CAUTION!
Damage to the catalytic converter can result if your
vehicle is not kept in proper operating condition. In
the event of an engine malfunction, particularly one
involving engine misfire or other apparent loss of
performance, have your vehicle serviced promptly.
Prolonged operation of your vehicle while it is
overheated may result in damage to the converter
and vehicle.
WARNING!
²Do not park or operate this vehicle in areas where
combustible materials such as dry grass or leaves
can come in contact with a hot exhaust, since a fire
could occur.
²Undercoating should not be applied to the cata-
lytic converter.
To minimize the possibility of catalytic converter dam-
age:
1. Use UNLEADED GASOLINE ONLY of the type rec-
ommended in ªFuel selectionº.
2. Do not drive with an extremely low fuel level; running
out of fuel could damage the catalytic converter.
3. Do not shut off the engine or interrupt the ignition
when the transaxle is in gear and the vehicle is in motion.
4. Do not try to start the engine by pushing or towing the
vehicle. If the battery is weak or discharged, use jumper
cables to properly start the engine.
5. Do not idle the engine with any spark plug wires
disconnected or removed, such as when performing
diagnostic tests.
6. Do not idle the engine for prolonged periods if it is
idling roughly or otherwise obviously malfunctioning.
7. To prevent the catalytic converter from being dam-
aged due to unburned gas, do not race the engine when
turning off the ignition switch.
198 STARTING AND DRIVING

!24,000 Miles (38 000 km) or at 24 months
NCheck automatic transaxle fluid level.
NInspect disc brake pads, rotors and calipers for
wear and leaks.
NCheck brake hoses for deterioration or leaks.
NInspect drive shaft boots for grease leaks and
damage.
NChange engine oil and engine oil filter.
NRotate tires.
MILEAGE/
MONTHSDEALERSHIP
NAME/CODE DATEREPAIR
ORDER #
!30,000 Miles (48 000 km) or at 30 months
NReplace air cleaner filter.
NReplace spark plugs, standard type.
NCheck drive belts condition (for the generator,
water pump, power steering pump).
NCheck manual transaxle oil level.
NCheck coolant hoses (radiator hose, heater hose).
NCheck fuel hoses condition.
NInspect rear drum brake linings and rear wheel
cylinders (except vehicles with disc brakes) for
wear and leaks of all wheels.
NInspect ball joint and steering linkage seals for
grease leaks and damage.
NInspect suspension system for looseness and dam-
age.
NCheck and service exhaust system as required
(connection portion of muffler, muffler pipes and
converter heat shields).
MILEAGE/
MONTHSDEALERSHIP
NAME/CODE DATEREPAIR
ORDER #
MAINTENANCE 347
9

!54,000 Miles (86 000 km) or at 54 months
NChange engine oil and engine oil filter.
NRotate tires.
MILEAGE/
MONTHSDEALERSHIP
NAME/CODE DATEREPAIR
ORDER #
!60,000 Miles (96 000 km) or at 60 months
NReplace air cleaner filter.
NReplace spark plugs, standard type.
NReplace timing belt.*1
*1: For California, Massachusetts and Vermont
this maintenance is recommended but not re-
quired.
NChange automatic transaxle fluid.
NCheck drive belts condition (for the generator,
water pump, power steering pump).
NCheck manual transaxle oil level.
NCheck fuel hoses condition.
NFlush and replace engine coolant.
NInspect rear drum brake linings and rear wheel
cylinders (except vehicles with disc brakes) for
wear and leaks of all wheels.
NInspect disc brake pads, rotors and calipers for
wear and leaks.
MILEAGE/
MONTHSDEALERSHIP
NAME/CODE DATEREPAIR
ORDER #
MAINTENANCE 349
9

