Symptom:
P-1682 CHARGING SYSTEM VOLTAGE TOO LOW
When Monitored and Set Condition:
P-1682 CHARGING SYSTEM VOLTAGE TOO LOW
When Monitored: With no other charging system codes set. With the ignition on and the
engine running above 1500 RPM.
Set Condition: The battery sensed voltage is 1 volt below the charging system goal for 25
seconds. The PCM senses the battery voltage, turns off the field driver and senses the
battery voltage again. If the voltages are the same, the code is set.
POSSIBLE CAUSES
ASD RELAY OUTPUT CIRCUIT OPEN
GENERATOR FIELD DRIVER CIRCUIT OPEN
GENERATOR DEFECTIVE
GENERATOR DEFECTIVE (B)
PCM DEFECTIVE
TEST ACTION APPLICABILITY
1 Start engine, and allow it to idle.
Note: Battery must be fully charged.
Note: Generator Belt tension and condition must be checked before con-
tinuing.
With the DRB, read the Target Charging voltage.
Is the Target Charging voltage above 15.1 volts?All
Ye s®Go To 2
No®Go To 6
2 Ignition On, Engine Not Running
Using DRB Temperature Probe, measure the under hood temperature near PCM.
With the DRB, read the Ambient/BAT Temp.
Is the battery temperature within þ12 degrees C (10 degrees) of the under hood
temperature?All
Ye s®Go To 3
No®Replace the PCM.
Perform Powertrain Verification Test VER-3A.
21
CHARGING
ProCarManuals.com
Page 30 of 364
Symptom:
* CHECKING CHARGING SYSTEM OPERATION WITH NO DTC'S
POSSIBLE CAUSES
TROUBLE CODES PRESENT
VOLTAGE DIFFERENCE >= 1 VOLT
GENERATOR FIELD TERMINAL INTERMITTENT DEFECTIVE
GENERATOR GROUND CIRCUIT HIGH RESISTANCE
B+ CIRCUIT HIGH RESISTANCE (0.4 VOLT)
B+ CIRCUIT HIGH RESISTANCE (1 VOLT)
PCM DEFECTIVE (CHARGING SYSTEM NO CODE)
GENERATOR BELT VISIBLY DEFECTIVE
TROUBLE CODES PRESENT 1600 RPM
TEST ACTION APPLICABILITY
1Note: Battery condition must be verified prior to this test.
Inspect the Generator Belt tension and condition.
Is the Generator Belt in good condition?All
Ye s®Go To 2
No®Repair as necessary.
Perform Powertrain Verification Test VER-3A.
2 Engine Running
With the DRB, set engine speed to 1600 RPM for 30 seconds.
With the DRB, return the engine to idle speed and read codes.
Are there any Charging System trouble codes?All
Ye s®Refer to Symptom List for problems related to Charging.
Perform Powertrain Verification Test VER-3A.
No®Go To 3
3 Turn ignition on. (Engine off)
With the DRB, actuate the Generator field.
Using a Voltmeter, backprobe Generator Field Driver Terminal at the back of
Generator.
Note: The voltage should cycle from 7.2 volts to Battery voltage every 1.4
seconds, at both Terminals.
While monitoring the Voltmeter, wiggle the field Terminals back to the PCM and ASD
Relay.
Was there any interruption in the normal cycle between 7.2 volts and Battery
voltage?All
Ye s®Repair the Wire where wiggling interrupted the voltage cycle.
Perform Powertrain Verification Test VER-3A.
No®Go To 4
24
CHARGING
ProCarManuals.com
Page 31 of 364
TEST ACTION APPLICABILITY
