trunk release CHRYSLER SEBRING 2004 2.G Owners Manual

NTo Use The Panic Alarm.................20
NTo Program Additional Transmitters.........20
NGeneral Information....................21
NTransmitter Battery Service...............21
mVehicle Theft Alarm.....................22
NTamper Alert.........................22
NSecurity System Manual Override...........23
mTrunk Lock And Release..................23
mTrunk Safety Warning....................23
NTrunk Internal Emergency Release..........24
mPower Windows........................24
NWind Buffeting........................25
mOccupant Restraints.....................25
NLap/Shoulder Belts.....................26NPretensioners.........................30
NEnhanced Driver Seat Belt Reminder System
(BeltAlert)...........................30
NSeat Belts And Pregnant Women............31
NSeat Belt Extender......................31
NDriver And Right Front Passenger Supplemental
Restraint System (SRS) - Airbag............32
mEngine Break-In Recommendations..........47
mSafety Tips............................48
NExhaust Gas..........................48
NSafety Checks You Should Make Inside The
Vehicle..............................48
NPeriodic Safety Checks You Should Make
Outside The Vehicle....................49
10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

REMOTE KEYLESS ENTRY Ð IF EQUIPPED
This system allows you to lock or unlock the doors or
open the trunk from distances up to 23 feet (7 meters)
using a transmitter. You don't have to point the transmit-
ter at the vehicle to activate the system.
To unlock the doors:
Press and release the UNLOCK button once to unlock the
driver's door. Press the button twice within 5 seconds to
unlock all doors. If your vehicle is equipped with Illumi-
nated Entry, the interior lights also come on and remain
on for about 30 seconds, when you unlock the doors.
NOTE:The system may be programmed to unlock all
the doors upon the first press of the Unlock button. To
toggle between the first press unlock of the driver's door
to unlock of all doors, perform the following procedure:
1.Press and hold the Unlock button on the transmitter.
2. Continue to hold the Unlock button, wait at least 4
but no longer than 10 seconds, then press the LOCK
button.
3. Release both buttons.
The headlights will flash twice to acknowledge the
unlock signal.
NOTE:The Lamp Flash can be enabled or disabled by
performing the following procedure:
1. Press and hold the Lock button on the transmitter.
2. Continue to hold the Lock button, wait at least 4 but
no longer than 10 seconds, then press the Trunk
button.
3. Release both buttons.
To lock the doors:
The horn will chirp and the headlamps will flash once to
acknowledge the lock signal.
NOTE:The horn chirp can be enabled or disabled by
the following procedure:
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19
2

1. Press and hold the Lock button on the transmitter.
2. Continue to hold the Lock button, wait at least 4 but
no longer than 10 seconds, then press the Unlock
button.
3. Release both buttons.
To unlock the trunk:
Press and hold the Trunk button on the transmitter to
unlatch the trunk.
NOTE:The transmitter can be programmed to unlatch
the trunk immediately upon activation of the Trunk
button (without pressing and holding) by performing the
following procedure:
1. Press and hold the Unlock button on the transmit-
ter.
2. Continue to hold the Unlock button, wait at least 4
but no longer than 10 seconds, then press the Trunk
button.
3. Release both buttons.Panic Alarm
The panic mode unlocks the driver's door, turns on the
interior lights, flashes the headlights, and sounds the
horn for about 3 minutes or until the alarm is turned off.
To use the Panic Alarm:
Press and hold the Panic Button for at least 1 second to
activate the panic alarm. Press and hold the panic button
a second time or unlock the door with the key (if
equipped with central locking) to deactivate the alarm.
The alarm will also shut itself off after 3 minutes, or when
the vehicle speed reaches 15 MPH (24 km/h).
To Program Additional Transmitters:
Up to 4 transmitters can be programmed to your vehicle.
To program a transmitter, perform the following proce-
dure:
1. With the vehicle in Park, turn the ignition switch to the
ON/RUN position.
2. Using a currently programmed transmitter, press the
Unlock button on the transmitter. Continue to hold the
Unlock button, wait at least 4 but no longer than 10
seconds, then press and hold the Panic button for at least
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Security System Manual Override
The system will not arm if you lock the doors using the
manual lock control.
TRUNK LOCK AND RELEASE
Use the key or the Remote Keyless Entry Transmitter to
open the trunk from outside the vehicle. From inside the
car the trunk lid can be released by depressing the Trunk
Release Button located on the instrument panel to the left
of the steering wheel. The transmission must be in Parkbefore the switch will operate. Vehicles with manual
transmissions must be at zero mph for the switch to work.
With the ignition ON, the word ªdeckº will be displayed
in place of the odometer display indicating that the trunk
is open. The odometer display will reappear once the
trunk is closed or if the trip button is depressed.
With the key in lock position or key out, the ªdeckº will
be displayed until the trunk is closed.
TRUNK SAFETY WARNING
WARNING!
Do not allow children to have access to the trunk,
either by climbing into the trunk from outside, or
through the inside of the vehicle. Always close the
trunk lid when your vehicle is unattended. Once in
the trunk, young children may not be able to escape,
even if they entered through the rear seat. If trapped
in the trunk, children can die from suffocation or
heat stroke.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23
2