!78,000 Miles (125 000 km) or at 78 months
NChange engine oil and engine oil filter.
NRotate tires.
MILEAGE/
MONTHSDEALERSHIP
NAME/CODE DATEREPAIR
ORDER #
!84,000 Miles (134 000 km) or at 84 months
NCheck automatic transaxle fluid level.
NInspect disc brake pads, rotors and calipers for
wear.
NCheck brake hoses for deterioration or leaks.
NInspect drive shaft boots for grease leaks and
damage.
NChange engine oil and engine oil filter.
NRotate tires.
MILEAGE/
MONTHSDEALERSHIP
NAME/CODE DATEREPAIR
ORDER #
!90,000 Miles (144 000 km) or at 90 months
NReplace air cleaner filter.
NReplace spark plugs, standard type.
NCheck drive belts condition (for the generator,
water pump, power steering pump).
NCheck manual transaxle oil level.
NCheck fuel hoses condition.
NCheck automatic transaxle fluid level.
NFlush and replace engine coolant.
NInspect rear drum brake linings and rear wheel
cylinders (except vehicles with disc brakes) for
wear and leaks of all wheels.
NInspect ball joint and steering linkage seals for
grease leaks and damage.
NInspect suspension system for looseness and damage.
NCheck and service exhaust system as required
(connection portion of muffler, muffler pipes and
converter heat shields).
MILEAGE/
MONTHSDEALERSHIP
NAME/CODE DATEREPAIR
ORDER #
MAINTENANCE 351
9

!114,000 Miles (183 000 km) or at 114 months
NChange engine oil and engine oil filter.
NRotate tires.
MILEAGE/
MONTHSDEALERSHIP
NAME/CODE DATEREPAIR
ORDER #
!120,000 Miles (192 000 km) or at 120 months
NReplace air cleaner filter.
NReplace spark plugs, standard type.
NReplace timing belt.*1
*1:For California, Massachusetts and Vermont this
maintenance is recommended but not required.
NChange automatic transaxle fluid.
NCheck drive belts condition (for the generator,
water pump, power steering pump).
NCheck manual transaxle oil level.
NCheck fuel hoses condition.
MILEAGE/
MONTHSDEALERSHIP
NAME/CODE DATEREPAIR
ORDER #
!120,000 Miles (192 000 km) or at 120 months
NFlush and replace engine coolant.
NInspect rear drum brake linings and rear wheel
cylinders (except vehicles with disc brakes) for
wear and leaks of all wheels.
NInspect disc brake pads, rotors and calipers for
wear and leaks.
NInspect suspension system for looseness and dam-
age.
NInspect ball joint and steering linkage seals for
grease leaks and damage.
NCheck and service exhaust system as required
(connection portion of muffler, muffler pipes and
converter heat shields).
MILEAGE/
MONTHSDEALERSHIP
NAME/CODE DATEREPAIR
ORDER #
MAINTENANCE 353
9

!30,000 Miles (48 000 km) or at 30 months
NReplace air cleaner filter.
NReplace spark plugs, standard type.
NCheck drive belts condition (for the generator,
water pump, power steering pump).
NChange manual transaxle oil.
NChange automatic transaxle fluid.
NCheck fuel hoses condition.
NInspect rear drum brake linings and rear wheel
cylinders (except vehicles with disc brakes) for
wear and leaks of all wheels.
NInspect ball joint and steering linkage seals for
grease leaks and damage.
NCheck and service exhaust system as required
(connection portion of muffler, muffler pipes and
converter heat shields).
NCheck coolant hoses (radiator hose, heater hose).
NInspect suspension system for looseness and damage.
MILEAGE/
MONTHSDEALERSHIP
NAME/CODE DATEREPAIR
ORDER #
!30,000 Miles (48 000 km) or at 30 months
NChange engine oil and engine oil filter.
NInspect disc brake pads, rotors and calipers for
wear and leaks.
NRotate tires.
MILEAGE/
MONTHSDEALERSHIP
NAME/CODE DATEREPAIR
ORDER #
!33,000 Miles (52 800 km) or at 33 months
NChange engine oil and engine oil filter.
NRotate tires.
MILEAGE/
MONTHSDEALERSHIP
NAME/CODE DATEREPAIR
ORDER #
MAINTENANCE 357
9

