Outside
1. Engine compartment!p. 253
Engine hood!p. 412. Windshield wiper and washer!p. 124
3. Sunroof (if so equipped)!p. 45
4. Outside rear-view mirrors!p. 184
5. Whip antenna!p. 215
6. Headlights!p. 117, 288, 289
7. Front turn signal lights and parking lights
!p. 117, 291
8. Fog lights!p. 118
9. Front side marker lights!p. 292
10. Tire inflation pressure!p. 326
Changing tires!p. 264
Tire rotation!p. 330
Tire chains!p. 331
Wheel covers (if so equipped)!p. 262
11. Locking and unlocking!p. 26
Keyless entry system!p. 29
12. Stop and tail lights!p. 287
13. High-mounted stop lights!p. 296
14. Trunk lid!p. 35
15. License plate lights!p. 296
16. Back up lights!p. 287
17. Rear turn signal lights!p. 287
18. Rear side-marker lights!p. 287
19. Fuel filler!p. 39
8 INTRODUCTION

QUICK INDEX
If this warning light comes on¼
NOTE:These warning lights will illuminate for a few seconds for a bulb check when the ignition key is first turned on.
Warning light Do this Ref. page
´Park the vehicle in a safe place and turn off the engine.
Test the system as described on page 111.
´If the light does not go out after the test, or if it illumi-
nates again, have your vehicle inspected at an autho-
rized dealer.
´When this light comes on, the anti-lock braking system is
not functioning and only the ordinary braking system is
functioning.P. 111
Anti-lock braking system
´If this light comes on while driving, check to see that the
parking brake is fully released.
´If this light stays on after releasing the parking brake,
stop and check the brake fluid level is correct.
´If the brake fluid level is correct, call an authorized
dealer for assistance.P. 1 1 5
Brake warning light
´If this light comes on while driving, park your vehicle in
a safe place and stop the engine immediately.
Call an authorized dealer for assistance.P. 1 1 2
Oil pressure warning light
10 INTRODUCTION

If you hear the sound¼
Sound Do this Ref. page
If you hear a chime constantly when
the driver 's door is opened.ªKey reminder chimeº
A chime will sound if the driver 's door is opened while
the ignition key is in the ªLOCKº or ªACCº position.
Remove the key to stop the chime.
OR
ªHeadlight reminder chimeº
A chime will sound if the driver 's door is opened when
the ignition key is in the ªLOCKº or ªACCº position or
removed from the ignition switch with the lights on.
If the driver 's door is closed, the chime will stopP. 27, 146
P. 1 1 8
N50B001D
INTRODUCTION 13
1

If this problem occurs¼
Problem Do this Ref. page
The engine does not start.
The lights do not come on or dim.
The horn does not honk or weak sound.
The battery may have a weak charge. P. 273
The engine coolant temperature gauge
indicator enters the ªHº (hot) position.
Steam comes out of the engine
compartment.
The engine is overheated.
Carefully stop the vehicle in a safe place.
If necessary call for roadside assistance.P. 272
INTRODUCTION 17
1

KEYLESS ENTRY SYSTEM
Press the keyless transmitter button(s), and all doors will
be locked or unlocked as desired. The PANIC button can
also help you signal for attention.
To lock the doors
Press the LOCK button, and all doors will be locked.
When they are locked with the reading light in the ªOFFº
position, the reading light blinks twice. All turn signal
lights also blink twice and the horn sounds once.
To unlock the doors
Pressing the UNLOCK button once will unlock the
driver's door only. Press the UNLOCK button one more
time, and all doors will be unlocked.
When the driver's door only, or all doors are unlocked
with the reading light in the ªOFFº position, the reading
light will illuminate for 30 seconds.
All turn signal lights will also blink once.
To unlock the trunk lid
Press the TRUNK button twice within five seconds and
the trunk lid will be unlocked. The trunk lid must be
closed manually after it has been unlocked.
Confirmation function
The confirmation functions provided by the horn and
turn signal lights after operation of the keyless entry
system can each be turned ON or OFF as desired. The
following procedures must be performed with the key
removed from the ignition switch. At the end of each
procedure, a chime sounds once if the function has been
turned ON or twice if the function has been turned OFF.
F12D0350T
LOCK
button
UNLOCK
button
TRUNK
button
LOCKING AND UNLOCKING 29
2