Trunk Internal Emergency Release
NOTE:
As a security measure, a Trunk Internal Emer-
gency Release lever is built into the trunk latching
mechanism. In the event of an individual being locked
inside the trunk, the trunk can be simply opened by
pulling on the glow-in-the-dark handle attached to the
trunk latching mechanism. See picture.
POWER WINDOWS
The window controls on the driver's door operate all
windows.
The driver's window switch has an Auto Down feature.
Press the window switch past the detent, release, and the
window will go down automatically.
To open the window part way, pull the window switch
part way and release it when you want the window to
stop.
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

U.S. federal regulations require that upon transfer of
vehicle ownership, the seller certify to the purchaser the
correct mileage that the vehicle has been driven. There-
fore, if the odometer reading is changed, during repair or
replacement, be sure to keep a record of the reading
before and after the service so that the correct mileage can
be determined.
The trip odometer shows individual trip mileage. To
switch from odometer to trip odometer, press and release
the Trip Odometer button. Press and release the Trip
button a second time to return to the odometer. While in
trip mode, press and hold the button for at least
1¤2second
to reset the trip odometer.
Door, Deck or Trunk Ajar Warnings
If you move the vehicle and a door is not completely
closed, the word DOOR will replace the odometer dis-
play and a chime will sound once. The odometer display
will reappear when the door is closed. If the trunk is not
completely closed, the work DECK will replace the
odometer display. The odometer display will reappear
when the trunk is closed.
16. Anti-Lock Warning Light Ð If Equipped
This light monitors the Anti-Lock Brake System
described elsewhere in this manual. This light
will come on when the ignition key is turned to the
RUN position and may stay on for several seconds. If
the light does not come on, have the system checked
by an authorized dealer. The warning light should be
checked frequently to assure that it is operating prop-
erly.
If the ABS light remains on or comes on during driving,
it indicates that the Anti-Lock portion of the brake system
is not functioning and that service is required, however,
the conventional brake system will continue to operate
normally provided that the BRAKE warning light is not
on.
17. Oil Pressure Light
Shows low engine oil pressure. The light will
come on and remain on briefly when the igni-
tion is turned on as a bulb check. If the bulb does not
come on during starting, have the bulb repaired
promptly.
UNDERSTANDING YOUR INSTRUMENT PANEL 89
4

Cavity Fuse Circuit
1 30 Amp Green Blower Motor
2 10 Amp Red Right High Beam Headlight,
High Beam Indicator
3 10 Amp Red Left High Beam Headlight
4 15 Amp Blue Power Door Lock Switch Illu-
mination, Transmission
Range Switch, Daytime Run-
ning Light Module (Canada),
Power Windows, Anti-lock
Brake System Module
5 10 Amp Red Power Door Lock and Door
Lock Arm/Disarm Switches,
Vanity, Reading, Map, Rear
Seating, Ignition, and Trunk
Lights, Illuminated Entry,
Radio, Power Antenna, Data
Link Connector, Body Con-
trol Module, Power Amplifier
6 10 Amp Red Heated Rear Window Indica-
tor
7 20 Amp Yel-
lowInstrument cluster illumina-
tion, Park and tail Lights
8 20 Amp Yel-
lowPower Receptacle, Horns,
Ignition, Fuel, StartCavity Fuse Circuit
9 15 Amp Blue Power Door Lock Motors
(Body Control Module)
10 20 Amp Yel-
lowDaytime Running Light Mod-
ule (Canada)
11 10 Amp Red Instrument Cluster, Transmis-
sion Control, Park/Neutral
Switch, Body Control Module
12 10 Amp Red Left Low beam Headlight
13 20 Amp Yel-
lowRight Low Beam Headlight,
Fog Light Switch
14 10 Amp Red Radio
15 10 Amp Red Turn Signal and Hazard
Flashers, Wiper Switch, Seat
Belt Control Module, Wiper
Relays, Rear Window De-
froster Relay
16 10 Amp Red Airbag Control Module
17 10 Amp Airbag Control Module
18 20 Amp
C/BRKRPower Seat Switch, Remote
Trunk Release
19 30 Amp
C/BRKRPower Windows
220 MAINTAINING YOUR VEHICLE

