Turn Signals
Move the Multi-Function Lever upward or downward
and the corresponding turn signal indicator on the in-
strument panel will flash to show proper operation of the
front and rear turn signal lights.You can signal a lane change by moving the lever
partially upward or downward without moving beyond
the detent.
Check for a defective outside light bulb if either light
remains on and does not flash or has a very fast flash rate.
If an indicator fails to light when the lever is moved, it
would suggest that the fuse or indicator is defective.
Highbeam/Lowbeam Select Switch
Push the Multi-Function Control Lever away from you to
switch the headlights to HIGH beam. Pull the Lever
toward you, to switch the headlights back to LOW beam.
Turn Signal Control
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

(Refer to ªTire Inflation Pressuresº under ªTires Ð Gen-
eral Informationº and to ªTire Pressure Monitor System
(TPMS)º in Section 5 of this manual for more informa-
tion).
25. Malfunction Indicator Light
This light is part of an onboard diagnostic system
called OBD that monitors emissions, engine, and
automatic transaxle control systems. The light
will illuminate when the key is in the ON/RUN position
before engine start. If the bulb does not come on when
turning the key from LOCK/OFF to ON/RUN, have the
condition checked promptly.
Certain conditions such as a loose or missing gas cap,
poor fuel quality, etc. may illuminate the light after
engine start. The vehicle should be serviced if the light
stays on through several of your typical driving cycles. In
most situations the vehicle will drive normally and will
not require towing.If the Malfunction Indicator Light flashes when the
engine is running, serious conditions may exist that
could lead to immediate loss of power or severe catalytic
converter damage. The vehicle should be serviced as
soon as possible if this occurs.
26. High Beam Indicator
This light shows that the headlights are on high
beam. Push the turn signal lever away from the
steering wheel to switch the headlights from high or low
beam.
27. Electronic Vehicle Information Center (EVIC)
DisplayÐPremium Cluster Only
This display shows the EVIC messages when the appro-
priate conditions exist. Refer to ªElectronic Vehicle Infor-
mation Center (EVIC)º in this section for more informa-
tion.
186 UNDERSTANDING YOUR INSTRUMENT PANEL

WARNING!
²The Anti-Lock Brake System contains sophisticated elec-
tronic equipment that may be susceptible to interference
caused by improperly installed or high output radio trans-
mitting equipment. This interference can cause possible loss
of anti-lock braking capability. Installation of such equip-
ment should be performed by qualified professionals.
²Pumping of the Anti-Lock Brakes will diminish their effec-
tiveness and may lead to an accident. Pumping makes the
stopping distance longer. Just press firmly on your brake
pedal when you need to slow down or stop.
²
Anti-lock system (ABS) cannot prevent the natural laws of
physics from acting on the vehicle, nor can it increase braking
or steering efficiency beyond that afforded by the condition
of the vehicle brakes and tires or the traction afforded.
²The ABS cannot prevent accidents, including those resulting
from excessive speed in turns, following another vehicle too
closely, or hydroplaning. Only a safe, attentive, and skillful
driver can prevent accidents.
²The capabilities of an ABS equipped vehicle must never be
exploited in a reckless or dangerous manner, which could
jeopardize the user's safety or the safety of others.
All vehicle wheels and tires must be the same size and
type and tires must be properly inflated to produce
accurate signals for the computer.
Anti-Lock Brake Light
The ABS light monitors the Anti-Lock Brake
System. The light will come on when the
ignition switch is turned to the ON position
and may stay on for as long as four seconds.
If the ABS light remains on or comes on while driving, it
indicates that the Anti-Lock portion of the brake system
is not functioning and that service is required. However,
the conventional brake system will continue to operate
normally if the Brake System Warning Light is not on.
If the ABS light is on, the brake system should be serviced
as soon as possible to restore the benefits of Anti-Lock
brakes. If the ABS light does not come on when the
ignition switch is turned to the ON position, have the
bulb repaired as soon as possible.
STARTING AND OPERATING 269
5

NA/C Air Filter Ð If Equipped............370
NPower Steering Ð Fluid Check............371
NFront Suspension Ball Joints..............372
NSteering Linkage......................372
NBody Lubrication.....................372
NWindshield Wiper Blades................373
NWindshield Washers...................374
NExhaust System......................374
NCooling System.......................375
NHoses And Vacuum/Vapor Harnesses.......381
NFuel System.........................381
NBrake System........................381
NAutomatic Transaxle...................384NFront And Rear Wheel Bearings...........387
NAppearance Care And Protection
From Corrosion......................387
NCleaning The Center Console Cup Holders . . . 392
mConvertible Top Care....................393
NSoft Top............................393
NWeather Strip Care Ð Soft & Hard Top......395
mFuses (Totally Integrated Power Module)......395
mVehicle Storage........................400
mReplacement Bulbs......................400
mBulb Replacement......................401
NLow Beam Headlight, High Beam Headlight . . 401
NFront Turn Signal/Park Light.............402
352 MAINTAINING YOUR VEHICLE

