CHRYSLER SEBRING COUPE 2004 2.G Owners Manual

GENERAL VEHICLE DATA
Overall length 191.9in (4,875mm)
Overall width 69.9in (1,775mm)
Overall height 53.9in (1,370mm)
Wheel base 103.7in (2,635mm)
TIRES AND WHEELS
Item 2.4 liter3.0 liter
LX LXi
Ti reType Radial, tubeless
Size P205/60R16 91HP215/50R17
90H
Spare tire T125/70D16
WheelType Steel/Aluminum* Aluminum
Size 16x6JJ 17x6 1/2JJ
PCD 4.5 in. (114.3 mm)
Offset 1.81 in. (46 mm)
Spare wheel 16x4T
*: optional
VEHICLE WEIGHTS
Item 2.4 liter 3.0 liter
Gross vehicle
weight rating4,061lb (1,842 kg) 4,227lb (1,917 kg)
Gross axle
weight
ratingFront
2,171lb (985 kg) 2,322lb (1,053 kg)
Rear
1,894lb (859 kg) 1,905lb (864 kg)
Seating capacity 5 persons
GVWR: maximum total weight(load) limit
specified for the vehicle
GAWR: maximum weight(load) limit specified for
the front or rear axle.
seating capacity: the number of maximum
occupants
cargo capacity: weight subtracted 68 kilograms
times the designated seating
capacity from the vehicle capacity
weight
SPECIFICATIONS 361
10

CAUTION!
Do not use the gross vehicle weight rating data
provided in the chart or on the safety certification
label for determining vehicle passenger and/or cargo
load capacity.
Use the values provided on the tire and loading
information placard (Refer to the section ªVehicle
labelingº).
362 SPECIFICATIONS

ENGINE SPECIFICATIONS
Item Specifications
Engine model 4 Cylinder 6 Cylinder
Engine displacement 2,351dm
3(143.4 CID) 2,972dm3(181.3 CID)
No. of cylinders and cylinder arrangement 4 in-line 6 - V60 É
Bore 86.5 mm (3.41 in) 91.1 mm (3.58 in)
Stroke 100 mm (3.94 in) 76.0 mm (2.99 in)
Compression ratio 9.0 9.0
Controlled by-pass thermostat 88 ÉC (190 ÉF) 88 ÉC (190 ÉF)
Spark plugs NGK BKR5E-11 FR5E1
DENSO K16PR-U11 Ð
CHAMPION RC10YC4 Ð
Spark plug gap 1.0 to 1.1 mm
(.039 to .043 in )0.7 to 0.8 mm
(.028 to .031 in )
Firing order 1-3-4-2 1-2-3-4-5-6
Ignition timing idle speed and mixture Refer to the ªVehicle emission control informationº label
under the engine hood.
NOTE
1. Your engine is equipped with intake and exhaust valve auto-lash adjusters that require no adjustment.
2. Your vehicle has one of the listed spark plugs. Use any one of the listed spark plugs for replacement.
SPECIFICATIONS 363
10

CAPACITIES
Item Capacity Recommended Lubricants
Fuel (approximate) 62dm3(16.3 gal) Ð
Engine oil Oil pan 4dm3(4.2 qt) Engine oils displaying
ILSAC certification symbol
or conforming to the API
classification SL, SL/CF Oil filter 0.3dm
3(0.32 qt)
Power steering 1.2dm
3(1.3 qt) Diamond ATF
Automatic transaxle 4 Cyl.: 7.7dm3(8.2 qt)
6 Cyl.: 8.4dm3(8.9 qt)Diamond ATF SPIII
Manual transaxle 4 Cyl.: 2.2dm3(2.3 qt)
6 Cyl.: 2.8dm3(3.0 qt)Gear oil API classification
GL-4 SAE 75W-85W or
75W-90
Brakes and clutch As required Conforming to Brake fluid
DOT3 or DOT4
Transaxle linkage, Parking brake cable mechanism, hood
lock and hook, door latches, seat adjustersAs required Multipurpose grease NLGI
Grade 2
Door hinges, trunk lid hinges As required Engine oil
Engine coolant 4 Cyl.±M/T: *8.0L (8.5 qt)
±A/T: *7.9L (8.3 qt)
6 Cyl.±M/T: *9.2L (9.7 qt)
±A/T: *9.1L (9.6 qt)Long Life Antifreeze Coolant
or an equivalent
Refrigerant (air conditioning) 425g (15 oz) HFC-134a
Windshield washers 4 L (4.2 qt) Ð
*: Include 0.65 L (.69 qt.) in reserve tank.
364 SPECIFICATIONS

