Page 410 of 475

CHRYSLER SEBRING CONVERTIBLE 2009 3.G Owners Manual CavityCartridge FuseMini FuseDescription 17 —10 Amp RedIgnition Off Draw (IOD) — Wireless Control Module (WCM)/ Clock/Steering Control Module (SCM) 1840 Amp Green—Battery Feed — Auto Shutdown

Page 411 of 475

CHRYSLER SEBRING CONVERTIBLE 2009 3.G Owners Manual CavityCartridge FuseMini FuseDescription 26 —15 Amp Lt. BlueAuto Shutdown (ASD) Relay Feed 2 27 —10 Amp RedIgnition Run — Occupant Classi- fication Module (OCM)/Occupant Restraint Control- ler (