VEHICLE STORAGE
If you will not be using your vehicle for more than 21
days you may want to take steps to preserve your battery.
You may:
²Remove the IOD (Ignition Off-Draw) mini fuses from
the Totally Integrated Power Module located in the
engine compartment.
²Or, disconnect the batter negative cable.
REPLACEMENT BULBS
All the inside bulbs are brass or glass wedge base.
Aluminum base bulbs are not approved and should not
be used for replacement.
LIGHT BULBS Ð Interior Bulb Number
Front Courtesy/Reading Lights. . LED (Dealer Service)
Center Console Courtesy Light...........578/W5W
Glove Box Light......................... 194
Rear Compartment (Trunk) Light............. 579NOTE:For lighted switches, see your dealer for replace-
ment instructions.
LIGHTS BULBS Ð Outside Bulb No.
Low Beam Headlight.....................9006
High Beam Headlight.....................9005
Front Park/Turn Signal/Side Marker Light. . . 3457AK
Front Fog Light.....................9145//H10
Center High Mounted Stop Light (CHMSL)....W16W
(921)
Rear Tail/Stop..........................3057
Decklid Tail Light.......................T3.25
Rear Turn Signal.......................3757A
Backup Light..........................3157K
License Light........................... 168
400 MAINTAINING YOUR VEHICLE

CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with any oily surface, clean the
bulb with rubbing alcohol.
4. Install the bulb and connector assembly into the
headlight housing and rotate it
1¤4turn clockwise to lock
it in place.
Front Turn Signal/Park Light
1. Open the hood.
2. Rotate the bulb's electrical connector
1¤4turn counter-
clockwise and remove it from the headlight housing.
Front Turn Signal/Park Light
402 MAINTAINING YOUR VEHICLE

2. Remove the bulb from the connector socket and install
the replacement bulb.
CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with an oily surface, clean the
bulb with rubbing alcohol.
3. Install the bulb and connector assembly into the fog
light housing and rotate the connector
1¤4turn clockwise
to lock it in place.
Tail/Stop Light, Rear Turn Signal Light, Backup
Light
The taillights are a two-piece design. The tail/stop lights
and rear turn signal lights are located in the rear corner
body panels. The backup lights and rear fog lights are
located in the trunk lid.
Changing the Tail/Stop Light or Rear Turn Signal
Light
1. Open the trunk.
404 MAINTAINING YOUR VEHICLE

2. Remove the two plastic wing nuts from the taillight
housing.
3. Grasp the taillight housing with one hand on the
bottom of the housing and the other hand on the inboard
housing flange and pull it outward firmly to disengage
the housing from the vehicle.4. Rotate the applicable bulb's electrical connector1¤4
turn counterclockwise and remove it from the taillight
housing.
Location Plastic Wing Nuts
1 Ð Tail/Stop Light
2 Ð Turn Signal LightMAINTAINING YOUR VEHICLE 405
7

Jacking Instructions...................... 340
Jump Starting.......................... 344
Key, Programming........................ 17
Key, Replacement........................ 16
Key, Sentry (Immobilizer)................... 15
Key-In Reminder......................... 14
Keyless Entry System...................... 21
Keys................................. 12
Knee Bolster..........................48,52
Lane Change and Turn Signals...........142,183
Lap/Shoulder Belts....................... 40
LATCH
(Lower Anchors and Tether for CHildren).....66,68
Latch Plate............................. 41
Latches................................ 76
Hood............................... 137
Lead Free Gasoline...................... 307Leaks, Fluid............................ 76
Life of Tires............................ 295
Light Bulbs..........................76,400
Light Replacement....................... 401
Lights...........................76,138,401
Airbag......................52,53,59,75,177
Anti-Lock........................... 269
Automatic Headlights................... 139
Back-Up............................. 404
Battery Saver......................... 144
Brake Assist Warning................... 278
Brake Warning........................ 182
Bulb Replacement...................... 401
Center Mounted Stop................... 408
Courtesy/Reading..................... 144
Daytime Running...................... 140
Dimmer Switch, Headlight.............138,142
Electronic Stability Program (ESP)
Indicator.........................276,278
442 INDEX

