wiper fluid CHRYSLER SEBRING CONVERTIBLE 2005 2.G Owners Manual

MAINTAINING YOUR VEHICLE
CONTENTS

2.4L Engine..........................201

2.7L Engine..........................202

Onboard Diagnostic System—OBD II......203

Emissions Inspection And Maintenance
Programs
............................204

Replacement Parts.....................205

Dealer Service........................205

Maintenance Procedures.................206
▫Engine Oil..........................206
▫Crankcase Emission Control System........213
▫Maintenance-Free Battery................213
▫Air Conditioner......................214▫Power Steering—Fluid Check............215
▫Suspension Ball Joints..................216
▫Body Mechanism Lubrication.............216
▫Windshield Wiper Blades................218
▫Windshield Washers...................218
▫Exhaust System......................219
▫Cooling System.......................220
▫Hoses And Vacuum/Vapor Harnesses.......224
▫Brakes.............................224
▫Fuel System Hoses....................227
▫Automatic Transmission................227
7

•Trunk latches
•Ash tray
Windshield Wiper Blades
Clean the rubber edges of the wiper blades and the
windshield periodically with a sponge or soft cloth and a
mild non abrasive cleaner. This will remove accumula-
tions of salt or road film.
Operation of the wipers on dry glass for long periods
may cause deterioration of the wiper blades. Always use
washer fluid when using the wipers to remove salt or dirt
from a dry windshield. Avoid using the wiper blades to
remove frost or ice from the windshield. Keep the blade
rubber out of contact with petroleum products such as
engine oil, gasoline, etc.
Windshield Wiper Blade Replacement
•
Lift the wiper arm away from the glass.
•Push the release tab and slide the wiper blade assem-
bly away from the wiper arm. Gently place the wiper
arm on the windshield.
•Install the new blade assembly onto the wiper arm tip
until it locks in place.
Windshield Washers
The fluid reservoir in the engine compartment should be
checked for fluid level at regular intervals. Fill the
reservoir with windshield antifreeze (not radiator anti-
freeze) rated not to freeze at -25°F (-31°C). Operate the
system for a few seconds to flush out the residual water.
Washer Fluid Reservoir
218 MAINTAINING YOUR VEHICLE

Voltmeter.............................. 92
Warning, Door Ajar...................... 14
Warning Flasher, Hazard................. 186
Warnings and Cautions.................... 6
Warranty Information.................... 270
Washer, Adding Fluid................... 218
Washers, Windshield..................71,218
Washing Vehicle........................ 230
Waxing and Polishing................... 230Wheel Alignment and Balance............. 171
Wind Buffeting......................... 23
Window Fogging....................... 131
Windows.............................. 22
Power.............................. 22
Windshield Washers...................71,218
Windshield Wipers.................70,71,218
Wiper Blade Replacement................. 218
Wipers, Intermittent...................... 72
Wood Trim Cleaning.................... 233
INDEX 291
