ENGINE SPECIFICATIONS
Item Specifications
Engine model 4 Cylinder 6 Cylinder
Engine displacement 2,351dm
3(143.4 CID) 2,972dm3(181.3 CID)
No. of cylinders and cylinder arrangement 4 in-line 6 - V60 É
Bore 86.5 mm (3.41 in) 91.1 mm (3.58 in)
Stroke 100 mm (3.94 in) 76.0 mm (2.99 in)
Compression ratio 9.0 9.0
Controlled by-pass thermostat 88 ÉC (190 ÉF) 88 ÉC (190 ÉF)
Spark plugs NGK BKR5E-11 FR5E1
DENSO K16PR-U11 Ð
CHAMPION RC10YC4 Ð
Spark plug gap 1.0 to 1.1 mm
(.039 to .043 in )0.7 to 0.8 mm
(.028 to .031 in )
Firing order 1-3-4-2 1-2-3-4-5-6
Ignition timing idle speed and mixture Refer to the ªVehicle emission control informationº label
under the engine hood.
NOTE
1. Your engine is equipped with intake and exhaust valve auto-lash adjusters that require no adjustment.
2. Your vehicle has one of the listed spark plugs. Use any one of the listed spark plugs for replacement.
SPECIFICATIONS 363
10