INTRODUCTION INTRODUCTION HOW TO USE THIS MANUAL WARNINGS AND CAUTIONS VEHICLE IDENTIFICATION NUMBER VEHICLE MODIFICATIONS / ALTERATIONS THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS
Ignition Key RemovalKey-In-Ignition ReminderSENTRY KEY Replacement KeysSentry Key ProgrammingGeneral InformationSECURITY ALARM SYSTEM - IF EQUIPPED Rearming of the SystemTo Arm the SystemTo Disarm the SystemILLUMINATED ENTRY SYSTEM
- IF EQUIPPED REMOTE KEYLESS ENTRY To unlock the doorsTo lock the doorsConvertible Top OperationTo Unlatch the TrunkExpress Down Window FeatureUsing The Panic AlarmProgramming Additional TransmittersBattery ReplacementGeneral InformationREMOTE
STARTING SYSTEM - IF EQUIPPED How To Use Remote StartDOOR LOCKS Manual Door LocksPower Door LocksWINDOWS Power WindowsWind BuffetingTRUNK LOCK AND RELEASE TRUNK SAFETY WARNING Trunk Emergency Release OCCUPANT
RESTRAINTS Lap/Shoulder BeltsLap/Shoulder Belt Untwisting ProcedureSeat Belt PretensionersEnhanced Seat Belt Reminder System (BeltAlert) Automatic Locking ModeSeat Belts And Pregnant WomenSeat Belt ExtenderDriver and Front Passenger Supplemental
Restraint System (SRS) - AirbagEvent Data Recorder (EDR)Child RestraintENGINE BREAK-IN RECOMMENDATIONS SAFETY TIPS Transporting PassengersLock Your VehicleExhaust GasSafety Checks You Should Make Inside The VehiclePeriodic Safety Checks You
Should Make Outside The VehicleUNDERSTANDING THE FEATURES OF YOUR VEHICLE CONVERTIBLE TOP OPERATION Power Convertible Top Usage PrecautionsCargoProtectorPower Convertible Top ControlsLowering the Power Convertible TopRaising the Power
Convertible TopWind StopPower Convertible Top Operation and Warning MessagesMIRRORS Automatic Dimming MirrorOutside MirrorsPower Remote Control MirrorsHeated Remote Control Mirrors - If EquippedVanity Mirror - If EquippedHANDS-FREE COMMUNICATION
(UConnect) - IF EQUIPPED OperationPhone Call FeaturesUConnect System FeaturesAdvanced Phone ConnectivityThings You Should Know About Your UConnect SystemGeneral InformationVOICE RECOGNITION SYSTEM (VR) - IF EQUIPPED Voice Recognition System
(VR) OperationCommandsVoice TrainingSEATS Manual Front Seat AdjustmentsEasy Entry SystemPower Seats - If EquippedHead RestraintsHeated Seats -If EquippedTO OPEN AND CLOSE THE HOOD LIGHTS Exterior and Interior Lighting ControlHeadlights and Parking
LightsAutomatic Headlights - If EquippedHeadlights with Wipers (Available with Auto Headlights Only)Headlight Time Delay - If EquippedDaytime Running Lights (DRL) - If EquippedLights-On ReminderFog Lights - If EquippedTurn SignalsHighbeam/Lowbeam Select Switch
Flash to PassInterior LightsWINDSHIELD WIPERS AND WASHERS Intermittent Wiper SystemMist FeatureHeadlights with Wipers (Available with Auto Headlights Only)Windshield WashersAdding Washer FluidTILT/TELESCOPING STEERING COLUMN ELECTRONIC
SPEED CONTROL - IF EQUIPPED Electronic Speed Control OperationTo ActivateTo Set At A Desired SpeedTo DeactivateTo Resume SpeedTo Vary The Speed SettingTo Accelerate For PassingGARAGE DOOR OPENER - IF EQUIPPED Programming HomeLinkGate
Operator/Canadian ProgrammingUsing HomeLinkReprogramming A Single HomeLink ButtonSecurityTroubleshooting TipsGeneral InformationELECTRICAL POWER OUTLETS Electrical Outlet Use With Engine OffCIGAR LIGHTER AND ASH RECEIVER - IF EQUIPPED Cup Holder Ash Receiver - If EquippedCUP HOLDERS Front Seat Cup HolderHeated or Cooled Cup Holder - If EquippedRear Seat Cup HoldersCONSOLE FEATURES StorageSliding Armrest - If EquippedUNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT
PANEL FEATURES BASE INSTRUMENT CLUSTER PREMIUM INSTRUMENT CLUSTER INSTRUMENT CLUSTER DESCRIPTIONS ELECTRONIC VEHICLE INFORMATION CENTER (EVIC)- IF EQUIPPED Electronic Vehicle Information Center (EVIC) DisplaysOil
Change RequiredTrip FunctionsCompass DisplayPersonal Settings (Customer Programmable Features)SETTING THE ANALOG CLOCK RADIO GENERAL INFORMATION Radio Broadcast SignalsTwo Types of SignalsElectrical DisturbancesAM ReceptionFM Reception
SALES CODE REQ - AM/FM STEREO RADIO AND 6-DISC CD/DVD CHANGER
(MP3/WMA AUX JACK) Operating Instructions - Radio ModeOperation Instructions - (DISC MODE for CD and MP3/WMA Audio Play, DVD-VIDEO)Notes On PlayingMP3/WMA FilesLIST Button (DISC Mode for MP3/WMA Play)INFO Button (DISC Mode for MP3/WMA Play)
SALES CODE REN - MULTIMEDIA SYSTEM - IF EQUIPPED Operating Instructions - Satellite Radio (If Equipped)Operating Instructions - Voice Recognition System (VR) (If Equipped)Operating Instructions - Hands-Free Communication (UConnect) (If Equipped)Clock Setting
ProcedureSALES CODE RER - MULTIMEDIA SYSTEM - IF EQUIPPED Operating Instructions - Satellite RadioOperating Instructions - Hands-Free Communication (UConnect) (If Equipped)Clock Setting ProcedureUNIVERSAL CONSUMER INTERFACE (UCI) - IF
EQUIPPED Connecting the iPod DeviceControlling the iPod using Radio ButtonsPlay ModeList or Browse ModeSATELLITE RADIO (RSC) - IF EQUIPPED (RER/REQ/REN RADIOS ONLY) System ActivationElectronic Serial Number/Sirius Identification Number (ENS/SID)
Selecting Satellite ModeSatellite AntennaReception QualityOperating Instructions - Satellite ModeOperating Instructions - Hands Free Phone (If Equipped)Operating Instructions - Video Entertainment System (VES) (If Equipped)REMOTE SOUND SYSTEM CONTROLS
- IF EQUIPPED Right-Hand Switch FunctionsLeft-Hand Switch Functions for Radio OperationLeft-Hand Switch Functions for Media (i.e. CD) OperationRADIO OPERATION AND CELLULAR PHONES CD/DVD DISC MAINTENANCE CLIMATE CONTROLS Manual Air
Conditioning and Heating System Automatic Temperature Control (ATC) - If Equipped Operating TipsREAR WINDOW FEATURES Electric Rear Window Defroster - If EquippedSTARTING AND OPERATING STARTING PROCEDURES Automatic TransaxleNormal Starting
Extremely Cold Weather (below -20 degrees F or -29 degrees C)If Engine Fails to StartAfter StartingENGINE BLOCK HEATER - IF EQUIPPED AUTOMATIC TRANSAXLE Brake/Transaxle Interlock SystemAutomatic Transaxle Ignition Interlock System4 Speed or 6 Speed
(AutoStick) Automatic TransaxleAUTOSTICK - IF EQUIPPED AutoStick OperationAutoStick General InformationPARKING BRAKE BRAKE SYSTEM Anti-Lock Brake System - If EquippedPOWER STEERING DRIVING ON SLIPPERY SURFACES AccelerationTraction
DRIVING THROUGH WATER Flowing/Rising WaterShallow Standing WaterTRACTION CONTROL SYSTEM (TCS) - IF EQUIPPED BRAKE ASSIST SYSTEM (BAS) - IF EQUIPPED ELECTRONIC STABILITY PROGRAM (ESP) - IF EQUIPPED ESP Operating Modes
ESP/BAS Malfunction Indicator Light and ESP/TCS Indicator LightSynchronizing ESPTIRE SAFETY INFORMATION Tire Markings Tire Identification Number (TIN)Tire Loading and Tire PressureTIRES - GENERAL INFORMATION Tire PressureTire Inflation Pressures
Radial-Ply TiresCompact Spare Tire - If EquippedLimited Use Spare - If EquippedTire SpinningTread Wear IndicatorsLife of TireReplacement TiresAlignment And BalanceTIRE CHAINS SNOW TIRES TIRE ROTATION RECOMMENDATIONS TIRE PRESSURE MONITOR