IF YOU NEED CONSUMER ASSISTANCE
CONTENTS
mSuggestions For Obtaining Service
For Your Vehicle
.......................366
NPrepare For The Appointment............366
NPrepare A List........................366
NBe Reasonable With Requests.............366
mIf You Need Assistance..................366
mWarranty Information...................368
mMopar Parts..........................369
mCustomer Arbitration Board..............369
mReporting Safety Defects.................369
NIn Canada..........................369
mPublication Order Forms.................371
mDepartment Of Transportation Uniform
Tire Quality Grades
....................373
NTreadwear..........................373
NTraction AA, A, B, C...................373
NTemperature A, B, C...................374
11

SUGGESTIONS FOR OBTAINING SERVICE FOR
YOUR VEHICLE
Prepare For The Appointment
If you're having warranty work done, be sure to have the
right papers with you. Take your warranty folder. All
work to be performed may not be covered by the
warranty, discuss additional charges with the service
manager. Keep a maintenance log of your vehicle's
service history. This can often provide a clue to the
current problem.
Prepare A List
Make a written list of your vehicle's problems or the
specific work you want done. If you've had an accident,
or work done that is not on your maintenance log, let the
service advisor know.
Be Reasonable With Requests
If you list a number of items, and you must have your
vehicle by the end of the day, discuss the situation with
the service advisor and list the items in order of priority.
At many dealers you may obtain a rental vehicle at a
minimal daily charge. If you need a rental, it is advisable
to make these arrangements when you call for an ap-
pointment.
IF YOU NEED ASSISTANCE......
DaimlerChrysler Motors Corporation and its dealers are
vitally interested in your satisfaction. We want you to be
happy with our products and services.
Your selling dealer is best equipped and most anxious to
provide prompt resolution for any warranty issue or
related matter that you may experience. DaimlerChrysler
Motors Corporation dealers have the facilities, factory-
trained technicians, special tools, and the latest informa-
tion to assure your vehicle is fixed correctly and in a
timely manner. DaimlerChrysler Motors Corporation has
empowered its dealers to make warranty and repair
decisions that ensure you are not inconvenienced. There
is no need for you to wait for a decision from the
DaimlerChrysler Motors Corporation. If a special circum-
stance occurs that requires information from
DaimlerChrysler Motors Corporation, we have asked the
dealer's service management to make the contact on your
behalf.
This is why you should always talk to your dealer's
service manager first. Most matters can be resolved with
this process.
366 IF YOU NEED CONSUMER ASSISTANCE

²If for some reason you are still not satisfied, talk to the
general manager or owner of the dealership. They
want to know if you need assistance.
²If your dealership is unable to resolve the concern, you
may contact the DaimlerChrysler Motors Corporation
Customer Center.
Any communication to the DaimlerChrysler Motors Cor-
poration Customer Center should include the following
information:
²Owner's name and address
²Owner's telephone number (home and office)
²Dealership name
²Vehicle identification number
²Vehicle delivery date and mileage
DaimlerChrysler Motors Corporation Customer
Center
P.O. Box 21±8004
Auburn Hills, MI 48321±8004
Phone: (800) 992-1997
DaimlerChrysler Canada Inc. Customer Service
Chrysler Center
P.O. Box 1621
Windsor, Ontario N9A 4H6
Phone ÐRefer to your Warranty Booklet
In Mexico contact:
Lago Alberto #320
Mexico 11320, D. F.
In Mexico (915) 729±1248 or 729±1240
Outside Mexico (525) 729±1248 or 729±1240
IF YOU NEED CONSUMER ASSISTANCE 367
11