Horn deactivation/reactivation
The confirmation function can be set in the following
three ways.
Each time the confirmation function is set, a buzzer will
sound to tell you the condition of the confirmation
function.
One buzzer: The horn will sound if the doors are locked
with the keyless entry system. The horn will sound
regardless of whether the doors are locked or unlocked.
Two buzzers: The horn will not sound, even if the doors
are locked with the keyless entry system.
Three buzzers: The horn will sound if the doors are
already locked and the keyless entry system is used
again.
In this mode, the horn will only sound when the keyless
entry LOCK switch is pressed again to reconfirm that the
doors are locked.
1. Press the LOCK switch (1) for 4 to 10 seconds and
press the UNLOCK switch (2) during this period.2. Release the LOCK and UNLOCK switches at the same
time.
Turn signal light feature±ON/OFF
The confirmation function provided by the turn signal
lights when the doors are locked and the confirmation
function provided when they are unlocked can be
deactivated/reactivated separately.
At the end of each procedure, a buzzer sounds once if the
function has been reactivated or twice if the function has
been deactivated.
1. Press the UNLOCK button for 4 to 10 seconds and
press the LOCK button within this period.
2. To turn ON/OFF the function provided when the
doors are locked, release the LOCK button and then
release the UNLOCK button.
3. To turn ON/OFF the function provided when the
doors are unlocked, release the UNLOCK button and
then release the LOCK button.
30 LOCKING AND UNLOCKING

Using the panic alarm
If you are near your vehicle and feel threatened, you may
activate the alarm to call attention.
1. Press the PANIC button.
2. The headlights will blink on and off and the horn will
sound intermittently for about 3 minutes.
3. To turn off the alarm, press any button on the keyless
transmitter.
NOTE
1. The keyless entry system will not operate if the key is
in the ignition switch.
2. The keyless transmitter will operate within about 12 m
(39 ft) from the vehicle. However, the operating range
may change if the vehicle is located near a TV transmit-
ting tower, power station, or radio broadcasting station.
3. If the UNLOCK button is pressed when all doors are
closed and no door is opened within approximately 30
seconds, re-locking will automatically occur.
4. If the following conditions are observed after pressing
a keyless transmitter button, the battery in the keyless
transmitter may need to be replaced.
·The doors cannot be locked or unlocked.
·The trunk lid cannot be unlocked.
·The panic alarm cannot be operated.
5. Do not leave the keyless transmitter where it may be
exposed to heat caused by the direct rays of the sun.
6. If your transmitter is lost or damaged, please contact
an authorized dealer for a replacement.
F12D0360
PANIC
switch
LOCKING AND UNLOCKING 31
2

7. The driver should not arm the system until first
confirming that all passengers have left the vehicle. If the
driver arms the system while a passenger(s) in the
vehicle, the alarm may be activated when the passen-
ger(s) leave the vehicle.
Alarm stage
The alarm will be activated if any of the following occur
while the vehicle is parked and the system is armed.
1. The driver's or passenger 's door is opened without
using the key or the remote keyless transmitter.
2. The trunk lid is opened without using the key or the
remote keyless transmitter.
TYPE OF ALARM
When the alarm is activated:1. The headlights blink on and off for 3 minutes. After 3
minutes the headlights automatically shut off.
2. The horn will sound intermittently for 3 minutes.
NOTE: The alarm will continue to operate for 3 minutes.
At the end of that period, the alarm will automatically
shut off to save battery power. The system will then be
rearmed until the proper disarming step is taken.
F30A0020
Horn sounds!
Headlights blink on and off!
50 LOCKING AND UNLOCKING

3. If the UNLOCK switch is pressed when all doors are
closed and no door is opened within approximately 30
seconds, re-arming will automatically occur.
NOTE: Once the system has been disarmed, it cannot be
rearmed except by repeating the arming procedure.
Testing the theft-alarm system
Use the following procedure to test the system:
1. Lower the driver's window.
2. Arm the system as explained in ªArmed stageº.
3. Make sure that the theft-alarm indicator illuminates
and goes off in approximately 20 seconds.
4. Wait a few seconds and then unlock the driver's side
door by using the inside door lock knob and opening the
door.
5. Check to be sure that the horn sounds intermittently
and the headlights blink on and off when the door is
opened.6. Disarm the system by unlocking the front driver's
door, passenger's door or the trunk lid by using the key
or the remote keyless transmitter.
NOTE: To make sure the alarm sounds when the trunk
lid is opened, open the trunk lid by using the trunk lid
release lever.
52 LOCKING AND UNLOCKING

INSTRUMENTS AND CONTROLS
CONTENTS
mInstrument cluster......................104
NMeter cluster.........................104
NIndicator and warning light package........105
NSpeedometer.........................106
NTachometer..........................106
NFuel gauge..........................107
NOdometer/Trip odometer................108
NEngine coolant temperature gauge..........109
NTurn signal indicators/hazard warning lights . . 110
NHigh beam indicator...................110
NTheft-alarm indicator...................110
NDoor-ajar warning light and chime.........110NAnti-lock braking system warning light
(if so equipped).......................111
NCruise/speed control indicator............111
NLow-fuel warning light and chime..........111
NFront fog light indicator.................112
NCharging system warning light............112
NOil pressure warning light...............112
NMalfunction indicator light
(SERVICE ENGINE SOON)...............113
NSupplemental Restraint System (SRS)-air bag
warning light.........................114
NBrake warning light....................115
NSeat belt reminder/warning light...........116