SYSTEM (TPMS) - IF EQUIPPED Base System - If EquippedPremium System - If EquippedGeneral InformationFUEL REQUIREMENTS 2.4L and 2.7L Engines3.5L EngineReformulated GasolineGasoline/Oxygenate BlendsMMT In GasolineMaterials Added to FuelFuel
System CautionsCarbon Monoxide WarningsFLEXIBLE FUEL- 2.7L ENGINES ONLY (EXCEPT CALIFORNIA EMISSION STATES) E-85 General InformationETHANOL FUEL (E-85)Fuel RequirementsSelection Of Engine Oil For Flexible Fuel Vehicles (E-85) and Gasoline
VehiclesStartingCruising RangeReplacement PartsMaintenanceADDING FUEL Fuel Filler Cap (Gas Cap)Loose Fuel Filler Cap MessageVEHICLE LOADING Vehicle Certification LabelGross Vehicle Weight Rating (GVWR)Gross Axle Weight Rating (GAWR)Overloading
LoadingTRAILER TOWING Common Towing DefinitionsTrailer Hitch ClassificationTrailer Towing Weights (Maximum Trailer Weight Ratings)Trailer and Tongue WeightTowing RequirementsTowing TipsRECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) TOWING
THIS VEHICLE BEHIND ANOTHER VEHICLE (Flat towing with all four wheels on the ground)WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER IF YOUR ENGINE OVERHEATS Engine Oil Overheating - 2.4L Engine Only (If Equipped)JACKING AND TIRE
CHANGING Preparations For JackingJack LocationSpare Tire StowageJacking InstructionsJUMP-STARTING PROCEDURES FREEING A STUCK VEHICLE TOWING ADISABLED VEHICLE WITHOUT THE IGNITION KEYTOWING THIS VEHICLE BEHIND ANOTHER VEHICLE (Flat towing with all four wheels on the ground)TOWING THIS VEHICLE BEHIND ANOTHER VEHICLE WITH A TOW DOLLYMAINTAINING YOUR VEHICLE 2.4L ENGINE COMPARTMENT 2.7L ENGINE COMPARTMENT 3.5L ENGINE COMPARTMENT
ONBOARD DIAGNOSTIC SYSTEM - OBD II Loose Fuel Filler Cap MessageEMISSIONS INSPECTION AND MAINTENANCE PROGRAMS REPLACEMENT PARTS DEALER SERVICE MAINTENANCE PROCEDURES Engine OilEngine Oil FilterDrive BeltSpark Plugs
Engine Air Cleaner FilterCatalytic ConverterMaintenance-Free BatteryAir Conditioner MaintenanceA/C Air Filter - If EquippedPower Steering - Fluid CheckFront Suspension Ball JointsSteering LinkageBody LubricationWindshield Wiper BladesWindshield WashersExhaust
SystemCooling SystemHoses and Vacuum/Vapor HarnessesFuel SystemBrake SystemAutomatic TransaxleFront and Rear Wheel BearingsAppearance Care And Protection From CorrosionCleaning The Center Console Cup HoldersCONVERTIBLE TOP CARE Soft Top
Weather Strip Care - Soft and Hard TopFUSES (TOTALLY INTEGRATED POWER MODULE) VEHICLE STORAGE REPLACEMENT BULBS BULB REPLACEMENT Low Beam Headlight, High Beam HeadlightFront Turn Signal/Park LightFront Fog LightTail/Stop Light, Rear
Turn Signal Light, Backup LightLicense Plate LightCenter High-Mounted Stop Light (CHMSL)FLUIDS AND CAPACITIES FLUIDS, LUBRICANTS, AND GENUINE PARTS EngineMAINTENANCE SCHEDULES EMISSION CONTROL SYSTEM MAINTENANCE
MAINTENANCE SCHEDULE Required Maintenance IntervalsIF YOU NEED CONSUMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE Prepare For The AppointmentPrepare A ListBe Reasonable With RequestsIF YOU NEED
ASSISTANCE DaimlerChrysler Motors Corporation Customer CenterDaimlerChrysler Canada Inc. Customer CenterIn Mexico contactCustomer Assistance For The Hearing Or Speech Impaired (TDD/TTY)Service ContractWARRANTY INFORMATION (U.S. Vehicles Only)
MOPAR PARTS REPORTING SAFETY DEFECTS In the 50 United States and Washington D.CIn CanadaPUBLICATION ORDER FORMS DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES TreadwearTraction GradesTemperature GradesINDEX
