Warnings........................... 165
Transaxle............................. 211
Additives........................... 213
Automatic........................... 211
Filter.............................. 213
Manual............................. 184
Selection of Lubricant.................. 212
Transmission
Range Indicator....................... 88
Transmission....................See TransaxleTransmitter Battery Service................ 21
Transmitter, Garage Door Opener............ 71
Transmitter, Remote Keyless Entry........... 19
Transporting Pets........................ 47
Tread Wear Indicators................... 156
Trip Computer.......................... 91
Trip Odometer.......................... 88
Trunk Release, Emergency...............23,24
Trunk Release Remote Control.............. 23
Turn Signals.........................65,87
Underhood Fuses....................... 219
Uniform Tire Quality Grades.............. 258
Universal Transmitter.................... 71
Vacuum/Vapor Harnesses................ 209
Vanity Mirrors.......................... 56
Vehicle Identification Number............... 6
Vehicle Loading.....................148,165
Vehicle Modifications/Alterations............ 7
Vehicle Theft Alarm...................... 22
Vinyl Trim............................ 216
Viscosity, Engine Oil..................194,227
272 INDEX