Driving
On Slippery Surfaces.................. 182
Electrical Outlet, Auxiliary................. 77
Electronic Speed Control.................. 68
Emergency, In Case of
Jacking............................. 174
Emergency Trunk Release...............23,24
Emission Control System Maintenance....190,232
Engine............................187,188
Block Heater......................... 134
Break-In Recommendations............... 47
Checking Oil Level.................... 192
Compartment.....................187,188
Cooling............................ 205
Oil .............................192,227
Oil Change Interval................... 193
Oil Selection......................... 194
Oil Synthetic......................... 195
Overheating......................... 172
Partial Zero Emissions Vehicle for 2.4 Liter . . 232
Timing Belt.......................... 198
Engine Oil Viscosity..................194,227Engine Oil Viscosity Chart................ 194
Entry System, Illuminated................. 14
Exhaust Gas Caution.................... 204
Exhaust System........................ 204
Exterior Light Service.................... 222
Filters
Air Cleaner.......................... 196
Automatic Transaxle................... 213
Engine Fuel......................... 196
Engine Oil.......................... 195
Flashers
Hazard Warning...................... 172
Flexible Fuel Vehicles
Cruising Range....................... 170
Engine Oil.......................... 194
Maintenance......................... 170
Replacement Parts.................... 170
Starting............................ 170
Floor Console.......................... 53
Fluid Capacities........................ 227
Fluid Leaks............................ 49
INDEX 265
10

Radio Broadcast Signals................... 95
Radio Operation..................105,110,118
Radio Remote Controls................... 118
Rear Window Defroster.................. 124
Recommended Fluids, Lubricants and Genuine
Parts............................... 228
Reformulated Gasoline................... 161
Refrigerant............................ 200
Reminder, Lights On..................... 64
Reminder, Seat Belt...................... 30
Remote Keyless Entry.................... 19
Remote Trunk Release.................... 23
Replacement Tires...................... 156
Reporting Safety Defects................. 256
Restraints, Occupant..................... 25
Rotation, Tires......................... 158
Safety Checks Outside Vehicle.............. 49
Safety Defects, Reporting................. 256
Safety Information, Tire.................. 144
Safety Tips............................. 48
Schedule, Maintenance................... 233
Seat Belt Maintenance................... 218Seat Belt Reminder...................... 30
Seat Belts.............................. 26
Adjustable Upper Shoulder Anchorage...... 29
And Pregnant Women.................. 31
Child Restraint....................39,40,44
Extender............................ 31
Front Seat............................ 27
Inspection........................... 48
Operating Instructions.................. 27
Reminder............................ 91
Seats................................. 57
Adjustment.......................... 57
Cleaning............................ 216
Head Restraints....................... 59
Lumbar Support....................... 58
Power.............................. 58
Rear Folding......................... 59
Reclining............................ 57
Security Alarm......................... 22
Sentry Key.......................... 11,12
Service Assistance...................... 252
Service Contract........................ 254
Service Engine Soon Light................. 87
270 INDEX

Replacement......................... 156
Rotation............................ 158
Safety...........................144,151
Sizes............................... 145
Snow Tires.......................... 158
Spinning............................ 155
Tread Wear Indicators.................. 156
Towing...........................183,184
Disabled Vehicle...................... 183
Traction Control....................67,86,143
Trailer Towing......................... 165
Minimum Requirements................ 166
Trailer and Tongue Weight.............. 166
Warnings........................... 165
Transaxle............................. 211
Additives........................... 213
Automatic........................... 211
Filter.............................. 213
Manual............................. 184
Selection of Lubricant.................. 212
Transmission
Range Indicator....................... 88
Transmission....................See TransaxleTransmitter Battery Service................ 21
Transmitter, Garage Door Opener............ 71
Transmitter, Remote Keyless Entry........... 19
Transporting Pets........................ 47
Tread Wear Indicators................... 156
Trip Computer.......................... 91
Trip Odometer.......................... 88
Trunk Release, Emergency...............23,24
Trunk Release Remote Control.............. 23
Turn Signals.........................65,87
Underhood Fuses....................... 219
Uniform Tire Quality Grades.............. 258
Universal Transmitter.................... 71
Vacuum/Vapor Harnesses................ 209
Vanity Mirrors.......................... 56
Vehicle Identification Number............... 6
Vehicle Loading.....................148,165
Vehicle Modifications/Alterations............ 7
Vehicle Theft Alarm...................... 22
Vinyl Trim............................ 216
Viscosity, Engine Oil..................194,227
272 INDEX
