Page 25 of 130

25
1.
POWER TRAIN PLANS*
Powertrain plans complement the factory powertrain warranty by
providing enhanced roadside coverage and car rental allowance if
your vehicle is not drivable and must be kept overnight. Certain
plans also provide additional distance coverage.
Major components covered are:
• engine • transmission • front-wheel drive • rear-wheel dri\
ve
• 4-wheel drive (4x4) • all-wheel-drive vehicles
2. “G OLD ” PLANS *
Each plan provides full mechanical repair protection to non-powertrain
(Gold) components. Certain plansalso provide full mechanical
protection against powertrain component repairs beyond your vehicle’s\
powertrain warranty coverage. Contracts are available with or without
a deductible.
Major components covered are:
• steering • air conditioning • engine cooling and fuel • fr\
ont
suspension • rear suspension • electrical • hydraulic brake
components • anti-lock brakes
* Maximum terms available on new vehicles registered in Canada only. 3.
“G OLD PLUS ” PLANS *
The most complete protection available for your new vehicle is one
of three “Gold Plus” Service Contracts which combines the benefits\
of “Gold” • Mechanical repair coverage for non-powertrain components
plus the most important vehicle maintenance functions • Engine oil and oil filter changes
plus • Tire rotation every other service
plus • “Peace-of-Mind” motoring with Tire Road Hazard
Protection which provides full, or pro-rata, replacement
of the original four tires, or their repair
plus • Rental car allowance for same-day warranty repairs –
your vehicle need not be kept overnight before eligibility
for the rental allowance is met.
OPTIONAL DAIMLERCHRYSLER CANADA SERVICE CONTRACTS
2005 Passenger Car • Minivan • Pacifica – October 1, 2004
Page 39 of 130

2005 Passenger Car • Minivan • PacificaDealer Copy
Remove and attach to Repair Order 26-92-02-01 3N.
Maint enance Service
Sc hedule “B”
Odometer Reading
Date
24,0 00 km
Maint
enance Service Sc hedule “B”
24,0 00 km
Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension componen\
ts.
Inspect the engine air cleaner filter and replace if necessary (Sebring\
, PT Cruiser, SRT-4
and SX 2.0 only).
Replace the engine air cleaner filter if required (Pacifica and Minivan\
only).
Inspect and replace, if required, the make-up air filter located inside \
the air cleaner
(PT Cruiser, SRT-4 and SX 2.0 only).
Change the all-wheel-drive power transfer unit fluid.*
INSPECT THE FOLLOWING:
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug condition
(SX 2.0, SRT-4 and PT Cruiser only, if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
*The all-wheel-drive power transfer unit fluid and overrunning clutch/re\
ar carrier
fluid must be changed at more frequent intervals than shown in schedule \
B if the
vehicle is used for trailer tow, taxi, or other type of commercial servi\
ce.