Customer Assistance For The Hearing Or Speech
Impaired (TDD/TTY)
To assist customers who have hearing difficulties,
DaimlerChrysler Motors Corporation has installed spe-
cial TDD (Telecommunication Devices for the Deaf)
equipment at its Customer Center. Any hearing or speech
impaired customer who has access to a TDD or a
conventional teletypewriter (TTY) in the United States
can communicate with DaimlerChrysler Motors Corpo-
ration by dialing 1±800±380±CHRY.
Service Contract
You may have purchased a service contract for your
vehicle to help protect you from the high cost of unex-
pected repairs after your DaimlerChrysler Motors Cor-
poration new vehicle limited warranty expires.
DaimlerChrysler Motors Corporation stands behind only
Genuine DaimlerChrysler Motors Corporation Service
Contracts. If you purchased a Genuine DaimlerChrysler
Motors Corporation Service Contract, you will receive
Plan Provisions and an Owner Identification Card in the
mail within three weeks of your vehicle delivery date. If
you have any questions about your service contract, call
the DaimlerChrysler Motors Corporation Service Con-
tract National Customer Hotline at 1-800-521-9922.DaimlerChrysler Motors Corporation will not stand be-
hind any service contract that is not a Genuine
DaimlerChrysler Motors Corporation Service Contract. It
is not responsible for any service contract other than a
Genuine DaimlerChrysler Motors Corporation Service
Contract. If you purchased a service contract that is not a
Genuine DaimlerChrysler Motors Corporation Service
Contract, and you require service after your
DaimlerChrysler Motors Corporation new vehicle lim-
ited warranty expires, please refer to your contract docu-
ments, and contact the person listed in those documents.
We appreciate that you have made a major investment
when you purchased your new vehicle. Your dealer has
also made a major investment in facilities, tools, and
training to assure that you are absolutely delighted with
your ownership experience. You'll be pleased with their
sincere efforts to resolve any warranty issues or related
concerns.
WARRANTY INFORMATION
See your DaimlerChrysler Motors Corporation Warranty
Information Booklet for information on warranty cover-
age and transfer of warranty.
368 IF YOU NEED CONSUMER ASSISTANCE

MOPAR PARTS
Mopar fluids, lubricants, parts, and accessories are avail-
able from your DaimlerChrysler Motors Corporation
dealer. They will help you keep your vehicle operating at
its best.
CUSTOMER ARBITRATION BOARD
In the 50 United States, and Washington, D.C.,if a
warranty dispute has not been resolved to your satisfac-
tion, you may submit the issue to a DaimlerChrysler
Motors Customer Arbitration Board.
Additional information and the address of each Cus-
tomer Arbitration Board is contained in the Customer
Arbitration Board Brochure included in the Glove Box
Kit.
REPORTING SAFETY DEFECTS
In the 50 United States and Washington D.C.: If you
believe that your vehicle has a defect which could cause
a crash or cause injury or death, you should immediately
inform the National Highway Traffic Safety Administra-
tion (NHTSA) in addition to notifying DaimlerChrysler
Corporation.If NHTSA receives similar complaints, it may open an
investigation, and if it finds that a safety defect exists in
a group of vehicles, it may order a recall and remedy
campaign. However, NHTSA cannot become involved in
individual problems between you, your dealer, and
DaimlerChrysler Corporation.
To contact NHTSA, you may either call the Auto Safety
Hotline toll free at 1-800-424-9393 (or 366-0123 in Wash-
ington DC area) or write to: NHTSA, U.S. Dept. of
Transportation, Washington DC 20590. You can also
obtain other information about motor vehicle safety from
the Hotline.
In Canada:
If you believe that your vehicle has a safety defect, you
should contact the Customer Service Department imme-
diately. Canadian customers who wish to report a safety
defect to the Canadian government should write to
Transport Canada, P.O. Box 8880, Ottawa Postal Station,
Ottawa, Ontario K1G 3J2.
IF YOU NEED CONSUMER ASSISTANCE 369
11

370 IF YOU NEED CONSUMER ASSISTANCE
