tire pressure reset CHRYSLER SEBRING SEDAN 2007 3.G Owners Manual

off for 60 seconds when a system fault is detected. The
flash cycle will repeat every ten minutes or until the fault
condition is removed and reset.
If this indicator comes on, the entire, PRNDL/ odometer,
display will brighten to FULL DAYTIME INTENSITY
and will not be dimmable.
CAUTION!
The TPMS has been optimized for the original
equipment tires and wheels. TPMS pressures and
warning have been established for the tire size
equipped on your vehicle. Undesirable system op-
eration or sensor damage may result when using
replacement equipment that is not of the same size,
type, and/or style. Aftermarket wheels can cause
sensor damage. Do not use tire sealant from a can, or
balance beads if your vehicle is equipped with a
TPMS, as damage to the sensors may result.
15. Odometer/Trip Odometer
A vacuum fluorescent display indicates the total distance
the vehicle has been driven. Also, the cluster odometer
will display the following vehicle warning messages:
door/trunk ajar and loose gas cap.
Loose Fuel Filler Cap
If the vehicle diagnostic system determines that the fuel
filler cap is loose, improperly installed, or damaged,
“FUEL CAP OFF” will be displayed in the instrument
cluster odometer. Tighten the fuel filler cap properly and
press the odometer reset button to turn the “FUEL CAP
OFF” message off.
NOTE:If vehicle is equipped with the optional Elec-
tronic Vehicle Information Center (EVIC) in the instru-
ment cluster, all warnings including “DOOR AJAR”, and
“TRUNK AJAR” will only be displayed in the EVIC
display. For additional information, refer to “Electronic
Vehicle Information Center — If Equipped” in Section 3.
The two (if equipped) trip odometers show individual
trip mileage. To switch from odometer to trip odometers,
press and release the Trip Odometer button. To reset a
142 UNDERSTANDING YOUR INSTRUMENT PANEL

ELECTRONIC VEHICLE INFORMATION CENTER
(EVIC) – IF EQUIPPED
The Electronic Vehicle Information Center (EVIC) fea-
tures a driver-interactive display. It is located in the lower
left part of the cluster below the fuel and engine tem-
perature gauge. The EVIC consists of the following:
•System Status
•Vehicle information warning message displays
•Personal Settings (customer programmable features)
•Compass heading (N, S, E, W, NE, NW, SE, SW)
•Outside temperature display (°F or °C)
•Trip computer functions
•UConnect™ hands-free communication system dis-
plays (if equipped)
•Audio mode display – 12 preset Radio Stations or CD
Title and Track number when playing
•Tire Pressure Monitor System (TPMS) (if equipped)
•Navigation system screens (if equipped)
Electronic Vehicle Information Center (EVIC)
Displays
When the appropriate conditions exist, the Electronic
Vehicle Information Center (EVIC) displays the following
messages.
•Turn Signal On (with a continuous warning chime)
•Left Front Turn Signal Light Out (with a single chime)
•Left Rear Turn Signal Light Out (with a single chime)
EVIC Display Location
UNDERSTANDING YOUR INSTRUMENT PANEL 147
4

ABS (Anti-Lock Brake System)............. 218
Adding Engine Coolant (Antifreeze)......... 306
Adding Fuel.......................... 256
Adding Washer Fluid.................... 111
Additives, Fuel........................ 252
Air Cleaner, Engine
(Engine Air Cleaner Filter)................ 299
Air Conditioner Maintenance.............. 301
Air Conditioning....................... 190
Air Conditioning Filter................... 200
Air Conditioning, Operating Tips........... 201
Air Conditioning Refrigerant...........301,302
Air Conditioning System................. 301
Air Pressure, Tires...................... 236
Airbag.............................. 40,48
Airbag Deployment...................... 50
Airbag Light.................. 41,47,52,64,140
Airbag Maintenance...................... 51
Airbag, Side....................... 42,47,48
Airbag, Window (Side Curtain)......... 43,47,48
Alarm System (Security Alarm).......... 14,140
Alignment and Balance.................. 242
Alterations/Modifications, Vehicle............ 6Antenna, Satellite Radio.................. 184
Antifreeze (Engine Coolant)............305,327
Disposal............................ 307
Anti-Lock Brake System (ABS)............. 218
Anti-Theft Security Alarm (Theft Alarm)...... 14
Appearance Care....................... 313
Ashtray .............................. 126
Auto Up Power Windows.............. 27,122
AutomaticDimmingMirror ................ 70
Automatic Door Locks.................. 24,25
Automatic Transaxle............. 10,207,211,312
Adding Fluid.....................312,329
Fluid Level Check..................... 312
Interlock System.................... 11,212
Reset Mode......................... 212
Selection Of Lubricant................. 329
Shifting............................ 213
Special Additives..................... 313
Autostick ............................. 214
BallJoints ............................ 302
Battery ............................... 300
GasCaution ......................... 300
358 INDEX