!60,000 Miles (96 000 km)
NReplace air cleaner filter.
NReplace spark plugs, standard type.
NCheck drive belts condition (for the generator,
water pump, power steering pump).
NReplace timing belt.*1
*1: For California, Massachusetts and Vermont
this maintenance is recommended but not re-
quired.
NChange manual transaxle fluid.
NChange automatic transaxle fluid.
NCheck fuel hoses condition.
NFlush and replace engine coolant.
NCheck coolant hoses (radiator hose, heater hose).
NInspect rear drum brake linings and rear wheel
cylinders (except vehicles with disc brakes) for
wear and leaks of all wheels.
NCheck brake hoses for deterioration or leaks.
MILEAGE/
MONTHSDEALERSHIP
NAME/CODE DATEREPAIR
ORDER #
!60,000 Miles (96 000 km) or at 48 months
NInspect ball joint and steering linkage seals for
grease leaks and damage.
NInspect drive shaft boots for grease leaks and damage.
NCheck and service exhaust system as required
(connection portion of muffler, muffler pipes and
converter heat shields).
NCheck fuel system for leaks
(tank, pipe line and connection, and fuel tank
filler tube cap).
NCheck evaporative emission control system (ex-
cept evaporative emission canister).
NCheck distributor cap and rotor.
NChange engine oil and engine oil filter.
NInspect disc brake pads, rotors and calipers for
wear and leaks.
NRotate tires.
MILEAGE/
MONTHSDEALERSHIP
NAME/CODE DATEREPAIR
ORDER #
360 MAINTENANCE

!84,000 Miles (134 000 km) or at 84 months
NChange engine oil and engine oil filter.
NInspect disc brake pads, rotors and calipers for
wear and leaks.
NRotate tires.
NCheck automatic transaxle fluid level.
NCheck brake hoses for deterioration or leaks.
NInspect drive shaft boots for grease leaks and
damage.
NInspect suspension system for looseness and dam-
age.
MILEAGE/
MONTHSDEALERSHIP
NAME/CODE DATEREPAIR
ORDER #
!87,000 Miles (139 000 km) or at 87 months
NChange engine oil and engine oil filter.
NRotate tires.
MILEAGE/
MONTHSDEALERSHIP
NAME/CODE DATEREPAIR
ORDER #
!90,000 Miles (144 000 km) or at 90 months
NReplace air cleaner filter.
NReplace spark plugs, standard type.
NCheck drive belts condition (for the generator,
water pump, power steering pump).
NChange manual transaxle fluid.
NChange automatic transaxle fluid.
NCheck fuel hoses condition.
NFlush and replace engine coolant.
NInspect rear drum brake linings and rear wheel
cylinders (except vehicles with disc brakes) for
wear and leaks of all wheels.
NCheck brake hoses for deterioration or leaks.
NInspect ball joint and steering linkage seals for
grease leaks and damage.
NCheck and service exhaust system as required
(connection portion of muffler, muffler pipes and
converter heat shields).
NCheck coolant hoses (radiator hose, heater hose).
MILEAGE/
MONTHSDEALERSHIP
NAME/CODE DATEREPAIR
ORDER #
MAINTENANCE 363
9

Engine coolant......................... 318
Engine coolant level warning light.......... 107
Engine coolant temperature gauge.......106,111
Engine hood release...................... 41
Engine oil and oil filter.................. 314
Engine overheating..................... 277
Engine serial number.................... 371
Engine specifications.................... 375
Exhaust system.....................328,375
Fluid
Automatic transaxle fluid............... 325
Brake fluid.......................... 319
Clutch fluid......................... 320
Fog light switch........................ 123
Front fog lamp indicator lamp............. 114
Front seat adjustment..................... 57
Fuel
Filler Cap........................... 148
Fuel economy........................ 149
Fuel filler............................ 39
Fuel gauge.......................106,109
Fuel hoses.......................... 311Fuel selection........................ 144
Low-fuel warning light..............107,113
Fuses................................ 284
Fusible links.......................... 285
Garage Door Opener.................... 132
GasCap .............................. 148
Gasoline/Oxygenate Blends............... 146
Gauges.........................106,109,111
Gear positions......................... 156
General maintenance
Maintenance service................... 314
General vehicle data..................... 373
Glove compartment..................213,214
Handling of Compact Discs............... 232
Hazard warning flasher switch............. 124
Hazard warning light.................107,112
Head restraints......................... 66
Headlights (Type 1)..................... 292
Headlights (Type 2)..................... 293
Headlights
Aiming............................. 295
390 INDEX
